1. Raspberry Pi Start Kits
A. Generation Introduction:
The Raspberry Pi 3 Starter Kit is a great way to gain a solid introduction to the small, credit-
card sized computer. The starter kit makes the Raspberry Pi intuitive and easy to learn.
With this kit, you will be able to get your Raspberry Pi 3 as your own credit card sized
computer, getting started with programming and coding. So, if you are looking for a new
challenge or a way to get in on the RPi craze, check out the Raspberry Pi 3 Starter Kit!
UCTRONICS team has carefully done the compatibility test for all components, and offer
the plug and play boot operation system like Raspbian. Users only need additional HDMI
monitor and keyboard/mice to use this kit as a standard PC desktop.
B. Parking list:
➢1pcs 16GB Micro SD Pre-Loaded with Raspbian
➢1pcs Power Supply Adapter Charger 5V 2.5A (US)
➢1pcs USB cable with ON/OFF switch
➢1pcs ABS Protective Case
➢3pcs Heatsink kit with Thermal Pad

www.uctronics.com
3
2. Assembly
A.16GB Micro SD Pre-Loaded with Raspbian
This Micro SD Card Bundle for the Raspberry Pi consists of a SanDisk Class 10 Micro SD card
pre-loaded with the Official Raspberry Pi Raspbian.
Specification:
➢Capacity: 16GB
➢Weight: 0.2g
➢Simply plug this SD card into your Raspberry Pi
➢Fully tested to work with the Raspberry Pi 3 Model B
➢Pre-Loaded with pre-loaded with the Raspberry Pi Raspbian image

www.uctronics.com
4
B. Power Supply Adapter Charger 5V 2.5A (US)
These have a standard USB ‘A’ connector for the output so you can power your Arduino,
Raspberry Pi, etc. through a USB cable. Any device that uses a USB cable for charging or
power can be powered with this supply.
Specification:
➢Input Voltage: AC100-240V 50/60Hz
➢Output: DC 5.0v 2500mA (2.5A)
➢Adapter plug type: US
➢Overload Protection
➢Consistent fixed switching voltage

www.uctronics.com
5
B. USB cable with ON/OFF switch
This Raspberry Pi Micro USB Cable with ON / OFF Switch is specifically designed for Raspberry
Pi. Just press the button to turn your Pi on or off, no need to pull the cable to restart or reboot
your Raspberry Pi which prevents the Raspberry Pi's Micro USB connector from frequent
pulling and inserting the USB cable. 1.5m length can be used as power supply for the
Raspberry Pi module, not for data transfer use.
Specification:
➢Type: On/Off switch
➢Length: 1.5m Long
➢Color: Black
➢Connector Type A: USB
➢Connector Type B: Micro USB

www.uctronics.com
6
C. ABS Protective Case
It has slim openings for all your cables, an easy-to-remove beveled slot for your Micro SD
card, slots for both your Pi Camera and upcoming Display, and a space for your GPIO cable
to extend out from the Pi. Two-piece injection- ABS Case that snaps together which is easy
to stall.
Specification:
➢Material: ABS plastic case
➢Dimensions: External:96 x 66 x 41mm
➢Color: black
➢With 4 screws and 4 non-slip mats

www.uctronics.com
7
D. Heatsink kit with Thermal Pad
The Raspberry Pi Heat Sink Kit consists of three high quality aluminum heat sinks, each
selected to match the size of the main heat out-put components on the Raspberry Pi board.
The heatsinks are designed to fit on top of the Broadcom and Ethernet SOC's which will
Extend the life of your Raspberry Pi and reduce the risk of hardware failure.
Specification:
➢Number: 3 pcs Silver Aluminum Heat Sinks
➢Thermal Resistance: 25°C/W.
➢Dimension: 9x9x5mm
14x14x6mm
➢Floor Thinness: 1.6mm, 1.1mm
➢Vane Thickness: 0.8mm, 0.6mm

www.uctronics.com
8
3. Installation diagram
Figure1.
Caution: The internal Wi-Fi antenna is fragile, be careful and please don't press with too much
strength when installing.
Figure2

www.uctronics.com
9
Figure3
Figure4.

www.uctronics.com
10
A. Getting started
1. If you have a case, start by installing the Raspberry pi inside the case.
2. Insert a pre-programmed MicroSD card into the MicroSD card slot on the bottom side of
the Raspberry Pi.
3. Connect a USB keyboard and mouse to the USB ports.
4. Connect a HDMI monitor or TV to the Raspberry Pi using a HDMI cable. Ensure your
monitor or TV is turned on and that you have selected the correct input.
5. Once all connections have been made, it is now time to connect the MicroUSB Power
Supply to the board. When the power is connected, the Raspberry Pi will start to boot.

www.uctronics.com
11
B. Raspbian System
Raspbian is the Foundation’s official supported operating system. Raspbian comes pre-
installed with plenty of software for education, programming and general use. It has Python,
Scratch, Sonic Pi, Java, Mathematica and more.
Raspbian desktop overiew
Programming menu

www.uctronics.com
12
Office menu
Internet menu

www.uctronics.com
13
Games menu
Accessories menu

www.uctronics.com
14
Help menu
Preferences menu

www.uctronics.com
15
Run... menu
Shutdown... menu

www.uctronics.com
16
C. Guide to connecting WIFI
If you want to connect your Raspberry Pi to the internet or local network then you will need
to follow these steps:
1. WiFi connections can be made via the network icon at the right-hand end of the menu
bar. left-clicking this icon will bring up a list of available WiFi networks.
2. If no networks are found, it will show the message "No APs found - scanning...": just wait
a few seconds without closing the menu, and it should find your network.
3. The icons on the right show whether a network is secured or not, and its signal strength.
Click the network that you want to connect to. If it's secured, a dialogue box will appear
prompting you to enter the network key.
4. Enter the key and press OK, then wait a couple of seconds. The network icon will flash
briefly to show that a connection is being made. Once it's ready, the icon stops flashing
and shows the signal strength.
