UMAY U11 User manual

1
TREADMILL USER’S MANUAL
CAUTION
Read all precautions
and instructions in this
manual before using
this equipment.
Keep this manual for
future reference.
MODEL:U11

2
Contents
1. IMPORTANT PRECAUTIONS..................................(1)
2. MAIN TECHNICAL FEATURES ………...………………(3)
3. ASSEMBLY…………...……………………………....(4)
4. WORKOUT GUIDELINES ……………………...........(7)
5. TREADMILL OPERATION………….…..............….(8)
6. MAINTENANCE………………………………...….. (9)
7. RECYCLING INFORM.........……………..…….(12)
8. WARRANTY…………………………………………(13)

3
1 .IMPORTANT PRECAUTIONS
In order to decrease the risk of suffering severe injuries, read carefully all the
important instructions and warnings regarding the use of a treadmill before using it.
UMAY doesn’t take any responsibility for personal injuries or property damages
resulting from the use of this product.
1-Before starting any workout program, consult your doctor. It’s specially important
for people older than 35 years old, people with health problem and pregnant women.
2-The owner must ensure that all users are correctly informed about the warnings.
3-Use the equipment as explained in the instructions manual.
4-Keep the equipment in an enclosed area, away from dust or humidity. Don’t
store it in a garage, indoor backyard or near the water. Humidity, dust and water
could lead to a malfunction of the equipment, annulling its guarantee.
5-Place the unit on a flat surface. If the surface is uneven, the proper functioning could
be affected. Some models include levelers or leveling threads on the back of the legs to
aid in leveling. Please read the manual to verify if your unit is provided with one of
them.
6-The unit must be placed in a ventilated area. Don’t use it in places with sprays or
with oxygen dispenser. The air you breath may be affected and cause an accident.
7-Keep children younger than 12 years old and pets away from the equipment. Keep
MINIMUN
USER
HEIGHT
140 cm
MAX
USER
WEIGHT
100 kg.
WARNING:
A CORRECT LUBRICATION OF THE TREADMILL WITH SILICON OIL OR TEFLON IS REALLY
IMPORTANT. THIS LUBRICATION MUST BE PERFORMED REGULARLY DEPENDING ON EACH
PERSON, EVEN BEFORE ITS FIRST USE.
YOU MUST PRESERVE THE ORIGINAL PACKAGING WITH ITS PROTECTIONS, PURCHASE
RECEIPT, MANUAL AND COMPONENTS DURING THE GUARANTEE PERIOD.

4
the security distance.
8-Check in the manual the maximum weight your equipment can support. An
excessive weight could lead to a malfunction in the operating system, which
won’t be covered by the guarantee.
9-Wear suitable clothes and shoes. Do not use loose clothe that may get hooked.
10-If your equipment is working through a power supply: make sure that the power
cord and plug are in good conditions. Carry out the connection only when the circuit
has ground connection, otherwise it could cause damages on the equipment or in the
property which the guarantee won’t cover. Power cords must be away from hot
surfaces.
11-If it is a battery-powered unit: check and make sure that they are charged enough
so the display will fully function.
12-If your equipment is provided with a security key, please understand the produce
before using it. The security key has a magnet which must be put in the display. At the
end of the lace there is a clamp which should be attached to the clothes.The treadmill
will start working only if the key is placed in the display.THIS IS ESSENTIAL.
13-If your unit works thanks to a power supply: don’t put it into operation while you
are on the belt. The motor would be unnecessarily loaded. The right way is placing
yourself with open legs, each one on a side of the belt and sit up once it is ongoing.
14-If your unit works with an electric supply: check the speed it can reach, for your
security. The best is to adjust gradually the speed in order to avoid sudden changes.
15-If your unit works through an electric supply: never leave the machine
unattended while it’s working. Take the security key off, turn the “on“ button
into “off“ and unplug the power cord.
16-If your equipment is provided with a pulse sensor, you may know it isn’t a medical
instrument. It’s designed as a help for the workout and determines the tendencies of
heart rates. There are some factors which could affect the accuracy of the heart rate
interpretations, for example the movements of the user.
17- Machines don’t take too much space as they can be folded. Once folded, make sure
that all is well assembled to the locking system, either if it has a lock or an hydraulic
engine. Don’t try to move it or raise unless you are insured. Should any damage happen
being the machine uninsured, it won’t be covered by the guarantee.
18-Check and tighten all screws on a regular basis, because due to vibrations
screws and nuts tend to loosen. Damages caused by a lack of maintenance won’t
be covered by the guarantee.
19-A correct lubrication of the treadmill with silicon oil or Teflon is REALLY
IMPORTANT. This lubrication must be performed regularly depending on each person,
even before its first use.The lubrication must be carried out this way: disconnect the
equipment of the electricity supply (in case you have one), pull up the tapestry from
the side with one hand and spread the oil on the board. Please repeat this procedure
from the other lateral side. Connect the equipment to the power supply (in case you
have one) and turn the “on” button (red button) into the correct position (I), insert the
security key and let the treadmill work for several minutes without any weight on it.
Repeat this action on a regular basis.

5
20-Two people will be required to take the unit from the package. Otherwise, the
damages caused in this moment won't be covered by the guarantee.
21-Don't let any object fall into the grooves.
22-If the unit works through a power cord: unplug always the power cord before
cleaning it, after the workout and before performing any maintenance duty.
23-This unit is designed for a domestic purpose and in an interior place, not for
business environment or outside.
24-Do a workout with stretches before and after the sessions, you will avoid injuries.
25-Drink water before, during and after the workout.
26-If you start feeling pain or dizziness while training: STOP IMMEDIATELY.
27-YOU MUST PRESERVE THE ORIGINAL PACKAGING WITH ITS PROTECTIONS,
MANUAL AND COMPONENTS DURING THE GUARANTEE PERIOD.
28-The accessories can be different to the other models.
29-This electronic product can't be thrown under any circumstances into the
municipal rubbish bins. With the aim of preserving the environment, this product
must be recycled according to the applicable law of your country. Please contact your
town council to know more about this procedure.
30-Should you need technical assistance or advise with the installation of pieces, You
can get in touch with us.
YOU MUST KEEP THE PURCHASE RECEIPT IN ORDER TO HAVE ACCESS TO THIS SERVICE
KEEP THESE ADVISES FOR FUTURE REFERENCES
2.MAIN TECHNICAL FEATURES
IPAD HOLDER
MOTOR COVER
RUNNING BELT
END CAP
SIDE STRIP

6
3.ASSEMBLY
STEP 1
1. Carry out the machine from the package by two persons and place it lightly on flat
floor, and put other fittings beside the machine.
2. Open the folding handle in the direction shown in Figure A, and the lower ends of
the column pipe will naturally open to both sides.
3. Lift the column tube to the upper point in the direction shown in figure B.
Input Voltage
110V±10%
Frequency
50/60 HZ
Running area
1100X410mm
Function
Remote Controller,Bluetooth APP
Speed Range
1.0-12KM/H
Max user weight
100kg
Power
2.0HP
No.
Fittings
Qty
1
Screw
ST4*16
2
2
Screw
M8*50
4
3
Flat
4
4
14-15mm wrench
2
5
Silicone oil
1
6
5mm wrench
1
7
6mm wrench
1
8
Multi- wrench
1
9
Safe lock
1
10
Ipad holder
1
11
Foam handrail R/L
2
NOTICE:ASSEMBLY REQUIRES TWO PERSONS

7
STEP 2
1. Press down the folding handle to lock the column pipe in the direction shown in
Fig. C.
2. Fix the iPad holder on the lower cover of the electronic watch with 2 ST4*16 cross
countersunk head screws.

8
STEP 3
1. Cut out two square silica gel plugs as shown in the figure
2. Insert the left and right handrails into the corresponding positions respectively,
and put 2 M8*50 semicircle head hexagonal socket screws through the column pipe
respectively, and lock the 5mm hexagonal socket wrench inside the screw package
into the corresponding screw hole, and then put the square silicone plug back into
the front hole.
(Note: If it is difficult for the half-round head screw and the hexagonal socket screw
to pass through, you can use the 6mm hexagonal socket wrench in the part package
to pass through the column pipe to connect the handrail for positioning, and then
insert the half-round head screw and the hexagonal socket screw.)

9
STEP 4
Put the safety lock, open the power switch can be started.
4.WORKOUT GUIDELINES
BEWARE: Before starting to use this or any exercise programs, consult your doctor. This is specially
important for people older than 35 years old, or for people with health problems.
If your equipment is provided with a pulse sensor, you must keep in mind this isn’t a medical instrument.
Several factors can vary the accuracy of the heart rate interpretations. The pulse sensor is just a help for
the work outs, determining the general tendency of the heart rate.
PROGRAMM WITH WARM UP WORKOUTS:
WARM UP: Start stretching and slightly activating the muscles between 5 and 10 minutes. The warm up will
increase your corporal temperature, your heart rate and your blood flow, making you ready for the

10
workouts.
WORKOUT FOCUSED ON THE TRAINING AREA: Do some exercises during 20-30
minutes with your heart rate (don’t maintain your heart rate more than 20 minutes during the
first weeks of the exercise program). Breath constantly and deeply during the workout (never
hold your breath).
COOL DOWN: Finish with stretching exercises during 5-10 minutes. Stretching
increases the flexibility of your muscles and help you to avoid injuries after the workouts.
FREQUENCY OF THE WORKOUT: In order to be fit or improve your shape, complete three workout
sessions each week, with a rest day between the workouts. After some moths of regular training, you will
be able of completing up to five workouts a week.
5.TREADMILL OPERATION
5.1. Interface is introduced
Digital tube window
In standby mode, the digital tube displays the time, and the LED light of the time is
on.
In operation mode, the digital tube displays "time -- distance -- calorie -- speed" in
turn, and the corresponding LED light is on, and the display is switched every 5S.
Buttons
A. 2 speed buttons: speed + and speed -
B. 1 start button
C. 1 stop button
D. Speed shortcuts
Specification
A. Max speed 12Km.
B. Longest exercise time in time mode: 99 minutes.
C. Longest exercise distance in distance mode: 99 Km.
D. Biggest calorie figure in calorie mode: 990 Cal.
5.2. Operating Instructions
Standby mode
In standby mode, press Start to Start the treadmill.

11
operational mode
1. In running mode, press the speed shortcut key or the speed step key to adjust the
speed of the treadmill to the target speed. Long press the speed step key to quickly
change the speed.
2.When the treadmill is in operation, press STOP at any time to Stop the treadmill.
3. The maximum running time of the treadmill is 100 minutes each time. After 100
minutes of continuous running, the treadmill will stop automatically. You can Start
the treadmill again by clicking Start.
4. Through the mobile APP (SPAX), the treadmill can be connected to Bluetooth to
obtain the treadmill movement data. If the APP supports the operation interface, the
treadmill can be controlled through the mobile APP.
Sleep mode
In standby mode, the treadmill enters sleep mode without any button operation
within 10 minutes, and the treadmill can be awakened by pressing any button.
6. MAINTENANCE
This product must be earthed. If the power cord is
damaged,it must be replaced with a manufacturer
recommended power cord.
DO NOT TANGLE THE POWER CORD
REGULAR MAINTENANCE OF THE TREADMILL
STORAGE: Keep your equipment in a enclosed place, away from dust
or humidity. Don’t store it neither in a garage or in a indoor backyard, or near

12
the water. Humidity, dust and water could damage it and have an effect on its
functioning
ELECTRIC CABLE: Make sure that the cable and plug are in perfect
conditions. Electric cables must be away from hot surfaces
SCREWS AND CONNECTING CABLES: Supervise and tighten the
screws on a regular basis, because due to the vibration the screws and nuts
tend to loosen.
LUBRICATION: After running for a period of time, the treadmill must be
configured with special silicone oil for lubrication.
Suggestion:
Do not lubricate more than what you need to. Remember: regular and reasonable
lubrication is to improve the lifespan of your treadmill.
Whether it is necessary to lubricate, make sure the
machine is switched off and unplug the electricity.
Lift the running belt, observe if there are any silicon
remaining on the running board which is under the
running belt. If it is dry, then you need to apply the lubricant.
a) The step to lubricate the running board is as follows: (see the above figure)
b) Stop the running belt and fold the treadmill.
c) Turn over the running belt at the back of the mainframe. Insert the lubricant
pot as deep as possible into the middle of the running belt. Apply the lubricant
onto the inner side of the running belt. Lubricate both sides of the running belt.
After the lubrication is completed, start the machine at 1km/h to let the running
belt bring silicon all over the board.
ALIGN AND TIGHTEN THE BELT OF THE TREADMILL
ALIGN THE BELT: Due to its use, the belt can
move off center. If the belt has moved to the left, start
treadmill and increase the speed to 3MPH .Use the 5mm
Wrench to turn the fixed left bolt clockwise or turn the
< 3 hours/week
2 months
4 – 7 hours/week
1 month
> 8 hours/week
15 days

13
fixed right bolt counterclockwise. Don’t tighten the belt
too much in order to be able to walk. Repeat this
procedure until the belt is properly aligned.
TIGHTEN THE BELT: (if the belt slips on the
treadmill when walking). Start treadmill and increase the
speed to 3MPH.Using the 5mm Wrench , turn both bolts
1/4 clockwise. If the belt is properly tight to walk, you
must be able to pull up each side of the belt 5 or 7 cm off
the platform. Be careful and maintain the belt aligned.
Repeat this procedure until the belt is properly
tightened.
TIGHTEN THE DRIVE BELT: if the drive belt
becomes loose after using for a period of time,you need to:
(1) Open the motor cover .
(2) Use the 5mm wrench to turn the adjusting
bolt clockwise.
Repeat this procedure until the drive belt is not
slippery anymore.
如果跑带左偏,则顺时针调节左
边螺丝或逆时针调节右边螺丝
如果跑带右偏,则顺时针调节右
边螺丝或逆时针调节左边螺丝
If deviate to the right, then
adjust the screw on the right side
clockwise or the screw on the left
side anticlockwise.
If deviate to the left, then
adjust the screw on the left side
clockwise or the screw on the
right side anticlockwise.
if the running belt slips,use 6mm wrench,turn
both sides bolts 1/4 clockwise.Repeat this
procedure until the belt is properly tightened.
Adjusting bolt

14
CLEANING: Don't use abrasive products. A damp cloth is enough.
LEVELING: If your unit is provided with leveling wheels, please
adjust them in order to avoid vibrations and therefore malfunctions.
KEEP THESE MAINTENANCE ADVISES FOR FUTURE REFERENCES
7. RECYCLING INFORMATION
This electronic product must not be disposed of in municipal waste. To preserve the environment, this
product must be recycled after its useful life as required by law.
A correct lubrication of the treadmill with silicon oil or Teflon is REALLY IMPORTANT. This lubrication
MUST BE PERFORMED REGULARLY DEPENDING ON EACH PERSON, EVEN BEFORE ITS FIRST USE.
YOU MUST PRESERVE THE ORIGINAL PACKAGING WITH ITS PROTECTIONS, PURCHASE RECEIPT, MANUAL
AND COMPONENTS DURING THE GUARANTEE PERIOD

15
IX.WARRANTY
We have one year quality warranty to the products. Within the warranty
period, we provide the FREE replacement parts. If caused by incorrect
assembly, incorrect use or change of parts failures, our company takes
no responsibility. You should show our products series no. and relative
pictures or information before getting the warranty.
This treadmill is only for home use, if the problems occurred by
commercial used, our company takes no responsibility.

16
If you have any questions or problems,
please email us: [email protected]
You can also call us: [phone]
You can also contact us through Skype: [phone]
you can also leave your phone number to the same email address to consult us.
