Unicorn Computer ENDAT-4946i/M User manual

User’s Manual I
ENDAT-4946i/M
User’s Manual
Rev. A6
PCB version: A6 and later
Jan.4.2010

II The ENDAT-4946i/M System Board
Copyright Notice
The content of this manual has been checked for accuracy. The manufacturer
assumes no responsibility for any inaccuracies that may be contained in this
manual. The manufacturer reserves the right to make improvements or
modification to this document and/or the product at any time without prior
notice. No part of this document may be reproduced, transmitted, photocopied or
translated into any language, in any form or by any means, electronic, mechanical,
magnetic, optical or chemical, without the prior written permission of the
manufacturer.
Intel® Core™ Solo, Core™ Duo and Core™2 Duo mobile processor is registered
trademark of Intel Incorporation
Multiscan is a trademark of Sony Corp of America
IBM, EGA, VGA, PC/XT, PC/AT, OS/2 and PS/2 are registered trademarks of
International Business Machines Corporation
Plug and Play is registered trademarks of Intel Corporation
Microsoft, Windows and MS-DOS are trademarks of Microsoft Corporation
Award is a trademark of Phoenix Software Inc.
PCI is a registered trademark of PCI Special Interest Group
Other product names mentioned herein are used for identification purpose only
and may be trademarks and/or registered trademarks of their respective
companies.
Installation Notice
The manufacturer recommends using a grounded plug to ensure proper
motherboard operation. Care should be used in proper conjunction with a
grounded power receptacle to avoid possible electrical shock. All integrated
circuits on this motherboard are sensitive to static electricity. To avoid damaging
components from electrostatic discharge, please do not remove the board from the
anti-static packing before discharging any static electricity to your body, by wearing
a wrist-grounding strap. The manufacturer is not responsible for any damage to the
motherboard due to improper operation.

User’s Manual III
Specification:
Model ENDAT-4946i/M
Form Factor Mini-ITX 170 mm x 170 mm (6.69”x6.69”)
System Chipset INTEL® 945GM + INTEL® ICH7
ENDAT-4946M: 533/667 FSB with 478 pin Intel® Celeron® M 423
processor
CPU Supporting ENDAT-4946i: 533/667 FSB with 478 pin Intel® Core™ Solo, Intel®
Core™ Duo and Intel® Core™2 Duo processor
Memory 1 x 240 pin DDR2 socket supports DDR2 533/667 up to 2GB
Ethernet Realtek 8111B PCIE Gigabit LAN
VGA INTEL® GMA950 Graphic Controller with DVMT up to 224MB(max)
LCD Interface Onboard LVDS support 18/24/36/48bit Single/Dual Channels via internal
box header (optional)
DVI Interface Onboard DVI output via internal pin header (optional)
Display ratio 4:3 and 16:9
Serial / Parallel 4 Serial Port w/+5V, +12V Power Selector / 1 Parallel port
Watchdog Timer Winbond 83627THG on-chip support 1 to 255 seconds/minutes
IDE Connector 1 x 40pin IDE connector support UDMA 33/66/100
SATA Connector 2 ports 300MHz Serial ATA Device
AUDIO On-board AC’97 with 1.2W amplifier
Expansion Slot One PCI slot with PCI 2.2 compliance
PS/2 Keyboard / Mouse Connector
2 x USB (2.0) + RJ-45 Connector w/LED indicator
D-sub Connector for COM 1, 2, 3 with POWER
1 x 25 Pins D-Sub Connector (LPT)
1 D-Sub Connector (VGA)
I/O Port
Internal pin header: KB, MS, USB (2.0) x4, AUX/CD-IN, SPDIF IN/OUT,
RF MIC IN, IR
Digital IO 8 bit input and 8 bit output (TTL level) by pin header
RS-422/485 Via COM2 (Optional)
USB Port 6 x USB2.0 onboard
Power Supply ATX power supply

IV The ENDAT-4946i/M System Board
TABLE OF CONTENTS
CHAPTER 1. INTRODUCTION.......................................................1
1-1. FEATURES..............................................................................................2
1-2. UNPACKING............................................................................................3
1-3. ELECTROSTATIC DISCHARGE PRECAUTIONS ...................................3
1-4. MOTHERBOARD LAYOUT......................................................................4
CHAPTER 2. SETTING UP THE MOTHERBOARD.......................5
2-1. JUMPERS AND CONNECTORS..............................................................5
2-2. INSTALLING MEMORY..........................................................................15
2-3. SHARED VGA MEMORY .......................................................................15
2-4. ASSIGNING IRQs FOR EXPANSION CARDS .......................................15
2-5. WATCHDOG TIMER…………………………………………………………. 16
2-6. DIGITAL I/O…………………………………………………………...………. 18
CHAPTER 3. AWARD BIOS SETUP ............................................20
3-1. STANDARD CMOS FEATURES.............................................................21
3-2. ADVANCED BIOS FEATURES...............................................................22
3-3. ADVANCED CHIPSET FEATURES........................................................24
3-4. INTEGRATED PERIPHERALS...............................................................25
3-5. POWER MANAGEMENT SETUP...........................................................39
3-6. PnP/PCI CONFIGURATIONS.................................................................31
3-7. PC HEALTH STATUS.............................................................................32

User’s Manual V
CHPATER 4. VGA, LCD, FEATURE.............................................33
4-1. VGA FEATURE....................................................................................... 33
4-2. LVDS PANEL FEATURE......................................................................... 34
4-3. DRIVER UTILITY INSTALLATION GUIDE.............................................. 35
APPENDIX A: FLASH MEMORY UTILITY...................................36
APPENDIX B: CONNECTOR PIN ASSIGNMENT .......................37
APPENDIX C: LIMITED WARRANTY..........................................39

User’s Manual 1
Chapter 1. Introduction
ENDAT-4946i/M supports high performance processor of Intel® Celeron® M 423
(for ENDAT-4946M), Intel® Core™ Solo, Intel® Core™ Duo and Intel® Core™2
Duo processor (for ENDAT-4946i) with 533 and 667 Front Side Bus. It also
supports high speed DDR-2 memory with 64-bit wide interfaces with non-ECC
DIMM (up to 2GB). Only Double-Data-Rate Two Synchronous Dynamic Random
Access Memory is supported and the speed of memory can be 533 and 667 MHz.
ENDAT-4946i/M provides an integrated graphics (Intel® Graphics Media
Accelerator 950) accelerator delivering cost competitive 3D, 2D, and video
capabilities.
ENDAT-4946i/M video engines support video conferencing and other video
applications. Instead of a dedicated local graphics memory interface,
ENDAT-4946i/M uses a UMA configuration for optimal memory utilization and
performance that deliver 3D graphics with sharp images, fast rendering, smooth
motion and extreme detail.
ENDAT-4946i/M contains one integrated Serial ATA host controllers capable of
independent DMA operation on two ports. The SATA controllers are completely
software transparent with the IDE interface, while providing a lower pin count and
higher performance. The data transfer rate is up to 300 MB/s.
ENDAT-4946i/M is an ideal model for various kind of application:
-POS system
-KIOSK
-Interactive system
-Airport Terminal Controller
-Industrial controller
-Digital entertainment
-Embedded system equipment

2 The ENDAT-4946i/M System Board
1-1.Features
Basic Feature:
Board format: Mini-ITX (170mm x 170 mm)
Supports Socket 478 CPU (FSB 400/533/667 MHz)
Digital I/O: 8 bits in and 8 bits out (5V)
Supports DDR-2 533/667 SDRAM up to 2GB
Serial ATA connector x 2
Enhance IDE connector x 1
Multiple I/O ports: COM port x 4; USB (2.0) x 6
All COM ports with +5V, +12V power selector
Watchdog Timer
Realtek Gigabit LAN and Audio function onboard
Optional features:
On board chip provides LVDS interface (18/24/36/48 bit, single/dual
channels)
DVI Output interface
RS 422/485 via COM 2
Barebones system: niche into Unicorn U-6000 & U-8000 Chassis
Full Software Support:
Drivers for major operating systems and APIs: Windows 2000,
Windows XP, Direct3D, DirectDraw and DirectShow, OpenGL ICD
and DXVA for Windows 2000 and Windows XP

User’s Manual 3
1-2Unpacking
The motherboard comes securely packaged in a sturdy cardboard shipping carton.
In addition to the User’s Manual, the motherboard package includes the following
items:
ENDAT-4946i/M System Board
HDD / IO Cables
LCD cable (Optional)
CDROM Driver includes: Drivers for Windows 2000, XP and AMI / AWARD FLASH
ROM utilities.
Driver utilities for on-board VGA drivers, LAN adapter
If any of these items are missing or damage, please contact the dealer from whom
you purchase the motherboard. Save the shipping material and carton in the event
that you want to ship or store the board in the future.
Note: Please leave the motherboard in its original package until you are ready to
install it!
1-3. Electrostatic Discharge Precautions
Make sure you properly ground yourself before handling the motherboard, or other
system components. Electrostatic discharge can easily damage the components.
Note: You must take special precaution when handling the motherboard in dry or
air-conditioned environments.

4 The ENDAT-4946i/M System Board
1-4. Motherboard Layout

User’s Manual 5
Chapter 2. Setting up the Motherboard
2-1. Jumpers And Connectors
Jumpers/Connectors Overview:
Function Jumpers/Connectors
Cooling Fan Connector FAN1, FAN2
ATX Power Supply Connector ATXPWR
DVI Output Pin Header DVI1, DVI2
LCD Panel Connector LVDS1
LCD Voltage Selector JP2
Clear CMOS JBAT1
PS/2 Mouse/KB Pin Header J1
PS/2 Mouse/KB CN1
USB Port CN8, J8, J9
40-Pin IDE Connector IDE1
SATA 1, SATA2 SATA 1, SATA2
Header for Case Panel JP6
HDD LED JP6: Pin 1(-), Pin 2(+)
External Speaker JP6: Pin 3(-), Pin 6(+)
Buzzer On/Off JP6: Pin 4, Pin 5
Hardware Reset Switch JP6: Pin 7, Pin 8
ATX Power Supply On/Off Switch JP6: Pin 9, Pin 10
Power LED JP6: Pin 11(-), Pin 12(+)
WDT Function Enable/Disable JP6: Pin 13, Pin 14
External Power Good JP6: Pin 15, Pin 16
Internal Power Good JP6: Pin 16, Pin 17
DDR2 RAM Socket DIMM1
CRT Output CN4
IR Pin Header J3
COM1/2/3/4 Voltage Selector JP5
COM1 Connector CN2
COM2 & COM3 Connector CN5
LPT1 CN3
LAN Connector CN8
AC’97 Speaker Output CN9
AC’97’ Speaker Output, MIC-In Pin Header J5

6 The ENDAT-4946i/M System Board
Function Jumpers/Connectors
5.1Ch Speaker output Pin Header J6
Line-In, CD-In Pin Header J7
COM2 Box Header CN7
COM4 Box Header CN6
RS232 / 422 / 485 Selector for COM2 JP3, JP4
DIGITAL I/O Pin Header J2
SPDIF Pin Header J10
Please double-check the insertion and orientation of the LCD cable
before applying power. Improper installation will result in permanent
damage LCD panel.
Part 1: Onboard Jumpers
JP2: LCD Voltage Selector (2.0mm)
LCD power JP2 (2.54mm)
Pin-1, 2* +3.3V
Pin-3, 4 +5V
Pin-5, 6 +12V
Caution: Improper setting will damage LCD panel.
JP3, JP4: RS232 / 422 / 485 Selector for COM2 (2.0mm)
TYPE JP3 (3x4/2mm) JP4 (2x3/2mm)
RS-232 * 1-2, 4-5, 7-8, 10-11 1-2
RS-422 2-3, 5-6, 8-9, 11-12 3-4
RS-485 2-3, 5-6, 8-9, 11-12 5-6
JP5: COM1/2/3/4 Voltage Selector (2.0mm)
Voltage COM1 COM2 COM3 COM4
+12V 1-2 7-8 13-14 19-20
R.I* 3-4 9-10 15-16 21-22
+5V 5-6 11-12 17-18 23-24

User’s Manual 7
JP6: Header for Case Panel (2.54mm)
Pin No. Function
1(-), 2(+) IDE LED
3(-), 6(+) External Speaker
4,5 Buzzer On/Off
7,8 Hardware Reset Switch
9,10 ATX Power On/Off
11(-), 12(+) Power LED
13,14 Close: Enable WDT function
15,16 External Power Good
16,17 Internal Power Good(Default)
Part 2: Onboard Connectors
J1: PS/2 Keyboard / Mouse Pin Header Connector (2.54mm)
Pin No. Function Pin No. Function
1 KB Data 2 MS Data
3 KEY 4 KEY
5 GND 6 GND
7 +5V(DC) 8 +5V(DC)
9 KB_CLK 10 MS_CLK
J2: Digital I/O Pin Header (2.54mm)
Pin No. Function Pin No. Function
1 +5V 2 +5V
3 DIO-O0 4 DIO-I0
5 DIO-O1 6 DIO-I1
7 DIO-O2 8 DIO-I2
9 DIO-O3 10 DIO-I3
11 DIO-O4 12 DIO-I4
13 DIO-O5 14 DIO-I5
15 GND 16 GND
17 DIO-O6 18 DIO-I6
19 DIO-O7 20 DIO-I7
21 +3.3V 22 +3.3V

8 The ENDAT-4946i/M System Board
J3: IR Pin Header (2.54mm)
Pin No. Function Pin No. Function
1 VCC 4 GND
2 N.C 5 IRTX
3 IRRX
J5: AC’97 Speaker Output, MIC-In Pin Header (2.54mm)
Pin No. Function Pin No. Function
1 Speaker Output–RIGHT 2 Alternative LFE–Output
3 GND 4 GND
5 GND 6 GND
7 Speaker Output–LEFT 8 First MIC Input/CEN–Output
J6: 5.1Ch Speaker output Pin Header (2.54mm)
Pin No. Function Pin No. Function
1 Surround Output – LEFT 2 Center Output
3 GND 4 GND
5 GND 6 GND
7 Surround Output – RIGHT 8 Low Frequency Effect Output
J7: Line-In, CD-In Pin Header (2.54mm)
Pin No. Function Pin No. Function
1 Line Input – RIGHT 2 CD Input – RIGHT
3 GND 4 GND
5 GND 6 GND
7 Line Input – LEFT 8 CD Input – LEFT
J8, J9: USB Port Pin Header (2.54mm)
Pin No. Function Pin No. Function
1 USB_VCC 2 USB_VCC
3 USBD 2/4- 4 USBD 3/5-
5 USBD 2/4+ 6 USBD 3/5+
7 USB_GND 8 USB_GND
9 USB_GND 10 USB_GND

User’s Manual 9
J10: SPDIF Pin Header (2.54mm)
Pin No. Function Pin No. Function
1 +5V 4 GND
2 KEY 5 SPDIF-IN
3 SPDIF-OUT
ATXPWR: ATX Power Supply Connector (3.96mm)
Pin No. Function Pin No. Function
1 +3.3V 2 +3.3V
3 +3.3V 4 -12V
5 GND 6 GND
7 +5V 8 PS-ON
9 GND 10 GND
11 +5V 12 GND
13 GND 14 GND
15 POWER OK 16 -5V
17 5V_SB 18 +5V
19 +12V 20 +5V
FAN1, FAN2: Cooling Fan Connector
Pin No. Function
1 Sensor Pin.
2 +12V
3 GND
CN3: Printer (LPT1) Connector
Pin No. Function Pin No. Function
1 STB# 10 ACK#
2 PD0 11 BUSY
3 PD1 12 PE
4 PD2 13 SLCT
5 PD3 14 AFD#
6 PD4 15 ERR#
7 PD5 16 INIT#
8 PD6 17 SLIN#
9 PD7 18-25 GND

10 The ENDAT-4946i/M System Board
CN4: CRT Connector
Pin No. Function Pin No. Function
1 RED 9 n/c / +5V
2 GREEN 10 GND
3 BLUE 11 n/c
4 n/c 12 DDC DAT
5 GND 13 H-Sync
6 GND 14 V-Sync
7 GND 15 DDC CLK
8 GND
CN6: COM4 Pin Header (RS-232)
Pin No. Function Pin No. Function
1 DCD 6 DSR
2 RXD 7 RTS
3 TXD 8 CTS
4 DTR 9 RI
5 GND 10 n/c
D-SUB Type Connector for COM2 port (RS-4224 Wire)
Pin No. Function Pin No. Function
1 –TXD 6 NA
2 +RXD 7 NA
3 +TXD 8 NA
4 NA 9 –RXD
5 NA
D-SUB Type Connector for COM2 port (RS-4852 Wire)
Pin No. Function Pin No. Function
1 Data – 6 NA
2 NA 7 NA
3 Data + 8 NA
4 NA 9 NA
5 NA

User’s Manual 11
D-SUB Type Connector for COM port (RS-232)
Pin No. Function Pin No. Function
1 Data – 6 NA
2 NA 7 NA
3 Data + 8 NA
4 NA 9 NA
5 NA
DVI1: DVI-DIGITAL Output Pin Header (2.0mm)
Pin No. Function Pin No. Function
1 TD2- 2 +5V
3 TD2+ 4 KEY
5 EDID DATA 6 HPDET
7 EDID CLOCK 8 TD0-
9 TD1- 10 TD0+
11 TD1 12 LVDS_GND
13 TLC- 14 TLC+
DVI2: DVI-ANALOG Output Pin Header (2.0mm)
Pin No. Function Pin No. Function
1 CRT_RED 2 VGAVSYNC
3 CRT_GREEN 4 GND_CRT
5 CRT_BLUE 6 VGAHSYNC
7 n/c 8 CRT-Pin-6

12 The ENDAT-4946i/M System Board
IDE1: IDE Box Header (2x20 with 2.54mm)
Pin No. Function Pin No. Function
1 IDE Reset# 2 GND
3 IDE data7 4 IDE data8
5 IDE data6 6 IDE data9
7 IDE data5 8 IDE data10
9 IDE data4 10 IDE data11
11 IDE data3 12 IDE data12
13 IDE data2 14 IDE data13
15 IDE data1 16 IDE data14
17 IDE data0 18 IDE data15
19 GND 20 N.C.
21 IDE REQ 22 GND
23 IDE IOW# 24 GND
25 IDE IOR# 26 GND
27 IDE Ready 28 GND
29 IDE ACK# 30 GND
31 IDE IRQ 32 N.C.
33 IDE A1 34 P66DET
35 IDE A0 36 IDE A2
37 IDECS1# 38 IDESC3#
39 HDLED# 40 GND

User’s Manual 13
LVDS1: Dual Channel of LVDS I/F (2.0mm)
Pin No. Function Pin No. Function
1 VBL (+12V) 2 VBL (+12V)
3 GND 4 GND
5 DISP.ON/OFF 6 GND
7 LVDD 8 LVDD
9 GND 10 GND
11 RxO0+ 12 RxO0-
13 RxO1+ 14 RxO1-
15 RxO2+ 16 RxO2-
17 RxO3+ 18 RxO3-
19 RxOC+ 20 RxOC-
21 GND 22 KEY
23 RxE0+ 24 RxE0-
25 RxE1+ 26 RxE1-
27 RxE2+ 28 RxE2-
29 RxE3+ 30 RxE3-
31 RxEC+ 32 RxEC-
33 LVDD 34 LVDD
35 GND 36 GND
37 GND 38 GND
39 VBL (+12V) 40 VBL (+12V)
Please make sure the Pin 1 location before inserting the LCD connector.

14 The ENDAT-4946i/M System Board
LVDS1: Single Channel of LVDS I/F (2.0mm)
Pin No. Signal Pin No. Signal
1 VBL (+12V) 2 VBL (+12V)
3 GND 4 GND
5 DISP.ON/OFF 6 GND
7 LVDD 8 LVDD
9 GND 10 GND
11 Rx0+ 12 Rx0-
13 Rx1+ 14 Rx1-
15 Rx2+ 16 Rx2-
17 Rx3+ 18 Rx3-
19 RxCLK+ 20 TxCLK-
21 GND 22 KEY
23 n/c 24 n/c
25 n/c 26 n/c
27 n/c 28 n/c
29 n/c 30 n/c
31 n/c 32 n/c
33 LVDD 34 LVDD
35 GND 36 GND
37 GND 38 GND
39 VBL (+12V) 40 VBL (+12V)
Please make sure the Pin 1 location before inserting the LCD connector.
LCD Panel Number:
Panel Number
1024x768 24Bit 1CH
1280x1024 48Bit 2CH
1280x768 24Bit 1CH
1366x768 24Bit 1CH
