U.S. Products COBRA-300H User manual

03/10 revised 11/11 FORM NO. 56041891
COBRA®-300H
EXTRACTOR
100V
INFORMATION
&
OPERATING
INSTRUCTIONS
DO NOT OPERATE MACHINE UNTIL YOU HAVE READ
ALL SECTIONS OF THIS INSTRUCTIONS
IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY
1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
2. Keep machine from rain and snow, extremes in temperatures, and store in a
heated location. Use the machine indoors. Do not use outdoors.
3. Do not let the pump run dry.
4. Use approved chemicals only. NO SOLVENTS.
5. Wear gloves or use rags when removing quick disconnects to prevent burns.
6. Never use water above 54º C/130º F in the solution tank.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

FORM NO. 56041891 - 2
IMPORTANT SAFETY INSTRUCTIONS
This machine is only suitable for commercial use, for example in hotels, schools, hospitals,
factories, shops and offices other than normal residential housekeeping purposes.
When using any electrical appliance, basic precautions should always be followed, including the
following:
NOTE: Read all instructions before using this machine.
WARNING!
To reduce the risk of fire, electric shock, or injury:
•Do not leave the machine unattended when it is plugged in. Unplug the unit from the outlet when not in use
and before servicing.
•To avoid electric shock, do not expose to rain or snow. Store, and use, indoors.
•Do not allow to be used as a toy. Close attention is necessary when used near children.
•Use only as described in this manual. Use only the manufacturer’s recommended attachments.
•Never add water over 54º C/ 130º F to the solution tank.
•Do not use with damaged cord or plug. If the machine is not working as it should, has been dropped,
damaged, left outdoors or dropped into water, return it to a service center.
•Do not pull by the cord, use the cord as a handle, close a door on the cord, or pull the cord around sharp
edges or corners. Do not run the machine over the cord. Keep the cord away from heated surfaces. To
unplug, grasp the plug, not the cord.
•Do not handle the plug, the cord, or the machine with wet hands.
•Extension cords must be 12/3 and no longer than 50 feet. Replace the cord or plug immediately if the ground
prong becomes damaged.
•Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and
anything that may reduce air flow.
•Keep loose clothing, hair, fingers, and all parts of body away from openings and moving parts.
•Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes, or any health
endangering dusts. Do not use to pick up flammable or combustible liquids such as gasoline or use in areas
where they may be present.
•Turn off all controls before unplugging.
•Use extra care when cleaning on stairs.
•Connect to a properly grounded outlet only.
•Liquid ejected at the spray nozzle could be dangerous as a result of its temperature, pressure, or chemical
content.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

FORM NO. 56041891 - 3
INSPECTION:
Carefully unpack and inspect your COBRA-300H for shipping damage. Each machine is tested and in-
spected before shipping. Any shipping damage incurred is the responsibility of the carrier. You should
notify the carrier immediately if you notice damage to the box or to the machine or parts.
CLEANING SOLUTIONS:
We recommend liquid cleaning chemicals, such as our Magic Fabric Cleaner. Powder chemicals may be
used, but unless mixed very thoroughly they could cause a build-up in the pump, lines, heat exchanger
and/or quick disconnects. Any problem caused by a chemical build-up is not covered by warranty. Use
a neutral cleaner with a pH between 6 and 9 to avoid premature wear of the pump, seals, and/or other
components. Damage caused by the use of strong chemicals is not covered by the warranty.
MAINTENANCE:
For optimum performance flush the machine with clear water at the end of each working day. Once a
month, minimum, run a flushing compound through the machine to break up any mineral or chemical
build-up that may have formed. U.S. Products’ “X-1500” is recommended. The vacuum motor, pump
motor, and the pump do not require any scheduled maintenance; however, the motors may require
replacement brushes after 1000 - 1500 hours, and the pump and bypass valve may require rebuild kits
after 1000 - 1500 hours, typically (refer to machine part list for numbers) Clean the body with an all
purpose detergent, and protect it with an automobile interior polish. Lubricate the wheels, castors, and
quick disconnects with an all purpose silicone spray.
(and be sure to register your warranty; go to www.usproducts.com)
Serial Number: __________________
Model: COBRA-300H-JP
Purchase Date:_____________
Write the name and phone number of your distributor: ______
_______________________________
___________________________________________
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

FORM NO. 56041891 - 4
HOLDING TANK LID SWITCH PLATE LID (RECOVERY TANK)
VAC INTAKE
LATCH (2)
DRAIN GATE
QUICK-DISCONNECT
CASTOR
VENT
WHEEL
VACUUM (1), PUMP (2)SWITCHES:
These switches are powered by cord #1. Switches light up when turned on.
CARPET/UPHOLSTERY SWITCH (3):
This switch is also powered by cord #1. The carpet setting (down position) is high pressure
(approximately 300 PSI). The upholstery setting (up position) is low pressure (approximately 50 PSI
with a K1 or V2 spray tip).
PRIMING HOSE IN
POSITION FOR PRIMING
VAC PUMP CARPET
UPHOLSTERY
123
SWITCH PLATE
KNOW YOUR MACHINE
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

FORM NO. 56041891 - 5
SET-UP:
1. Fill the holding tank with clear water and the detergent of your choice. Mix well. Although this
machine is designed to supply instant hot water, the addition of warm water (not exceeding 54º C/130º
F) to the holding tank will increase the efficiency of the heater.
2. Plug in cord #1. Attach the priming hose to the machine (see illustration on previous page). Turn the
pump on and set the switch to the upholstery setting. Run the pump until the pump is fully primed,
then turn off the pump. Remove the priming hose, and attach the cleaning hoses and tool.
3. Turn on the pump, and spray through the cleaning tool for a few seconds to fill the lines with solution.
4. Plug in cord #2 (identified by a red “H” on the back of the extractor). Wait 2 minutes for the heat
exchanger to reach operating temperature. You may now begin cleaning. It will take about 10 seconds
for the initial heat to reach the wand.
BALL FLOAT VAC SHUTOFF:
When the recovery tank is full, the float system will shut off the incoming air flow and prevent water from
entering the vacuum motors. The float may not work properly if the float filter is clogged or if there is foam in
the tank.
CAUTION: To avoid vac motor damage, always make sure the float filter is clean and the ball
travels freely before turning on the machine, and use a defoamer whenever foam is present.
SPECIFICATIONS:
Rotomolded Body:
Vacuum:
VAC Shutoff:
Pump:
Waterlift:
Heat:
Heater:
Wand:
Weight:
Dimensions:
Lifetime Warranty
One, 3-stage, 7.2”
Ball float
Positive displacement, 300 psi carpet, 50 psi upholstery
125”
212º F
1500 Watts
Stainless steel, double bend, twin tip
99 lbs.
26.5H x 18W x 28.75L (inches)
TROUBLE SHOOTING:
IF THIS OCCURS CHECK THIS
NO SPRAY
PUMP DOEN’T RUN
Solution tank is empty.
Clogged spray tip.
Pump not running.
Valve on wand not operating.
No power to pump. Test the switch.
Test the motor directly to AC power.
Debris plugging cleaning tool or vacuum hose.
Drain gate is not completely closed, or seals are damaged.
Vacuum lid is not closed tight.
No power to motor. Test the switch. Test the vacuum motor.
Spraying too long. Try spraying for 12-15 seconds per cycle. Heat exchanger
needs to be flushed.
Wrong tool being used.
Too much water passing through, (longer hose, larger diameter hose, or larger
spray tip), than standard.
No power in the wall outlet - check to see if the breaker has tripped.
Check power cord for ‘opens’.
Call your distributor for additional help.
LOW SUCTION
NO SUCTION
LOW HEAT
NO HEAT
revised 10/10
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

FORM NO. 56041891 - 6
COBRA-300H
100V
7
5
6
4B
3
4
1
4A
2
11
10
4B 4A 14
16
15
15
16A 17 18
19
20
21
22
23
24
25
26
29
3233
34 35
36
37
38
39
32
32
45
41
42
43
44
46
47
57 55 47
48
48
59
60
61
62
63
64
65
66
67
39
68
69
70 71
72
80
79
77
76
75
48 49
50
52
51
53
54
55
56
82
55
48
48
48
55 83
84
84
85
86
93
88
87
89
91 87
92
95
94
93
48
85
93
96
97
98
98
91
99
100101
98
91
102
35A
35
Priming Hose
72A
9A
9
8
9A
73
64A
103
104 104
105
106
revised 11/11
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

FORM NO. 56041891 - 7
COBRA-300H 100V
Item Ref. No. Qty Description
1#903USP 1 Drain Gate (see Misc.)*
2 21 4 Screw, Button Head, 10/32 X 5/8”
3#56471194 2 Latch
4
#187USP 1 O-ring
4A 187B 2 Washer, flat Rubber
4B#185USP 1 Nut, 1-1/2”
5 FP208 1 Vacuum Tank, Complete, Cobra
6 907 1 Hose Barb, 1-1/2”
8 1074 1 Gasket (Machines made after 2-15-05)
9 2086A 1 Lid and Ring (Machines made after 2-15-05)
56380968 1 O-Ring for 2086A Lid
9A FP436 2 Chain and Hardware
10#924A 1 Float, Ball & Cage
11 FP193 1 Ball Float Assembly, Complete
14#922USP 1 PVC Elbow, 1-1/2”
15#156USP 4 Hose Clamp, (size 28)
16 430B 1 Hose, Vacuum, Rubber, 2” x 21”
16A FP171D 1 Hose, Vacuum, Rubber, 2” x 19”
17 913B 1 Vacuum Motor, 3-stage
18 7 3 Nut, jam, 5/16”
19 15 3 Washer, flat
20 194 1 Split Ring
21 934 1 Chain, 13”
22 320AB 3 Nut, Finish, 5/16”
23 34 3 Washer, Split lock
24 179 3 Bolt, 5/16 x 4”
25#959USP 1 Gasket, Vacuum Motor
26 MA-6 1 Manifold, Vacuum
29 FP220 1 Flange, Exhaust, w/Hose & Hardware
32 928 3 Louver, 3” (includes screws)
33 909A 2 Latch Strike, for Latch, S/S
34#45USP 1 Quick Disconnect, 1/4 n.p.t.
35#115USP 3 Washer, Fiber
35A 116A 1 Bushing, Fiber
36#31USP 1 Washer, Brass
37 5 8 Bolt, 1/4-20 x 3/4”
38 2002 2 Castor, Swivel, 3”
39 8 10 Lock Nut, 1/4-20
41 2001B 2 Label Cobra-300H White on Black
42#27AUSP 2 Axle Cap, Black
43 2003 2 Wheel, 8”
44#910-1693 2 Axle, 18-13/16”
45 BS-6 1 Base, Cobra, Black
46 FP439 1 Gasket, Cobra Base
47#92AUSP 2 Nipple, S/S, 1/4 p.t.
48#91USP 7 Elbow, Brass
49 2023A 1 Hose Assembly, Heater Outlet, 29-1/2”
50 FP159E 1 Heat Exchanger, Complete, 100V
51#455USP 1 Mount, Heat Exchanger
52 76A 1 Hose Clamp
53#103USP 1 Elbow, 1/8 f.p.t. x 1/8 m.p.t.
54 224 1 Hose Assembly, 8”
55#222USP 4 Quick Disconnect, Female, Open, 1/8 p.t.
56 2164 1 Pressure gauge
57#219USP 1 Quick Disconnect, male
59 2B1 4 Screw, 6/32 x 2-1/4”
60 2015 1 Guard, Fan
61 2014 1 Fan, Cooling
62 16 4 Locknut, 6/32”
63 937 1 Reducer, PVC
64#184USP 1 Cord Retainer
Item Ref. No. Qty Description
64A 495A 1 Power Cord, 25’, Yellow
65 918 1 Heat Sink Plate
66 (see Misc.) 1 Thermistor Control with Potentiometer **
67 4 2 Bolt, 1/4-20 x 1”
68 HT-2 1 Holding Tank
69 CWBLK 1 Cord Wrap, Black
70 203 4 Washer, Plastic
71 260 2 Nut, Acorn, 3/16”
72#207USP 1 Filter, Pump Inlet, 40 Mesh, S/S
72A 217 1 Nipple, PVC, 1/2 N.P.T.
73#901USP 1 Lid, Holding Tank
75 FP578 1 Switch, Carpet/Upholstery
76 FP578 1 Switch, Pump
77 FP578 1 Switch, Vacuum
79 28 4 Screw, #4 x 3/8”
80 2006D 1 Switch plate
82 944 1 Hose, Pulsation Dampening, 28”
83 97 1 Bushing, Brass
84 223 2 Quick Disconnect, Male, 1/8” Pipe Thread
85 168 3 “T”, Brass
86#221USP 1 Quick Disconnect, Male, Open, 1/4 p.t.
87 165 2 Hose Barb
88 FP167F 1 Pump, complete, no motor or solenoid
89 FP170A 1 Hose, Pump Inlet, 1/2” X 16”
91#166USP 6 Hose Clamp
92 211 1 Plug, Brass
93#92AUSP 4 Nipple, 1/4 p.t., S/S
94 2060 1 Motor, AC, for Pump
95 2061 1 Mount Plate, Pump Motor
96#105USP 1 Reducer Nipple, Brass
97 FP238 1 Bypass Valve, Complete for Cobra-300H
98 164 3 Hose Barb
99 FP169E 1 Hose, 3/8” X 8”
100 208 1 Hose Barb, Brass 1/8 p.t. x 3/8 hose
101 2062 1 Solenoid (without fittings)
FP230 1 Solenoid (with fittings)
102 FP169C 1 Hose, Pump Bypass, 3/8” X 18”
103 SYP1 1 Priming Hose Assy
104#216 2 Elbow, 1/4 Street, 90 Deg
105#182 1 Bushing 3/8 X 1/4 Pipe Brass
106#56003873 1 Nut-Hex Flange SS M4-0.7
[ ]#140USP 1 Elbow 45deg.angle 1/4 Male x 1
[ ]#425 1 Gasket, 40 Shore – Santoprene (5.5”)
[ ]#92USP 1 Nipple 1/4 Pipe Brass
[ ]#220 2 Quick Connect Brass 1/4 Fpt
*#56044507 1 Literature Pack
MISCELLANEOUS PARTS
*FP231A Drain Gate Assembly, Complete (with
o-rings & nut)
FP212B Pump & Motor Complete (NO solenoid,
mount bracket, mount bracket or hoses)
950A Cam/Bearing Assembly
#291USP Bypass Valve Rebuild Kit
950CP Valve/O-Ring Kit, for 300 PSI pump
#250USP Piston/Seal Kit, for 300 PSI pump
FP194E Heat repair Kit, includes thermistor control, probe,
cutout (for machines built after June 14, 2005)
NOTE: Items in kits not sold separately.
#= Revised or new since last update
[ ] = Not Shown
* = Optional, Not Included
revised 11/11
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

425-322-0133 / 800-257-7982 / FAX: [phone]
11015 - 47th Ave. W. / Mukilteo, WA 98275
VISIT US AT: http://www.usproducts.com
https://harrissupplyind.com-ToOrderPartsCall608-268-8080
