Unicorn Computer ENDAT-LX301 User manual

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
- 1 -
ENDAT-LX301
User’s Manual
Rev. A3
For ENDAT-LX301 PCB ver. A3 or later
10/29/2008
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
- 2 -
Copyright Notice
The content of this manual has been checked for accuracy. The manufacturer
assumes no responsibility for any inaccuracies that may be contained in this
manual. The manufacturer reserves the right to make improvements or
modification to this document and/or the product at any time without prior
notice. No part of this document may be reproduced, transmitted, photocopied or
translated into any language, in any form or by any means, electronic, mechanical,
magnetic, optical or chemical, without the prior written permission of the
manufacturer.
AMD is registered trademark ofAMD Technology Incorporation
GEODE LX is registered trademark of AMD Technology Incorporation
Realtek is registered trademark of Realtek Technologies Inc.
Multiscan is a trademark of Sony Corp ofAmerica
IBM, EGA, VGA, PC/XT, PC/AT, OS/2 and PS/2 are registered trademarks of
International Business Machines Corporation
Intel is a registered trademark of Intel Corporation
VIA is registered trademark of VIATechnology Incorporation
Plug and Play is registered trademarks of Intel Corporation
Microsoft, Windows and MS-DOS are trademarks of Microsoft Corporation
Award is a trademark of Phoenix Software Inc.
PCI is a registered trademark of PCI Special Interest Group
Other product names mentioned herein are used for identification purpose only and
may be trademarks and/or registered trademarks of their respective companies.
Installation Notice
The manufacturer recommends using a grounded plug to ensure proper
motherboard operation. Care should be used in proper conjunction with a grounded
power receptacle to avoid possible electrical shock. All integrated circuits on this
motherboard are sensitive to static electricity. To avoid damaging components from
electrostatic discharge, please do not remove the board from the anti-static packing
before discharging any static electricity to your body, by wearing a wrist-grounding
strap. The manufacturer is not responsible for any damage to the motherboard due
to improper operation.

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
- 3 -
Specification:
Model ENDAT-LX301
Form Factor Mini-ITX 170 mm x 170 mm (6.69”x6.69”) with 6 layers PCB
System Chipset AMD GEODE LX + CS5536
CPU
Supporting Onboard AMD GEODE LX 700/800/900 series CPU integrate L1
64KB / L2 128KB cache Processor
Memory One DDR socket support 200/266/333/400MHz up to 1GB
Ethernet VIA VT6122 for 10/100/1000 Ethernet
VGA Integrated 2D graphic engine by AMD GEODE LX with
8/16/32/64/128/254MB frame buffer
LVDS LCD
panel On-board support 18/24 bit LVDS
Serial / Parallel 2 + 4 (by UCM-S MME module; optional) Serial Ports with +5V,
+12V Power Selector / 1 Parallel port
RS-422/485 Via COM2 (Optional)
IDE Connector 1 x 40pin IDE connector support UDMA 33/66/100,
1 x 44pin connector support Slim type HDD
CF card socket Shared with IDE interface (Optional)
AUDIO AMD CS5536 w/ AC’97 2.0 compliant
Expansion Slot One PCI expansion up to 3 PCI slot via riser card
with PCI 2.2 compliant
MME module Reserved 1 set (2 connectors) of MME module connector for
various features (COM ports, PCI device, or Display interfaces)
(Optional)
PS/2 Keyboard / Mouse Connector
2 USB port + 1 RJ-45 LAN Connector(10/100/1000)
VGA and COM1/COM2/LPT (LPT connector will be removed for
MME module) with D-Sub connectors
Back Panel I/O
Audio jack for SPEAKER-OUT
LVDS with 2.54mm 16-pin connector
VGA/LPT (shared from D-SUB) with 2.00mm Box Header
FDD with 2.54mm Box Header
I/O on board Pin Header for KB/MS, 4 x USB, CD-in, Mic-in, Line-in, Line-out,
Speaker-out, SM Bus, SPDIF, IRDA, KB/MS for external device
Digital IO 2.0mm Pin Header for 12-bits Digital I/O with
CMOS/TTL level (Bi-direction without buffer)
Power input ATX and DC +12V; Optional for Wide range DC (+5V to +27V)
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
- 4 -
TABLE OF CONTENTS
CHAPTER 1. INTRODUCTION.......................................................6
1-1. FEATURES ................................................................................................7
1-2. UNPACKING..............................................................................................8
1-3. ELECTROSTATIC DISCHARGE PRECAUTIONS....................................8
1-4. MOTHERBOARD LAYOUT........................................................................9
CHAPTER 2. SETTING UP THE MOTHERBOARD.....................10
2-1. JUMPERS AND CONNECTORS.............................................................10
2-2. INSTALLING MEMORY............................................................................20
2-3. SHARED VGA MEMORY.........................................................................20
2-4. IRQs MAPPING........................................................................................21
2-5. WATCH DOG TIMER ...............................................................................21
2-6. DIGITAL I/O…………………………………………………………………….23
CHAPTER 3. AWARD BIOS SETUP............................................25
3-1. STANDARD COMS FEATURES..............................................................26
3-2. ADVANCED BIOS FEATURES ................................................................27
3-3. ADVANCED CHIPSET FEATURES .........................................................27
3-4. INTEGRATED PERIPHERALS ................................................................29
3-5. POWER MANAGEMENT SETUP............................................................31
3-6. PnP/PCI CONFIGURATIONS..................................................................32
3-7. PC HEALTH STATUS...............................................................................33

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
- 5 -
CHPATER 4. VGA, LCD AND DRIVERS......................................34
4-1. VGA FEATURE.........................................................................................34
4-2. LCD FLAT PANEL ....................................................................................35
4-3. DRIVER UTILITY INSTALLATION GUIDE...............................................37
CHPATER 5. LAN ADAPTER.......................................................38
5-1. FEATURES...............................................................................................38
5-2. UTP CABLE/RJ-45 JACK DEFINITION...................................................39
5-3. CONNECTING 100BASE-TX FAST ETHERNET NETWORK.................40
5-4. REMOTE BOOT ROM FUNCTION..........................................................40
APPENDIX A: FLASH MEMORY UTILITY...................................41
APPENDIX B: LIMITED WARRANTY ..........................................42
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
- 6 -
Chapter 1. Introduction
In order to cope with the challenges of the system heating issues and demand of much more
diminutive embedded system in diverse application, ENDAT-LX301 system board provides
the ultimate solution by integrating with AMD GEODE LX technology CPU. ENDAT-LX301
not only provide the ideal solution for Hi-End POS system, but also can be adapted in various
applications such as kiosks, networking systems, control terminals and other embedded
systems with FANLESS environment.
ENDAT-LX301 is designed and integrated with AMD GEODE LX processor and
CS5536. Supports One DDR DIMM socket 200MHz up to 1GB DDR. The DRAM
controller supports standard DDR200 Synchronous DRAM (DDR SDRAM).
ENDAT-LX301 is integrated 2D graphics controller. Based on integrated graphic
controller, it supports TFT LCD panel or CRT/LCD monitor (simultaneous mode) as
needs. The TFT LCD panels support through LVDS interface, which includes 9-bit,
12-bit, 18-bit, and 24-bit. All resolutions support up to 1024 x 768 for TFT LVDS
panel or 1920 x 1440 for CRT monitor.
ENDAT-LX301 provides one standard PCI slot to support standard PCI adapter
with PCI 2.2 compliant. More, this board offers more flexibility through a MME
module connector which is an optional feature.
The ideal solutions of ENDAT-LX301
-POS system
-KIOSK
-Vehicle system
-Interactive system
-Industrial controller
-Gaming system
-Medical system
-Fan-less system
-Network server
-Embedded system equipment

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
- 7 -
1-1. Features
Basic Feature:
zA cost effective platform with x86 architecture.
zEmbedded AMD GEODE LX 800 processor @ 1.8W power
consumption to offer a totally FANLESS solution.
zOne DDR socket supports 200MHz (DDR400) up to 1GB DDR.
zAn internal 2D graphic controller with 8/16/32/64/128/254 MB frame
buffer share with system memory
zIntegrated 2D graphics controller resolutions up to 1920 x 1440 for
CRT/LCD monitor.
zDirect Flat panel interface support 18/24-bit LVDS LCD panel, the
resolution up to 1024 x 768.
z12 bits bi-directional I/O ports by standard on-board support.
zStandard PCI slot to support standard PCI adapter with PCI 2.2
compliant (3 slots through PCI riser card). A MME module connector
by optional features.
zAC97’Audio support with 1.2W amplifier built-in.
Software Support
zDrivers for major embedded operating systems: Linux, Windows XP,
Windows XP embedded and Windows CE 5.0/6.0.
Ordering information:
1. ENDAT-LX301: Standard version. (ATX and DC+12V)
2. ENDAT-LX301W: Support Wide range.(DC+5V~+27V)
3. ENDAT-LX301A: Support ATX Power only.
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
- 8 -
1-2. Unpacking
The motherboard comes securely packaged in a sturdy cardboard shipping carton. In
addition to the User's Manual, the motherboard package includes the following items:
• ENDAT-LX301 System Board
• HDD/FDD Cables
• LCD cable (Optional)
• CD with Driver utilities for on-board VGA and LAN adapter
If any of these items are missing or damage, please contact the dealer from whom you
purchase the motherboard. Save the shipping material and carton in the event that you want
to ship or store the board in the future.
Note: Leave the motherboard in its original package until you are ready to install it!
1-3. Electrostatic Discharge Precautions
Make sure you properly ground yourself before handling the motherboard, or other system
components. Electrostatic discharge can easily damage the components. Note: You must
take special precaution when handling the motherboard in dry or air-conditioned
environments.

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
- 9 -
1-4.MOTHERBOARD LAYOUT.
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
- 10 -
Chapter 2. Setting up the Motherboard
2-1. Jumpers and Connectors
Connectors Overview:
Function Jumpers/Connectors
ATX Power Connector ATX1
DC Input connector DC-IN1
DC Output connector HDDPWR
DDR SDRAM Socket DDRDIMM
LAN/USB Connector CN2
CRT Output Connector VGA1
COM1/COM2 Connector COM1, COM2
SPEAKER OUT connector SPEKER
LPT connector LPT1
IDE Connectors IDE1, IDELIM
FDD Connector FDD1
CF socket CF1
PCI, PCI Riser Slot PCI1, RISER1
MME Module Connectors PCIMM1, PCIMM2
Cooling Fan Connectors FAN1, FAN2
PS/2 MS/KB Connector CKBMS1
LVDS Panel Header LVDS1
VGA Box Header VGABH1
TTL level serial port (COM1) Header CM1TTL
LPT Box Header LPTBH1
USB Port Headers JUSB1, JUSB2
PS/2 MS/KB Pin Header CN6
External PS/2 device Header JKB1
SPDIF Pin Header SPDIF1
IR Pin Header IRDA1
SM Bus Header SMB1
DIGITAL I/O Pin Header GPIO1
MIC, CD IN, LINE IN, LINE OUT Header CN5
SPEAKER OUT Header CN1

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
- 11 -
Jumpers Overview:
Function Jumpers/Connectors
Clear CMOS JBAT1
COM Port Voltage Selector JP1
RS232 / 422/ 485 Selector for COM2 JP2, JP3
LVDS trigger edge selector JP4
LCD Voltage Selector JP5
Restore on AC power loss JP6
Header for Case Panel JP7
HDD active LED JP7: Pin 1(-), Pin 2(+)
External Speaker JP7: Pin 3, Pin 6
Buzzer On/Off JP7: Pin 4, Pin 5
Hardware Reset Switch JP7: Pin 10, Pin 11
Power LED JP7: Pin 12(+), Pin 13(-)
WDT Function Enable/Disable JP7: Pin 14, Pin 15
ATX Power Supply On/Off Switch JP7: Pin 16, Pin 17
CF card power / Master, Slaver selector JP8
Please double-check the insertion and orientation of the LCD cable before applying power.
Improper installation will result in permanent damage LCD panel.
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
- 12 -
Part 1: Onboard Jumpers
JBAT1: CMOS Data Clear (1x3 with 2.0mm)
Pin 1-2 * Normal
Pin 2-3 Close for clear CMOS
JP1: COM Port Voltage Selector (2x6 with 2.0mm)
Voltage +12V(DC) R.I. * +5V(DC)
COM1 1-2 3-4 5-6
COM2 7-8 9-10 11-12
JP2, JP3: RS232 / 422 / 485 Selector for COM2 (2.0mm)
TYPE JP2 (3x4 with 2mm) JP3 (2x7 with 2mm)
RS-232 * 1-2, 4-5, 7-8, 10-11 1-2
RS-422/485 2-3, 5-6, 8-9, 11-12 3-4, 5-6
JP4: LVDS chip trigger edge selector (1x3 with 2.0mm)
Pin 1-2 Rising edge
Pin 2-3 * Falling edge
Note: Change default location since A5 PCB version.
JP5: LCD Voltage Selector (2x3 with 2.0mm)
Pin 1-2 * +3.3V
Pin 3-4 +5V
Pin 5-6 +12V
Caution: Improper setting will damage LCD panel.
JP6: Restore on AC power loss (1x2 with 2.54mm)
Close Enable
Open* Disable
When JP6 was been closed, the system power will turn on automatically when AC
power applied.

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
- 13 -
JP7: Box Header for Case Panel (1x17 with 2.54mm)
Pin No. Function
1(-), 2(+) HDD active LED
3,6 External Speaker
4,5 * Buzzer On/Off
7,8 Reserved
8,9 * Reserved
10,11 Hardware Reset Switch
12(+), 13(-) Power LED
14,15 Close: Enable WDT function
16,17 ATX Power On/Off
JP8: CF card power / Master, Slaver selector (2x3 with 2.0mm)
Pin 1-3 * Slaver Pin 3-5 Master
Pin 2-4 * +5V CF card Pin 4-6 +3.3V CF card
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
- 14 -
Part 2: Onboard Connectors and Headers
VGABH1: CRT Box Header Connector (2x8 with 2.0mm)
Pin No. Description Pin No. Description
1 RED 9 N.C / +5V
2 GREEN 10 GND
3 BLUE 11 N.C.
4 N.C. 12 DDC DAT
5 GND 13 H-Sync
6 GND 14 V-Sync
7 GND 15 DDC CLK
8 GND
TTL1: TTL LCD Panel Box Header (2x22 with 2.0mm)
Pin No. Signal Pin No. Signal
1 VBL (+12V) 2 VBL (+12V)
3 GND 4 GND
5 LCD-PWR 6 LCD-PWR
7 ENBKLT 8 GND
9 B0 10 B1
11 B2 12 B3
13 B4 14 B5
15 B6 16 B7
17 G0 18 G1
19 G2 20 G3
21 G4 22 G5
23 G6 24 G7
25 R0 26 R1
27 R2 28 R3
29 R4 30 R5
31 R6 32 R7
33 GND 34 GND
35 CLK 36 V-SYNC
37 DE 38 H-SYNC
39 GND 40 LCD-PWR
41 LCD-PWR 42 KEY
43 LCD-PWR 44 LCD-PWR

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
- 15 -
LVDS1: LVDS LCD Pin Header (2x8 with 2.54mm)
Pin No. Description Pin No. Description
1 Y0- 2 Y2-
3 Y0+ 4 Y2+
5 Y1- 6 LCD-PWR
7 GND 8 Y3-
9 Y1+ 10 Y3
11 CK- 12 LCD-PWR
13 CK+ 14 ENBKLT
15 VBL (+12V) 16 GND
Please make sure the Pin 1 location before inserting the LCD connector.
IDE1 Box Header (2x20 with 2.54mm)
Pin No. Description Pin No. Description
1 IDE Reset# 2 GND
3 IDE data7 4 IDE data8
5 IDE data6 6 IDE data9
7 IDE data5 8 IDE data10
9 IDE data4 10 IDE data11
11 IDE data3 12 IDE data12
13 IDE data2 14 IDE data13
15 IDE data1 16 IDE data14
17 IDE data0 18 IDE data15
19 GND 20 N.C.
21 IDE REQ 22 GND
23 IDE IOW# 24 GND
25 IDE IOR# 26 GND
27 IDE Ready 28 GND
29 IDE ACK# 30 GND
31 IDE IRQ 32 N.C.
33 IDE A1 34 P66DET
35 IDE A0 36 IDE A2
37 IDECS1# 38 IDESC3#
39 HDLED# 40 GND
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
16
IDELIM: Slim IDE Connector (Shared IDE1, 2x22 with 2.0mm)
Pin No. Description Pin No. Description
1 IDE Reset# 2 GND
3 IDE data7 4 IDE data8
5 IDE data6 6 IDE data9
7 IDE data5 8 IDE data10
9 IDE data4 10 IDE data11
11 IDE data3 12 IDE data12
13 IDE data2 14 IDE data13
15 IDE data1 16 IDE data14
17 IDE data0 18 IDE data15
19 GND 20 N.C.
21 IDE REQ 22 GND
23 IDE IOW# 24 GND
25 IDE IOR# 26 GND
27 IDE Ready 28 GND
29 IDE ACK# 30 GND
31 IDE IRQ 32 N.C.
33 IDE A1 34 P66DET
35 IDE A0 36 IDE A2
37 IDECS1# 38 IDESC3#
39 HDLED# 40 GND
41 VCC (+5V) 42 VCC (+5V)
43 GND 44 N.C.

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
17
FDD1: FDD Box Header (2x17 with 2.54mm)
Pin No. Description Pin No. Description
1,3,5,7 GND 14 DSA#
9,11,13 GND 16 MOB#
15,17,19 GND 18 DIR
21,23,25 GND 20 STEP#
27,29,31 GND 22 WD#
33 GND 24 WE#
2 RWC# 26 TRAK0
4,6 N.C 28 WP#
8 INDEX# 30 RDATA#
10 MOA# 32 HEAD#
12 DSB# 34 DSKCHG#
CN6: PS/2 Keyboard / Mouse Pin Header (2x5 with 2.54mm)
Pin No. Signal (KB) Pin No. Signal (MS)
1 KB Data 2 MS Data
3 KEY 4 KEY
5 GND 6 GND
7 +5V(DC) 8 +5V(DC)
9 KB_CLK 10 MS_CLK
JKB1: External PS/2 Device Header (1x7 with 2.0mm)
Pin No. Signal (KB) Pin No. Signal (MS)
1 KB Data Out 2 KB Data In
3 KB Clk Out 4 KB Clk In
5 Key 6 +5V(DC)
7 GND
Note: Change to 2 hard wire jumpers (close pin 1 and 2, 3 and 4) from pin
header since A5 PCB version.
CM1TTL: COM1 TTL interface Pin Header (2x5 with 2.0mm)
Pin No. Function Pin No. Function
1 DCD 2 DSR
3 SIN 4 RTS
5 SOUT 6 CTS
7 DTR 8 RI
9 GND 10 +5V
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
18
JUSB1, JUSB2: Pin Header for USB port (2x5 with 2.54mm)
Pin No. Function Pin No. Function
1 USB_VCC 2 USB_VCC
3 USBD2/4- 4 USBD3/5-
5 USBD2/4+ 6 USBD3/5+
7 USB_GND 8 USB_GND
9 USB_GND 10 USB_GND
FAN1, FAN2: Cooling Fan Connector
Pin No. Function
1 GND
2 +12V
3 Sensor Pin
CN1: SPEAKER OUT (1x4 with 2.54mm)
Pin No. Function Pin No. Function
1 SPEAKER OUT-R 2 GND
3 GND 4 SPEAKER OUT-L
CN4: LINE OUT, LINE IN (2x4 with 2.54mm)
Pin No. Function Pin No. Function
1 LINE OUT-R 5 LINE IN-L
2 GND 6 GND
3 GND 7 GND
4 LINE OUT-L 8 LINE IN-R
CN5: MIC IN, CD IN Pin Header (2x4 with 2.54mm)
Pin No. Function Pin No. Function
1 MIC POWER 5 CD IN-R
2 GND 6 GND
3 GND 7 GND
4 MIC IN 8 CD IN-L
SPDIF1: SPDIF Pin Header (1x5 with 2.54mm)
Pin No. Signal (KB) Pin No. Signal (MS)
1 +5V 4 GND
2 N.C 5 SPDIF-IN
3 SPDIF-OUT

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
19
SMB1: SM Bus Pin Header (1x4 with 2.54mm)
Pin No. Function Pin No. Function
1 SMBCK 3 +3.3V
2 SMBDT 4 GND
IRDA1: IR Pin Header (1x5 with 2.54mm)
Pin No. Function Pin No. Function
1 +5V 4 GND
2 N.C 5 IRTX
3 IRRX
GPIO1: DIGITAL I/O Pin Header (2x9 with 2.0mm)
Pin No. Function Pin No. Function
1 +5V 2 +3.3V
3 DIO-P0-0 4 DIO-P0-1
5 DIO-P0-2 6 DIO-P0-3
7 DIO-P0-4 8 DIO-P0-5
9 DIO-P0-6 10 DIO-P0-7
11 GND 12 GND
13 DIO-P1-0 14 DIO-P1-1
15 DIO-P1-2 16 DIO-P1-3
17 +3.3V 18 +5V
D-SUB Type Connector for COM2 port (RS-422Æ4 Wire)
Pin No. Function Pin No. Function
1 –TXD 6 NA
2 +RXD 7 NA
3 +TXD 8 NA
4 NA 9 –RXD
5 NA
D-SUB Type Connector for COM2 port (RS-485Æ2 Wire)
Pin No. Function Pin No. Function
1 Data – 6 NA
2 NA 7 NA
3 Data + 8 NA
4 NA 9 NA
5 NA
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
20
ATXPWR: ATX Power connector
ATX
3.3V 11 1 3.3V
–12V 12 2 3.3V
GND 13 3 GND
PS ON 14 4 +5V
GND 15 5 GND
GND 16 6 +5V
GND 17 7 GND
–5V 18 8 POWER OK
+5V 19 9 5V SB
+5V 20 10 +12V
DC-IN1: DC Input Power
Pin No. Function
1 +V
2 GND
HDDPWR: DC Output Power for IDE device
Pin No. Function
1 +12V
2 GND
3 GND
4 +5V
2-2. Installing Memory
The ENDAT-LX301 CPU board offers one184pin DDR DIMM socket supporting up to 1GB of
memory. The speed of DDR memory can be DDR200, DDR266, DDR333 or DDR400.
2-3. Shared VGA Memory
The ENDAT-LX301 is using built-in graphic controller with Unified Memory Architecture
(UMA) -
up to 254MB of system memory. The amount of video memory on motherboard
determines the number of colors and the video graphic resolution.

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
21
2-4. IRQs Mapping
The IRQ number is automatically assigned to PCI expansion cards after those used by
onboard device. To install a PCI riser card, you need to set the correct "ADSEL" and "INT"
(interrupt) assignment.
IRQ Status Assignment
0 Occupied Timer
1 Occupied Keyboard
2 Occupied Second 8259
3 Occupied COM2/COM4 shared
4 Occupied COM1/COM3 shared
5 Occupied LPT1
6 Occupied Floppy Disk
7 Free Any
8 Occupied RTC
9 Shareable ACPI controller
10 Free Any
11 Free Any
12 Free When PS/2 mouse absent
13 Occupied Coprocessor
14 Free When IDE device absent
15 Occupied Reserved
2-5. Watch Dog Timer
Watchdog Timer (WDT) is a special design for system monitoring to secure the
system work normally. WDT has an independent clock from the oscillator and could
set time and clear/refresh WDT counter function. When time is up, WDT will send
hardware RESET signal to reset system.
Timeout Value Range
-1 to 255
-Second or Minute
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
22
Sample code (using TurboC/C++ 3.0):
#include <stdio.h>
#include <dos.h>
#include <dir.h>
void show_ver();
void main()
{
unsigned int tt;
clrscr();
show_ver();
tt=0;
while((tt==0)||(tt>255))
{
printf("\n\nPlease key in how many seconds you want to reset system (1~255):");
scanf("%d",&tt);
}
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x07); //Set Logic Device number pointer
outportb(0x2f,0x08);//Set Logic Device number
outportb(0x2e,0xF5); //Set WDT mode
outportb(0x2f,0x00);// bit2 : Enable the rising edgw of keyboard Reset to force Time-out
event. ( 0=Disable / 1= Enable). / bit3 : Select WDTO count mode (0 = second / 1= minute).
outportb(0x2e,0xf6); //Set Watch Dog Timer Time-out value.
outportb(0x2f,tt); //Set time out value of WDT
}
void show_ver()
{
unsigned char tmp0;
printf("Designed by ROBERT LIOU of UNICORN computer corp. \n2008/05/12 release
version:1.0a\n");
printf("This program is design for test Watch Dog Timer for ENADT-LX301(W83627).\n");
}

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
23
2-6. Digital I/O
Pin definition:
GPIO1: DIGITAL I/O Pin Header (2x9 with 2.0mm)
Pin No. Function Pin No. Function
1 +5V 2 +3.3V
3 DIO-P0-0 4 DIO-P0-1
5 DIO-P0-2 6 DIO-P0-3
7 DIO-P0-4 8 DIO-P0-5
9 DIO-P0-6 10 DIO-P0-7
11 GND 12 GND
13 DIO-P1-0 14 DIO-P1-1
15 DIO-P1-2 16 DIO-P1-3
17 +3.3V 18 +5V
This function is supported by onboard super I/O chip; it can be control easily by
change the register of super I/O chip via I/O port “2Eh” “2Fh”. Please see the
sample code of below for implement.
Voltage tolerance: +/- 5% with 0V to +5V.
DIGITAL I/O Pin (DIO-P0)Register configuration:
Bit No 7 6 5 4 3 2 1 0
Map P0-7 P0-6 P0-5 P0-4 P0-3 P0-2 P0-1 P0-0
Sample code for input (using Turbo C/C++ 3.0)
#define input_port 0x2f // Read digital input data define.
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x07); //Set Logic Device number pointer
outportb(0x2f,0x07);//Set Logic Device number
outportb(0x2e,0xF0); //Set Digital I/O(DIO-P0) Input/Output
outportb(0x2f,0xFF); //Set register value (FF for Input / 00 for output ).
outportb(0x2e,0xF2); //Set Read digital input data
read_data=inportb(input_port); // Read digital input data
printf("DIO-Input=%02X\n",read_data); //Show digital input data on screen
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
24
Sample code for output (using Turbo C/C++ 3.0):
DIGITAL I/O Pin (DIO-P1)Register configuration:
Bit No 3 2 1 0
Map P1-3 P1-2 P1-1 P1-0
Sample code for input (using Turbo C/C++ 3.0)
Sample code for output (using Turbo C/C++ 3.0)
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x07); //Set Logic Device number pointer
outportb(0x2f,0x07);//Set Logic Device number
outportb(0x2e,0xF0); //Set Digital I/O(DIO-P0) Output
outportb(0x2f,0x00);//Set register value (FF for Input / 00 for output ).
outportb(0x2e,0xF1); //Set active register is CRF1
outportb(0x2f,0x00); //Write data to digital output
#define input_port 0x2f // Read digital input data define.
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x07); //Set Logic Device number pointer
outportb(0x2f,0x09);//Set Logic Device number
outportb(0x2e,0xF0); //Set Digital I/O(DIO-P0) Input/Output
outportb(0x2f,0x0F);//Set register value (FF for Input / 00 for output ).
outportb(0x2e,0xF2); //Set Read digital input data
read_data=inportb(input_port); // Read digital input data
printf("DIO-Input=%02X\n",read_data); //Show digital input data on screen
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x87); //Unlock register
outportb(0x2e,0x07); //Set Logic Device number pointer
outportb(0x2f,0x09);//Set Logic Device number
outportb(0x2e,0xF0); //Set Digital I/O(DIO-P0) Input/Output
outportb(0x2f,0x0F);//Set register value (FF for Input / 00 for output ).
outportb(0x2e,0xF1); //Set active register is CRF1
outportb(0x2f,0x00); //Write data to digital output

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
25
Chapter 3. AWARD BIOS SETUP
Phoenix – Award BIOS CMOS Setup Utility
> Standard CMOS Features
> Advanced BIOS Features
> Advanced Chipset Features
> Integrated Peripherals
> Power Management Setup
> PnP/PCI Configurations
> PC Health Status
Load Optimized Defaults
Set Supervisor Password
Set Password
Save & Exit Setup
Exit Without Saving
Use the BIOS CMOS setup program to modify the system parameters to reflect the
environment installed in your system and to customize the system as desired.
Press the <DEL> key to enter into the BIOS CMOS setup program when you turn
on the power. Settings can be accessed via arrow keys. Press <Enter> to choose
an option to configure the system properly.
In the main menu, press F10 or “SAVE & EXIT SETUP” to save your changes and
reboot the system. Choose “EXIT WITHOUT SAVING” to ignore the changes and
exit the setup procedure. Pressing <ESC> at anywhereduring the setup will return
to the main menu.
All of the above CMOS BIOS items require board knowledge on PC/AT system
architecture. Incorrect setup could cause system malfunctions.
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
26
3-1. Standard CMOS Features
The Standard Setup is used for the basic hardware system configuration. The main
function is for Data/Time and Hard Disk Drive settings.
˙Video
Select the type of primary video subsystem.
<Choice: EGA/ VGA, CGA 40, CGA 80, MONO>
˙Halt On
Set the system’s response to specific boot errors.
<Choice: All Errors, No Errors, All, But Keyboard,
All, But Diskette, All, But Disk/Key >
IDE Primary Master/Slaver
Item Optimized defaults
IDE HDD Auto-Detection Press Enter
IDE Channel Auto
Access Mode Auto
The specifications of your drive must match with the drive table. The hard disk will
not work properly if you enter incorrect information in this category. Select “Auto”
whenever possible. If you select “Manual”, make sure the information is from your
hard disk vendor or system manufacturer.
Item Optimized defaults
Date (mm:dd:yy)
Time (hh:mm:ss)
IDE Primary Master Press Enter
IDE Primary Slave Press Enter
Driver A 1.44M, 3.5 in.
Driver B None
Video EGA/VGA
Halt On All , But Keyboard

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
27
3-2. Advanced BIOS Features
This section allows you configuring your system for basic operation. You have the
opportunity to select the system’s default speed, boot-up priority, keyboard
operation and security.
3-3. Advanced Chipset Features
This section allows you to configure the system based on the specific features of
the installed chipset. This chipset manages bus speeds and the access to the
system memory resources, such as DRAM and the external cache. It also
coordinates the communications with the PCI bus. It must be stated that these
items should never be altered. The default settings have been chosen because
they provide the best operating conditions for your system. You might consider
making any changes only if you discover that the data has been lost while using
your system.
Item Optimized defaults
CPU Frequency Auto
Memory Frequency Auto
CAS Latency Auto
Interleave Select LOI
XOR BA0 Disable
Item Optimized defaults
Virus Warning Disabled
CPU Internal Cache Enabled
External Cache Enabled
First Boot Device HDD-0
Second Boot Device CDROM
Third Boot Device LS120
Boot Other Device Enabled
Swap Floppy Drive Disabled
Boot Up Floppy Seek Enabled
Boot Up NumLock Status On
Gate A20 Option Normal
Typematic Rate Setting Disabled
Typematic Rate (Chars/Sec) 6
Typematic Delay (Msec) 250
Security Option Setup
OS Select For DRAM > 64MB Non-OS2
HDD S.M.A.R.T. Capability Disabled
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
28
Item Optimized defaults
XOR BA1 Disable
XOR MB0 Disable
XOR Bit Select 18
Video Memory Size 64M
Output display CRT
Flat Panel Configuration Press Enter
Onboard Audio Enable
Onboard USB1.1 Enable
Onboard USB2.0 Enable
Onboard IDE Enable
Memory Hole At 15M-16M Disable
˙Video Memory Size
This field is used to select the onboard VGA’s frame buffer size that is shared
from the system memory.
<Choice: Disabled, 8M,12M,16M,32M,64M,128M,254M>
˙Flat Panel Configuration
˙Resolution
This field is used to select the resolution of LCD panel.
<Choice:320x240/640x480/800x600/1024x768/1152x864/1280x1024/
1600x1200>.
˙Data Bus Type
This field is used to select the data type of LCD panel. Generally is “Normal”.
<9-24 bits, 1 ppc and 18,24 bits, 2 ppc>.
˙Refresh Rate
This field is used to select the refresh rate (VSYNC frequency) to LCD panel.
Default is “60 Hz”. <Choice: 60/65/70/72/75/85>
Item Optimized defaults
Flat Panel Type LVDS
Resolution 800x600
Data Bus Type 9-24 bits, 1 ppc
Refresh Rate 60 Hz
HSYNC Polarity Normal low
VSYNC Polarity Active Normal low
SHFCLK Active Period Free runing
LP Active Period Free runing

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
29
˙HSYNC Polarity
This field is used to select the polarity of HSYNC for LCD. Default is “Normal
Low”. <Choice: Normal Low/Normal High>
˙VSYNC Polarity Active
This field is used to select the polarity of VSYNC for LCD. Default is “Normal
Low”. <Choice: Normal Low/ Normal High>
˙SHFCLK Active Period
This field is used to select the working period of shift clock. Generally is “Free
running”. <Choice: Free running/Active only>
˙LP Active Period
This field is used to select theworking period of line pulse. Generally is “Normal”.
<Choice: Free running/Active only>
If you apply one of the standard panels shown above, select the appropriate
option according to the type of panel that you apply. Or, please contact your
dealer or sales representative for custom-made BIOS that will suit the panel that
you apply.
3-4. Integrated Peripherals
The IDE hard drive controllers support up to two separate hard drives. These drives
have a master/slave relationship that is determined by the cabling configuration
used to attach them to the controller. Your system supports two IDE controllers--a
primary and a secondary--so you can install up to four separate hard disks.
Integrated Peripherals
Item Optimized defaults
Master Drive PIO Mode Auto
Slave Drive PIO Mode Auto
IDE Primary Master UDMA Auto
IDE Primary Slave UDMA Auto
IDE DMA transfer access Enabled
IDE HDD Block Mode Enabled
Onboard Lan Boot ROM Disabled
Onboard FDC Controller: Enabled
Onboard Serial Port 1 3F8/IRQ4
Onboard Serial Port 2 2F8/IRQ3
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
30
UART Mode Select Normal
RxD , TxD Active Hi,Lo
IR Transmission Enable
UR2 Duplex Mode: Half
Use IR Pins: IR-Rx2Tx2
Onboard Parallel 378/IRQ7
Parallel Port Mode: SPP
EPP Mode Select: EPP1.7
ECP Mode Use DMA 3
˙Master/Slave PIO Mode
The two IDE PIO (programmed Input/Output) fields let you set a PIO mode (0-4)
for each IDE device that the internal PCI IDE interface supports. Modes 0
through 4 provide successively increased performance. In Auto mode, the
system automatically determines the best mode for each device.
˙IDE Primary Master/Slave UDMA
These fields allow you to set the Ultra DMA in use. When Auto is selected, the
BIOS will select the best available option after checking your hard drive or
CD-ROM.
˙IDE HDD Block Mode
Block mode is also called block transfer, multiple commands, or multiple sectors
read/write.
˙Onboard LAN Boot ROM
By default, this field is disabled. Enable this field if you wish to use the boot ROM
(instead of a disk drive) to boot-up the system and access the local area network
directly.
˙UART Mode Select
Select an operating mode for the serial port 2.
<Choice: IrDA, ASKIR, Normal>
˙Parallel Port Mode
Set the parallel port mode.
<Choice: Standard/SPP/EPP1.7/EPP1.9/ECP/ECP+EPP>

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
31
3-5. Power Management Setup
The Power Management Setup allows users configuring the system to save energy
in a most effective way while operating in a manner consistent with their own style
of computer use. Item Optimized defaults
ACPI function Enabled
ACPI Suspend Type S1(POS)
Power Management ACPI
** PM Timers **
Standby Mode Disabled
Suspend Mode Disabled
HDD Power Down Disabled
Soft-Off by PWRBTN Instant-Off
Power-On by Alarm Disabled
Time (hh:mm:ss) Alarm 0
0
0
IRQ Wakeup Events Press Enter
˙ACPI Suspend Type
This field is used to select the type of Suspend mode.
S1(POS) Enables the Power On Suspend function.
IRQ Wakeup Events
Item Optimized defaults
IRQ1 (KeyBoard) ON
IRQ3 (COM 2) OFF
IRQ4 (COM 1) OFF
IRQ5 (LPT 2) OFF
IRQ6 (Floppy Disk) OFF
IRQ7 (LPT 1) OFF
IRQ8 (RTC Alarm) OFF
IRQ9 (IRQ2 Redir) OFF
IRQ10 (Reserved) OFF
IRQ11 (Reserved) OFF
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
32
Item Optimized defaults
IRQ12 (PS/2 Mouse) OFF
IRQ13 (Coprocessor) OFF
IRQ14 (Hard Disk) OFF
IRQ15 (Reserved) OFF
3-6. PnP/PCI Configurations
This section describes the configuration of the PCI bus system. PCI is a system
that allows I/O device to operate at speeds nearing the speed of the CPU itself,
when communicating with its own special components. This section covers some
very technical items. It is strongly recommended that only experienced users make
any changes to the default settings.
Item Optimized defaults
PNP OS Installed No
Init Display First PCI Slot
Reset Configuration Data Disabled
Resources Controlled By Auto(ESCD)
IRQ Resources Press Enter
DMA Resources Press Enter
Memory Resources Press Enter
PCI/VGA Palette Snoop Disabled
˙
˙Reset Configuration Data
Enabled The BIOS will reset the Extended System Configuration Data (ESCD) once automatically. It will then recreate a
new set of configuration data.
Disabled The BIOS will not reset the configuration data.
˙Resources Controlled By
Auto(ESCD) The system will automatically detect the settings for you.
Manual Choose the specific IRQ in the “IRQ Resources” field.
˙PCI/VGA Palette Snoop
When set to [Enabled], multiple VGA devices operating on different buses can
handle data from the CPU on each set of palette registers on every video device.
Bit 5 of the command register in the PCI device configuration space is the VGA
Palette Snoop bit (0 is disabled).

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
33
3-7. PC Health Status
This screen shows the information of temperature, Fan speed and Vcore etc. It also
can set CPU warning temperature to protect CPU.
PC Health Status
Item Optimized defaults
CPU Warning Temperature Disable
Current System Temp
Current CPU Temperature
Fan1 Speed
Fan2 Speed
+3.3 V
+5 V
+12 V
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
34
Chapter 4. VGA, LCD and drivers
4-1. Graphic controller Feature
The ENDAT-LX301 integrated a high performance with low power consumption 2D
graphics engine. The graphics controller is full compliance and compatibility with
IBM® VGA and VESA™ extended VGA.
The display controller is integrated video DACs and TFT LCD interface for various
embedded application. The display operation support CRT or TFT LCD only; the
simultaneous operation mode is not supported by this graphics controller.
The on-board Graphics Controller’s main system features include:
- High Performance 2D graphics controller
- Alpha BLT
- Hardware frame buffer compression improves UMA (Unified Memory
Architecture) memory efficiency
- Support up to 1920 x 1440 running at 85 HZ (CRT/LCD monitor)
- Hardware based VGA (Video Graphics Array)
- Hardware video up/down scalar
- Graphics/video alpha blending
- Integrated dot clock PLL (Phase Lock Loop) up to 230 MHZ
- Direct TFT LCD support up to 1024 x 768.

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
35
4-2. LCD Flat Panel
zFlat Panel Interface
The on-board graphics controller also supports industry standard LVDS TFT LCD:
LVDS interface: 18 and 24bit by standard feature support.
LVDS interface provides a low voltage, high speed and low EMI serial
DC-balanced differential data via optional onboard LVDS.
The flat panel interface provides or supports the following functions for various
panels:
- Generates flat panel interface signals like FLM, LP, SCLK, and DE
- Generates different video data formats to directly drive different types of
panels
- Vertical and horizontal expansion of video displays to LCD panel resolution
- Vertical and horizontal centering
- Panel power sequence
BIOS setting:
˙Flat Panel Type
This field is used to select the type of display to use when the system boot.
<Choice: CRT/LCD>
˙Resolution
This field is used to select the resolution of LCD panel.
<Choice: 640x480/800x600/1024x768/1152x864/1280x1024/1600x1200>
˙Bus Width
This field is used to select the bus width of LCD panel. Generally is “24bits”.
<Choice: 8/9/12/16/18/24>
˙Data type
This field is used to select the data type of LCD panel. Generally is “Normal”.
<Choice: Normal/2 X>
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
36
˙Refresh Rate
This field is used to select the refresh rate (VSYNC frequency) to LCD panel.
Default is “60 Hz”.
<Choice: 60/65/70/72/75/85>
˙HSYNC Polarity
This field is used to select the polarity of HSYNC for LCD. Default is “Low”.
<Choice: Low/High>
˙VSYNC Polarity Active
This field is used to select the polarity of VSYNC for LCD. Default is “Low”.
<Choice: Low/High>
˙SHFCLK Active Period
This field is used to select the working period of shift clock. Generally is “Free
running”.
<Choice: Free running/Active only>
˙LP Active Period
This field is used to select the working period of line pulse. Generally is
“Normal”.
<Choice: Free running/Active only>
Please note that the default setting is with “CRT only”. If the LCD display feature is
required, the setting will need to be revised in the system BIOS setting: “Select Display
Device” under “Advanced Chipset Features
”; unless it is specified at the time of order.

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
37
4-3. Driver Utility Installation Guide
1. When finishing the installation of Windows XP, please install the relative AMD display
and AUDIO driver manually for compliance compatibility of hardware environment.
2. Please contact sales department of UNICORN for Embedded OS user driver
(Windows CE and Windows XP embedded). All of embedded OS driver is not
be included in any versions of driver CD-ROM from UNICORN.
Please download or check from AMD Web site: www.amd.com for more information or last
versions of driver as needs!
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
38
Chapter 5. LAN Adapter
5-1. FEATURES.
The on-board VIAVelocity VT6122 Gigabit Ethernet Controller
The VIA Velocity™ VT6122 Gigabit Ethernet controller enables leading-edge
performance in a small 14x14mm 128-pin LQFP package, optimized for 32-bit PCI
applications in space-constrained systems. Integrating a feature laden MAC and
Cicada's patented SimpliPHY™ transceiver, the VT6122 Controller is optimized for
space constrained systems with a low power, low profile design.
Supporting 10/100/1000 Mbps triple-speed and full/half-duplex capability at all
speeds, the integrated Cicada PHY is fully compliant to IEEE 802.3 (10BASE-T),
802.3u (100BASE-TX), and 802.3ab (1000BASE-T) standards. With Cicada's
proven SimpliPHY design, VIA Networking's Velocity controllers feature leading
narrow band noise tolerance that delivers superior performance for real world
PCBs and cables.
To minimize host-side CPU utilization, VIA Velocity Gigabit Ethernet Controllers
adopt an adaptive interrupt scheme to reduce interrupts made to the processor,
and maximize the use of packet bursts for efficient PCI bandwidth usage. The
Velocity controllers can further offload tasks from the host CPU to improve the
overall system performance with TCP/UDP/IP checksum, and TCP segmentation
offloading.
Applications
The Velocity VT6122 controller is optimized for 32-bit PCI client-end applications.
Its small form factor 14x14mm, 0.4mm pin-pitch, 128-pin LQFPpackage provides a
low pin count body size that helps simplify signal routing, minimize board routing
area, resulting in a cost-effective board implementation. Furthermore, to allow a
flexible Gigabit Ethernet (10/100/1000-Mbps) or Fast Ethernet (10/100-Mbps)
implementations on the same board, VIA Networking offers a number of
configuration options integrating our wide range of Ethernet IC options.

ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
39
5-2. UTP Cable / RJ-45 Jack Definition
Straight through twisted pair cable is typically used to connect a hub to a server or
workstation. In a straight through connection, Pin 1 at the server, Pin 2 at the hub connects
to Pin 2 at the server, and so on. Figure A-1 shows the locations of pins on a standard RJ-45
plug on a twisted-pair cable.
Table A-1 shows the wiring in a straight-through twisted-pair cable (Pins 4, 5, 7 and 8 are not
used).
Twisted Pair
Number Pin Number Signal Description To Pin Number Signal Description
1 1
2 TD+ TD– Æ1 2 TD+ TD–
2 3
6 RD+ RD– Æ3
6 RD+ RD–
Table A-1
Figure A-1
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
40
5-3. Connecting 100Base-TX Fast Ethernet Network
To connect the adapter to 100Base-TX Fast Ethernet Network, you need a twisted-pair
Category 5 cable with RJ-45 modular jacks at both ends. This cable can have a maximum
length of 300 feet (100 meters).
5-4. Remote BOOT ROM function
This function is available with the BIOS programming for indicated operation system. The
remote boot function allows the computer to boot up over the network, instead of using the
local operating system device. This enables the system to be a diskless workstation
environment.
