One Year Limited Warranty
WARRANTOR: UNIDEN AMERICA CORPORATION (“Uniden”)
ELEMENTS OF WARRANTY: Uniden warrants, for one year, to the
original retail owner, this Uniden Product to be free from defects in
materials and craftsmanship with only the limitations or exclusions set
out below.
WARRANTY DURATION: This warranty to the original user shall
terminate and be of no further effect 12 months after the date of original
retail sale. The warranty is invalid if the Product is (A) damaged or not
maintained as reasonable or necessary, (B) modified, altered, or used
as part of any conversion kits, subassemblies, or any configurations not
sold by Uniden, (C) improperly installed, (D) serviced or repaired by
someone other than an authorized Uniden service center for a defect or
malfunction covered by this warranty, (E) used in any conjunction with
equipment or parts or as part of any system not manufactured by
Uniden, or (F) installed or programmed by anyone other than as
detailed by the Operating Guide for this product.
STATEMENT OF REMEDY: In the event that the product does not
conform to this warranty at any time while this warranty is in effect,
warrantor will repair the defect and return it to you without charge for
parts, service, or any other cost (except shipping and handling) incurred
by warrantor or its representatives in connection with the performance
of this warranty. THE LIMITED WARRANTY SET FORTH ABOVE IS
THE SOLE AND ENTIRE WARRANTY PERTAINING TO THE
PRODUCT AND IS IN LIEU OF AND EXCLUDES ALL OTHER
WARRANTIES OF ANY NATURE WHATSOEVER, WHETHER
EXPRESS, IMPLIED OR ARISING BY OPERATION OF LAW,
INCLUDING, BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
THIS WARRANTY DOES NOT COVER OR PROVIDE FOR THE
REIMBURSEMENT OR PAYMENT OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES. Some states do not allow this exclusion
or limitation of incidental or consequential damages so the above
limitation or exclusion may not apply to you.
LEGAL REMEDIES: This warranty gives you specific legal rights,
and you may also have other rights which vary from state to state.
This warranty is void outside the United States of America.
PROCEDURE FOR OBTAINING PERFORMANCE OF WARRANTY:
If, after following the instructions in this Operating Guide you are certain
that the Product is defective, pack the Product carefully (preferably in its
original packaging). Include evidence of original purchase and a note
describing the defect that has caused you to return it, The Product
should be shipped freight prepaid by traceable means, or delivered,
to warrantor at:
Uniden America Corporation
BCS-Repair
4700 Amon Carter Blvd.
Fort Worth, TX 76155
800-235-3874, 8 a.m. to 5 p.m. Central,
Monday through Friday
2
Y:...ANA9310 om.vp
Tue Dec 03 14:42:50 2002
Color profile: Disabled
Composite Default screen

PRECAUTIONS
Before you read anything else,
please observe the following:
WARNING!
Uniden America Corporation DOES NOT represent this unit
to be waterproof. To reduce the risk of fire, electrical shock,
or damage to the unit, DO NOT expose this unit to rain or
moisture.
Precautions!
Before you read anything else, please observe the
following:
Rechargeable Nickel-Metal-Hydride Battery
Warning
nThis equipment contains a Rechargeable Nickel-
Metal-Hydride battery.
nThe rechargeable Nickel-Metal-Hydride battery
contained in this equipment may explode if
disposed of in a fire.
nDo not short-circuit the battery.
nDo not charge the Rechargeable Nickel-Metal-
Hydride battery used in this equipment in any
charger other than the one designed to charge
this battery as specified in the owner’s manual.
Using another charger may damage the battery,
or cause the battery to explode.
Rechargeable Nickel-Metal-
Hydride Batteries Must Be
Disposed of Properly
Ni-MH
5
Y:...ANA9310 om.vp
Tue Dec 03 14:42:53 2002
Color profile: Disabled
Composite Default screen

Handset Controls & Functions
1. Headset Jack
2. Display
3. Hold (
hold ) Key
4. Talk (
TALK ) Key
5. Numeric Keypad
6. Pause (
pause ) Key
7. Redial (
redial ) Key
8. Microphone
9. Transfer (
xfer ) Key
10. Conference (
conf ) Key
11. Channel (
CH ) Key
12. Flash (
flash ) Key
13. Search (
search ) Key
14. Memo (
memo ) Key
15. Volume (
RING/VOL ) Key
16. Ringer On/Off & Mic Mute
(
ON/OFF MUTE ) Key
4
3
5
6
8
7
1
29
13
10
12
11
14
15
16
6
Y:...ANA9310 om.vp
Tue Dec 03 14:42:57 2002
Color profile: Disabled
Composite Default screen

Base Unit Controls & Functions
18. Hold ( hold ) Key
19.
Hold LED
20.
Status LED
21.
Page LED
22. Page/find (
page/find ) Key
19
18
21 2220
7
Y:...ANA9310 om.vp
Tue Dec 03 14:42:59 2002
Color profile: Disabled
Composite Default screen

Uniden®is a registered trademark of Uniden America Corporation.
AutoStandby™and AutoTalk™are trademarks of Uniden America Corporation.
AutoStandby is a patented invention of Uniden America Corporation.
1
TABLE OF CONTENTS
Important Safety Instructions ...............................................2
About Your ANA 9310 .....................................................4
Important Electrical Considerations .........................................5
Range ...............................................................5
Telephone Line Problems ................................................5
Radio Interference ......................................................6
More Than One Cordless Telephone .......................................6
Privacy ...............................................................6
ANA 9310 Features .......................................................7
Installing Your ANA 9310 ..................................................8
Selecting the Installation Location ..........................................8
Connecting the Telephone Line............................................8
Connecting the Telephone Cords ..........................................9
Tone/Pulse Switch .....................................................10
Applying Power to the Base and Charger Units ..............................10
Wall Installation .......................................................12
Attaching the Belt Clip to the Handset ......................................17
Installing the Handset Battery Pack........................................18
Charging the Handset Battery Pack .......................................19
Low Battery Indicator ...................................................20
Cleaning Charging Unit Contacts .........................................20
Using Your ANA 9310 Handset ............................................21
ANA 9310 Handset Controls .............................................21
Using the Handset .....................................................24
Answering a Call ......................................................25
Making a Call .........................................................25
Feature Buttons .........................................................26
Placing a call “on hold”.................................................26
Transferring a Call .....................................................26
Connecting a Conference Call............................................26
Programming the Feature Buttons.........................................27
Function Keys ..........................................................28
Using Your ANA 9310 Memory .............................................29
Storing a Number......................................................29
Erasing a Stored Number ...............................................30
Dialing a Stored Number ................................................31
Memory Search .......................................................31
Chain Dialing .........................................................32
Using Your ANA 9310 Base Unit ...........................................33
Using the Hold ........................................................33
Using the Page/Find ...................................................33
Optional Headset (EXP9730/9530) ..........................................34
Using an Optional Second 2500-type Analog Telephone .......................35
Connecting the Desk Telephone. .........................................35
Transferring a Call to the ANA 9310........................................35
Transferring a Call to the Desk Telephone ..................................35
Typical Applications ....................................................36
Optional Accessories and Replacement Parts ................................37
Troubleshooting.........................................................38
Specifications...........................................................39
9
Y:...ANA9310 om.vp
Tue Dec 03 14:43:01 2002
Color profile: Disabled
Composite Default screen

Important Safety Instructions
When using your telephone equipment, basic safety precautions
should always be followed to reduce the risk of fire, electrical
shock, and injury to persons, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a dry
cloth for cleaning.
4. Do not use this product near water; for example, near a sink
or in a wet area.
5. Do not place this product on an unstable cart, stand,
or table. The telephone may fall, causing serious damage
to the unit.
6. To protect the product from overheating, do not block or
cover any slots or openings in the base Unit. This product
should never be placed near or over a radiator or heat
register. This product should not be placed in a built-in
installation unless proper ventilation is provided.
7. This product should be operated only from the type of power
source indicated on the marking label.
8. Do not allow anything to rest on the power cord. Do not
locate this product where the cord will be damaged by
persons walking on it.
9. Do not overload wall outlets and extension cords, as this
can result in the risk of fire or electrical shock.
10. Never push objects of any kind into this product through the
Base Unit slots, as they may touch dangerous voltage points
or short out parts that could result in a risk of fire or electric
shock. Never spill liquid of any kind on the product.
11. To reduce the risk of electric shock, do not disassemble this
product. Contact qualified service personnel when some
service or repair work is required. Opening or removing
covers may expose you to dangerous voltages or other risks.
Incorrect reassembly can cause electric shock when the
appliance is subsequently used.
12. Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
A. When the power supply cord is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
2
10
Y:...ANA9310 om.vp
Tue Dec 03 14:43:01 2002
Color profile: Disabled
Composite Default screen

D. If the product does not operate normally when following the
operating instructions. Adjust only those controls that are
covered by the operating instructions. Improper adjustment
of other controls may result in damage, and will often require
extensive work by a qualified technician to restore the
product to normal operation.
E. If the product has been dropped, or the cabinet has
been damaged.
F. If the product exhibits a distinct change in performance.
13. Do not use the telephone to report a gas leak in the vicinity
of the leak.
CAUTION: To reduce the risk of fire or injury to persons by the
battery, read and follow these instructions:
1. Use only the appropriate type and size Battery Pack specified
in this Operating Guide.
2. Do not dispose of the Battery Pack in a fire. The cell
may explode.
3. Do not open or mutilate the Battery Pack. Released electrolyte
is corrosive and may cause damage to the eyes or skin. It may
be toxic if swallowed.
4. Exercise care in handling the battery in order not to short the
battery with conducting materials such as rings, bracelets, and
keys. The battery or conductor may overheat and cause burns.
5. Charge the Battery Pack provided with or identified for use
with this product only in accordance with the instructions and
limitations specified in the instruction manual provided for
this product.
6. Observe proper polarity orientation between the Battery Pack
and battery charger.
SAVE THESE INSTRUCTIONS
3
11
Y:...ANA9310 om.vp
Tue Dec 03 14:43:02 2002
Color profile: Disabled
Composite Default screen

About Your ANA 9310
Congratulations on your purchase of the Uniden ANA 9310
Cordless Telephone. The ANA 9310 is designed and engineered
to exacting standards for reliability, long life, and outstanding
performance. It is designed to work with a PBX system. To get the
most from your ANA 9310, please read this Operating Guide
thoroughly. To help familiarize you with the features of your cordless
phone, refer to the Handset illustration foldout from the front cover,
and the Base Unit illustration foldout from the rear cover.
Your ANA 9310 includes the following items:
If any of these items are missing or damaged, contact your PBX
Administrator. If your ANA 9310 is not performing to your
expectations, please try the simple steps listed in the Trouble
shooting section of this Guide. If you are still unable to resolve
the problem, contact your PBX Administrator.
4
Base Unit Handset Telephone Cord
2 AC Adapters
Rechargeable
Battery (BT930) Belt Clip (EXP9302)
Charging Unit Operating Guide
(OM9310)
Wall Plate Adapter
Charging Unit
Wall Mount (EXP9360)
12
Y:...ANA9310 om.vp
Tue Dec 03 14:43:17 2002
Color profile: Disabled
Composite Default screen

Important Electrical Considerations
Warning: Please do not attempt to unplug any appliance
during an electrical storm.
Unplug all electrical appliances when you know an electrical storm is
approaching. Lightning can pass through your household wiring and
damage any device connected to it. This phone is no exception.
Caution: Changes or modifications to this product not
expressly approved by Uniden, or operation of this
product in any way other than as detailed by this
Operating Guide, could void your authority to operate
this product.
Range
Your new phone is designed to achieve the maximum possible range
by transmitting and receiving according to the highest specifications set
forth by the FCC and IC. We have rated this phone to operate at a
maximum distance with the qualification that the range depends upon
the environment in which the telephone is used. Many factors limit
range, and it would be impossible to include all the variables in our
rating. The Maximum Range rating of this phone is meant to be used
as a means of comparison against other range claims.
Telephone Line Problems
The FCC and IC have granted the telephone company the right to
disconnect service in the event that your phone causes problems on
the telephone line. Also, the telephone company may make changes
in facilities and services which may affect the operation of your unit.
However, your telephone company must give adequate notice in
writing prior to such actions to allow you time for making necessary
arrangements to continue uninterrupted service.
If you are having trouble with your telephone service, you must first
disconnect your phone to determine if it is the cause of your problem.
If you determine that it is the cause, you must leave it disconnected
until the trouble has been corrected.
5
13
Y:...ANA9310 om.vp
Tue Dec 03 14:43:18 2002
Color profile: Disabled
Composite Default screen

Radio Interference
Radio interference may occasionally cause buzzing and humming
in your cordless Handset, or clicking noises in the Base Unit.
This interference is caused by external sources such as a TV,
refrigerator, vacuum cleaner, fluorescent lighting, computer
equipment, or electrical storm. Your unit is NOT DEFECTIVE.
If these noises continue and are too distracting, please check
around your office to see what appliances may be causing the problem.
In addition, we recommend that the Base not be plugged into a
circuit that also powers a major appliance because of the potential
for interference. Be certain that the antenna on the unit is fully
extended when needed.
In the unlikely event that you consistently hear other voices or
distracting transmissions on your phone, you may be receiving
radio signals from another cordless telephone or other source of
interference. If you cannot eliminate this type of interference, you
need to change to a different channel.
Finally, it should be noted that some cordless telephones operate
at frequencies that may cause interference to nearby TVs and
VCRs. To minimize or prevent such interference, the base of the
cordless telephone should not be placed near or on top of a TV
or VCR. If interference is experienced, moving the cordless
telephone farther away from the TV or VCR will often reduce or
eliminate the interference.
More Than One Cordless Telephone
If you want to use more than one cordless telephone in your office,
they must operate on different channels. Press the channel key to
select a channel that provides the clearest communication.
Privacy
Note: Cordless phones are radio devices. Communications
between the Handset and Base Unit of your cordless telephone are
accomplished by means of radio waves which are broadcast over
the open airways. Because of the inherent physical properties of
radio waves, your communications can be received by radio
receiving devices other than your own cordless telephone unit.
Consequently, any communications using your cordless telephone
may not be private.
6
14
Y:...ANA9310 om.vp
Tue Dec 03 14:43:18 2002
Color profile: Disabled
Composite Default screen

ANA 9310 Features
nLong Range 900MHz Digital
n2-line, 16-digit LCD Display
nRinger Volume Control
nHandset Volume Control
nSingle button access to: CONFERENCE,HOLD, and
TRANSFER features
nFour Function Keys: PAUSE, FLASH, REDIAL, SEARCH
n30 Simultaneous Conversations
n20 Number Memory Store and Search
nSeparate Charging Stand
nAutoStandby
nAutoTalk
nVibrator Ringer Alert
nEasy Installation
nOut of Range Protection
nLow Battery Protection System
nWall Mountable separate Base Unit
nWall Mountable separate Charging Unit
nHeadset Jack (2.5mm)
7
15
Y:...ANA9310 om.vp
Tue Dec 03 14:43:18 2002
Color profile: Disabled
Composite Default screen

Installing Your ANA 9310
Selecting the Installation Location
Select a location for the ANA 9310 to avoid excessive heat or
humidity. The Base Unit of your ANA 9310 can be placed on a
desk or tabletop near a standard 120V AC outlet and telephone
line jack. The Base Unit can also be mounted on a standard wall
plate using the included Wall Mount Adapter. If you will use the
ANA 9310 with a Standard 2500 type Telephone Desk Unit,
place the ANA 9310 near that phone. Keep the Base Unit and
Handset away from sources of electrical noise (motors, fluorescent
lighting, computers).
Connecting the Telephone Line
There are two types of phone outlets:
1) Modular Jack
Plug the telephone line cord from the Base Unit into a standard
modular telephone jack. (Note: If you do not have a modular
jack, contact your local telephone company for information on
the installation of these jacks.)
2) Hardwired Jack
A modular jack converter (not included) is required. You may
need to rewire when connecting the converter (making color-
coded connections).
Note: Your Uniden Telephone Dealer or a telephone supply store
can advise you on the proper adapter or converter.
8
16
Y:...ANA9310 om.vp
Tue Dec 03 14:43:18 2002
Color profile: Disabled
Composite Default screen

Connecting the Telephone Cords
The ANA 9310 must be connected to an analog PBX port or a
standard analog telephone line.
CAUTION:
nNever install telephone wiring during a lightning storm.
nNever touch uninsulated telephone wires or terminals unless the
telephone line has been disconnected at the network interface.
nUse caution when installing or modifying telephone lines.
You can also connect a standard 2500-type desk phone to the
ANA 9310:
9
Connect to the LINE OUT Jack
17
Y:...ANA9310 om.vp
Tue Dec 03 14:43:21 2002
Color profile: Disabled
Composite Default screen

Tone/Pulse Switch
Be sure the TONE/PULSE switch is in the TONE position.
Note: Most systems are Tone dialing. Check with your PBX
Administrator if you are not sure whether your system
is Tone or Pulse dialing.
Applying Power to the Base and Charger Units
10
Use only the supplied AC Adapter: EXP9704
18
Y:...ANA9310 om.vp
Tue Dec 03 14:43:24 2002
Color profile: Disabled
Composite Default screen

IMPORTANT! Route the power cord where it will not create a trip
hazard, or where it could become chafed and create a fire or other
electrical hazards.
Note: If you cannot plug the AC Adapter into the outlet, contact
someone about replacing the outlet.
The unique design of your ANA 9310 allows you to place the
Handset in the Charging Unit with or without the Belt Clip attached.
Use only the supplied AC Adapter: AD-970
11
19
Y:...ANA9310 om.vp
Tue Dec 03 14:43:28 2002
Color profile: Disabled
Composite Default screen

Wall Installation
Standard Wall Plate Mounting
These Phones are designed to be mounted on a standard wall
plate. To attach the wall mount stand to the Base Unit:
1. Slide the Wall Mount stand
into the notches at the top of
the Base Unit, push the Wall
Mount stand down and snap it
into place.
2. Plug the AC Adapter into the Base Unit
as previously described.
3. Place the AC Adapter cord
inside the molded channel of
the Wall Mount stand.
4. Plug one end of the telephone cord into the LINE jack on the
Base Unit. Optionally, plug one end of a standard 2500 type
desk phone into the PHONE jack. Then place the telephone
cord(s) inside the molded channel(s) on the bottom of the Wall
Mount stand.
5. Plug the other end of the telephone cord into the modular
wall jack.
12
20
Y:...ANA9310 om.vp
Tue Dec 03 14:43:32 2002
Color profile: Disabled
Composite Default screen

6. Place the Base Unit on the posts
of the wall plate and push down
until it’s firmly seated.
7. Plug the AC Adapter into a
standard 120V AC wall outlet.
Note: Do not use an outlet controlled by a wall switch.
Direct Wall Mounting
If you do not have a standard wall plate, you can mount your phone
directly on a wall. Before mounting your phone, consider the following:
nSelect a location away from electrical cables, pipes, or other
items behind the mounting location that could cause a hazard
when inserting screws into the wall.
nMake sure the wall material is capable of supporting the weight
of the Base Unit.
nUse #10 screws with anchoring devices suitable for the wall
material where the Base Unit will be placed.
13
21
Y:...ANA9310 om.vp
Wed Dec 04 12:06:54 2002
Color profile: Disabled
Composite Default screen

1. Insert two mounting screws
3 15/16 inches apart. Allow
about 3/16 of an inch between
the wall and screw heads for
mounting the phone.
2. Plug and secure the AC Adapter cord by following steps 2 and
3oftheStandard Wall Plate Mounting.
3. Plug one end of the telephone
line cord into the LINE jack on
the Base Unit. Optionally, plug
one end of a standard 2500
type desk phone into the
PHONE jack. Then place
the telephone cord(s) inside
the molded channel(s) on
the bottom of the Wall
Mount stand.
4. Place the Base Unit on the
posts of the wall screws
and push down until it’s
firmly seated.
5. Plug the other end of the
telephone cord into a
telephone wall jack.
6. Plug the AC Adapter into a standard 120V AC wall outlet by
following step 7 of the Standard Wall Plate Mounting.
14
22
Y:...ANA9310 om.vp
Tue Dec 03 14:43:41 2002
Color profile: Disabled
Composite Default screen
