Unicont SPb PCH-205 User manual

Unicont SPb Ltd
Power Supply/Automatic Battery Charger
PCH-205
Technical Documentation
(205-1-27062012)
St. Petersburg
2012

Unicont SPb Ltd Technical Documentation PCH-205
Page 2
Table of Contents
1.GENERAL DATA ............................................................................................................4
2.DELIVERY SET...............................................................................................................4
3.SPECIFICATIONS ..........................................................................................................6
4.SAFETY ENGINEERING INSTRUCTIONS ...............................................................7
5.OPERATION PRINCIPLE .............................................................................................8
6.CONTROLS AND INDICATORS..................................................................................9
7.INSTALLATION AND CONNECTION......................................................................14
8.ALARM SIGNALS OF PCH-205 .................................................................................19
9.TRANSPORTATION AND STORAGE ......................................................................20
10.RECYCLING ..................................................................................................................21
11.WARRANTY ..................................................................................................................22
12.DATE OF PACKING.....................................................................................................23
13.ACCEPTANCE DETAILS ............................................................................................23
14.DATE OF COMMISSIONING .....................................................................................23

Unicont SPb Ltd Technical Documentation PCH-205
Page 3
This Operating Manual applies to the PCH-205 Power Supply/Automatic Battery
Charger.
This Manual is intended to assist in the familiarization with the design, operating
principles and procedures established for the convection heater during its intended use or
maintenance. This Manual can also be used as a source of information about сведений об
устройстве to draw up corresponding sections in the operational documentation for the
equipment, вкоторой this product may be used as its component part.
All information contained in this Manual is distributed by the company for information
purposes only. The information is subject to changes without notification to consumers; the
information may contain errors or discrepancies. The information provided may not contain
obligations on the part of Unicont SPb Ltd

Unicont SPb Ltd Technical Documentation PCH-205
Page 4
1. General data
A power Supply/Automatic Battery Charger PCH-205 (hereinafter referred to as — PS,
device) is designed to provide devices of the shipboard equipment with constant voltage 24 V.
Also, the device operates as a charging device (hereinafter referred to as — CHD) and
carries out automatic charging of storage batteries connected to it (hereinafter referred to as —
SB).
The PS is designed for operation at sea and river vessels in dry personnel facilities of
the house, superstructures or enclosed decks.
The operator’s manual (OM) describes PS design and operation principles, installation,
setting, and operation instructions.
The OM is designed for PS installation and setting specialists and PS users. To install
the PS, an appropriate electrical safety group is required.
2. Delivery Set
1. Combined power supply/charging device PCH-205 1 ps.
2. Operator’s manual 1 ps.
The following devices can be used additionally (optionally) with this product:
1. Control panel of storage batteries BCP-136
2. Alarm unit AU-106
3. Temperature sensor of storage battery DTS-135
The PS is delivered in the following configurations (see Table 1):
Table 1. Device Configurations
Configuration Control and Management Functions
Base
(see Figure 1)
-LED indication of an operation mode
-Integrated audio and light alarm
-Alarm signal acknowledgement button
With integrated
control
(see Figure 2)
-Button keyboard of SB current and charging voltage control
-Digital indicator of SB current and charging voltage
-LED indication of an operation mode
-Integrated audio and light alarm
-Alarm signal acknowledgement button
With remote
control
(see Figure 3)
-Remote unit of set point value input of SB charge (with SB control
panel ВСР-136)
-Digital indicator of SB current and charging voltage
-LED indication of an operation mode
-Integrated audio and light alarm
-Remote audio and light alarm (as a part of SB control panel ВСР-136)
-Alarm signal acknowledgement button

Unicont SPb Ltd Technical Documentation PCH-205
Page 5
Figure 1. Base Configuration PCH-205
Figure 2. Configuration PCH-205 with Integrated Control
Figure 3. Configuration PCH-205 with Remote Control
