ubiolabs WCB137E User manual

Quick Start Guide
Wireless Car Mount
Universal Car Mount
for Cell Phones
www.ubiolabs.com
[email protected]
1-866-642-4428
(Monday - Friday 9am - 4:30pm PST)
2821 Northup Way, Suite 250
Bellevue, WA 98004
Model: WCB137E
We Are HereTo Help
Vent
Mount
Dash
Mount
Case
Car Charger
Plug into Qualcomm® Quick
Charge™ 3.0 USB-A Output
USB-C Cable
Magnet

SAVE THESE INSTRUCTIONS
Important Safety Instructions
WARNING - When using this product, basic precautions should
always be followed, including the following:
a) Read all manufacturers instructions before using this product.
b) To reduce the risk of injury, close supervision is necessary when
the product is used near children.
c) Do not put fingers or hands into the product.
d) Do not expose car mount to moisture, rain, or snow.
e) Use of a power supply or charger not recommended or sold by
car mount manufacturer may result in a risk of fire or injury to
persons.
f) Do not use the car mount in excess of its output rating.
Overloaded outputs above rating may result in a risk of fire or
injury to persons.
g) Do not disassemble the car mount. Take it to qualified service
person when service or repairs are required. Incorrect reassembly
may result in a risk of fire or injury to persons.
h) Do not expose the car mount to fire or excessive temperature.
Exposure to fire or temperature above 122°F may cause explosion.
The car mount’s working temperature is ≤104°F.
i) Have service performed by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the
product is maintained. This device complies with Part 18 of the
FCC Rules.
NOTE: This equipment has been tested and found to comply with
the limits for a wireless power charger, pursuant to Part 18 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for
help.
CAUTION: Changes or modifications not expressly approved by
the party responsible for compliance could void the user’s
authority to operate the product. This device contains
license-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s
license-exempt RSS(s). Operation is subject to the following two
conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference
that may cause undesired operation of the device.
This equipment complies with FCC/IC radiation exposure limits set
forth for an uncontrolled environment.
This equipment should be installed and operated with minimum
distance 20cm between the radiator and your body.
FCC:
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Caution: The user is cautioned that changes or modifications not
expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or
more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for
help.
IC:
This device complies with Industry Canada license-exempt RSS
standard(s).
Operation is subject to the following two conditions: (1) This device
may not cause interference, and (2) This device must accept any
interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de license. L'exploitation
est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si
le brouillage est susceptible d'en compromettre le fonctionnement
Car Mount Features
Technical Specifications
Component: WCC1001
Input: 5-9V / 2A (USB-C)
Output: 10W Qi / 7.5W / 5W
Dimensions: 4.7 x 2.6 x 3.9 inches
Weight: 4.8 oz
Battery Indicators: Green / amber LED indicator
Your wireless stand is designed to provide optimal
power delivery for yotur wireless device:
10W Qi certified fast charging for Samsung
Galaxy S10e, Galaxy S10, Galaxy S10+, Galaxy
Note9, Galaxy S9+, Galaxy S9, Galaxy Note8,
Galaxy S8+, Galaxy S8, Galaxy S7 Edge, Galaxy
S7, Galaxy S6 Edge, Galaxy S6, Galaxy Note5,
Motorola, LG
• 7.5W wireless charging for iPhone X Max,
iPhone X, iPhone X, iPhone X, iPhone 8,
iPhone 8 Plus
• 5W wireless charging for other compatible
device
Car Charger Features
Technical Specifications
Component: CHG1051
Input: 12-24V DC, Max 3.5A
Output 1: USB-A Quick Charge 3.6-8V/3A,
8-9V/2.7A, 9-12V/2A (24W max)
Output 2: USB-A 5V/2.4A 12W
Charge Indicator: White LED indicator
Dimensions: 0.97 x 0.97 x 2.5 inches
Weight: 0.8 oz.
SAVE THESE INSTRUCTIONS
www.ubiolabs.com
[email protected]
1-866-642-4428
(Monday - Friday 9am - 4:30pm PST)
2821 Northup Way, Suite 250
Bellevue, WA 98004
DO NOT RETURN TO
THE STORE
Model: WCB137
Our customer support team
is here to help.
LED Charge Indicator
Qualcomm®
Quick Charge™ 3.0
USB-A Output
5V/2.4A
USB-A
Output
LED Charge
Indicator
Suction Lever
Suction Cup
Base
Ball Joint
Power In
Magnetic Surface
Microsuction Surface
Qi Wireless Surface
User Manual and
Safety Instructions
Wireless Car Mount
Universal Car Mount
for Cell Phones
Warranty
At Ubio Labs, we are dedicated to designing and
manufacturing products with superior
performance and 100% customer satisfaction. All
of our products come with a 1 year limited
warranty from date of purchase.
We are always improving our products’ features
and functionality. We reserve the right to change
product specifications at any time without notice.
Qualcomm Quick Charge is a product of Qualcomm Technologies, Inc.
IMPORTANT, RETAIN FOR FUTURE
REFERENCE: READ CAREFULLY

G8/V50
LG
Adhere
magnetic
plate in
lower area
of device
Galaxy S10e
Galaxy S10/Note10
Galaxy S10+
Galaxy Note10+
Samsung
Adhere
magnetic
plate in
lower area
of device
Apple
iPhone 8 Plus/11 Pro Max
iPhone 11 Pro
iPhone 8 iPhone X/11
Adhere
magnetic
plate in
lower area
of device
Magnetic Plate
Placement Template
For Wireless Car Mount
For optimal performance, use this template to
install the magnetic plate to your device.
How to use:
• Find the template that matches your phone.
• Remove any phone case that may be on the phone.
• Place phone face down on template.
• Remove 3M film from magnetic plate.
• Place magnetic plate in the designated area
on the back of your phone.
Contact Ubio Labs customer service for
additional questions.
1-866-642-4428 (Monday - Friday 9am - 4:30pm PST)
www.ubiolabs.com
[email protected]
For additional templates
visit our website:
www.ubiolabs.com/support
