ULTRA BRIGHT UB-350-400-X User manual

LIGHT CHARACTERISTICS
Light Source 12 Ultra-High Intensity White LEDs
Lumens output 5 -35 Lumens
*Varies with Brightness Levels
Available LED Colors White
Light Mode Constant * Variable Brightness
Visible Range 100m-200m+
Horizontal Output (degrees) 360°
Vertical Divergence (degrees) 180°
LED Life Expectancy (hours) > 100,000 hrs
ELECTRICAL CHARACTERISTICS
Circuit Protection Integrated / Overcharge / Over
Discharge / Constant Current
Nominal Voltage (v) 3.2v Battery, 4v Solar
Power / Brightness Levels 7 Levels, User Adjustable with Magnet
Autonomy (hours) 10-140hrs *On full Charge
* Varies with Brightness Setting
Temperature Range 14-158°Fahrenheit
SOLAR CHARACTERISTICS
Solar Module Type Tempered Glass + Monocrystalline Cell
Power (watts) 0.8 Watts
Solar Module Efficiency (%) 18 % Super High Efficiency Cells
POWER SUPPLY
Battery Type NiMh
Battery Size 2pcs AA 1.2v
Battery Capacity (mAh) 1200 mA
Nominal Voltage (v) 2.4v (2pcs 1.2v AA Batteries)
Battery Service Life 1-3 years
*(Varies with local Environment)
Battery Service Access Yes: User Changeable / Replaceable
PHYSICAL CHARACTERISTICS
Body Material High Performance ASA
Lens Material Bayer UV Stabilized Poly Carbonate
External Lens Design Smooth / Clear
Internal Lens design NA
Water Proof Rating IP 68
Base Options: (Post Sizes) ➢4.00”x4.00” – (Generic/Vinyl)
➢3.5”x3.5” – (Generic/Wood)
Height 2.55” (65mm)
Width / Width 5.5” x 5.5” (140mm)
Weight 1.10 lbs / (0.50 kg)
OTHER
Other Options & Sizes Please Contact
1yr Limited Warranty * Information subject to change without notice
Pictured in white
Solar Post Cap:
Ultra Bright's Solar Post Cap Light is the most
advanced, powerful, robust, solar fence post light
available. Add safety, elegance and ambience to
your deck without the hassle of electrical wiring!
Patented magnet technology allows users to easily
adjust between 7-brightness levels to meet
seasonal performance, brightness, & run
preference.
Each side of the light has 12 white ultra-high
intensity downward shining LEDs that
automatically turn on at dusk and turn off at
dawn. Swipe the magnet quickly over the solar
panel to adjust between 7 brightness levels or
"OFF”.
Copyright Protected Design
PATENTED DESIGN
Ultra Bright Tech
P.O. Box 414
105 W. Simon St.
Laotto, IN 46763
Phone: [phone]
Fax: [phone]
E-mail [email protected]
Web: www.ultrabrighttech.com
SOLAR POST CAP
See www.ultrabrighttech.com for other color & size options
4-Season Rated
UB-350-400-X

1.0 Watt Tempered Glass
Solar Panel: Rated at 15+yrs
Automatic night
activation
Set Screw
12 Super High
Intensity White LEDs
IP 68 Fully Sealed &
Water Proof Electronics
*Various size base
post adaptors
4-10X More Powerful Solar Panel
5-20X Brighter Light
10x Longer Service Life
7 Adjustable Brightness Levels
IP 68 Waterproof Electronics
12 Ultra Bright White LEDs
UV Stabilized ASA Plastic
* NOTE: Information is a general reference in comparison to the best solar fence post lights we were able to find on the market.
Copyright Protected Design
PATENTED DESIGN 4-Season Rated
Vapor Vent
Magnet Switch
Adjustable Brightness Levels
Ultra Bright Tech
P.O. Box 414
105 W. Simon St.
Laotto, IN 46763
Phone: [phone]
Fax: [phone]
E-mail [email protected]
Web: www.ultrabrighttech.com
SOLAR POST CAP

Ultra Bright Tech
P.O. Box 414
105 W. Simon St.
Laotto, IN 46763
Phone: [phone]
Fax: [phone]
E-mail [email protected]
Web: www.ultrabrighttech.com
Dimensions: (In.)
BASE OPTIONS AVAILABLE FOR THIS MODEL
Ultra Bright Base Option Fits General Post Size * Various Popular Brands / Series
UBT-400-350-X 4.00” x 4.00” Inch VINYL/Generic 4x4 Post Covers
UBT-400-350-X 3.50” x 3.50” WOOD/Generic 4x4 Post Covers
4.00”
Fits General 4x4 Vinyl Post
Covers
Fits General 4x4 Wood Post
Covers (3.5”x3.5” Actual)
UBT-400-350-X
UBT-400-350-X
UBT-400-350 Post cap,
without the included base
adaptor will fit vinyl styles
& brands of 4.00x4.00”
post covers:
(Sharp or beveled corners)
Actual shape & profile
designs will vary with
different brands. This is a
general reference only.
UBT-400-350 Base Adaptor
will fit all of 4.00x4.00”
wooden post covers, with true
dimensions of 3.50”x3.50”:
(Sharp or beveled corners)
This is a general reference
only.
Vinyl Post
4.00
”
4.00”
3.50”
3.50”
3.50”
3.50”
Wood Post
4.00”

Use a screwdriver to remove the battery
cover & connect the battery: NOTE: Align
the connectors before joining.
Ensure the silicone pad is under the battery cover
and reinstall the cover in place. Tighten all screws
to ensure a waterproof seal.
SOLAR POST CAP
4
Ultra Bright Tech
P.O. Box 414
105 W. Simon St.
Laotto, IN 46763
Phone: [phone]
Fax: [phone]
E-mail [email protected]
Web: www.ultrabrighttech.com
3
12
Phillips Screwdriver
Place the solar Post Cap on the post. Mark both
holes on the post. Use an appropriate drill bit to
make a small pilot hole for the provided screws.
Use the provided screws to secure your solar
post light to the post.
Phillips Screwdriver

•TESTING: Place entire light in a dark room. Light should turn on, if not, swipe the magnet over the solar panel until light turns on.
•Run times will vary significantly based on factors such as; Sun Exposure, Season, Angle of Sunlight, Geographic Location, Shading,
Installed Location/Position, Battery Condition, and most importantly, the Brightness Setting in comparison to the yearly season.
•The following run times should only be used as a general reference and are not guaranteed. Consider your local environment
•Lower brightness settings use less power and leave more reserve power for cloudy days where less recharging takes place.
NOTE: RUN TIMES ARE BASED ON A FULL CHARGE: MANY FACTORS MAY PREVENT A FULL CHARGE SEE BELOW
Wave the magnet over the solar panel at NIGHT until you
find the activation area which changes the brightness level.
This operation only works at NIGHT or in absence of light.
Swipe the magnet quickly across the solar panel activation
area to change between brightness levels & OFF.
NOTE: In the OFF mode the battery will still charge during
the daytime, however at night the light will NOT turn on. NOTE: A quick swiping
motion across the solar
panel works best!
BRIGHTNESS SWITCH
SOLAR POST CAP
Ultra Bright Technologies 1-Year Limited Warranty
The retailer warrants the Solar Lights to be free from defects in workmanship and material present at time of shipment from the factory for a period of one year after the date of purchase by the original
purchaser. We agree to correct such defects without charge or at our option replace with a comparable or superior model if the product is returned to the retailer. To obtain warranty service, you must
present a copy of the receipt as proof of purchase. All costs of removing and reinstalling the product are you responsibility. Damage to any part such as by accident or misuse or improper installation or
by affixing any accessories, is not covered by this warranty. There is no other express warranty. The retailer hereby disclaims any and all warranties, including but not limited to, those of merchantability
and fitness for a particular purpose to the extent permitted by law. The duration of any implied warranty, which cannot be disclaimed, is limited to the time period as specified in the express warranty.
Some states do no allow limitation on how long an implied warranty lasts, so the above limitation may not apply to you. The retailer shall not be liable for incidental, consequential, or special damages
arising out of or in connection with product use or performance except as may otherwise be accorded by law. Some states do not allow the exclusion of incidental or consequential damage, so the above
exclusion or limitation may apply to you. This warranty gives specific legal rights, and you may also have other rights, which vary from state to state. This warranty supersedes all prior warranties.
PRODUCT & WARRANTY REGISTRATION: Visit www.ultrabrighttech.com/registration
