UCI BioBidet BB-300H User manual

OperatingInstructions
BB-300H
BioBidetTM
Union Conception International Inc.
205 Berg Street, Algonquin IL. 60102, U.S.A.
Phone: [phone] Fax: [phone]
E-mail: [email protected]

IMPORTANT SAFEGUARDS
Ⅰ
DANGER To reduce the risk of electrocution:
1. Do not place or store product where it may fall or be pulled into a tub or sink.
2. Do not immerse in water or other liquid.
3. Do not reach for the product if it does fall into the water. Unplug immediately.
WARNING   To reduce the risk of burns, electrocution, fire, or injury to persons.
1. Close supervision is necessary when this product is being used in households with children,
elderly, or persons with disabilities. Children should not be permitted to use or touch this product.
Do not leave children unattended in a room where this product has been installed.
2. Use this product only for its intended purposes as described in this manual. Do not use
attachments not recommended by the manufacturer.
3. Never operate this product if it has a damaged cord or plug, not working properly, has been
dropped, damaged, or dropped into water.
4. Install the unit properly by following the installation procedure.
5. Only authorized persons should install or repair the unit.
6. Keep the cord away from heated surfaces.
7. Never drop or insert any object into any opening or hose.
8. Do not use outdoors, where aerosol spray products are being used, or where oxygen is being
administered.
9. Always follow the grounding instructions in this booklet before plugging in the unit.
When using electrical products, especially when children are present, basic safety
precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING
SAVE THESE INSTRUCTIONS
1OPERATING INSTRUCTIONS 2
OPERATING INSTRUCTIONS
THIS UNIT WAS MANUFACTURED FOR HOUSEHOLD USE.
READ ALL OPERATING INSTRUCTIONS BEFORE INSTALLATION
AND USE.
1. Notes for installation
1) This product is intended for professional installation only.
2) Please read this manual carefully and install properly.
3) Please give this manual to the customer after installation.
2. Notes to customers
1) Please read this manual carefully and use this unit properly.
2) Please keep this manual for future reference.
CONTENTS
. IMPORTANT SAFEGUARDS 2
. CAUTIONS BEFORE INSTALLATION 3
. PARTS IDENTIFICATION 4
. INSTALLATION 5-6
. BEFORE OPERATION 7-8
. TRIAL OPERATION 9
. OPERATION 10
. MAINTENANCE 11-12
. SPECIFICATIONS 13
. WARRANTY CARD 14

3OPERATING INSTRUCTIONS
PARTS IDENTIFICATION
Ⅲ
4
OPERATING INSTRUCTIONS
CAUTIONS BEFORE INSTALLATION
Ⅱ
NOTE THE FOLLOWING IMPORTANT POINTS A. Main Unit
B. Accessories
1. Do not install in a location where the product may be exposed to water, excessive moisture, or condensation
formation.
2. To avoid damage to electronic components by high humidity, provide adequate ventilation by opening a
window and/or a door when bathing.
3. Use a water supply of 0.5kgf/cm2to 7.5kgf/cm2(49kpa~735kpa).
4. Connect to a potable water source.
5. The water remaining in the unit may sometimes freeze during storage in winter. Make arrangements to
prevent the hoses from freezing. If freezing occurs, warm the unit in room temperature before installation.
6. The thermal protector in the water tank may sometimes trip during storage or transportation in warm
weather, causing non-operation. If this occurs, cool the unit in room temperature before installation.
7. The rated power voltage is 120V AC, 60Hz and the rated power consumption is 630W. Use wiring and
electrical outlet appropriate for this level of power.
8. Do not supply electrical power to the unit unless the plumbing work has been completed. Damage could
result.
1. The electrical outlet, which must be a 120V~60-Hz and at least a 10-Amp grounded outlet,
should be located on the wall within reach of the units power cord.
2. Always use a three-prong grounded outlet. If you have only a standard two-prong outlet, it must
be replaced by a properly grounded three-prong outlet.
3. A personal protection Residual Current Device(R.C.D) must be installed in the circuit supplying
power to the unit.
4. If an extension cord is needed, only use an extension cord that has a three-prong grounded plug
and a three-slot receptor that will accept the units three-prong plug. The electrical rating of the
extension cord must be equal to or greater than the electrical rating of the unit.
Grounding Instructions
Failure to follow these grounding instructions may cause
electrical shock, fire, serious personal injury, or damage to the product.
WARNING!
Nozzle plate
Cleansing nozzle
Drain plug
Supporter body
Control panel Power supply cord
Water supply hose
to the nozzle
Main unit
Flexible Hose A Branching Valve
Flexible Hose B Conversion Nut

5OPERATING INSTRUCTIONS
C. Connecting the Water Supply to the Main Unit
Water Supply Pipe Shutoff Valve
Conversion Nut
Branching Valve
Hose A
Valve Coupling Nut
SHS


Water Supply Pipe
Shutoff Valve
Fill Valve
Flush Tank
Valve Coupling Nut
 Pipe "A"
(Replace with hose A)


Turn off the water at the shutoff valve (Please refer to the diagram on the following page).
Flush the toilet twice to empty the bowl and tank. Place a small pan below the shutoff valve
and the fill valve to catch any water left in pipes then unfasten fill valve nut.
If your existing pipe “A” is a copper pipe, replace it with our flexible hose A.
If water supply pipe connection is 3/8”, use the conversion nut and the packing to attach the
branching valve. In some cases, the water supply pipe connection may be 1/2” in which case
the conversion nut may be omitted.
Connect the hose A to the branching valve and tighten. You may need to use a valve coupling
nut. (see note below)
6
OPERATING INSTRUCTIONS
INSTALLATION
Ⅳ
1. Unfasten the nuts of the toilet seat to remove the toilet seat.
2. Put the nozzle plate on the toilet.
3. Align the center of the nozzle plate with the toilet, then tighten the nuts securely.
A. Attaching the Nozzle Plate to the Toilet
B. Installing the Main Unit to the Toilet
Mounting bolts
Washer
Flat packing
Hinge
Cone packing
Note: Check the condition of the flexible hose. If it is cracked, worn, or damaged, do not use
it.Replace the damaged hose before installing the unit. Also, if your toilet is equipped
with a non-flexible pipe, please replace the pipe with an appropriate flexible hose. (The
size of the valve coupling nut fitting is either 3/8” or 1/2”. Take your existing pipe to a
plumbing/hardware store to get the proper size of the flexible hose.)
FlushTank
Hose A
Branching Valve
Shutoff Valve
Bodyjoint
Hose B
Use the hose B to connect the body joint
of the main unit to the branching valve.
Tighten the coupling nuts at the body
joint and the branch outlet.

7OPERATING INSTRUCTIOS
BEFORE OPERATION
Ⅴ
1. DO NOT use with an electrical outlet into which the plug does not fit securely.
2. If this product is to be used by children, elderly or disabled persons, the temperature control should be set to
the lowest level to avoid irritation or injury.
3. If this product to be used by elderly persons or by children, appropriate supervision and precautions should
be observed.
4. If the unit becomes loose or moves out of position, retighten the nuts and bolts as necessary. Use of the
product without retightening could result in water leakage.
5. DO NOT apply force to the connecting flexible hoses or other plumbing; it could result in water leakage.
6. DO NOT splash water or urine on the unit; it could cause malfunction.
7. DO NOT allow this product to come into contact with paint, insecticide, nail polish, thinner, chlorine-based
detergents, etc.
8. Placing a heating appliance too close to the unit could cause deformation or discoloration.
9. Exposure of the unit to direct sunlight could cause deformation or discoloration.
10. DO NOT use the unit as a footstool or place heavy objects on the unit, as this could cause damage.
11. If the supply cord is damaged, it must be replaced by the manufacturer, a service agent, or a similarly
qualified person in order to avoid hazards.
1. If the unit is not in use for a long period of time, drain the water out of the water tank in the
main unit and unplug the power cord.
2. An automatic timer will shut off the water after one minute. This prevents the unit from
accidentally being left “on” in households with children. To continue usage, press the cleansing
button to re-initiate the water stream.
A. Cautionary Notes
1. Turn the shutoff valve (A) clockwise to close.
2. Loosen the drain (B) at the botton of the water tank to drain the water. Be sure to place a pan large enough to
contain the drained water.
3. After draining, securely tighten the plug (B).
4. To re-supply water after draining, open the shoutoff valve (A).
b. Instruction for Water Draining
Please check the following points before requesting service :
Service of any problems not covered under the warranty is provided by UCI Inc. for a moderate fee.
C. Troubleshooting
B. Important Things to Know
Freezing could cause damage to the water tank or hoses, etc.,
thus resulting in water leakage.
If there is a risk of freezing, use one of the following methods.
Method 1 : Use a heating appliance to heat the room.
Method 2 : Set the water temperature to ”HI”.
Method 3 : Drain the water out of the water tank.
a. Preventing Freezing
8
OPERATING INSTRUCTIONS
Shutoff Valve
Close
Main Unit
Branching Valve Hose A
SHS
Hose B
Flush Tank
Problem Possible Cause Suggestion
The unit does not turn on. • The unit is not plugged in securely. • Plug in securely.
The water stream does not spray • The water tank is not filled. • Wait about one minute.
• Timed operation stopped after • Press the desired switch once
one minute continuous use. again
• The shutoff vaive is closed. • Turn on the shutoff vaive to open
• Freezing inside the main unit • Heat the room (for about
or the water supply pipe. two hours). Operating the
unit while parts are frozen will
cause a malfunction.
The water stream is not warm. • The water temperature switch • Set switch to HI; it will take
is set to LO. about ten minutes for the water to
reach the set temperature.
• Continuous operation has • Wait about ten minutes.
depleted the supply of warm water.
The water pressure is weak. • The water pressure level is set to LO. • Reset the water pressure to HI.
• The strainer is clogged. • Clean the strainer.
(A)
(B)

9OPERATING INSTRUCTIONS
OPERATION
Ⅶ
STOP
HI
TEMP
HILO
LO
BB-300H
Made in Korea
10
OPERATING INSTRUCTIONS
TRIAL OPERATION
Ⅵ
1. Open the shutoff valve.
2. Plug in the power cord. The indicator will light up. Start supplying water to the water tank.
3. The water tank will take about a minute to fill up.
1. Shield the nozzle with your hand to prevent the water
from spraying too far during the trial operation.
2. Press the CLEANSING button to test the water stream.
3. Adjust the water stream using HI/LO button.
Confirm that there is no water leakage from the connections.
A. Preparation CONTROL PANEL FEATURES
B. Operation Test
Press this button to stop
CLEANSING.
STOP BUTTON
Water pressure is adjustable
to the desired level by
pressing HI or LO button.
WATER PRESSURE
ADJUSTMENT BUTTON
The temperature of water is
adjustable to the desired
level by pressing TEMP
button.
LED indicator lights
approximately correspond
to the following
temperatures:
WATER TEMPERATURE
ADJUSTMENT BUTTON
Pressing this button will
initiate the water stream for
one minute of personal
cleansing.
The Auto Shut-off ensures
that the unit will not be left
“on” by accident.
LED indicator lights will
show the relative water
pressure and temperature
levels.
CLEANSING BUTTON
LED INDICATOR LIGHTS
C. Check for Water Leakage
Hose B
Branching Valve
Shutoff Valve
Open
Hose A
Flush Tank
SHS
Room Temperature
85
o
F
95
o
F
104
o
F
LO HI

11 OPERATING INSTRUCTIONS
MAINTENANCE
Ⅷ
A. Cleaning the Strainer
CAUTIONS:
The unit will not operate properly if the strainer is clogged. Be sure to clean the strainer.
1. Close the shutoff valve.
2. Flush the toilet to empty the flush tank.
3. Unscrew the nut (A).
4. Clean the strainer using a small brush.
5. Re-screw the nut (A).
6. Open the shutoff valve.
DO NOT use chlorine-based detergents, benzene, thinner, alcohol, steel wool, etc. for cleaning;
that will damage the unit.
DO NOT wash with water. This is an electrical appliance and water could cause malfunction.
Flush Tank
Shutoff Valve
Strainer
Nut(A)
12
OPERATING INSTRUCTIONS
1. Pull down the nozzle from the nozzle plate by hand.
2. If the nozzle is clogged, clean it using a pin.
B. Cleaning the Nozzle
C. Water Draining From Water Tank
CAUTIONS : • Do not drink the drained water.
• Do not insert finger into the drain hole.
(Before draining unplug the power cord and wait 30 min until the appliance has cooled down.)
1. Turn the shutoff valve (A) clockwise to close.
2. Loosen the drain (B) at the botton of the water tank to drain the water. Be sure to place a pan large enough to
contain the drained water.
3. After draining, securely tighten the plug (B).
4. To re-supply water after draining, open the shoutoff valve (A).
Shutoff Valve
Close
Main Unit
Branching Valve Hose A
SHS
Hose B
Flush Tank
(A)
(B)

14
OPERATING INSTRUCTION MANUAL
13 OPERATING INSTRUCTION MANUAL
NO ITEM BB-300H
Power Rating AC 120V~60Hz
1 630W
Power Cord 4ft (1.2m)
Warm Water Flow Rate 14 - 33 oz/mim
Temperature Settings Room Temp., 85OF, 95OF, 104OF
Heater 600W
2 Safety Features Thermal Fuse
Float Switch
Thermal Switch
1Minute Auto Shut-off
Supply Water Pressure 0.5-7.5kgf/cm2
3Dimension & Weight
4.3”(W)14.6”(H)18.2”(L)
10 lbs
4 Ambient Temperature 40OF to 104OF
SPECIFICATIONS
Ⅸ
WARRANTY CARD
Ⅹ
WARRANTY
One Year Warranty
The manufacturer carefully tests every BioBidet
TM
before shipment. BioBidet
TM
made with
highest quality materials in the highest standard of production and workmanship, is
guaranteed to be free of defects.
The warranty is good for one year from purchase date.
Warranty Excludes the Following:
1. Replacement of parts due to discoloration from cleaning chemicals or mineral content
in water.
If you live in an area with strong minerals in the water, manufacturer recommends
using a water filter.
2. Replacement due to damage or malfunction caused by improper installation,
negligence, misuse or abuse.
3. Replacement due to improper installation.
4. Manufacturer is not responsible or liable for any damages caused by improper
installation or by use of parts which were not supplied by manufacturer.
Only the original purchaser may submit a claim under this limited warranty. To activate your
warranty, complete this form:
Purchase Date Purchased From
Invoice # Amout Paid Serial #
Name
Address City State Zip
Phone ( ) - Fax ( ) - E-mail
Mail, email or fax the warranty form to :
UCI, 205 Berg Street,
Algoquin IL, 60102
email to [email protected]
fax to 847-854-1296
Keep a copy for your records.
Questions: Call Customer Service @ 847-854-7292
Great Products for Your Healthy Living!

