Uniden iGO CAM 70R User manual

iGO CAM 70R
Accident CAM
Vehicle Recorder
For more exciting new products please visit our website:
Australia: www.uniden.com.au

2
UNIDEN iGO CAM 70R Vehicle Recorder
Important Safety Instructions
NOTE
Uniden does not represent this product to be waterproof. Do not
expose this product to Rain or Moisture.
NOTE
This product is intended for use in a motor vehicle. Don’t install
the device where it will block the driver’s view of the road
(including the mirrors!) or the deployment of the airbag.
NOTE
Keep your attention on the road! Don’t try to operate or focus
on any device while driving. If you have to concentrate on a
device, pull off the road for a few minutes.
NOTE
Ensure that the camera lens is kept clean and there is nothing
blocking the lens. Do not install the product in a location where
it can obstruct the driver’s eld of vision.
NOTE
Don’t leave the device in direct sunlight for a long period of time
or where the temperature could go above 60°C.
NOTE
You should examine, check and/or verify the device at least
once a month including the associated SD card, to ensure the
recording are working properly.
NOTE
Never attempt to disassemble, repair or make any modications
to your device.
NOTE
GPS signal may lost when surrounded with tall buildings, in a
tunnel or poor weather conditions. Over-tinting or a rain sensor
on the windshield can affect GPS reception.
NOTE
It may takes up to 10 minutes to get GPS signal for the rst time
and after that, it will normally takes up to 3 minutes. If the signal
is unstable please change the installation spot.

3
UNIDEN iGO CAM 70R Vehicle Recorder
CONTENTS
Important Safety Instructions ...................................... 2
What’s In The Box .......................................................... 4
Controls & Indicators .................................................... 5
Installation ..................................................................... 7
Operation ........................................................................ 8
Micro SD Card ...................................................................................................... 8
Battery Information ........................................................................................... 8
Power On ............................................................................................................... 9
Power O ............................................................................................................... 9
Screen Icons ....................................................................................................... 10
Record Mode ...................................................................................................... 10
Record Settings .............................................................................................. 10
Photo Mode ....................................................................................................... 10
Playback Mode ...................................................................................................13
Menu Settings .....................................................................................................13
General Settings ................................................................................................14
Connecting to a PC ......................................................................................... 15
Geotagged Video .............................................................................................. 15
SpecialFeatures...................................................................................................17
UsingtheApp.......................................................................................................18
Troubleshooting .......................................................... 20
Specication .................................................................. 21
Warranty ........................................................................ 22

4
UNIDEN iGO CAM 70R Vehicle Recorder
Make Sure These Items Arrived in the Box
What’s In The Box
USB Car Charger USB Charging Cable
GPS Sticker
Mount Bracket
• If any item is missing or damaged, contact your place of purchase
immediately. Never use damaged products!
• Need help? Get answers at our website:
www.uniden.com.au for Australian model.
iGO CAM 70R
• Owner’s Manual
Rear Camera 6M Rear Camera Cable

Controls & Indicators
UNIDEN iGO CAM 70R 5Vehicle Recorder
3
1
7
13
4
5
6
2
8
9
15
11 12
14
10
16
Front Camera
Rear Camera

6Vehicle RecorderUNIDEN iGO CAM 70R
Ref Component Description
1LED RED - Flashing indicates recording.
BLUE - Indicates charging battery.
2 LCD Screen
3 MENU Record Mode: Start emergency recording when
recording/Enter Settings menu when not recording.
Photo Mode: Enter Settings menu.
Playback Mode: Return to previous screen/mode.
4UP Record Mode: Enter Photo mode.
Photo Mode: Take a snapshot.
Playback Mode: Toggle to previous le/Delete.
5 DOWN Record Mode: Mute or unmute the Mic when
recording/Enter Playback mode.
Photo Mode: Enter Record mode.
Playback Mode: Toggle to next le.
6 OK Record Mode: Start/Stop video recording.
Photo Mode: Enter Record mode.
Playback Mode: Conrm Selection/Play/Pause.
7Card Slot Insert micro SD Card (up to 128GB min class 10).
8Reset If the device fails to operate, try resetting the device.
Press the reset button using a ne pen or paperclip.
9POWER Press & hold for 3 seconds to turn power on.
Press & hold for 3 seconds to turn power off.
10 Mini USB
Port
Connect the mini USB cable to the rear view camera.
11 Bracket Slot Slot in the GPS sticker mount bracket.
12 Micro USB
Port
Connect to the micro USB cable on the GPS sticker
mount bracket.
Connect to PC for data (SD card) transfer (USB data
cable is not supplied).
13 Speaker
14 MIC Records sound.
15 Lens
16 3M Sticker Attach the rear camera onto the windshield.

7
UNIDEN iGO CAM 70R Vehicle Recorder
Installation
Location
To have a better view, try to install the front camera at the center of the
windshield and the rear camera at the centre of the rear window. It can also
be placed on the front windshield to record the interior of the vehicle. Make
sure the lens is located in a place where the windshield is clean to ensure the
view is clear.
Make sure the device is not installed in a place where it will interfere with the
airbag. Make sure the GPS will not be obstructed by the windshield’s sun
control lm (window tint).
Installation Steps
1. Clean the area you desire to have the cameras placed before sticking the
device.
2. Slide the sticker mount bracket into the front camera bracket slot and
make sure it ts tightly.
3. Peel off the sticker protective lm of the 3M sticker of the cameras.
4. Press and apply force on the GPS sticker mount of the front camera onto
the windshield behind the rearview mirror.
5. Press and apply force on the sticker mount of the rear camera onto the
top center of the rear windshield.
6. Connect the front camera and rear camera with the mini USB cable.
7. Arrange and hide the cables to avoid obstruction for the driver’s view.
8. Adjust the cameras view by loosening the screw of the bracket and
fasten it back. We recommend the camera should point slightly
downwards ~10° below eye level.
NOTE
Please ensure the rear camera connection cable is connected/
disconnected when the device power is off or it will damaged
the product.

8
UNIDEN iGO CAM 70R Vehicle Recorder
Operation
Micro SD Card
NOTE
A compatible micro SD card (not supplied) is required to record
and store videos and photos.
The device can support micro SDHC cards (High Capacity SD) up to 128GB
in capacity. A micro SDHC card of at least 8GB capacity and minimum Class
10 speed is recommended.
Insert a formatted micro SD card gently in the slot at the side of the device.
To remove the card from the slot, press the edge of the SD card inwards for it
to pop out and then pull it out of the slot.
Uniden only recommends using good quality MLC/SLC micro SD cards.
Please ensure that the SD card used is rated for Dash Cam use.
Video Storage Capacity
Refer to the table below for the recording capacity for different card capacity
and some of the recording resolution at 30fps.
Resolution 8GB 16GB 32GB 64GB 128GB
1080P+1080P 40 mins 80 mins 160 mins 320 mins 640 mins
2716x1524 (front) 45 mins 90 mins 180 mins 360 mins 720 mins
2304x1296 (front) 50 mins 100 mins 200 mins 400 mins 800 mins
1920x1080 (front) 60 mins 120 mins 240 mins 480 mins 960 mins
Battery Information
Although primarily designed for in-car use, the device can operate from its
built-in battery for up to 10 minutes. Please note, the power usage would
depend on day/night recording and resolution setting.
The device will charge the battery whenever power is detected through the
USB port. The device will take about 180 minutes to charge completely.
NOTE
Please ensure that the battery is fully charged before using it for
the rst time. To extend the battery life, fully charge the device once
every 3 months. The battery life will degrade over a period of time
especially when the device is exposed to high temperature.

Power On
NOTE
When connected to a car charger with power, the device will
automatically power on and start recording.
1. Ensure the USB Charging Cable is connected to the USB car charger.
2. Plug in the USB car charger to the car’s cigarette lighter port.
3. Connect the other end of the USB charging cable into the micro USB port
found on top of the GPS mount bracket.
4. Connect the USB cable from the side of the GPS mount bracket into the
micro USB port found on the device.
5. The device will power on automatically when the car supplies the power to
the device.
6. The red dot on the screen will start ashing and recording starts
automatically.
At other times, press and hold the power button for at least 3 seconds.
NOTE
Be sure insert the SD card before powering up the device.
Format the SD card before you start recording for the rst time.
Power Off
When the car’s engine is turned off, the device will automatically turn off in a
few seconds.
At other times, press and hold the power button for at least 3 seconds to turn
off the device. Do no eject the SD card immediately to prevent damage to the
last recorded le.
If you wish to switch the device back on, press and hold the power button for
at least 3 seconds.
NOTE
Only use the USB Car Charger Adaptor and USB Charging
cable that comes with your device. Any other adaptor might
damage the device.
9Vehicle RecorderUNIDEN iGO CAM 70R

10 Vehicle RecorderUNIDEN iGO CAM 70R
NOTE
To record a video, ensure that a valid micro SD card (not
supplied) is inserted in the given slot. Also note, that inserting/
removing the SD card when the device is recording causes the
device to shutdown and in worst case malfunction.
Recording
When connected to a car charger, the device automatically goes into the
record mode and starts recording.
A red dot icon and a recording timer indicates that the device is recording.
To stop recording, press OK and the red dot disappears, indicating that the
recording has stopped.
Emergency Recording
An Emergency Recording is triggered when the Menu Button is pressed or
when the G-Sensor registers an impact while recording. The emergency icon
will appear on the screen. This indicates that those recordings have been
locked and will not be overwritten by new video clips.
Record Mode
Screen Icons
Recording Resolution
GPS Status
Loop Recording Indicator
WiFi/App Connection Status
Park Mode
Battery
Status
Recording
Timer
System Time
System Date Speed Indicator in Big
Speedo Viewing Mode
