Ultimate Sound Titanium TS124 Operating instructions

Titanium Subwoofers
S10
TS124
TS124DVC
TS104
TS104DVC
Installation and Operation Guide
Ultimate Sound, Inc Ultimate Europe AB
163 University Parkway Flojelbergsgatan 7A
Pomona, California SE 431 37
Phone: [phone] Molndal, Sweden
Fax: [phone] Phone: [phone]
e-mail Fax: [phone]
[email protected] [e-mail]

Ultimate®Sound
2
I. Introduction
You have purchased a very sophisticated subwoofer manufactured by
Ultimate®Sound. Founded in 1975, Ultimate®Sound makes speakers
for every car audio application, speakers for marine environments,
enclosed speaker systems, amplifiers, accessories and other products. Our
tradition of leadership and innovation in the audio industry continues with
innovative products like Titanium Subwoofers.
We recommend you have your new Titanium Subwoofers installed by a
professional. Professional installation shops have the equipment to do the
job correctly, and the experience to recommend the best mounting
locations in your vehicle.
Please use your new Titanium Subwoofers responsibly. Very loud
music can cause permanent hearing loss.
TITANIUM SUBWOOFER FEATURES:
•Titanium cone formula- for strength, durability and stability during
high power operation at extreme temperatures.
•The Butyl Rubber Surround has superior damping characteristics
and will last longer than foam surrounds
•Kapton®Voice Coil Former- Higher power handling than
aluminum voice coil formers.
•4 Layer voice coil windings keep more wire in the magnetic gap for
more output..
•Vented, extended pole piece- keeps the voice coil cool during long
excursions at high power.
•Bumped back plate- makes sure the voice coil never bottoms out.
II. Package Contents
•1 Titanium Subwoofer
•Instruction manual and warranty card.

Ultimate®Sound
3
III. Specifications
Model TS124 TS124DVC TS104 TS104DVC
Size 12"/305mm 12"/305mm 10"/254mm 10"/254mm
Impedance 4ΩDual 4Ω4ΩDual 4Ω
Frequency
Response 24Hz-
500Hz 24Hz- 500Hz 27Hz- 800Hz 27Hz- 800Hz
Voice Coil 2”/ 50.8mm 2”/ 50.8mm 1.5”/ 38mm 1.5”/ 38mm
Magnet 55 oz. 55 oz. 40 oz. 40 oz.
Fs 29Hz 24z 32Hz 31Hz
Vas-
ft3/Liter 2.4ft3/ 68 Liters 4.9ft3/ 140 Liters 1.38ft3/ 39 Liters 2.08ft3/ 59 Liters
Xmax 0.3”/7mm 0.3”/7mm 0.3”/7mm 0.3”/7mm
Qts .37 .36 .40 .41
Sensitivity 91.7dB 91.8dB 90.5dB 90.7dB
Power-
RMS 250 Watts 250 Watts 200 Watts 200 Watts
Power-
MAX 500 Watts 500 Watts 400 Watts 400 Watts
Cone Poly-
propylene Poly- propylene Poly- propylene Poly- propylene
Surround Butyl Butyl Butyl Butyl
Frame Steel Steel Steel Steel
Mounting
Depth(In.) 5.2" 5.2" 4.5" 4.5"
Mounting
Depth(mm) 130mm 130mm 114.3mm 114.3mm
Dual voice coil parameters are with voice coils connected in parallel for
2
Ω impedance. Coils may be wired in series without significant change in
box volume requirements.

IV. Installation- Sealed Enclosures
1. Sealed enclosures provide excellent performance with Titanium II
Symetec Subwoofers. They are the simplest enclosures to design and
build. We recommend you choose a sealed design if you have not
built subwoofer enclosures before. Remember to glue and screw all
joints, using enough glue to make sure all joints are air tight. Loosely
fill the enclosure with fiberglass, poly-fill, or cotton damping material.
Recommended Sealed Enclosures
TS124/
TS124DVC Recommended
Internal Volume Driver Displacement Total Internal Volume
Optimum 0.82ft3/23.2L 0.14ft3/4.08L 0.96ft3/27.28L
Minimum 0.35ft3/9.9L 0.14ft3/4.08L 0.49ft3/13.98L
TS104/
TS104DVC
Optimum 0.65ft3/18.4L 0.08ft3/2.27L 0.73ft3/20.67L
Minimum 0.3ft3/8.5L 0.08ft3/2.27L 0.38ft3/10.77L
Width Depth
Ultmate
Height
Internal Volume(ft3)= (in Inches)Internal Width X Depth X Height
1728
Internal Volume(L)= (in Centimeters)Internal Width X Depth X Height
1000
Ultimate®Sound
4

V. Installation- Ported Enclosures
1. Ported enclosures use a tuned vent to get additional output at the
tuning frequency. Smaller ports than recommended may cause noise
from air turbulence. Flared ports will produce less turbulence and
noise. Remember to glue and screw all joints, using enough glue to
make sure all joints are air tight.
2. Make sure there is at least 2” between the end of the port and the
adjacent wall of the enclosure.
Recommended Vented Enclosures
Optimum Volume TS124/TS124DVC
Volume 1.78ft3/ 50.41L
Driver Displacement 0.14ft3/ 4.0L
Port Displacement 0.03ft3/0.85L
Total Enclosure Volume 1.95ft3/ 55.2L
Port Diameter 3”/76mm
Port Length 7.8”/198mm
Tuning 33Hz
F335Hz
Optimum Volume TS104/TS104DVC
Volume 1.2ft3/ 33.98L
Driver Displacement 0.08ft3/2.27L
Port Displacement 0.05ft3/1.42L
Total Enclosure Volume 1.33ft3/ 37.67L
Port Diameter 3”/76mm
Port Length 11.7” / 297.2mm
Tuning 33Hz
F334Hz
Ultimate®Sound
5
See the supplied warranty card for service information
Call 888-909-9988 for technical assistance.
