QUICK REFERENCE GUIDE [1]
www.uniden.com
Step 1 Checking the Package Contents
Make sure your cordless phone‘s packaging includes the
following items (the number of items may vary depending on
model number within the series).
If any of these items are missing or damaged, contact the
Uniden Parts Department.
•Base Unit
•Handset(s)
•AC Adapter(s)
• Rechargeable Battery Pack(s)
• Telephone Cord
•Belt Clip(s)
• Owner's Manual
• Other Printed Materials
Uniden Parts Department at [phone]
Hours: M-F 8:00 a.m. to 5:00 p.m. CST.
or visit our website at
www.uniden.com for replacement parts.
Step 2 Install and Charge the Handset Battery
TO INSTALL THE HANDSET BATTERY
(see page 12 for details)
Charge the handset battery pack
for at least 15-20 hours before
using your new cordless telephone
for the first time!
Use only the Uniden rechargeable
battery pack supplied with your
new phone.
Remove the cover.
Connect the battery pack
connector with the correct
polarity and listen for a
click to insure connection.
Replace the cover.
Use only the Uniden AC adapter
supplied with your new phone.
Plug the AC adapter
cord into the base
unit and then into a
120V AC outlet.
Place the handset in
the base and charge
continuously for
15 - 20 hours before
using the phone.
QUICK REFERENCE GUIDE
UP01317BA0.book1ページ２００３年１０月３０日 木曜日 午前１０時４５分

[2] QUICK REFERENCE GUIDE
www.uniden.com
Step 3 Connect to Phone Line
When the handset battery pack is fully charged (after 15-20
hours of charging), plug the telephone cord into the base unit
and then into a telephone wall jack.
Your phone is set for tone dialing. If your local network
requires pulse dialing, please see “D. Choose the dialing mode”
on page 15.
Step 4 Setting Caller ID & Language Display Options
TO SET CALLER ID ON CALL WAITING AND CALL
WAITING DELUXE
For all Handset Menu Setup options, refer to page 21.
Press menu/del in standby mode.
Press ring/vol/∧or ring/vol/∨to select
Global
Setup
and then select/.
Press ring/vol/∧or ring/vol/∨to select
CIDCW and
then select/.
Press ring/vol/∧or ring/vol/∨to select
CW On/CWDX
On
, CW On/CWDX Off , or CW Off/CWDX Off and
then select/.
TO SET LANGUAGE
Press menu/del in standby mode.
Press ring/vol/∧or ring/vol/∨to select
Handset
Setup
and then select/.
Press ring/vol/∧or ring/vol/∨to select
Language
and then select/.
Press ring/vol/∨to choose a language
and then select/.
UP01317BA0.book2ページ２００３年１０月３０日 木曜日 午前１０時４５分

Guía de referencia rápida [3]
www.uniden.com
Negro
Rojo
Negro Rojo
1° Paso Inspección del contenido del embalaje
Asegúrese de que haya recibido los siguientes artículos en el
paquete (la cantidad de artículos puede variar dependiendo del
número del modelo dentro de la serie). Si alguno de estos
artículos falta o está dañado, comuníquese con el departamento
de partes de Uniden.
•Base
• Receptor(es)
• Adaptador(es) CA
• Paquete(s) de pilas recargable(s)
• Cable telefónico
• Pinza(s) para la correa
• Manual para el usuario
• Otros impresos
Uniden Parts Department
Teléfono: [phone]
Horas: de Lunes a Viernes desde las 8 a.m. hasta las 5:00
p.m., hora central
O visítenos en nuestra página Web en www.uniden.com
para conseguir las partes de reemplazo.
2° Paso Instalación y carga de la pila para el receptor
Para instalar la pila del receptor
(Consulte la página 12 para más detalles)
Cargue el paquete de batería to pila
por lo menos de 15 á 20 horas antes
de conectarlo a una línea telefónica.
Use solamente el paquete de pilas
recargable de Uniden suministrado
con su nuevo teléfono.
Quite la tapa.
Conecte el enchufe del
paquete de las pilas con la
polaridad correcta y
escuche por un clic para
asegurar la conexión.
Reponga la tapa.
Use solamente el adaptador CA
de Uniden suministrado con su
nuevo teléfono.
Conecte el cable del
adaptador CA en la base
y luego en una toma CA
de 120 V.
Antes de usar el
teléfono, coloque el
receptor en la base y
cárguelo continuamente
por 15–20 horas.
Guía de referencia rápida
Al enchue CA
Al CC IN 9V
Adaptador CA
(suministrado)
Enrolle el cable.
UP01317BA0.book3ページ２００３年１０月３０日 木曜日 午前１０時４５分

[4] Guía de referencia rápida
www.uniden.com
3° Paso Conexión a la línea telefónica
Cuando el paquete de pilas del receptor esté totalmente cargado,
después de una carga de 15-20 horas, conecte el cable telefónico
en la base y luego en el enchufe telefónico de la pared.
Su teléfono está programado para marcar por tono. Si su red
local requiere la marcación por pulso, por favor consulte "D.
Selección del modo de marcación" en la página 15.
4° Paso Programación de las opciones de identificación
de llamadas y del lenguaje en la pantalla
Para programar las opciones de identificación
de llamadas de llamadas en espera y llamada en
espera de lujo
Para todas las demás opciones de programación en el menú,
consulte la página 21.
Oprima menu/del en el modo de espera.
Oprima ring/vol/∧o ring/vol/∨para seleccionar la
Progr global , y luego select/.
Oprima ring/vol/∧o ring/vol/∨para seleccionar
CIDCW , y luego select/.
Oprima ring/vol/∧o rring/vol/∨para seleccionar
CW
Act/CWDX Act
, CW Act/CWDX Apg , o CW Apg/CWDX
Apg
, y luego select/.
Para programar el lenguaje
Oprima menu/del en el modo de espera.
Oprima ring/vol/∧o ring/vol/∨para seleccionar la
Progr receptor , y luego select/.
Oprima ring/vol/∧o ring/vol/∨para seleccionar el
Lenguaje , y luego select/.
Oprima ring/vol/∨para escoger el lenguaje,
y luego select/.
Al enchufe Telefónico
Cable de línea Telefónica
A la línea Telefónica
UP01317BA0.book4ページ２００３年１０月３０日 木曜日 午前１０時４５分

[5]
www.uniden.com
QUICK REFERENCE GUIDE 1
WELCOME/FEATURES/TERMINOLOGY 6
CONTROLS AND FUNCTIONS 8
DISPLAY AND ICONS 10
GETTING STARTED 11
Setting up the Phone 11
Mounting the Base Unit on a Wall 16
About the Menu Options 18
Setting up the Menu 21
BASICS 28
Making and Receiving Calls 28
Placing a Call on Hold 29
Redialing a Call 30
Adjusting the Handset Ringer, Earpiece and Speaker Volume 31
Mute Microphone 32
Tone Dialing Switch-over 32
Traveling Out-of-Range 32
Clarity Booster 33
Privacy Mode 33
Find Handset 34
Flash and Call Waiting 34
Using One Touch Voice Mail Access 35
PHONEBOOK 36
Phonebook 36
Storing Phone Numbers, Names, Distinctive Rings,
and Speed Dial 36
Steps for Entering Names and Special Characters 38
Viewing the Phonebook 40
Making Calls Using the Phonebook 41
Speed Dialing 41
Editing or Erasing a Stored Name,
Phone Number, Distinctive Ring, and Speed Dial 42
Chain Dialing 43
CALLER ID 44
Caller ID and CIDCW (Caller ID on Call Waiting) 44
Viewing the Caller ID List 45
Deleting a Caller ID Message 46
Using the Caller ID Message List 47
Call Waiting Deluxe Features 48
EXPANDING YOUR PHONE 49
Expanding Your Phone 49
Connecting the Charger 49
Register the Handset to the Base 50
Using the DirectLink Mode 51
Room Monitor 51
3-Way Conferencing 52
Intercom/Call Transfer Feature 52
Replacing the Base 53
ADDITIONAL INFORMATION 54
Changing the Digital Security Code 54
Installing the Beltclip 54
Headset Installation 54
Note on Power Sources 55
Maintenance 55
General Information 56
TROUBLESHOOTING 57
Liquid Damage 59
PRECAUTIONS & WARRANTY 60
I.C. NOTICE 62
INDEX 63
MEMORY LIST 64
Contents
UP01317BA0.book5ページ２００３年１０月３０日 木曜日 午前１０時４５分

[6] WELCOME/FEATURES/TERMINOLOGY
www.uniden.com
Congratulations on your purchase of the Uniden Multi-Handset Cordless System telephone. This
unit is different from conventional cordless telephones. When the base unit is connected to AC
power and a telephone line, it can support up to 4 handsets. Using extra handsets, you can
establish a 3-way conference call (2 handsets and an outside line), while two other handsets are
making an intercom call. You can now place a fully featured cordless handset anywhere in your
home or office where AC power is available to connect the handset chargers.
Note: Some illustrations in this manual may differ from the actual unit for
explanation purposes.
As an Energy StarPartner, Uniden has determined that this product or product
models meets the Energy Starguidelines for energy efficiency.
Energy Staris a U.S. registered mark.
Note: Energy Starapplies to DCT646 only.
• 2.4GHz Frequency Hopping Spread Spectrum
• 4 Multi-Handset Expandability
• Hands Free Speakerphone in the Handset
• Call Waiting Deluxe
• Caller ID/Caller ID On Call Waiting
• 100 Dynamic Memory Location (Phonebook & Caller ID)
• Trilingual Handset Display Menus (English, French, and Spanish)
• Call Transfer between Handsets
• 20 Distinctive Ring Options (10 ringer tones and 10 melody ringers)
• Mute Feature
• Flash and Pause
• 88 Channel Auto Scan
• DirectLinkMode
• Voice Mail Access
• Room Monitoring Feature
• Battery Level Indicator
• Clock Display
WELCOME/
FEATURES/
Welcome
Features
UP01317BA0.book6ページ２００３年１０月３０日 木曜日 午前１０時４５分

WELCOME/FEATURES/TERMINOLOGY [7]
www.uniden.com
This series features include AutoTalkand AutoStandby. AutoTalk allows you to answer a call by just removing
the handset from the cradle so you don't have to waste time pushing buttons. AutoStandby allows you to hang up by
simply returning the handset to the cradle.
To protect you against mis-billed calls, which might result from your phone being activated by other equipment, this
series has Random Codedigital security, which automatically selects one of over approx. 130,000 digital security
codes for the handset and base.
Frequency Hopping Spread Spectrum (FHSS) technology improves calling range and clarity, and eliminates cross talk.
Because it rapidly changes transmission frequencies within the 2.4GHz bandwidth, this cordless phone helps reduce
the possibility of eavesdropping.
DirectLink mode is used when you have 2 or more handsets. You can use your handsets as transceivers.
Be sure to visit our web site: www.uniden.com
Unidenis a registered trademark of Uniden America Corporation.
AutoTalk, AutoStandby, DirectLink, and Random Code are trademarks of Uniden America.
Terminology
•Standby Mode - The handset is not in use and talk/flash has not been pressed.
•Talk Mode - The handset is not in the cradle and talk/flash or speaker has been pressed enabling a dial tone.
Talk
appears on the display.
WELCOME/
FEATURES/
UP01317BA0.book7ページ２００３年１０月３０日 木曜日 午前１０時４５分

[8] CONTROLS & FUNCTIONS
www.uniden.com
Controls & Functions
1. Handset Antenna
2. Headset Jack Cover
3. Beltclip Hole
4. Hands-Free Speaker
5. Handset Battery Compartment
6. New Message LED
7. Handset Earpiece
8. LCD Display
9. Menu/del (delete) Key (P. 21 / P. 30, 42, 46)
10. (ring)/vol(volume)and∧/∨(P.31/P.21)
a. ringer and volume control b. scroll keys for display screen
11.
*
/tone/←Key (P. 22 / P. 32 / P. 39)
12. redial/pause Key (P. 30/ P. 28)
13. speaker Key (P. 28)
14. Select/(voice mail) Key (P. 21 / P. 35)
15. Call id (Caller ID) key (P. 45)
16. End Key (P. 28)
17. Talk/flash Key (P. 28 / P. 34)
18. #/→Key (P. 22 / P. 39)
19. (Phonebook) Key (P. 36)
20. Hold/transfer/int'com (Intercom) Key (P. 29 / P. 53 / P. 52)
21. Handset Microphone
22. Handset Charging Contacts
2
1
3
5
4
6
7
8
9
11
12
22
14
13
18
19
16
15
20
21
17
10
