Uniden iGO CAM 755 User manual

iGO CAM 755
Accident CAM
Vehicle Recorder
For more exciting new products please visit our website:
Australia: www.uniden.com.au

NOTE
Uniden does not represent this product to be waterproof. Do not
expose this product to Rain or Moisture.
NOTE
This product is intended for use in a motor vehicle. Don’t install
the device where it will block the driver’s view of the road
(including the mirrors!) or the deployment of any airbags.
NOTE
Keep your attention on the road! Don’t try to operate or focus
on any device while driving. If you have to concentrate on a
device, pull off the road for a few minutes.
NOTE
Ensure that the camera lens is kept clean and there is nothing
blocking the lens.
NOTE
Don’t leave the device in direct sunlight for a long period of time
or where the temperature could go above 60°C.
2
UNIDEN iGO CAM 755 Vehicle Recorder
Important Safety Instructions

Important Safety Instructions ............................................. 2
What Do I Do First? ................................................................4
Make Sure These Items Arrived in the Box .................................................4
Controls & Indicators ............................................................5
How Do I Put It in My Car? .................................................... 7
Attaching the Windshield Mount ..................................................................7
Operation .............................................................................. 8
Micro SD Card .......................................................................................................8
Plug it in, Power On/O .................................................................................... 9
Record Mode ......................................................................................................10
Photo Mode ....................................................................................................... 14
Playback Mode ................................................................................................. 14
Connecting to a PC .......................................................................................... 15
iGO CAM Player ................................................................................................. 15
Special Features .................................................................................................17
Important Information ................................................................................... 19
Warranty ..............................................................................20
3
UNIDEN iGO CAM 755 Vehicle Recorder
Contents

4
UNIDEN iGO CAM 755 Vehicle Recorder
Make Sure These Items Arrived in the Box
What Do I Do First?
DC (CAR) Adaptor
• If any item is missing or damaged, contact your place of purchase
immediately. Never use damaged products!
• Need help? Get answers at our website:
www.uniden.com.au for Australian model.
• Owner’s Manual
Windshield Mount (with
built-in GPS antenna)
iGO CAM 755
USB Cable

Controls & Indicators
Ref Component Description
1HDMI HDMI output. Connect using an HDMI cable (not
provided).
2Bracket Slot Use to insert the windshield mount.
3USB/DC IN • Connect to External Power & charge battery.
• Connect to PC for data (SD card) transfer.
4GPS Port Use to connect the external GPS antenna (included).
UNIDEN iGO CAM 755 5Vehicle Recorder

6Vehicle RecorderUNIDEN iGO CAM 755
5Power LED
indicator
Glows red when the unit is turned on.
Glows blue when charging.
6Micro SD
Card Slot
Use this slot to insert the micro SD card.
7Mic Records Sound.
8 SOS button Presstomanuallylockles.
9 LCD Display
10 Power • Press to power on the unit.
• Press and hold to power off the unit.
11 LEFT Function varies with different screens/modes.
• In Menu list, move the cursor, one line up.
• In the Record Mode, press to turn on/off the
audio.
12 MENU Depending on the mode, press to open the Record/
Photo/Playback Menu.
Press again to open Settings Menu.
Press once more to exit the Menu Settings.
13 OK Acts as an ENTER key
• In Record mode, press to start or stop video
recording.
• In Photo mode, press to take a photo.
• InPlaybackmode,presstoselectaletoview.
• PresstoconrmaselectionintheMenu.
• Presstoconrmachangeinthesettings.
14 MODE • Use this button to switch between various modes -
Record, Photo and Playback.
15 RIGHT In Menu list, move the cursor, one line down.
16 RIf the device fails to operate properly, try resetting the
device.Presstheresetbuttonbyusinganepenor
paperclip.
17 Speaker
18 Camera Lens

7
UNIDEN iGO CAM 755 Vehicle Recorder
Attaching the Windshield Mount
How Do I Put It in My Car?
3.Pressthesuctioncupatagainstthewindshieldandrotatethesuctionlock
clockwise to secure the unit in place.
NOTE
Suction cups will not stick well on a curved/textured or wet surfaces.
4. Gently pull on the mount to make sure it is secure.
5. To remove the unit (including the windshield mount), rotate the suction lock
anti-clockwise and gently pull out the suction cup. To detach the unit from
the windshield mount pull the lever up and gently pull the unit out.
It maybe a good idea to secure the power cord with cable clips so that it does
not interfere while driving.
Avoid rotating the unit at 360° as it might damage the cabling inside.
1. Slide the bracket hook into the bracket slot provided on the top of the unit.
2. After inserting the hook, push it down till it locks in position.

Micro SD Card
NOTE
A compatible micro SD card has to be inserted before you start
using the unit. Ensure that the unit is turned off before inserting
or removing the micro SD card.
The unit can support micro SDHC cards (High Capacity SD) up to 64GB in
capacity. A micro SDHC card of at least 8GB capacity and minimum speed of
Class 10 is recommended.
Insert a formatted micro SD card gently in the slot at the side of the unit. To
remove the card from the slot, press the edge of the micro SD card inwards
for it to pop out and then pull it out of the slot.
It is important to format the micro SD card before using it, so as to avoid any
damagetothelescreatedoniGOCAM755.
Uniden recommends using good quality micro SD cards.
Operation
8Vehicle RecorderUNIDEN iGO CAM 755
Battery Information
The unit has an in-built battery of 250mAh capacity.
The iGOCAM 755 is designed mainly for in-vehicle use, drawing on vehicle
power and the duration of portable use is limited by the settings and the
battery operating time.
The unit will charge the battery whenever power is detected through the USB/
DC IN port on the unit or on the bracket.
The unit will take around 3-4 hours to charge completely.
NOTE
Please ensure that the battery is fully charged before using it
forthersttime.Toextendthebatterylife,chargetheunitfully
once every 3 months.

Plug it in, Power On/Off
NOTE
When connected to a car charger with power, the unit will power
on automatically and start recording.
Connect the DC car adaptor to the power connector (USB/DC IN port)
found on the device.
Connect the other end of the DC car adaptor to your car’s cigarette lighter.
When connected to the car charger the unit will power on automatically
and start recording. When the car’s engine is turned off, the unit will
automatically turn off.
To manually turn the unit on press the POWER button, to turn off press and
hold the POWER button for 2-3 seconds.
The GPS icon on the screen:
-ashesredwhentheunithasn’tdetectedtheGPSsignal
- glows blue when the unit has detected the GPS signal.
- remains gray when the unit is not connected to the GPS antenna.
NOTE
Only use the DC car adaptor that comes with your device. Any
other adaptor might damage the device.
Full Half full Low Empty
9
UNIDEN iGO CAM 755 Vehicle Recorder
Battery Alert
The image given below indicates the battery level at different stages.
The GPS icon on the screen:
-ashesredwhentheunithasn’tdetectedtheGPSsignal

10
UNIDEN iGO CAM 755 Vehicle Recorder
Record Mode
NOTE
To record a video, ensure that a valid micro SD card is inserted
in the given slot. Though this unit has an internal memory, we
recommend that you use a valid micro SD card to record videos.
Using the iGO CAM 755 you can record videos and take photos. To record
videos, you need to ensure that the unit is in the Record mode.
Press the MODE button to switch between Record, Photo and Playback
modes.
When connected to a car charger with power, the unit automatically goes into
the record mode and starts recording.
Aashingreddotappearsatthetoprighthandofthescreenindicatingthat
the unit is recording. To stop recording, press OK and the red dot disappears,
indicating that the recording has stopped.
Recording
Protect the Current Recording
While recording, if you want to protect the current recordings, then press the
SOS button, the icon will appear on the screen. This indicates that those
recordings have been locked and will not be overwritten by new video clips.
Menu Settings
NOTE
Please note, you cannot access MENU in the record mode,
when the unit is recording. To access the Menu settings, you will
need to stop recording.
Press MENU to open the Record Menu. Press MENU again to open the
Settings Menu. Press MENU once more to exit from the Menu settings.
The Left/Right keys can be used to scan through the options, under each
menu setting. Press OK to select the required option.

In the Record mode, press MENU to open the Record Menu.
Item Description
Resolution Set the recording resolution. The options available
are, 2560x1080 30P, 2304x1296 30P, 1920x1080
30P, HDR_1920x1080 30P, 1280x720 60P and
1280x720 30P
Image Quality Choose between the options - Super Fine, Fine,
Normal-todenethedetailintherecordings.
Time Lapse Time Lapse setting helps you compress a long
recording to just under a few seconds. By default, the
option is turned off.
The options available are Off, Intelligent mode,
0.2sec, 0.5sec, 1sec, 5sec and 30sec.
For example, if you opt for 5sec, then an image is
captured every 5 seconds. The captured images
are then stitched together to playback a high speed
video.
If you opt for Intelligent mode, the unit will switch
to normal recording when it detects movement.
However, if no movement is detected for around 3
minutes, then the unit will switch back to time lapse
recording.
Metering Mode This setting allows you to record better videos or
capture better images by controlling the manner in
which the camera determines the exposure.
Anti-Flicker Change depending on the electrical power frequency
in your area (Default setting is 50Hz and you may not
have to change this setting).
Stamp Opt to have the date, time and car plate number
displayed on the recordings.
Loop Record Use this option to set the length of each video clip. If
you choose the option ‘Off’ then the recorder will not
looprecordandtheleswillnotbeoverwrittenon
the micro SD card.
11
UNIDEN iGO CAM 755 Vehicle Recorder
Record Menu

12 Vehicle RecorderUNIDEN iGO CAM 755
ADAS Detect ADAS (Advanced Driver Assistance System)
includes the four functions detailed below:
1. Lane Departure Warning System (LDWS) - This
option alerts you when the vehicle is moving into
another lane.
2. Front Collision Warning System (FCWS) - This
option alerts you when it detects a possible front
collision.
3. Front Vehicle Moving Detection (FVMD) - At the
trafclightswhenthevehicleinfrontmoves,this
option will alert you.
4. Low Light Warning System (LLWS) - This option
alerts you in low light environment.
However, this option will not function when the speed
displayorthetrafccameraalertisturnedon.
The ADAS detect feature will not work under the
following resolutions; 2304x1296 30P and HDR
1920x1080 30P
ADAS Calibration The ADAS Detect feature requires correct calibration
to capture road markings. Adjust the sensor lines to
encompass only the area of the display where road
markings can be seen (Page 17).
G Sensor Thisfunctionshelpsprotect/lockvideolesincase
of a sudden movement/collision. You can change the
sensitivity level of the G-sensor.
Motion Detection Enable this setting to allow the unit to record only
when it detects movement.
MIC Opt to turn on or off the audio for the recordings.
Park Mode When the car engine and the unit is turned off, this
mode enables the unit to turn back ON automatically
and create a 30sec locked recording when G Sensor
picksupvibration.Unitmusthavesufcientbattery
power remaining in order to record. The G Sensor
must also be turned on.
Live View Choose to either have LIVE view or the speedometer
displayed on the LCD.

Depending on the mode, press MENU to open the Record/Photo/Playback
Menu. Press MENU again to open Settings Menu.
Please Note: Settings Menu is common to all the 3 modes.
Language Set the language.
SD Card Capacity Indicates the capacity of the inserted micro SD
card.
Car Plate Stamp Enter the details of your car plate number. Use the
Left/Right keys to select a number or an alphabet
andpressOKtoconrmandmovetothenext
character.
Date&Time Use the Left/Right and the OK buttons to set the
date and time.
Time Zone Set Default is +10.
Format Use this option to format the micro SD card.
Default Use to change the settings to the default factory
settings.
Auto Power Off Enable the unit to shut down when it is not
recording.
LCD Off Opt to turn off the LCD to save power.
Delay Power Off Use this option to keep the unit on for 15secs,
30secs or 1minute even after being disconnected
from external power.
Key Tone Enable or disable this feature to sound a tone or go
mute when you press the keys.
TrafcCameraAlert Please refer to page 17.
Over Speed Alert Enable this option to receive alerts when over the
selected speed limit.
Version Firmware version
Settings Menu
13 Vehicle RecorderUNIDEN iGO CAM 755

14
UNIDEN iGO CAM 755 Vehicle Recorder
Photo Mode
• Press the MODE button to switch to the photo mode, the icon will
display on the top left corner of the screen.
• Now, press the OK button to take a photo.
In the Photo mode, press MENU to open the Photo Menu. Press MENU
again to open the Settings Menu. Press MENU once again to exit the Menu
settings. The Left/Right keys can be used to scan through the options, under
each menu setting. Press OK to select the required option.
In the Photo mode, press MENU to open the Photo Menu.
Item Description
Photo Resolution Set the image resolution. The options available are
- 4M, 9M, 13M, 16M.
Image Quality Choose between the options - Super Fine, Fine,
Normal-todenethequalityoftheimages.
Stamp Opt to have the date, time and car plate number
displayed on the images.
Playback Mode
Press the MODE button to switch to the playback mode.
Press Menu, the Playback Menu will open with the following two options
displayed on the screen.
Playback Mode:
Select this option to play back or repeat one or all of the recorded videos
Delete File
PressOKtoselectaparticularleandthenpressMenutorevealtheoptions,
Deletethisle,Deleteallles.

iGO CAM Player
iGO CAM Player allows you to view the recordings on the iGO CAM 755 and
trace them on a map.
iGO CAM Player software is supported on Windows XP, Windows 7 and
Windows 8.
Installing iGO CAM Player
Download the iGO CAM Player from the Uniden website. You may need to
unziptheleusingtheappropriatearchivingsoftwarebeforeyoucanusethe
player. Double click on the iGO CAM Player icon.
15
UNIDEN iGO CAM 755 Vehicle Recorder
Connecting to a PC
The iGO CAM 755 can be connected to a PC (plug the USB cable (supplied)
into the USB/DC IN port).
When the unit is connected to a PC, ‘USB Connected’ is displayed on the
unit’s screen.
Select the external drive, and you will notice two folders, EVENT and
NORMAL.IntheEVENTfolder,alltheSOSlesarestored.
Access the Recorded Files
BeforeplayingtherecordedlesontheiGOCAMPlayer,ensurethatyoucan
accesstheleseasily.
Either remove the micro SD card from the recorder, and access the card
(les)onthecomputerviaacardreader.
or
Connect one end of the USB cable to the recorder and the other end to the
USB port on your computer.

16
UNIDEN iGO CAM 755 Vehicle Recorder
Ensure that the PC is connected to the internet to view the map screen.
View the Recorded Files
ToviewtherecordedlesontheiGOCAMPlayer,followthestepsbelow:
1. Start the iGO CAM Player (i.e., double click on the iGO CAM Player icon
on your desktop, or click windows start and search from the program
listing).
2.ClickontheoptionFileandselectOpentoopenthelesontotheiGO 
CAM Player.
3. Click on the PLAY button (Playback Controls) to start playback.
NOTE
GPS Player version is subject to change without notice. See
Uniden website to download the latest GPS Player.
Click on the ‘Snap Shot’ icon to take photos of the recording. These photos
will automatically save into a folder named ‘screenshot’. This folder is located
in the GPS Player folder stored in your PC.
Menu
Video
Playback
Screen
Playback
Controls
Snapshot Speed Compass
Map

17
UNIDEN iGO CAM 755 Vehicle Recorder
Special Features
TheiGOCAM755alertstheuserwhenthereisaxedSpeed/RedLight/Red
Light-Speed or Average Speed Camera.
Forthisfeaturetowork,pleaseensurethattheMenuoption,TrafcCamera
Alert, in the Record mode is turned on.
Whenthevehicleisclosetoanyofthexedcameras,theLCDwilldisplay
thecameraalerticonalongwithspecicinformation.Thisinformationwill
includethedistancefromthevehicletothecamera,thespeciedspeedlimit
and the current speed of the vehicle. The display is accompanied by a voice
alert.
TrafcCameraAlerts
GPS
The iGO CAM 755 has a GPS antenna, allowing your videos to be geo-
tagged.PleaseensurethatthebracketisttedontheunitandtheGPS
antenna is plugged into the GPS port for the unit to be able to detect the
GPS signal. You can view the recorded videos on the iGO CAM Player and
trace them on a map.
The cameras alerts will be disabled when the unit loses the GPS signal.
ADAS Calibration
ADAS includes the following 4 functions: LDWS - Lane Departure Warning
System, FCWS - Front Collision Warning System, FCMD - Front Vehicle
Moving Detection and LLWS - Low Light Warning System.
1. First, ensure that the iGO CAM 755 is mounted and powered on and the
vehicle is safely parked.
2. Next, ensure that the Menu option (in the Record Mode) ADAS Detect is
turned ON.
3. After that select the Menu option, ADAS Calibration, (Record Mode). You
will see 2 sensor lines (Purple and Red) displayed on the screen.
4. Press the MODE button to select either of the sensor lines. Then use the
Left and Right keys to position the lines to encompass only the area of
the display where road markings can be seen. Please refer to the image
on the next page.
Ensure to follow the steps listed and read the notes below to get the most out
of this feature.
TheADASdetectwillnotfunctionwhenthetrafccameraalertisturnedon
or when the live view is turned on to Speed Display. It also won’t work under
the following resolutions; 2304x1296 30P and HDR 1920x1080 30P.

• The ADAS Detect feature requires correct calibration to capture road
markings.
• ADAS Detect will be limited in poor visibility or where there is inconsistent
or faded road markings.
• Line Calibration is best carried out with the iGO CAM mounted and
powered on with the vehicle safely parked.
• ADAS feature is best suited for drivers who spend time on long roads
who are worried about falling asleep at the wheel – truck drivers, etc. So
the feature is not suited for drivers traversing short roads in city areas
where deliberate lane changing is done often.
18
UNIDEN iGO CAM 755 Vehicle Recorder
Please Note:
RED LINE
PURPLE LINE

General Problems Possible Solutions
The unit cannot take photos or
record videos. The unit stops
automatically when recording.
Use the recommended type of SD card
(8GB Class 10) and ensure that is
formatted.
The recorded video doesn’t
show mapping information on
the iGO CAM Player.
Please ensure the PC is connected to
internet.
Cross-stripe interference in
an image
This is due to the light frequency. Change
Anti-Flicker setting depending on the
local power supply.
The unit crashes Reset the unit, by pressing the Rbutton.
Important Information
Solving Problems
Listed below are some of the problems and the possible solutions. If you still
need help, visit our website, listed on the front cover.
19
UNIDEN iGO CAM 755 Vehicle Recorder

20 Vehicle RecorderUNIDEN iGO CAM 755
Warranty
UNIDEN iGO CAM 755
IMPORTANT: Satisfactory evidence of the original purchase is required
for warranty service
Please refer to our Uniden website for any details or warranty durations offered
in addition to those contained below.
Warrantor: The warrantor is Uniden Australia Pty Limited ABN 58 001 865 498
(“Uniden Aust”).
Terms of Warranty: Uniden Aust warrants to the original retail purchaser only
that the iGO CAM 755 (“the Product”), will be free from defects in materials and
craftsmanship for the duration of the warranty period, subject to the limitations
and exclusions set out below.
Warranty period: This warranty to the original retail purchaser is only valid in
theoriginalcountryofpurchaseforaProductrstpurchasedeitherinAustralia
or New Zealand and will expire one (1) year from the date of the original retail
sale.
If a warranty claim is made, this warranty will not apply if the Product is found
by Uniden to be:
(A) Damaged or not maintained in a reasonable manner or as recommended
in the relevant Uniden Owner’s Manual;
(B) Modied,alteredorusedaspartofanyconversionkits,subassembliesor
  anycongurationsnotsoldbyUnidenAust;
(C) Improperly installed contrary to instructions contained in the relevant
Owner’s Manual
(D) Repaired by someone other than an authorized Uniden Repair Agent
in relation to a defect or malfunction covered by this warranty; or
(E) Used in conjunction with any equipment, parts or a system not
manufactured by Uniden.
Parts Covered: This warranty covers the Product and included accessories.
User-generated Data: This warranty does not cover any claimed loss of
or damage to user-generated data (including but without limitation phone
numbers, addresses and images) that may be stored on your Product.
