uhuru FRAME RISE User manual

FRAME RISE 47"DESK
ASSEMBLY AND CARE
HELL[email protected] 718 855 6519 UHURUDESIGN.COMFRAME RISE DESK
CLEANING AND CARE
Clean surfaces with a dry or damp
soft cloth. Do not use abrasive,
oil or chemical based cleaners. It
is recommended to use coasters
to protect surface from heat
and water. Do not leave spills
unattended.
WARNING
Serious or fatal crushing injuries
can occur from furniture tip-over.
To help prevent tip-over, read this
entire warning.
To further reduce the risk of
serious injury and death from tip-
overs:
• Never stand on furniture
• Furniture intended for
placement on floor
• Do not place items over
300lb on furniture
QUESTIONS?
Email [email protected]
For warranty claims, visit this link:
www.uhurudesign.com/pages/claims
DIMENSIONS
L47 W28 H24-49
!
55LB
67LB
Slide the control box into leg frame.
Using the pre-drilled holes for guidance, attach the control
handset on either the left or right side of the desk with ST5X16
screws.
Connect handset, power cord, and motor cords to the control
box.
Have someone help you lift the by the legs and rotate the desk
upright.
place the desk in its intended spot and adjust the leveling glides.
Plug power cable into an outlet.
If necessary, manage cables with ATC-17.
If placing electronics such as a computer monitor on the table
top, ensure that cords are long enough to allow the table to rise
to its full height.
ELECTRONIC SETUP PROCEDURE
The setup procedure needs to be done as soon as the table is
set up, and then any time it is moved, unplugged, or if the legs
somehow happen to get out of sync.
FAILURE TO RESET BEFORE USE CAN CAUSE IRREPARABLE
DAMAGE TO ELECTRONIC COMPONENTS
To reset - push the down button until the base reaches the lowest
position it will go to, release then press the down button again
and hold for about 7 seconds. Then release the down button
push it again and hold until the base bottom’s itself out, then
slightly rises
8
9
10
11
FRAME RISE DESK
7

ASSEMBLY INSTRUCTIONS
Slide leg frames onto rails.
Place desk top on the floor upside down, using a blanket or
carpet to avoid scratching.
Place frame assembly on table top. Align holes of leg frame with
holes in leg and attach M6X10 screws.
Important Tip: Place the triangle end brackets in place to prop
up the leg and facilitate the hole alignment. The holes may not
appear to align if you do not have the brackets in place.
Slide brackets into ends of frame assembly and attach both
M6X14 screws.
Attach feet to legs with M6X14 screws.
Align the bracket holes and leg frame holes with the pre-drilled
holes in the desk top. Attach using ST5X20 screws.
Roughly center spanning rails by sliding them between leg
assemblies. Insert and tighten M6X10 screws into rails, pinning
them in place.
1
4
2
5
3
6
FRAME RISE DESKFRAME RISE DESK FRAME RISE DESK
FRAME RISE - SIT STAND DESK
CONTENTS
This page lists the contents included in the box. This product
does require assembly. As you unpack, place the contents on a
carpeted or padded area to protect them from damage. Improper
unpacking can result in personal or property damage.
CONTENTS
40003 POWER BOX 40019 CONTROLS
M6X10 (X16)
ST5X20 (X7)
M6X14 (X12)
ST5X16 (X2)
