Ultimate Sound Ux12 Operating instructions

UXSubwoofersS10
UX12
UX10
Installation and Operation Guide
Ultimate Sound, Inc Ultimate Europe AB
163 University Parkway Flojelbergsgatan 7A
Pomona, California SE 431 37
Phone: [phone] Molndal, Sweden
Fax: [phone] Phone: [phone]
e-mail Fax: [phone]
[email protected] europeansupport@ultimate-
europe.com

Ultimate®Sound
2
I. Introduction
You have purchased a very sophisticated subwoofer manufactured by
Ultimate®Sound. Founded in 1975, Ultimate®Sound makes speakers
for every car audio application, speakers for marine environments,
enclosed speaker systems, amplifiers, accessories and other products. Our
tradition of leadership and innovation in the audio industry continues with
innovative products like UXSubwoofers.
We recommend you have your new UX Subwoofers installed by a
professional. Professional installation shops have the equipment to do the
job correctly, and the experience to recommend the best mounting
locations in your vehicle.
Please use your new UXSubwoofers responsibly. Very loud music can
cause permanent hearing loss.
UXSUBWOOFER FEATURES:
•Graphite Injected Cone- for stiffness, strength, durability and
stability during high power operation at extreme temperatures.
•The Butyl Rubber Surround has superior damping characteristics
and will last longer than foam surrounds
•Kapton®Voice Coil Former- Higher power handling than
aluminum voice coil formers.
•4 Layer voice coil windings keep more wire in the magnetic gap for
more output..
•Vented, extended pole piece- keeps the voice coil cool during long
excursions at high power.
•Bumped back plate- makes sure the voice coil never bottoms out.
II. Package Contents
•1 UXSubwoofer
•Instruction manual and warranty card.

Ultimate®Sound
3
III. Specifications
Model UX12 UX10
Size 12"/305mm 10"/254mm
Impedance 4Ω4Ω
Frequency
Response 24Hz-500Hz 27Hz-800Hz
Fs 24.3Hz 29Hz
Vas- ft3/Liter 4.4ft3/ 125.2 Liters 2.2ft3/ 62.35 Liters
Xmax 0.3” / 7mm 0.3”/7mm
Qts .45 .40
Sensitivity 90dB 89dB
Power- 300 Watts 200 Watts
Cone Graphite injected Graphite injected
Surround Butyl Butyl
Frame Steel Steel
Mounting Depth(In.) 5.12" 4.5"
Mounting Depth(mm) 130mm 114.3mm

IV. Installation- Sealed Enclosures
1. Sealed enclosures provide excellent performance with UX
Subwoofers. They are the simplest enclosures to design and build.
We recommend you choose a sealed design if you have not built
subwoofer enclosures before. Remember to glue and screw all joints,
using enough glue to make sure all joints are air tight. Loosely fill the
enclosure with fiberglass, poly-fill, or cotton damping material.
Recommended Sealed Enclosures
UX12 Recommended
Internal Volume Driver Displacement Total Internal Volume
Optimum 1.25ft3/35.38L 0.14ft3/4.08L 1.39ft3/39.46L
Minimum 1.00ft3/28.32L 0.14ft3/4.08L 1.14ft3/32.40L
UX10
Optimum 1.00ft3/28.32L 0.08ft3/2.27L 1.08ft3/30.59L
Minimum 0.75ft3/21.24L 0.08ft3/2.27L 0.83ft3/23.51L
Width Depth
Ultmate
Height
Internal Volume(ft3)= (in Inches)Internal Width X Depth X Height
1728
Internal Volume(L)= (in Centimeters)Internal Width X Depth X Height
1000
V. Installation- Ported Enclosures
1. Ported enclosures use a tuned vent to get additional output at the
tuning frequency. Smaller ports than recommended may cause noise
from air turbulence. Flared ports will produce less turbulence and
noise. Remember to glue and screw all joints, using enough glue to
make sure all joints are air tight.
2. Make sure there is at least 2” between the end of the port and the
adjacent wall of the enclosure.
Ultimate®Sound
4

Recommended Vented Enclosures
UX12
Volume 2.00ft3/ 56.6L
Driver Displacement 0.14ft3/ 4.0L
Port Displacement 0.05ft3/1.42L
Total Enclosure Volume 2.19ft3/62.02L
Port Diameter 3”/76mm
Port Length 10.5”/265.65mm
Tuning 27Hz
F334Hz
UX10
Volume 1.35ft3/ 38.21L
Driver Displacement 0.08ft3/2.27L
Port Displacement 0.06ft3/.85L
Total Enclosure Volume 1.49ft3/ 41.33L
Port Diameter 3”/76mm
Port Length 11” / 278mm
Tuning 33Hz
F336Hz
Ultimate®Sound
5
See the supplied warranty card for service information
Call 888-909-9988 for technical assistance.
Ultimate
Height
Width Depth
