U.S.Cellular MiFi M1000 User manual
overview
SYSTEM REQUIREMENTS
Your computer, tablet, or other Wi-Fi devices need
Wi-Fi capability and Internet browser software only.
OPERATIONsActions
Power On Press and hold the Power
button until LEDs turn on.
Power Off Press and hold the Power
button until LEDs turn off.
Factory Reset With your MiFi powered on,
remove the back battery
cover and push and hold the
RESET button for 3 seconds.
REMOVING THE BATTERY COVER
Open the charging tab and insert your nger to
gently lift the battery cover.
operations
©2015 Novatel Wireless,Inc. All Rights R eserved.
MiFi® is a registered trademark of NovatelWireless, Inc. PN: 90029179 - R1
WARNING! Please use only an approved charger to charge your MiFi.
Improper handling of the charging port, or the use of an incompatible
charger, may cause damage to your MiFi and void the warranty.
OVERVIEW
OPERATIONS
ICONS
ADMIN
SUPPORT
REGULATORY
QUICK START GUIDE
M100
RESETTING YOUR MiFi
To restore your MiFi M100 to factory settings:
1. Verify that your MiFi is powered on.
2. Remove the back battery cover and nd the
RESET button. Leave the battery inserted and
the MiFi turned ON.
3. Press the Reset button with an unfolded
paperclip and hold for 3 seconds.
4. Replace battery cover and wait for device to
cycle back ON.
NOTE: All settings will return to the original factory
default settings. Any changes you have made will
be lost and you will need to use the SSID/Password
printed on the sticker inside the battery cover
to connect to Wi-Fi and to Log In to the Admin
dashboard.
Reset
Button
INSTALLING & CHARGING THE BATTERY
1. After installing the SIM card, align the gold-
colored contacts on the battery and the device,
and gently slide the battery into place.
2. Connect the MiFi M100 to the power cable and
charge until the battery is fully charged. You can
also connect the device to your computer USB
port for charging.
3. Replace the battery cover.
CONNECTING TO THE INTERNET
1. Power on your MiFi M100 by pressing and
holding the power button until the LEDs display.
2. Open the Wi-Fi application or controls on the
Wi-Fi capable device that you want to connect
to and nd the Wi-Fi network (SSID) named
MiFi-xxxxxx.
3. Your SSID/Password is printed on the sticker
inside the battery cover. Select Connec t and
enter your Passwird when prompted. Your
device is now connected to the Internet.
Align
Contacts
Battery
cover
app
DOWNLOADING AND INSTALLING
You can use the MiFi mobile app after downloading
it to your smartphone. To download to your
iPhone from Apple’s App Store:
1. Press the iPhone App Store button.
2. Select Search and enter MiFi in the search
eld.
3. Select the MiFi app to download.
4. The app can be used after download is
complete.
To download to your Android phone from Google’s
Play Store:
1. Launch the Play Store application.
2. Search for MiFi and install.
3. The application can be used after download
is complete.
SIGNING UP
The MiFi SI GN UP page is the rst page you see when
opening the MiFi app. To set-up your account:
1. Be sure the M100 is turned ON and connected
to Wi-Fi.
2. Enter your Email Address and Password into the
appropriate elds, then click Sign Up.
3. The Device Password entry page will display.
Enter your Password (case sensitive), printed on
the sticker inside the batter y cover, then click
Connect.
4. After the initial Sign-Up, you will simply enter
your Email Address and Password, then click
Log in to enter your account.
Charging
tab
Power Button
Press and hold to turn the
MiFi M100 ON/OFF.
Charging
Port
Signal Strength
LEDs
Reset Button
(under battery cover)
Battery Charge
LEDs
MiFi HOME DASHBOARD
To access the MiFi website, open a web browser
and type ht t p://192.168.1.1 or my.mi then press Enter.
MiFi HOME ICONS
MiFi HOME is your gateway to the MiFiWeb
UI where you can view and customize your
MiFi M100 activity and settings.
CONNECTED DEVICES displays devices
connected to or blocked from your MiFi M100.
DATA USAGE displays your estimated data
usage, allows you to customize your data
usage settings and alerts.
SETTINGS displays Wi-Fi, Device, Mobile and
Advanced configuration options.
CUSTOMER SUPPORT access the MiFi M100
User Guide and additional device information.
ABOUT displays Internet status, and device,
diagnostics and SW update information.
website
SELECTING YOUR SETTINGS
To make device changes such as allowing Wi-Fi
devices to connect, shutting down when no devices
are connected, and enabling Stealth Mode:
1. Power on your MiFi M100.
2. Open a web browser and type http://my.mi or
ht tp: //192.168.1.1, then press Enter.
3. Enter your Password, found on the sticker inside
the battery cover, into the Admin dashboard,
then click Sig n In.
4. Select Settings from the MiFi Home Navigation
panel, then click on the desired setting option.
CHANGING YOUR Wi-Fi/ADMIN PASSWORD
To change the Wi-Fi/Admin Password (printed on
the sticker inside the batter y cover):
1. Sign In to the MiFi website and select Settings >
DeviceSettings >Admin Password.
2. Type the current Admin Password in the Current
MiFi Admin Password Field.
3. Type the new Admin Password in the New
Admin password eld.
4. Type the new Admin Password in the Conrm
new Admin password eld. Be sure to record
your new password as you will need it to Log In
to the MiFi website.
5. Click Save Changes.
Wi-Fi CONNECTIONS
When connected to the 4G LTE network, the default
settings allow 15 Wi-Fi capable devices to connect
wirelessly to the MiFi’s Wi-Fi network.
To change the number of devices that can connect
to the MiFi’s Wi-Fi network, Sign In to the MiFi website
and select Connected Devices > Change Max Connections
> Max Wi-Fi Connections.
DATA USAGE
Your current estimated data usage displays on the
MiFi Home page.
To check your estimated usage level, reset the Data
Counter, and customize your Data Plan and Usage
Alert Settings, select MiFi Home > Data Usage.
MiFi M100 Data Usage
A User Guide for your MiFi M100 is available online.To
download the complete User Guide and learn how to
use your MiFi, go to http://www.nvtl.com/support.
Contact Novatel Wireless Customer support for your
MiFi M100 product related questions by calling
888-997-5211. For all other account inquiries, please
contact your local service provider.
support
FEDERAL COMMUNICATIONSCOMMISSION NOTICE
(FCC - UNITED STATES) AND INDUSTRY CANADA(IC )
Electronic devices, including computers and wireless modems,
generate RF energy incidental to their intended function and are
therefore subject to FCC rules and regulations.
This equipment has been tested to, and found to be within the
acceptable limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. Theselimits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
residential environment.
This equipment generates radio frequency energy and is designed
for use in accordance with the manufacturer’s user manual.However,
there is no guarantee that interference will not occur in any particular
installation. If this equipment causes harmful interference to radio
or television reception, which can be determined by turning the
equipment o and on, you are encouraged to try to correct the
interference by one or more of the following measures.
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the
receiver.
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/television
technician for help.
This device complies with Part 15 of the Federal Communications
Commission (FCC) Rules and Industry Canada ICES-003 for EMI
compliance. Operation is subject to the following two conditions.
• This device may not cause harmful interference.
• This device must accept any interference received,
including interference that may cause undesired operation.
WARNING: DO NOT ATTEMPT TO SERVICE THEWIRELESS
COMMUNICATIONDE VICEYOURSELF. SUCH ACTION MAY VOIDTHE
WARRANTY. THE MiFi MODEM IS FACTORY TUNED. NO CUSTOMER
CALIBRATION ORTUNING IS REQUIRED. CONTACT NOVATELWIRELESS
TECHNICAL SUPPORT FOR INFORMATION ABOUT SERVICINGYOUR
WIRELESS COMMUNICATIONDE VICE.
FCC CAUTION: Any changes or modication not expressly approved by
the party responsible for compliance could void the user’s authority to
operate this equipment.
MODIFICATIONS: The FCC requiresthat you be notied that any
changes or modications made to this device that are not expressly
approved by NovatelWireless, Inc. may void your authority to operate
the equipment.
NOTE: The Radio Frequency (RF) emitter installed in your modem must
not be located or operated in conjunction with any other antenna
or transmitter, unless specically authorized by NovatelWireless
Technologies.
RF Exposure Content
FCC Equipment Authorization ID: PKRNVWMIFIM100
This device is authorized for use in mobile and portable applications.
This product has been evaluated for SAR and meets the FCC Guidelines
for exposure to radio waves.
For better signal reception, coverage rangeand data throughput, do
not place the router near any physical obstruction, including in a pocket
or in close proximity of any object. For RF Safety, a mandatory minimum
of 10 mm (1 cm) should be maintained between the device and any
part of a human body when using the device. Increasing the separation
between the device and the body will result in better reception and
reduced exposure to radio energy.
regulatory
app menu
MiFi MENU OPTIONS
You can display and makes changes to your Wi-Fi
Network and roaming settings, and access device
information and help from your MiFi menu.
To display and select a menu option:
1. Click the Settings icon at the top right side of the
screen to display the menu options.
2. Tap the desired menu option to select.
MiFi DASHBOARD
The MiFi dashboard displays current information
about the operations of your MiFi M100, including
your Wi-Fi Name and Password, Network Provider,
roaming status, signal strength, remaining battery
power and estimated data usage.
You will also be able to see and manage the number
of devices connected to your MiFi M100.
app dashboard
MiFi M100 Home Dashboard
MiFi M100 App Dashboard MiFi M100 App Menu
