Ubique ZG-075-GY-GG User manual

Thank you for your purchase!
Lift Top
Bench
ASSEMB INSTRUCTIONS

 



 



CHOKING HARD  
DO NOT ALLOW CHILDREN TO CLIMB ON FURNITURE


 


 I  
ZG-075-GY-GG I ZG-075-OAK-GG I ZG-075-WAL-GG

Congratulations!
You just purchased a piece of happiness. At Ubique Group, we believe you can transform your spaces
into the most inspired places with furnishings that are the perfect combination of form, function and
style. As original innovators of online furniture retail, we offer the best selection of popular,
contemporary styles at cool, comfortable prices. And, with decades of proven shipping and packaging
expertise, our Extended Quality Checklist ensures a rewarding, hassle-free experience time and time
again. It's just what you need to bring your vision to life.
your friends at Ubique Group
Thank you & Enjoy!!
Share it on social
& Tell a friend!
#Spaces2Places
LIKE IT!
Write an online
product review
where purchased
LOVE IT! NOT SURE?
Let us help!
Contact our
customer support.
Have a question, concern or simply need a hand? Your satisfaction is our top priority.
Contact us at 866-552-2810 or [email protected]. We're here to help!
Browse Our Branded Collections
There's something for everyone inside our family of brands.
Visit www.theubiquegroup.com/brands or scan this code.

Quality &
Durability Tested
Packaged
with Care
Shipped from
our U.S. Facility
Designed
for Easy
Assembly
Ethically
Sourced
Please visit https://www.theubiquegroup.com/warranty for complete warranty information.
EVERY UBIQUE GROUP PRODUCT
We pride ourselves on providing an excellent customer experience
starting right here with your package and instructions. Everything you
need should be right where you need it, so you can get to enjoying your
new item ASAP. But despite our best efforts, sometimes "slips happen."
If you need any support, from replacement parts to recommendations,
please reach out to our wonderful customer support team at 866-552-
2810 or [email protected]. We're here to help!
Read this manual before using this product. Failure to follow the instructions
and safety precautions in this manual can result in serious injury or death.
Keep this manual in a safe location for future reference.

Male Camlock x 20
A
D
Female Camlock x 20
B C
Wood Dowel x 8
Tools required
Phillips screwdriver
(medium & large)
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
The screw length is measured from the head to the point (30mm screw shown).
E
6*15mm Screw x 4
Hardware
Please ensure you have all parts listed below
6*60mm Screw x 4
F
G H I
J
3.5*14mm Screw x 36
Hinge x 2
Hydraulic Lift x 2
K
Ø20mm Screw Cover x 8
6*30mm Screw x 4
Air Vent Cover x 2
L
Felt Pad x 2
Note:
may be supplied than is required.
The quantities below are the correct amount to complete the assembly. In some cases more hardware

Using Camlocks
12
DO NOT OVER TIGHTEN.
34
4
Step 1
Step 3
Step 2
Step 4
Connect the male
camlock as diected in
the assembly instructions
using a scewdriver.
Push the male camlock
into the entry hole.
Insert the female
camlock as shown in the
instruction.
Note：Ensure that the
arrow on the top of the
camlock points towards
the entry hole for the
male camlock.
Turn the female camlock
clockwise with a
screwdriver.
You should feel a click
when the camlock is
locked in place.
The joint is now secure.

Parts
1
2
3
4
5
6
6
7
8
8
9
9
10

Assembly Instructions
