U-Prox IC L User manual

U-Prox IC L Installation
Features
Power:
oMicro USB B
oIEEE 802.3af PoE: power class 0, up to 12,95W:
Direct operation with U-Prox IP500 panels
oISM band (915.5-927.5 MHz) device with bi-directional communication
oGuaranteed range of 20 m
oU-Prox HE and U-Prox HW repeaters for range extension
One micro USB B port for network settings configuring and firmware upgrade
Isolated Ethernet port, 10BASE-T/100BASE-TX, 802.3af PoE
Adjusted with U-Prox IP software. Supports automatic configuration for one-range
network.
Real-time clock
Non-volatile memory:
Events
35000
Connected devices
512
Temperature range: 0 -55 0C at 80.% relative humidity.
Maximum relative humidity 80% without condensation
Panel The view of the control panel is shown in Fig. 1
Figure 1. U-Prox IC L
Location of jumpers and connectors on control panel board and their function
shown on Fig. 2:
1. Ethernet port
2. Micro USB B port
3. Reset button
1
2
3

Figure. 2. Dimensions
Figure 2. U-Prox IC L board
Assignment of the access control panel connections
Contact
Name
Purpose
USB Connector
Micro USB B
USB Connector
For network settings configuration and
firmware upgrade
Jumper
BAT
BAT
For memory and Real-Time Clock
backup battery switch
Button
FUNC
FUNC
Service button
Light emitting diodes (LED’s)
LED’s from left to right:
Link LED Ethernet cable is OK when lit
Act. LED Frequent flashing means data exchange
LED –bi-color LED:
Red flashes 2 times per second –no connection to the ACS server
Green flashes once per second –connection to the ACS server is
OK
Connection and mounting
U-Prox IC L control panel shipped in the plastic enclosure without the power
supply. Dimensions marked on the Fig. 2.
Connection
1. Perform initial network
setup of control panel (that
specifies settings of
network parameters) with
utility "Configurator" via
USB port before
installation, if it is
impossible to adjust them
automatically

Figure 3. Fixing holes marking
2. Prepare the place for installation mark and drill mounting holes (see
Mount recommendations)
3. Perform Ethernet wiring
4. Perform power wiring if it is necessary
5. Install and fix the enclosure cover with screws
6. Attach self-adhesive washers over the screws
7. Load the control panel in the U-Prox IP software (according to the
software manual)
8. Download the control panel
9. The device is ready for operation
Mounting recommendations
Mount the control panel in the place,
convenient for service.
To mount the control panel on the wall,
perform the following (Figure 3.):
Mark the holes using the tem
plate provided;
Fix the enclosure;
Connect wires
Template for device installation
-----------------------------------------------------------------------------------------------------------
