Uniden UBC-RH96 User manual

UBC-RH96
Remote Head unit for the
UBCD396T & UBCD996T
Digital Scanners
UBC-RH96 Digital Scanner OM.indd1 1UBC-RH96 Digital Scanner OM.indd1 1 10/9/07 4:15:55 PM10/9/07 4:15:55 PM

2
UBC-RH96 Digital Scanner OM.indd2 2UBC-RH96 Digital Scanner OM.indd2 2 10/9/07 4:15:56 PM10/9/07 4:15:56 PM

3
Table of Contents
Introduction..................................................................................................... 5
Mounting the UBC-RH96............................................................................... 7
Using the Mounting Bracket..................................................................... 7
Using Hook and Loop Material ................................................................ 9
UBC-RH96 Connections............................................................................... 10
Connecting Cables ........................................................................................ 11
Remote Head and Scanner Power........................................................... 11
Control Cable.......................................................................................... 11
Data Port Cable — Firmware Updates ................................................... 12
Control Configuration Guides ..................................................................... 13
The UBCD396T Key Configuration....................................................... 14
The UBCD996T Key Configuration....................................................... 15
Operation....................................................................................................... 16
Setting the UBC-RH96 Backlight........................................................... 17
Configuration — Menu Mode................................................................. 18
Setting the UBC-RH96 LCD Contrast.................................................... 18
Setting Mobile Options................................................................................. 19
Mobile Default Key Assigment .............................................................. 19
Setting Handy Options ................................................................................. 21
Default Handy Option Key Assigment ................................................... 21
Setting the Function Mode ........................................................................... 22
Setting Hold Timer.................................................................................. 22
Setting Auto Release............................................................................... 23
Miscellaneous................................................................................................. 23
Volume Settings - For Handy Scanner.................................................... 23
Control Limitations................................................................................. 24
Serial Operation Precautions .................................................................. 24
UBC-RH96 Digital Scanner OM.indd3 3UBC-RH96 Digital Scanner OM.indd3 3 10/9/07 4:15:56 PM10/9/07 4:15:56 PM

4
Initialize Memory (Reset)....................................................................... 25
Using the Cable Clamp ........................................................................... 25
Specifications ................................................................................................. 26
One Year Limited Warranty ........................................................................ 26
UBC-RH96 Digital Scanner OM.indd4 4UBC-RH96 Digital Scanner OM.indd4 4 10/9/07 4:15:57 PM10/9/07 4:15:57 PM

5
Introduction
Your UBC-RH96 Remote Head helps you get more out
of your Uniden UBCD396T or UBCD996T scanner.
The UBC-RH96 provides the following features:
It controls all the functions of your Uniden mobile or
handy scanner (with the exception of the scanner’s
power control.)
It gives you three shortcut keys that you can assign
to your scanner’s most often used operations.
It serves as a large LCD with your handy scanner.
It recognizes the scanner baud rate for reliable
•
•
•
•
communications between units.
Its Volume and Squelch controls emulate those on
the scanner.
It provides a large, easy to read LCD display with
adjustable backligh and contrast levels.
It emulates your mobile scanner’s Close Call and
Alert LED signals.
Please read the entire manual to familiarize yourself
with installation and operation for maximum
enjoyment.
•
•
•
UBC-RH96 Digital Scanner OM.indd5 5UBC-RH96 Digital Scanner OM.indd5 5 10/9/07 4:15:57 PM10/9/07 4:15:57 PM

6
Included with your UBC-RH96
Your Remote Head is supplied with essential
components and accessories to get you operational.
Supplied are:
The UBC-RH96 Remote Head unit.
A steel mounting bracket with
attachment washers factory installed.
Mounting hardware (screws and washers)
to attach the bracket.
Threaded knobs to allow mounting the
Remote Head quickly to the bracket.
•
•
•
•
Remote connection cable, 3m in length.
A correctly polarized vehicle DC adapter to let you
connect the Remote Head to a convenience outlet in
your vehicle that provides 12-13.8 VDC.
This Owner’s Manual.
A set of pocket-sized Quick Reference Configuration
cards for convenient setup and usage.
A Self Adhesive Cable Clamp
If any of the above items are missing or damaged, im-
mediately contact your place of purchase.
•
•
•
•
•
UBC-RH96 Digital Scanner OM.indd6 6UBC-RH96 Digital Scanner OM.indd6 6 10/9/07 4:15:57 PM10/9/07 4:15:57 PM

7
Mounting the UBC-RH96
The following two mounting methods are suggestions
used by most. Depending upon your individual
situation, you may decide on a different approach.
Using the Mounting Bracket
For most vehicles, the supplied bracket will be the
easiest method of mounting.
With the bracket removed from the Remote Head, use
the holes in the bracket as a template to initially mark
the location you plan to use in your vehicle. Be abso-
lutely certain of what might be behind the mounting
surface before making any holes, be it above, or below,
or in front of your dash, armrest console, or other
location. If you drill carelessly, expensive damage can
result. If in doubt, consult your vehicle dealer’s service
department or a qualified professional installer.
Important: AVOID AIRBAG DEPLOYMENT
ZONES. Ignoring this installation concern may result
in bodily harm and the inability of the airbag to per-
form properly.
Be sure to select a mounting location so that when you
route power and remote cables they do not interfere
with any existing cables or other controls.
UBC-RH96 Digital Scanner OM.indd7 7UBC-RH96 Digital Scanner OM.indd7 7 10/9/07 4:15:57 PM10/9/07 4:15:57 PM

8
-
•Using the supplied screws or other suitable
hardware, secure the bracket.
Insert the UBC-RH96 and insert the bracket
knobs to lock the Remote Head in position.
Attach the provided Cigarette Lighter Power Cord
to the rear power jack marked DC IN 13.8V.
Then plug the adapter end into a dash mounted
12V DC socket.
Insert the 3-Conductor Mini-Plug of the supplied
ten-foot cable in the REMOTE jack on the back
of the scanner.
1.
2.
3.
4.
Star
Washers
& Screws
Under Dash
Bracket
Bracket
Knobs UBC-RH96
UBC-RH96 Digital Scanner OM.indd8 8UBC-RH96 Digital Scanner OM.indd8 8 10/9/07 4:15:58 PM10/9/07 4:15:58 PM

9
Route the Remote Cable through the Slotted Guide
(3) so it lies flat. Route the Power Cord so it does
not interfere with any other wires.
Using Hook and Loop Material
The rear of the unit, when all connectors and cables
are properly routed, is flat. This permits using hook
and loop material (not supplied) that has a heavy-duty
peel and stick adhesive on one side. This material is
generally available from electronic supply stores and
hardware stores.
Do not apply the tape to the rear until all cables are
installed and routed correctly.
Do not cover the slotted guide with the tape.
5.
Follow the directions supplied with the hook and loop
material. Locate a suitable spot on the dash, console,
or other area. If you use the Remote Head in another
place such as a radio room, using tape lets you quickly
mount or remove the Head as desired.
UBC-RH96 Digital Scanner OM.indd9 9UBC-RH96 Digital Scanner OM.indd9 9 10/9/07 4:15:58 PM10/9/07 4:15:58 PM

10
REMOTE
DC IN 13.8V
UBC-RH96 Connections
DC Power Input Jack
To Remote Cable
Mini-Plug
Cable Routing Guides
Data Port (for firm-
ware updates)
1
23
4
1
2
3
4
Always route both cables
through the channel.
Note: Connect the Remote Cable and route it through the cable channel as
shown. Then connect the DC Power Cable and route it through the channel.
UBC-RH96 Digital Scanner OM.indd10 10UBC-RH96 Digital Scanner OM.indd10 10 10/9/07 4:15:58 PM10/9/07 4:15:58 PM
