UltraLux SSMFR4Z User manual

ver.1.1
1
www.ultralux.bg
1
www.ultralux.bg
2.4G RF multifunctional touch remote control, 4 zones
Model № SSMFR4Z
DESCRIPTION
2.4G SMART RGBW system contains of RF multifunctional controller and multifunctional TOUCH remote
control. The controller supports four control modes: single colour LED strip, colour temperature control,
RGB and RGBW LED strips. The multifunctional touch remote control allows grouping of LED lighting up to
four zones.
SSMFR4Z is an RF remote control for multifunctional controller SSMFC24A.
TECHNICAL DETAILS
•Working voltage: 2x AAA batteries 1.5 V
•Number of control zones: 4
•Frequency: 2.4 GHz
•Index of protection: IP20
•Remote distance: up to. 20 m
•Dimensions: 148/40/21 mm
•Working temperature: -10⁰ C ÷ +40⁰ C
•Warranty: 2 years
Wall hanger for RF remote, which can be mounted by mounting sticker or by fastener included in the kit.
INSTRUCTIONS
The number of controllers and remote controls in one system is unlimited. 2.4G Smart RGBW system has
one unique RF code for communication. Each controller and each remote control can remember only one
RF code, recorded in the first programing. New RF code can be recorded after delete the old one.
•Pairing of SSMFR4Z to controllers
Step
Operation
Instructions
1
Connect the load to the controllers and turn
the power on.
1.It is necessary to clear the code first, if the
controllers was coded before.
2.Pairing operation can be performed within
the remote control range.
2
Select area
Select the area with the "Zone" key and the
corresponding indicator lights up
3
Press and hold “ON” on the remote control for
5 seconds. The indicator of the remote control
will flash quickly, means it enters the pairing
code transmission.
Remote controller will automatically exit code
transmission after 60 seconds, or by pressing
any key.
4
The load flashes 3 times and return to the
initial state
Pairing is finished successfully

ver.1.1
2
www.ultralux.bg
2
www.ultralux.bg
•Clearing RF Code from controllers
Step
Operation
Instructions
1
Connect the load to the controllers and turn
the power on.
1. The clearing operation should be finished
within 1 minute after the controllers are
powered on. If exceeds the time, can be
powered on again.
2. Pairing operation can be performed within
the remote control range.
2
Press and hold the remote control “OFF”for 5
seconds. The indicator of the remote control
flashes quickly, means it enters the clearing
code transmission. There is no need to select
the corresponding area when clearing code.
1. Remote controller will automatically exit
code transmission after 60 seconds, or by
pressing any key.
2. If the original remote controller is lost, the
new remote controller can be used for
clearing operations.
3
The load flashes 3 times and return to the
initial state
Clearing coding is finished successfully
•RF Code learning operation between remote controls
Since each remote controller has its own unique RF code at the time of delivery, when there are multiple
remote controllers in one system, one of them must be selected as a main, and other remote controls
should copy its RF code.
1. Main remote control: Press and hold “ON” key for 5 seconds. The indicator of the remote control
will flash quickly, means it enters the pairing code transmission status.
2. New remote control: Press and hold “MODE”key for 5 seconds.
3. Indicator of the new remote control flash three times after successful code learning.
•Remote control RF code learning from controllers
1. Turn off the power supply of the controllers.
2. Press and hold “MODE”key for 5 seconds until indicator of remote control turns off.
3. Turn on the power supply of the controllers. Indicator of the remote control flashes three times
after successful code learning.
Note: The distance from controllers to remote controls should be less than 2 meters. If the distance of
controllers of different zones to remote control is more than 2 meters, upper steps must be repeated for
every zone.
•Restoring factory settings of remote control
1. Press and hold “MODE” key for 20 seconds until indicator of remote controller turns off.
2. Press “OFF”button. Indicator of the remote control flashes three times after successful operation.

ver.1.1
3
www.ultralux.bg
3
www.ultralux.bg
REMOTE CONTROL FUNCTIONS
•Control single colour LED strip
•CCT –colour temperature control
Key
Function
ON
Turns ON selected zone (all zones together)
OFF
Turns OFF selected zone (all zones together)
Dimming ring
Decrease brightness clockwise direction
M
Two working modes: flash, fade
Brightness 10%
Decrease light brightness –10%, 30%, 50%,
70%, 100%
Increase light brightness –10%, 30%, 50%, 70%,
100%
B-
Smooth decrease of light brightness
B+
Smooth increase of light brightness
S-
Decrease speed of dynamics modes
S+
Increase speed of dynamics modes
Zone selection
Select zone to control
Zone indicator
light
Indicates controlled zone (all zones)
Key
Function
ON
Turns ON selected zone (all zones together)
OFF
Turns OFF selected zone (all zones together)
CCT ring
Colour temperature control
M
Four working modes: flash, fade, 2 colours flash, 2
colours fade
Brightness 10%
Decrease light brightness –10%, 30%, 50%,
70%, 100%
Increase light brightness –10%, 30%, 50%, 70%,
100%
B-
Smooth decrease of light brightness
B+
Smooth increase of light brightness
S-
Decrease speed of dynamics modes
S+
Increase speed of dynamics modes
Zone selection
Select zone to control
Zone indicator
light
Indicates controlled zone (all zones)

ver.1.1
4
www.ultralux.bg
4
www.ultralux.bg
•Control RGB LED strip
•Control RGB LED strip
Note: Short press “Zone Selection” key, for
single zone shift, selected zone indicator
lights on. Long press “Zone Selection” key
for 2 seconds selects all zones –all
indicators light up. All zones are controlled
simultaneously.
TAKING CARE OF THE NATURAL ENVIRONMENT CLEANLINESS
•The product and its components are not harmful to the environment
•Please dispose the package elements separately in containers for the corresponding material.
•Please dispose the broken product separately in containers for out of usage electrical
equipment.
Key
Function
ON
Turns ON selected zone (all zones together)
OFF
Turns OFF selected zone (all zones together)
Color ring
Colour selection ring
M
Eight working modes
Turns ON/OFF white colour
Colour selection –cyan, purple, yellow, blue,
green, red
Colour selection –red, green, blue, yellow,
purple, cyan
B-
Smooth decrease of light brightness
B+
Smooth increase of light brightness
S-
Decrease speed of dynamics modes
S+
Increase speed of dynamics modes
Zone selection
Select zone to control
Zone indicator
light
Indicates controlled zone (all zones)
Key
Function
ON
Turns ON selected zone (all zones together)
OFF
Turns OFF selected zone (all zones together)
Color ring
Colour selection ring
M
Eight working modes
Turns ON/OFF white colour
Smooth decrease of white colour brightness
Smooth increase of white colour brightness
B-
Smooth decrease of RGB colours brightness
B+
Smooth increase of RGB colours brightness
S-
Decrease speed of dynamics modes
S+
Increase speed of dynamics modes
Zone selection
Select zone to control
Zone indicator
light
Indicates controlled zone (all zones)
