UMAGE SWAG KIT User manual
SWAG KIT
textile cord set |user guide
WITH LOVE FROM COPENHAGEN
At UMAGE, our designers take inspiration from the dis-
tinct nature of the Nordic landscape to create unique
designs related to the way we live in an urban setting.
Influenced by the design language, colours and materials
found around us in Scandinavia, we create a collection
that is rooted in our home but designed for everyone.
SAFETY PROCEDURES
Read and keep these instructions for
future reference
• This product is NOT a children’s toy and should
NOT be used in any other manner than described
throughout this user guide.
• Alwaysturnelectricalpoweroattheelectric-
al service panel of the household before hand-
ling electrical wires. Keep electrical power
turnedothroughouttheentireinstallation
procedure.
• NEVER touch the light bulb immediately
afterthelighthasbeenturnedo.Bewareof
possiblescalding!Letthelightbulbcoolo
sucientlybeforechangingthebulb.
• ONLYusethisproductwherethesameo-
cial electrical and technical parameters, as
described, exists!
• This product is for indoor use ONLY, excluding
any wet areas.
• DoNOTinstallthisproductnearammableor
heat-sensitive objects.
• Do NOT try to repair the product if any of the
electrical or mechanical components are in any
way broken, not as expected, or malfunctioning.
Pleasecontactaqualiedelectrician.
WARNING
Ignoring any of the Safety Instructions, or
deviating from any of the steps in either the
Installation-, the Maintenance- or the Suitable
LampShadesectionmayresultinariskofre
or electric shock. You are advised to contact a
qualiedelectricianfortheseprocedures.
INSTALLATION
1. 1x A – Swag kit
2xB–Ceilinghook
2x C – Cord holder bracket
2. Screw ceiling hooks into ceiling, making sure
the thread is completely inside the ceiling. Use
proper ceiling anchors, if needed (anchors not
included).Dierenttypesofceilingsrequire
dierenttypesofanchors.
NOTE: Ensure the ceiling hook is placed close
enough to the wall outlet to avoid tension on the
cord. Likewise, make sure the ceiling hooks are
close enough to each other to avoid tension on
the cord. Take the cord holder bracket and guide
the cord through it as shown (1).
Conrmthecordisproperlysecuredinsidethe
bracket before hanging it onto the ceiling hook.
The height of the lamp holder can be adjusted
by repositioning the cord on the cord holder
brackets.
3. If desired, fasten a suitable lamp shade (not
included) onto the lamp holder by unscrewing
the ring from the lamp holder. Mount the lamp
shade onto the lamp holder, then screw the ring
back onto the lamp holder until the lamp shade
is completely fastened (2).
NOTE: Always refer to the lamp shade manual
when installing a lamp shade. See last section
of the user guide for suitable lamp shade re-
quirements.
Install the appropriate bulb as indicated on the
label on the lamp holder for maximum wattage.
Neverputyourngersintoalivelampholder.
4. When the lamp shade and light bulb are properly
installed, turn the power on.
MAINTENANCE
• Alwaysturnelectricalpowerobeforecleaning
the product or changing the bulb.
• Cleaning should be done with dry cloth. Avoid
using any form of moisture, solvents and
chemicals. when cleaning the product.
• NEVER touch the light bulb immediately after
thelighthasbeenturnedo.Bewareofpossible
scalding!Letthelightbulbcoolosuciently
before changing the bulb.
• Avoid tension on the textile cord while handling
the product.
SUITABLELAMPSHADES
• The diameter of the lamp shade should NOT
exceed 15.75 in (400 mm).
• The lamp shade should have openings in both top
and bottom to facilitate heat dissipation.
• The minimum diameter of open area of both top
and bottom of the lamp shade should NOT be
less than 4 in (100 mm); The open area in both
top and bottom of the lamp shade is at least 3 in2
(19.3 cm2).
• The weight of the lamp shade should NOT exceed
5 lb (2.3 kg).
Model no.: 4009 or 4010
Rating parameter: 120V, 60HZ, AC ONLY
Lamp holder: E26 / TYPE A
Find assembly videos by using the QR code or by
going online at our website
umage.com/instructions
ASSEMBLY GUIDE
A x 1 pc.
C x 2 pcs.
B x 2 pcs.
2x
ACORN
black | polished brass
GET THE FREE UMAGE APP
Preview our entire collection in
your own home – before you buy
Imagine an UMAGE lamp or
furniture piece in your home. Is it
the right design, size and colour?
We made it easier for you to nd
the perfect UMAGE design. Just
download our free UMAGE Unfold
at Home app from the App Store
or Play Store, and see how our
designs will look in your home!
191010
