U-Line H-2812 User manual

PAGE 1 OF 19 1015 IH-2812
πH-2812
DIGITAL
TIME CLOCK
1-800-295-5510
uline.com
SETUP
WARNING! This equipment has been tested
and found to comply with the limits for a
Class A digital device, pursuant to Part 15
of FCC Rules. These limits are designed
to provide reasonable protection against
harmful interference when the equipment is
operated in a commercial environment. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instruction
manual, may cause harmful interference
to radio communications. Operation of this
equipment in a residential area is likely to
cause harmful interference in which case the
user will be required to correct the interference
at his or her own expense.
CAUTION! Changes or modifications not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.
NOTE: This digital apparatus does not exceed
the Class A limits for radio noise emissions
from digital apparatus as set out in the radio
interference regulations of the Canadian
Department of Communications.
TABLE OF CONTENTS
Alert Definitions .....................................................................2
Precautions ...........................................................................3
Introduction ..........................................................................4
Features ................................................................................4
Equipment......................................................................... 4-5
ES700 .................................................................................. 4
Open and Close Unit.......................................................... 5
Power the Unit/Print Positioning ........................................... 5
Important Things to Remember When Using The ES700 .......6
Quick Start.............................................................................6
Atomic Synchronization...................................................... 6
Set Time Zone (-5 EST, -6 CST, -7 MST, -8 PST)....................... 6
Automatically Receive Atomic Signal ................................ 6
Turn DST OFF........................................................................ 6
Program the Time Recorder..................................................7
Settings.............................................................................7-15
Time .....................................................................................7
Date.................................................................................... 8
12/24 Hour Format .............................................................. 8
Print Order........................................................................... 9
Year Digit ............................................................................ 9
Hour/Minute ................................................................... 9-10
Leading Zero .................................................................... 10
Preset Comments.............................................................. 10
Language.......................................................................... 11
Print Length ........................................................................ 11
Print Method ................................................................. 11-12
Daylight Saving Time (DST)............................................12-14
Set Password.................................................................14-15
Enter Password...................................................................15
Cancel the Password.........................................................15
Reset Factory Default Settings ....................................... 15-16
Wall Mounting .....................................................................16
Replacing the Ribbon Cassette.......................................... 17
Troubleshooting...................................................................18
Specifications .....................................................................19
ES700
816
15
AM
SU MO TU WE TH FR SA
R
Serial number label for bottom of clock.
Information contained in this manual is company private to Acroprint Time Recorder Co., and shall not be modified, used, copied, reproduced or disclosed in whole or in part
without the written consent of Acroprint. Contents herein are current as of the date of publication. Acroprint reserves the right to change the contents without prior notice. This
manual has been carefully prepared to cover all aspects of this unit. However, if any explanations are inadequate, unclear, or difficult to understand, please contact Acroprint.
We recommend that you carefully read this manual to maximize the use of this unit. © 2008 Acroprint Time Recorder Co. All Rights Reserved.

PAGE 2 OF 19 1015 IH-2812
SETUP CONTINUED
READER ALERT MEANING
Alerts you to supplementary information.
Alerts you to helpful tips (information given as a guide to action).
Alerts you to supplementary information that is essential to the completion of a task.
Alerts you to possible data loss, breaches of security, or other more serious problems.
Alerts you that failure to take or avoid a specific action might result in physical harm to you
or to the hardware.
Alerts you to stop immediately. Failure to do so will result in physical harm to you or to the
hardware.
Alerts you that improper handling may cause electrical shock resulting in serious injury or
death.
Alerts you not to disassemble or modify the unit.
Alerts you to remove power cord from wall outlet
Alerts you "do not" perform an action.
ALERT DEFINITIONS
For your safety and the protection of the unit, the following alerts are used throughout this manual.

PAGE 3 OF 19 1015 IH-2812
SETUP CONTINUED
PRECAUTIONS
ALERT DESCRIPTION
• Insert the power plug as far as it will go. Improper insertion of the plug may result in fire or
electric shock.
• Do not disassemble the unit. High voltage is present inside that may lead to an
electric shock.
• Do not modify the unit. Modifications may cause a fire and/or electric shock.
• Do not use any voltage of the power source other than designated.
• Do not share a single outlet with another plug. This may lead to a fire or electric shock.
• Do not damage, break, or modify the power cord.
• Do not put heavy objects on, pull, or forcefully bend the cord. These may damage the
cord, possibly resulting in a fire or electric shock.
• Do not plug or unplug the unit with a wet hand. This may lead to an electric shock.
• Do not place the unit on an uneven or tilted surface. This may result in injuries due to the
unit dropping or falling off.
• Do not put a water-filled container or a metal object on top of the unit. If water is spilled
or the metallic object slips inside, a fire or electric shock may occur.
• Do not install the unit in a humid or dusty environment. This may result in a fire or
electric shock.
• Do not place the unit near a kitchen counter or humidifier. Oil, smoke, or steam
generating from them may cause fire or electric shock.
• Do not yank the power cord to disconnect from the outlet. Hold the plug with your hand
to do so, or the cord may be damaged. This may lead to a fire or electric shock.
• Do not insert or drop any other time card than specified into the slot. Such misuse may
cause a fire or electric shock.
• Do not come in contact with the print head. This may result in personal injury.
• If any anomaly occurs, for example, heat or smoke is generated or an odor is emitted,
unplug the unit immediately and contact your dealer for servicing. There is a danger
that further use may cause a fire or electric shock.
• If foreign matter should get in the unit (including a piece of metal, water, or liquid),
disconnect the plug from the outlet immediately and contact your dealer for servicing.
There is a danger that further use may cause a fire or electric shock.
• Remove the line cord plug from the outlet before transferring the unit, or it may damage
the cord. This may lead to a fire or electric shock.
• If the unit should be dropped or the case is broken, unplug the unit and contact your
dealer for servicing. Further use may lead to a fire or electric shock.

PAGE 4 OF 19 1015 IH-2812
EQUIPMENT
Unpack the unit and check its contents to ensure that the time recorder unit and all accessories shown below are
included. If equipment has been damaged in transit, report the extent of damage to the transportation company
and to Acroprint. Order replacement equipment, if necessary.
SETUP CONTINUED
INTRODUCTION
Thank you for purchasing an Acroprint Model ES700 Time Recorder. We are confident this unit will give you full
satisfaction. Items such as the time and date are preset at the factory. After plugging in the power cord to the wall
outlet, this unit can be used. However, we recommend reading this manual before you start using this unit.
FEATURES
Main Applications: Payroll/job cost recorder or time stamp.
• Atomic Synchronization sets time and date automatically
• Quartz Time Recorder
• Digital LCD (Date, Hour, Minute, Day of the Week)
• Perpetual Calendar
• Dot-Matrix Printer
• Automatic Daylight Saving Time (DST)
• Automatic Date, Month Year Change to 2099
• 3-way Print Activation:
a. Automatic
b. Semi-Automatic
c. Manual
• Durable Snap-in Ribbon Cartridge
• Adjustable Print Positions
• Prints in 4 languages
• Prints Date
• 13 Preset Comments
• Selectable 2- or 4-digit Year
• 12 or 24-Hour Format
• Regular Minute, Tenths, or Hundredths of an Hour
• Password Protection
• Wall or Desktop Mount
ES700 Manual x 1
Front View (With Cover) Front View (Without Cover) Back View
Wall Bracket x 2
(2 Screws)
Keys x 2 Ribbon Cassette x 1
(Factory Installed)
Wall-Mount Fitting x 1
(4 Screws, 4 Mollies, 1 Sheet)
Key Hole
Display
Cover
Push Bar
Control
Buttons
Display Ribbon
Cassette
Print Head
AC
Adapter
AC Adapter Cord
Wall-Mount Holes

PAGE 5 OF 19 1015 IH-2812
AC Outlet
AC Adapter
OPEN AND CLOSE UNIT
OPEN UNIT
1. Insert the key into the lock on cover of the unit. Turn
the key in the clockwise position to unlock the unit.
Remove the cover. (See Figure 1)
When you open the unit for the first time,
you must remove the Protective Pad and
Cardboard Insert. Plug the AC Adapter
into the back of the unit. Refer to Remove
Protective Pad and Cardboard Insert/Plug
AC Adapter into Unit below. (See Figure 2)
Ribbon may dislodge. To avoid damage to
the printer, press the ribbon cartridge firmly
into position after removing the protective pad.
Refer to Remove Protective Pad and Cardboard
Insert/Plug AC Adapter into Unit. (See Figure 2)
2. Remove protective pad and cardboard
insert. Plug AC adapter into unit.
(See Figure 2)
CLOSE UNIT
Replace the cover. Insert the key into the lock on the
cover of the unit. Turn the key in the counter-clockwise
position to lock the unit. Refer to Close Unit below.
(See Figure 3)
POWER THE UNIT/PRINT POSITIONING
Plug the transformer into the AC outlet.
Insert a card to get a sample print.
Refer to Power the Unit below.
(See Figure 4)
Print position from the card edge is adjustable by pressing
and sliding the print position button located on the right
outside bottom of the unit. Maximum distance from
edge of form to print is approximately 1⁄" (30 mm).
Refer to Print Position on Time Card below. (See Figure 5)
SETUP CONTINUED
Open Unit
Figure 1
Figure 2
Cardboard
Insert
Protective
Pad
AC Adapter
Figure 3
Figure 4
Figure 5
Close Unit
Power the Unit
Print Position on Time Card

PAGE 6 OF 19 1015 IH-2812
IMPORTANT THINGS TO REMEMBER
WHEN USING THE ES700
You must open the unit to make changes
to the settings. After each use, replace the
cover and lock it. Refer to "Open and Close
Unit" on page 5.
After performing each procedure on the unit, remember
to press SET until the unit returns to normal operation
mode. To exit program mode anytime, press SET until the
unit returns to normal operation mode. (See Figure 6)
When you are setting a digit or an option on
the display, flashing means that it is ready to
be changed. You must press SELECT until you
reach the desired digit or option. Then press
SET to lock the desired value in place.
Printing is always disabled while settings are being
changed. Once the final SET has been completed in
any given operation, printing is enabled.
QUICK START
ATOMIC SYNCHRONIZATION
The clock receives the NIST WWVB Signal, which will
automatically set the time and date. Refer to Atomic
Synchronization Time Zones to the right.
For more information about the WWVB Radio Signal
(Atomic Signal), visit NIST’s website at: www.nist.gov.
Daylight Saving Time (DST) defaults to AUTOMATIC.
If you are in the EST Time Zone and observe
DST, the Atomic Synchronization should work
automatically after the AC cord has been
plugged into the AC outlet overnight.
SET TIME ZONE (-5 EST, -6 CST, -7 MST, -8 PST)
1. Press SELECT until the arrow points to Time Zone.
2. Press CHANGE until your Time Zone appears.
(See Time Zones on page 8.)
3. Press SET .
AUTOMATICALLY RECEIVE ATOMIC SIGNAL
1. Plug the transformer into the AC outlet overnight.
2. If the Atomic Clock Symbol indicator (See Figure 7) is on
in the morning, your clock is receiving the atomic clock
signal and the time and date should be set properly.
3. If you did not receive the atomic signal, try
repositioning the clock or set the unit manually as
described above.
If you do not observe DST, follow the
procedure below to turn DST off.
TURN DST OFF
1. Press SELECT (twice). Arrow points to DST.
2. Press CHANGE until "2" is displayed.
3. Press SET .
SETUP CONTINUED
Atomic Synchronization Symbol Indicator
ATOMIC SYNCHRONIZATION TIME ZONES (DEFAULT = ES-05)
DISPLAY TIME ZONE DESCRIPTION
12
11
10
09
08
07
06
05
04
03
02
01
00 Greenwich
-01
-02
-03
-04 Atlantic Standard Time
ES-05 (Default) Eastern Standard Time
CS-06 Central Standard Time
-07 Mountain Standard Time
PS-08 Pacific Standard Time
AS-09 Alaska Standard Time
HS-10 Hawaiian Standard Time
-11
-12
Figure 6
Figure 7

PAGE 7 OF 19 1015 IH-2812
OPERATION
PROGRAM THE TIME RECORDER
Most of the procedures in this manual are
performed from the Time Recorder menu.
Refer to Time Recorder Menu below. Refer to
Time Recorder Function Buttons below.
Press SELECT . The unit changes into the program mode
showing pon the display positioned under the "TIME"
mark. (See Figure 8)
SETTINGS
TIME
Set the Time Zone before setting the Time
(See Set Time Zone on page 6). Changing
the Time Zone will change the Time.
Example: Change the time from 9:08 AM to 10:09 AM.
1. Press SELECT until the pis under the "TIME" mark.
2. "Hour" flashes. (See Figure 9)
CHANGE HOUR
1. Press CHANGE until the Hour is "10."
2. Press SET .
3. The flashing changes from "Hour" to "Minute."
(See Figure 10)
CHANGE MINUTE
1. Press CHANGE until the Minute is "09."
2. Press SET .
3. The "Second" starts to run from "00."
(See Figure 11)
(+/&6%,"&%i!GPMi%*-6CA%
-:F1(&1=28A18()15>
Figure 8
Figure 9
Figure 10
Figu re 11
TIME RECORDER FUNCTION BUTTONS
CONTROL FUNCTION
SELECT Press SELECT to choose the desired
program setting mode. The selected
program mode is indicated by pon the
display.
CHANGE Press CHANGE to cycle through the
options.
SET Press SET to set the option. After an option
has been set, always press SET again to
return the unit to normal operation mode.
Time Recorder Menu
SELECT CHANGE SET
TIME
Second Hour Minute
AM
*)
*)

PAGE 8 OF 19 1015 IH-2812
DATE
Example: Change the date from September 20, 2007 to
October 21, 2008.
1. Press SELECT until the pis under the "DATE" mark.
2. "Year" flashes. (See Figure 12)
CHANGE YEAR
1. Press CHANGE until the year is "08."
2. Press SET .
3. The flashing changes from "Year" to "Month."
(See Figure 13)
CHANGE MONTH
1. Press CHANGE until the Month is "10."
2. Press SET .
3. The flashing changes from "Month" to "Date."
(See Figure 14)
CHANGE DATE
1. Press CHANGE until the Date is "21."
2. Press SET . (See Figure 15)
12/24 HOUR FORMAT
Example: Change the hour format from 12-hour format
to 24-hour format.
1. Press SELECT until the pis under the "HOUR" mark.
2. The flashing digit indicates "Hour Display Format
Options." (See Figure 16)
CHANGE HOUR
1. In this example, press CHANGE until the option is "2"
(24-Hour Format). Refer to Hour Display Options
below. (See Figure 17)
2. Press SET .
OPERATION CONTINUED
Figure 12
Figure 15
Figure 13
Figure 16
Figure 14
SELECT CHANGE SET
DATE
Year Month Date
SELECT CHANGE SET
DATE
HOUR DISPLAY OPTIONS
OPTION HOUR DISPLAY FORMAT OPTIONS DISPLAY
112 Hour PM 3:00
224 hour 15:00
Fi gu re 17

PAGE 9 OF 19 1015 IH-2812
PRINT ORDER
Example: Set print order to "Month, Date, Year, Hour, Minute."
1. Press SELECT until the pis under the "PRINT ORDER" mark.
2. The flashing digit indicates "Print Order Options."
(See Figure 18)
3. Refer to Print Order Options below.
4. In this example, press CHANGE until the option is "3"
(M.D.Y.H.Min.).
5. Press SET . (See Figure 19)
YEAR DIGIT
CHANGE YEAR DIGIT
If you have selected the unit to print the year, this allows
you to choose the number of digits in the year (two or four).
Example: Change the year imprint to 4 digits.
1. Press SELECT until the pis under the "YEAR DIGIT" mark.
2. The flashing digit indicates "Year Digit Options."
(See Figure 20)
3. In this example, press CHANGE until the option is "2"
(4 Digits). Refer to Year Digit Options below.
4. Press SET . (See Figure 21)
HOUR/MINUTE
CHANGE HOUR/MINUTE
Example: Set the "Hour" and "Minute" to 24 Hour and
1/100 Min.
1. Press SELECT until the p is under the "HOUR/MIN" mark.
2. The flashing digit indicates "Type of Hour."
(See Figure 22)
OPERATION CONTINUED
Figure 18
PRINT ORDER
SELECT CHANGE SET
Figure 19
PRINT ORDER
SELECT CHANGE SET
LEGEND
Y = Year H = Hour
M = Month Min = Minute
D = Date S = Second
DOW = Day of the Week C = Comment
PRINT ORDER OPTIONS
OPTION PRINT ORDER OPTIONS PRINT EXAMPLE
1M.D.H.Min JAN 31 AM 10:00
2D.M.H.Min 31 JAN AM 10:00
3M.D.Y.H.Min JAN 31 '08 AM 10:00
4D.M.Y.H.Min 31 JAN '08 AM 10:00
5Y.M.D.H.Min '08 JAN 31 AM 10:00
6Y.M.D.H.Min.S '08 JAN 31 AM 10:00:00
7D.H.Min 31 AM 10:00
8DOW.D.H.Min TH, 31 AM 10:00
9Y.M.D '08 JAN 31
10 M.D JAN 31
11 DOW.D.M.Y TH, 31 JAN '08
12 C.M.D.Y SENT JAN 31 '08
13 C.D.M.Y SENT 31 JAN '08
14 C.Y.M.D SENT '08 JAN 31
15 M.D.Y.C JAN 31 '08 SENT
16 D.M.Y.C 31 JAN '08 SENT
17 Y.M.D.C '08 JAN 31 SENT
18 C.D.H.Min SENT 31 AM 10:00
Figure 20
Figure 21
Figure 22
YEAR DIGIT OPTIONS
OPTION YEAR DIGIT OPTIONS PRINT EXAMPLE
12 Digits JAN 31 '08 AM 10:00
24 Digits JAN 31 2008 AM 10:00

PAGE 10 OF 19 1015 IH-2812
OPERATION CONTINUED
HOUR/MINUTE CONTINUED
3. In this example, press CHANGE until the option is "2"
(24 Hour). Refer to Type of Hour Options below.
4. Press SET .
5. The flashing digit indicates from "Hour" to "Minute."
(See Figure 23)
6. In this example, press CHANGE until the option is "2"
(1/100 Min.). Refer to Type of Minute Options below.
7. Press SET . (See Figure 24)
LEADING ZERO
CHANGE LEADING ZERO
Example: Set the Leading Zero to "ZERO Disabled."
1. Press SELECT until the p is under the "LEADING ZERO" mark.
(See Figure 25)
2. The flashing digit indicates "Leading Zero Options."
3. In this example, press CHANGE until the option is "1"
(Leading Zero Option disabled). Refer to Leading
Zero Options below.
4. Press SET . (See Figure 26)
PRESET COMMENTS
Prior to enabling Preset Comments, refer to
Print Order Options on page 9 to ensure that
you have set up the print order options to
allow Preset Comments. (Options 12 through
18 allow Preset Comments.)
Example: Change the comment to "SENT."
1. Press SELECT until the p is under the "COMMENT" mark.
2. The flashing digit indicates "Comment Options."
(See Figure 27)
CHANGE COMMENT OPTIONS
1. In this example, press CHANGE until the option is "2"
(SENT). Refer to Preset Comment Options below.
2. Press SET . (See Figure 28)
TYPE OF HOUR OPTIONS
OPTION TYPE OF HOUR PRINT EXAMPLE
112 Hour JAN 31 PM 3:00
224 Hour JAN 31 15:00
TYPE OF MINUTE OPTIONS
OPTION TYPE OF MINUTE PRINT EXAMPLE
11/60 Min JAN 31 2008 10:10
21/100 Min JAN 31 2008 10.17
3 1/20 Min (=5/100 Min) JAN 31 2008 10.15
41/10 Min JAN 31 2008 10.1
Figure 23
Figure 24
Figure 25
Figure 26
Figure 27
Figure 28 COMMENT
SELECT CHANGE SET
LEADING ZERO OPTIONS
OPTION LEADING ZERO PRINT EXAMPLE
1Zero Disabled JAN 1 PM 3:00
2Zero Disabled JAN 01 PM 03:00

PAGE 11 OF 19 1015 IH-2812
OPERATION CONTINUED
LANGUAGE
This setting is available if you select "Month," "Day of the
Week," or "Comment" in previous "PRINT ORDER."
Example: Change the print language to French.
1. Press SELECT until the u is beside the "LANGUAGE" mark.
2. The flashing digit indicates "Print Language Options."
(See Figure 29)
3. In this example, press CHANGE until the option is "2"
(French). Refer to Language Options table below.
4. Press SET . (See Figure 30)
PRINT LENGTH
The print length default is 4. You may select from six (1-6)
font sizes (refer to Print Length Examples 1-6 below).
If the font size is too large to print, the font will
revert to a smaller size before printing correctly.
Example: Change the print length from 4 to 2.
1. Press SELECT until the u is beside the "PRINT LENGTH" mark.
2. The flashing digit indicates "Print Length Options."
(See Figure 31)
3. In this example, press CHANGE until the option is "2."
Refer to Print Length Examples 1-6 above.
4. Press SET . (See Figure 32)
PRINT METHOD
Example: Change the print direction to "Left" and the
print activation to "Manual."
1. Press SELECT until the qis above the "PRINT
DIRECTION/PRINT ACTIVATION" mark.
2. The flashing digit indicates "Print Direction Options."
(See Figure 33)
PRESET COMMENT OPTIONS
OPTION COMMENT OPTIONS PRINT EXAMPLE
1 RCVD (Received) JAN 31 '08 RCVD
2SENT JAN 31 '08 SENT
3IN JAN 31 '08 IN
4OUT JAN 31 '08 OUT
5CFMD (Confirmed) JAN 31 '08 CFMD
6FILED JAN 31 '08 FILED
7PAID JAN 31 '08 PAID
8USED JAN 31 '08 USED
9FAXED JAN 31 '08 FAXED
10 VOID JAN 31 '08 VOID
11 ORIGN (Original) JAN 31 '08 ORIGN
12 APR’D (Approved) JAN 31 '08 APR’D
13 CMPL’D (Completed) JAN 31 '08 CMPL’D
LANGUAGE OPTIONS
OPTION PRINT LANGUAGE OPTIONS PRINT EXAMPLE
1ENGLISH TH 25 DEC '08
OUT 31 10:00
2FRENCH JE, 25 DEC '08
SORT 31 10:00
3SPANISH JU, 25 DIC '08
SAL 31 10:00
4PORTUGUESE QI, 25 DEZ '08
SAIDA 31 10:00
Figure 29
Figure 30
1
2
3
4
5
6
Figure 31
Figure 32
Figure 33

PAGE 12 OF 19 1015 IH-2812
PRINT METHOD CONTINUED
CHANGE PRINT DIRECTION
1. In this example, press CHANGE until option is "2"
(Left-Hand Margin Form). Refer to Print Direction
Options below.
2. Press SET .
3. The flashing digit changes from "Print Direction" to
"Print Activation." (See Figure 34)
CHANGE PRINT ACTIVATION
1. In this example, press CHANGE until the option is "3"
(Manual). Refer to Print Activation Options below.
2. Press SET . (See Figure 35)
DAYLIGHT SAVINGS TIME (DST)
DST begins on the second Sunday in March and ends
on the first Sunday in November. Refer to DST below.
• At 2:00 AM on the first day of DST, the clock
automatically gains one hour to show 3:00 AM.
• At 2:00 AM on the last day of DST, the clock
automatically loses one hour to show 1:00 AM.
Not all places in the US observe DST.
DST Mode may be set to one of the following
options:􏰕
OPERATION CONTINUED
Figure 34
Figure 35
PRINT DIRECTION OPTIONS
OPTION PRINT DIRECTION OPTIONS
1Right-Hand Margin Form
2Left-Hand Margin Form
Push Bar
Press Push Bar
Figure 36
PRINT ACTIVATION OPTIONS
OPTION PRINT METHOD OPTIONS
1Automatic –Allows you to print by inserting a card
or piece of paper.
2Semi-Automatic – Allows you to print by pressing
the push bar only when a card or piece of paper
is inserted (prints only if the card or form reaches
the sensor). Refer to Press Push Bar. (See Figure 36)
3Manual – Allows you to print by pressing the push
bar (even if the card or paper does not reach the
sensor). Refer to Press Push Bar. (See Figure 36)
4Combination – Allows you to print by pressing the
push bar or inserting a card or piece of paper.
Refer to Press Push Bar. (See Figure 36)
PRINT METHOD OPTIONS
OPTION DESCRIPTION
1Automatic –Automatically sets from the atomic signal.
2Off –DST is off.
3Manual –The customer manually sets the DST feature
(refer to "Manually Setting DST" on page 13).
DST
YEAR
DST BEGINS 2 AM
(2ND SUNDAY
IN MARCH)
DST ENDS 2 AM
(1ST SUNDAY IN
NOVEMBER)
2015 3/8 11/1
2016 3/13 11/6
2017 3/12 11/5
2018 3/11 11/4
2019 3/10 11/3
2020 3/8 11/1
2021 3/14 11/7
2022 3/13 11/6

PAGE 13 OF 19 1015 IH-2812
DAYLIGHT SAVINGS TIME CONTINUED
MANUALLY SETTING DST
Example:
Start Date – Sunday, March 9, 2008
End Date – Sunday, November 2, 2008
In this example, the unit remembers the Start Date as
the second Sunday in March and the End Date as
the first Sunday in November. Once the unit is set, it
automatically updates the settings every year thereafter.
No further manual setting is necessary.
1. Press SELECT until the q is above the "DST" mark.
(See Figure 37)
2. Press CHANGE until the option is "3" (Manual.)
3. Press SET .
4. The flashing digit indicates "Year." (See Figure 38)
START DATE
CHANGE THE YEAR
1. In this example, the "Year" is not being changed.
Refer to DST on page 12.
2. Press SET . (See Figure 39)
3. The flashing changes from "Year" to "Month."
(See Figure 40)
CHANGE THE MONTH
1. In this example, press CHANGE until the month is "3"
(March). Refer to DST on page 12.
2. Press SET. (See Figure 41)
3. The flashing changes from "Month" to "Date."
(See Figure 42)
CHANGE THE DATE
1. In this example, press CHANGE until the date "09."
Refer to DST on page 12.
2. Press SET .
3. The "Starting Date" of the display changes the
display from flashing to steady and the p mark is
displayed under "SU." (See Figure 43)
Figure 43 SU
SELECT CHANGE SET
DST
START
OPERATION CONTINUED
Figure 37
Figure 39
SELECT CHANGE SET
DST
START
Figure 40
SELECT CHANGE SET
DST
START
Figure 41
SELECT CHANGE SET
DST
START
Figure 42
SELECT CHANGE SET
DST
START
Figure 38
SELECT CHANGE SET
Year Month Date
MO TU WE TH FR SA SU
DST
START

PAGE 14 OF 19 1015 IH-2812
OPERATION CONTINUED
DAYLIGHT SAVINGS TIME CONTINUED
END DATE
CHANGE THE YEAR
1. Press SELECT until the q is above the "DST END" mark.
2. The flashing digit indicates "Year."
3. In this example, the "Year" is not being changed.
Refer to DST on page 12.
4. Press SET . (See Figure 44)
5. The flashing changes from "Year" to "Month."
(See Figure 45)
CHANGE THE MONTH
1. In this example, press CHANGE until the month is "11"
(November). Refer to DST on page 12.
2. Press SET .
3. The flashing changes from "Month" to "Date."
(See Figure 46)
CHANGE THE DATE
1. In this example, press CHANGE until the date is "02."
Refer to DST on page 12.
2. Press SET .
3. The "Ending Date" of the display changes from
flashing to steady and the pmark is displayed
under "SU." (See Figure 47)
SET PASSWORD
Once the password is set, you must enter it before
changing any settings. Refer to "Enter Password" on
page 15.
You may choose any 4-digit number from
0001 to 9998. Numbers "0000" and "9999"
are not valid passwords.
All settings must be reset if you forget the password.
Refer to "Reset Factory Default Settings" on page 15.
Example: Set the Password to "1234."
1. Press SELECT until the qis above the "PASSWORD" mark.
(See Figure 48)
2. The first 2 digits flash. (See Figure 48)
SELECT CHANGE SET
Year Month Date
DST
END
MO TU WE TH FR SA SU
Figure 44
Figure 45
SELECT CHANGE SET
DST
END
Figure 46
SU
SELECT CHANGE SET
DST
END
Figure 47
SU
SELECT CHANGE SET
DST
END
Figure 48

PAGE 15 OF 19 1015 IH-2812
SET PASSWORD CONTINUED
CHANGE THE FIRST TWO DIGITS
1. In this example, press CHANGE until the first two
digits are "12."
2. Press SET .
3. The flashing changes to the last two digits.
(See Figure 49)
CHANGE THE LAST TWO DIGITS
1. In this example, press CHANGE until the last two
digits are "34."
2. Press SET . (See Figure 50)
ENTER PASSWORD
Once the password is set, you must enter
the current password before changing any
settings.
1. Press SELECT twice.
2. The numbers "9999" are displayed and the first two
digits flash. (See Figure 51)
SET THE FIRST TWO DIGITS
1. In this example, press CHANGE until the first two
digits are "12."
2. Press SET .
3. The flashing changes to the last two digits.
(See Figure 52)
SET THE LAST TWO DIGITS
1. In this example, press CHANGE until the last two
digits are "34." (See Figure 53)
2. Press SET twice.
CANCEL THE PASSWORD
The code "0000" must be entered to cancel password
activation.
RESET FACTORY DEFAULT SETTINGS
Press the reset switch with a pointed object to return all
settings to the factory default settings. Refer to Press Reset
Button below. Refer to Factory Default Settings on page 16.
All custom settings will be deleted and will
revert to the factory default settings when
the reset button is pressed. (See Figure 54)
OPERATION CONTINUED
Figure 49
Figure 50
Figure 51
Figure 52
Figure 53
Reset Button
Press Reset Button
Figure 54

PAGE 16 OF 19 1015 IH-2812
FEATURE FACTORY DEFAULT SETTINGS
TIme Default = 8:00 AM
Date Default = 01/01/2008
12/24 Hour Format Default = 1 (12 hours format, AM/PM)
Print Order Default = 1 (M.H.D. Min)
Year Digit Default = 1 (2 Digits)
Hour/Minute Hour Default = 1 (12 hours)
Minute Default = 1 ( 60 minutes format)
Leading Zero Leading Zero Default = 1 (zero disabled)
Pre-Programmed Comments Default = 1 (RCVD)
Language Default = 1 (English)
Print Length Print Length Default = 4
Print Method Print Direction Default = 1 (right-hand margin form)
Print Activation Default = 1 (automatic)
Daylight Savings Time Default = 1 (automatic)
Time Zone -05, Eastern Standard Time
Password Default = 0000
OPERATION CONTINUED
FACTORY DEFAULT SETTINGS
WALL MOUNTING
The ES700 should be mounted on 1/2" drywall
using two ST 4 x 20 screws and fasteners.
1. Install the supplied wall-mount screws by using the
template. Refer to Install Wall-Mount Screws below.
Be sure to keep about 1/4" (6mm) of the screw
head away from the wall. The recommended
height from floor to bottom of unit is 45".
(See Figure 55)
2. Open the unit. Refer to "Open Unit" on page 5.
3. Hang the unit on the wall and install wall mount
brackets. Refer to Hang Unit below. (See Figure 56)
4. Close the unit. Refer to "Close Unit" on page 5.
Figure 55 Wall
Figure 56

PAGE 17 OF 19 1015 IH-2812
REPLACING THE RIBBON CASSETTE
1. Open the unit. Refer to "Open Unit"on page 5.
2. Hold the ribbon cassette by its tab and pull the
ribbon cassette straight out to remove it.
(See Figure 57)
3. Turn the knob of the new ribbon cassette in the direction
of the arrow (clockwise) to tighten the ribbon. Refer to
Tighten Ribbon Cassette below. (See Figure 58)
4. Install the ribbon cassette inside the unit as shown.
Refer to Install Ribbon Cassette below. Push the
ribbon cassette until it snaps into position.
Turning the knob on the ribbon cassette may
make installation easier. (See Figure 59)
Install the ribbon cassette so that the ribbon is
between the print head and the ribbon mask.
Printing will not function properly if the ribbon
is placed behind the ribbon mask. Refer to
Install Ribbon Cassette Between Print Head and
Ribbon Mask below. (See Figure 60)
5. Turn the knob of the ribbon cassette in the direction of
the arrow to tighten the ribbon. Refer to Tighten Ribbon
Cassette below. (See Figure 61)
6. Close the unit. Refer to "Close Unit" on page 5.
Tighten Ribbon Cassette
OPERATION CONTINUED
Remove Ribbon Cassette
Figure 57 Figure 60
Figure 61
Figure 59
Tighten Ribbon Cassette
Figure 58
Install Ribbon Cassette Between
Print Head and Ribbon Mask
Print Head
Ribbon Mask
Ribbon
Install Ribbon Cassette

PAGE 18 OF 19 1015 IH-2812
ERROR NO. ERROR CONTENTS CORRECTIVE ACTION
E-00 CPU error Contact Acroprint at [phone] (USA).
E-01 The remaining life of lithium
battery for memory back-up is
short.
E-05 The card is not inserted in the
Time Recorder properly.
Correctly insert the card.
E-30 Cannot print, the printer motor
or home position sensor is not
normal.
Make sure that the ribbon cassette is correctly inserted
in place.
E-38 Cannot print, the printer head
motor or the sensor does not
operate properly.
Press the push bar.
E-40 Incorrect password Enter the correct password again.
E-41 DST setting mistake Confirm the correct starting and ending dates of
daylight saving time and enter again.
E-49 Setting data you entered is not
usable
Refer to your manual on the page related to the item
you want to set and enter correct setting data.
ERROR CORRECTIVE ACTION
Unit does not operate Ensure the power cord is properly plugged into the wall outlet and
power is available.
Unit does not print Ensure the ribbon cassette is installed correctly and the proper print
method is set.
Card is jammed Press the push bar and try to pull out the card or paper at the same
time.
TROUBLESHOOTING
ERROR NO. APPEARS
OTHER FAILURES

PAGE 19 OF 19 1015 IH-2812
SPECIFICATIONS
Clock Accuracy Monthly accuracy ± 15 sec. (at ordinary temperatures)
Calendar Year up to 2099. Automatically adjusted to leap years, 31-day months
and months with 30 or fewer days, and the days of the week.
Printing System Dot matrix
Power Failure Compensation Five years of cumulative power failure hours after the date of
shipment.
Operating Environment Temperature: -5° to +45°C, +25° to +113°F
Humidity: 20 to 80%, no condensation
The unit operates normally at temperatures of 5°C (25°F) or below, but
the print density and reaction of the liquid crystal display are inferior
to those at normal temperature operation.
Dimensions 6.45" (w) x 5.63" (h) x 6.77" (d)
164mm (w) x 143mm (h) x 172mm (d)
Weight Approx. 4.4 lbs. with AC Adapter (2.0 kg with AC Adapter)
Rating AC Adapter:
I/P 120 VAC 60 Hz
O/P 15 V 1300 mA
πCHICAGO • ATLANTA • DALLAS • LOS ANGELES • MINNEAPOLIS • NYC/PHILA • SEATTLE • MEXICO • CANADA
1-800-295-5510
uline.com
Use only the supplied AC Adapter with this unit.
5640 Departure Drive
Raleigh, NC 27616 USA
919.872.5800
800.334.7190 (in USA)
919.850.0720 (Fax)
www.acroprint.com
[email protected]
