Uniden GNC 701 User manual

1
Quick-Start Guide
GNC 701/710
IP Camera
Use this Quick-Start Guide to connect the camera to the network
and for basic installation and setup procedure. For more detailed
instructions refer to the online Owner’s Manual on the Uniden
website www.uniden.com.au. This quick start guide is for reference
only. Slight difference may be found in user interface.
In the Box
Model GNC701 GNC710
QSG 1 1
Mounting Screw
Kit
1 1
Installation
Position Map
1 1
Hex wrench 1 -
If any item is missing or damaged, contact your place of purchase
immediately. Never use damaged products!
Need help? Get answers at our website:
www.uniden.com.au for Australian model

2
1. Do not drop, puncture or disassemble the camera.
2. DO NOT expose the camera to excessive water or moisture.
3. Never tug on the power cable to unplug from the power outlet. Always
grasp the AC adapter when unplugging.
4. Do not expose the camera to high temperature or leave it in direct
sunlight. Doing so may damage the camera or cause camera
temporary malfunction.
5. For your own safety, avoid using the camera or power off the camera
when there is a storm or lightning.
6. Remove the power adaptor during long periods between usages.
7. Use only the accessories and power adaptors supplied.
8. Please use correct power supply to operate the device
Important Safety Instructions

3
Getting to know your GNC701
4
1 Dome cover
2 Dome enclosure
3 Power Port
4 I/O Port
5 Network Port
3
1
2
5
6
7
6 Audio Input Port
7 Audio Output Port
8 Reset Button
9 SD Card Slot
8
9

4
GNC701 Installation
Step 1: Use the included inner hex
wrench to unfasten the dome enclosure.
Step 2: Install Micro SD card (optional).
Step 3: Place and stick the installation
position map on the ceiling or the wall to
suit your desired location.
Step 4: Find and drill the small cross
signs on the map to fit three plastic
expansion bolts holes. Insert the
expansion bolts into the holes.
Step 5: Position the dome body to
match the three screw holes. Fasten
the installation screws to secure the
dome body onto the ceiling or wall. Do not let the cable get caught in between the dome body
and the wall.
Step 6: Adjust the lens viewing direction by rotating the LED cover or rotate the dome bracket
or tilt it vertically. Range of adjustment: vertical (0°~64°), horizontal (0°~355°) & image rotation
(0°~355°).
Step 7: Put on back the dome enclosure according to the hole and fasten the three inner hex
screws firmly.

5
Getting to know your GNC710
1
1 Bullet cover
2 Network Port
3 Power Port
4 Reset Button
1
2
3
5
6
7
8
5 SD Card Slot
6 SD Card (not included)
7 Cover Plate
8 Cover Screw
4

6
GNC710 Installation
Step 1: Open the cover plate to insert SD Card (optional)
Step 2: Place and stick the installation position map on the ceiling or the wall to suit your desired
location.
Step 2: Mark and drill holes on the wall or ceiling.
Step 2: Insert the expansion bolt into the hole.
Step 3: Fasten the installation screws to secure the device on the wall or ceiling. You may move
device the cover back and forth and tighten the it.
Step 4: Please use screwdriver to loosen the adjusting screw and adjust the camera to desired
viewing direction and tighten back the screw.

7
Network Port Water Resistant Seal (Optional)
If you powered your camera over PoE, you can further protect it from water. You need a cabler
installer for this purpose.
Step 1: Fix the rubber ring into the network pork. Keep the smaller diameter hole outwards.
Step 2: Install the rubber ring into the main body of water resistant connector.
Step 3: Pull the Ethernet cable without Ethernet connector through the main body of water
resistant connector, fixing rubber ring and cover.
Step 4: Install the Ethernet connector onto the Ethernet cable.
Step 5: Connect the Ethernet Connector onto the network port.
Step 6: Pull and place the water resistant connector on the network port and rotate it clockwise
to lock firmly.
Step 7: Place the cover on the water resistant connector and rotate it clockwise to lock firmly.

8
Reset the Camera
To reset the GNC 701/710, press and hold the ‘Reset’ button for 10
seconds, then only release the ‘Reset’ button.
Troubleshooting
If... Try This...
The NVR cannot find
the camera
Make sure your network supports DHCP
protocol.
Make sure that the DHCP option is turned on.
Make sure the camera and your NVR
connected to the same switch/router.
Make sure the switch/router is properly
powered on.
Make sure the camera is properly powered on.
Make sure the WiFi router has enabled SSID
broadcasting.
The camera does not
obtain an IP address
Please reset the camera and try again.
Make sure the camera was powered up
correctly.
Connect the camera directly to NVR.
Please test it with another Ethernet cable.
Make sure the camera has the same subnet
mask and gateway as the NVR/switch/router.
As the Uniden App is constantly under development to enrich user
experience, the icons/screens shown in this QSG may vary slightly from
the actual app. This QSG uses icons from the iPad app.

9
Adding GNC 701/710 to existing GNVR 86xx /
87xx / 167xx System using a switch/router.
Please use PoE supported switch/router if you only want to power the
camera using Ethernet cable (not included) otherwise please supply
power using a power adapter (not included). Please make sure the NVR
and camera are on the same network/switch/router.
For more detailed instructions or modification refer to the online
Owner’s Manual for GNVR 86xx/87xx/167xx series on the Uniden
website www.uniden.com.au to add IP Camera into existing setup .
1. Right click with your mouse on the NVR live view interface to view
menu options. Select Remote Device to add GNC 701/710 into the
system.

10
3. Click IP search to search the IP address of GNC 701/710.
4. Once the GNC 701/710 IP address found, tick the device. You may
tick more devices if you have 2 or more GNC 701/710 connected to
the same network. Click Add to add selected device(s) to the Added
Device list.
5. When status showing green dot indicates the connection is good while
red dot indicates connection failed. You may click in the Added
Device box to edit GNC 701/710 password if the connection fail or
showing invalid password at live view interface. The default password
is “admin”.
6. Right click the mouse button to exit Remote Device window.
2. Remote Device window shows up.
is quick start guide is for reference only. User interface may be dierent from actual product.
If there is any unclear or controversy, please visit Uniden website or call Uniden Australia.

ONEYEAR LIMITED WARRANTY
Terms of Warranty: Uniden Aust warrants to the original retail
purchaser only that the GNC 701/710 (“the Product”), will be free
from defects in materials and craftsmanship for the duration of the
warranty period, subject to the limitations and exclusions set out below.
Warranty Period: This warranty to the original retail purchaser is only
valid in the original country of purchase for a Product first purchased
either in Australia or New Zealand and will expire one (1) year from the
date of the original retail sale. If a warranty claim is made, this warranty
will not apply if the Product is found by Uniden to be:
A. Damaged or not maintained in a reasonable manner or as recommended
in the relevant Uniden Owner’s Manual;
B. Modified, altered or used as part of any conversion kits, subassemblies
or any configurations not sold by Uniden Aust;
C. Improperly installed contrary to instructions contained in the relevant
Owner’s Manual
D. Repaired by someone other than an authorized Uniden Repair Agent in
relation to a defect or malfunction covered by this warranty; or
E. Used in conjunction with any equipment, parts or a system
notmanufactured by Uniden.
Parts Covered: This warranty covers the Product and included
accessories.
User-generated Data: This warranty does not cover any claimed loss of
or damage to user-generated data (including but without limitation phone
numbers, addresses and images)that may be stored on your Product.
Satisfactory evidence of the original purchase is required for warranty
service. Please refer to our Uniden website for any details or warranty
durations offered in addition to those contained below.
The warrantor is Uniden Australia Pty Limited ABN 58 001 865 498
(“Uniden Aust”).
GNC 701/710
Important:
Warrantor:

Statement of Remedy: If the Product is found not to conform to this
warranty as stated above, the Warrantor, at its discretion, will either
repair the defect or replace the Product without any charge for parts or
service. This warranty does not include any reimbursement or payment
of any consequential damages claimed to arise from a Product’s failure to
comply with the warranty. Our goods come with guarantees that cannot
be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the
goods repaired or replaced if the goods fail to be of acceptable quality and
the failure does not amount to a major failure. This warranty is in addition
to and sits alongside your rights under either the COMPETITION AND
CONSUMER ACT 2010 (Australia) or the CONSUMER GUARANTEES
ACT (New Zealand) as the case may be, none of which can be excluded.
Procedure for Obtaining Warranty Service: Depending on the
country in which the Product was first purchased, if you believe that
your Product does not conform with this warranty, you should deliver
the Product, together with satisfactory evidence of your original
purchase (such as a legible copy of the sales docket) to Uniden at
the address shown below. You should contact Uniden regarding any
compensation that may be payable for your expenses incurred in making
a warranty claim. Prior to delivery, we recommend that you make a
backup copy of any phone numbers, images or other data stored on
your Product, in case it is lost or damaged during warranty service.
UNIDEN AUSTRALIA PTY LTD
Phone number: 1300 366 895
Email: custser[email protected]
