UNAOHM FCV 5G User manual

UNAOHM S.r.l. - Via G. di Vittorio 49 - 20068 Peschiera Borro eo (MI) Italy
Tel. [phone] - Fax [phone] - Web : www.unaoh .it - E- ail : sales@unaoh .it

FCV 5G (Rev. 0) 1
1
Contents
1. WARNINGS .......................................................................................................................2
1.1. SAFETY REGULATIONS .................................................................................................2
1.2. PRECAUTIONS ................................................................................................................3
1.3. MAINTENANCE ................................................................................................................3
1.4. NOTES .............................................................................................................................3
2. INTRODUCTION ................................................................................................................4
3. USING THE CONVERTER ................................................................................................5
4. TECHNICAL DATA ............................................................................................................6
4.1 SUPPLIED ACCESSORIES ..............................................................................................7
5. WARRANTY .......................................................................................................................8
UNAOHM S.r.l. reserves the right to make changes to the described product at any time, for technical or commercial
reasons as well as for compliance with legal requirements in the various countries. For this reason the information
contained in this manual may not be up to date.

FCV 5G (Rev. 0) 2
1 . W A R N I N G S
Marking
This equipment complies with the following standards:
EMC: EN 50082-1 * EN 55011 * EN 61000-3-2 * EN 61000-3-3 * IEC 801-2 * IEC801-3 * IEC 801-4
Safety: EN61010-1
The safety standards and precautions listed below must be applied scrupulously during all phases of
use and maintenance of the unit in order to prevent damage to persons, animals and objects.
UNAOHM S.r.l. assumes no liability for any incorrect use of the instrument or any use
different than that specified.
1.1. SAFETY STANDARDS
•Power the instrument with a voltage which falls within the limits specified in the characteristics
section.
•Do not use the unit without the relative locks.
•The instrument is intended for use in covered areas. Therefore do not expose it to rain or
dripping.
•Do not use the unit in an explosive atmosphere constituted by flammable gases, vapours, smoke
and powders.
•The instrument can be used in overvoltage Category IIa and pollution grade 2.
•Do not switch on the unit immediately after moving it from a very cold room to a hot one,
in order to prevent the formation of moisture condensate.
•Do not obstruct any cooling slots and do not place the unit close to heat sources.
•Do not apply DC voltage or RF signals greater than those prescribed to the input connectors.
This symbol indicates that the instructions manual must be consulted for
additional information.
This symbol indicates parts of circuit in which dangerous voltage may be present.

FCV 5G (Rev. 0) 3
3
1.2. PRECAUTIONS
•Do not place the unit near strong magnetic or electric fields (motors, transformers, solenoid
valves, etc.)
•One of the most frequent causes for technical support intervention is due to internal short circuits
due to foreign bodies, even very small ones, which enter the unit despite all of the precautions
taken to prevent this from happening. It is therefore recommended, especially when joining
coaxial cables, not to do this in the immediate vicinity of the unit because even very small pieces
of the mesh shielding could penetrate the unit and cause occasional short circuits which are not
easily detected by technical support engineers.
1.3. MAINTENANCE
The only interventions allowed concern battery replacement
Opening the instrument and any operations must be done exclusively by qualified personnel or by
personnel with basic electro-technical and electrical safety knowledge.
•For the units equipped with a battery remember the notes included in section 1.1.
•Use suitable measures to prevent the accumulation of electrostatic charges. Do not touch circuits
inside the unit without first applying the dedicated antistatic bracelet.
•To clean the external parts:
Use soft cloths and dampen them if necessary. Do not use aggressive liquid detergents and
avoid using hydrocarbon-based substances.
Do not allow liquids or other substances to penetrate inside the unit.
1.4. NOTES
•Do not drop the unit or subject it to strong shocks. If the instrument is transported in a vehicle,
place it on a non-rigid support in order to avoid strong vibrations.
•Before using the unit carefully read the instructions contained in this user manual.
•It is strongly recommended to regularly perform (at least annually) a periodic operational test of
the instrument, accompanied by any necessary calibration operations.

FCV 5G (Rev. 0) 4
4
2.INTRODUCTION
The FCV300 frequency converter is an accessory that, when coupled with a Field Meter, allows
displaying frequencies between 3000 MHz and 4000 MHz in "Spectrum Analyser" mode included
the frequency range of 5G signal from 3600 MHz to 3800 MHz.
In the event of random signals (that is signals which are not present continuously), if the Field Meter
is equipped with a Max Hold function, it is possible to observe these as well; these types of signals
are otherwise impossible to measure given their temporal inconsistency.
The converted carrier will be displayed in IF SAT band, that is, in the frequency range between
1000 MHz and 2000 MHz.
The size and weight are very small while the power, between 13 ± 18 Volt, is applied directly on the
RF outlet connector through LNB remote power, supplied by the same Field Meter.

FCV 5G (Rev. 0) 5
5
3. USING THE CONVERTER
In practical applications, it is necessary that the input band to the converter be limited as its Local
Oscillator can create flutters that may cause unwanted "interferences" which, superimposed on the
frequency spectrum, disrupt vision and substantially alter the measurements.
Therefore it is recommended that the RF cable, antenna or satellite dish dedicated to the band you
wish to convert be carefully chosen and the use of band-stop filters is recommended to increase the
rejection of unwanted signals that fall outside of the operating band.
For some signals which are discontinuous over time it is necessary to use the Max Hold function
with which some of our Field Meters are equipped.
That said, the following is the sequence of operations for using the converter.
1. Connect an antenna able to receive the desired frequencies to the RF IN converter input.
2. Connect a coaxial cable from the output of the RF OUT converter to the RF BNC input of the
Field Meter.
3. Switch on the Field Meter to Spectrum mode and activate the Max Hold function, if present.
4. Power the converter via remote power supply (LNB)
5. Move to the " SAT " frequency. With the marker, go to a displayed carrier: to obtain the starting
valve of the original input frequency it is necessary to subtract 2000.00 MHz, which is the
frequency of the Local Oscillator, from the frequency indicated by the marker.

FCV 5G (Rev. 0) 6
6
4. TECHNICAL DATA
Input characteristics
Frequency 3000 ÷ 4000 MHz with conversion of the range
Impedance (1) 50 Ω
Dynamic - 80 Mm ÷ - 10 Mm
Input connector " N " female
Output characteristics
Frequency 1000 ÷ 2000 MHz
Impedance 75 Ω
Return loss
≥ 10 dB
Strength + 5 dBm (@ 1 dB gain compression)
Output connector BNC
Transfer
Type Conversion of single SAT bands (Down Converter)
Gain 0 dB ± 3 dB
Gain Stability ± 0.1 dB/°C (5 ÷ 40 °C)
Noise figure
≤ 15 dBm
Rejection of
interferences < 20dBµV without input
< -39 dB Carrier with single input carrier of -10dBm
Rejection of input
filter -45 dB 3000 Mhz
Characteristics of the oscillator
Frequency 2000 MHz
Precision ± 1 MHz
Power supply characteristics
With DC from the RF
connector
Via r
emote power (LNB) by RF output connector
13 ÷ 18 Volt/0.2A

FCV 5G (Rev. 0) 7
7
4.1. SUPPLIED ACCESSORIES
•"N" male adapter, female BNC
•1 BNC/BNC cable 75 Ω
•1 User manual
Environmental characteristics
Calibration temp. Room temperature of
23 °C ± 5 °C
Operating temp. From
+5 °C to + 40 °C
Rel. operating
humidity
80% for temperatures up to 31°C (with linear reduction up to 50% at 40°C)
Max. operating
altitude
2000 m
Non-operating temp.
From -10 °C to +60 °C
Non-operating
humidity Max
95 %
Mechanical characteristics
Dimensions (H x L x T) 150 x 90
x 25 mm
Weight
0.25 kg with bag
Finishing The unit is supplied in a nylon bag with an accessories compartment.

FCV 5G (Rev. 0) 2
5. WARRANTY
The instruments manufactured by us are guaranteed for twelve months from any faults attributable
to manufacturing defects or defects in the used materials.
Revision operations are carried out by Technical Support at our facility located at: UNAOHM Service
Via G. Di Vittorio N° 49 20068 Peschiera Borromeo, Italy, Tel [phone], where the units
must be sent. Shipment must be freight paid with appropriate packing preferably in the original
packaging in order to prevent damage during transportation.
In order to take advantage of the warranty a copy of the invoice or fiscal sales receipt relative to the
purchase of the instrument must be produced.
The warranty will be considered void in case of tampering, modifications or repairs carried out by
unauthorised personnel.
The power batteries and piles are not included in the warranty.
SERVICE NOT COVERED UNDER WARRANTY
We are available for our esteemed customers for the repair of instruments manufactured by us,
even after the warranty period, in order to restore equipment to its original condition (as long as it is
economically convenient).
The availability of mechanical and electronic spare parts is guaranteed for up to 5 years when the
circuits are manufactured with discreet components. In the event integrated circuits are used, the
supply of spare parts is ensured while supplies last and subject to their availability on the global
market. The repair of instruments which are no longer covered under warranty is normally carried
out against payment. Quotes must be requested upon delivery of the instrument. In the event the
quote is not accepted, the expenses sustained for its preparation shall be charged to the customer.
To avoid wasting time, it is very important that the unit be returned with its accompanying
documents complete with all data as required by law.
Use the dedicated forms in this manual or attach an accompanying letter, specifying the defect
detected, the name and telephone number of the person to be contacted for any additional
information or clarifications.
MISCELLANEOUS
The wiring diagram of the unit will not be provided (not even upon request). Any illustrations and
diagrams inserted in the brochure are purely indicative. We reserve the right to make any change
which may become necessary without updating the instruction manual.
