Uniden AS1101 Series User manual

AS1101 base
and cordless
handset
Cordless handset
If you purchased
model number:
You should
have:
AS1101 None
AS1101-2 1 of each
AS1101-3 2 of each
AS1101-4 3 of each
AS1101-5 4 of each
You will also find:
xRechargeable battery
xBattery cover
xAC adapter
xTelephone cord
If any items are missing or damaged, never use damaged products!
AS1101 Series User's Guide
What's in the box?
xRechargeable battery
xBattery cover
xAC adapter
Important safety instructions
When using your telephone equipment, basic safety precauons should
always be followed to reduce the risk of fire, electric shock and injury to
persons, including the following:
xThis unit is NOT waterproof. DO NOT expose this unit to rain or moisture.
xDo not use this product near water, for example, near a bath tub, wash
bowl, kitchen sink or laundry tub, in a wet basement, or near a swimming
pool.
xAvoid using a telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lightning.
xDo not use the telephone to report a gas leak in the vicinity of the leak.
xUse only the power cord and baeries indicated in this manual.
xDo not dispose of baeries in a fire. They may explode. Check with local
codes for possible special disposal instrucons.
xDo not place the handset in any charging cradle without the baery in-
stalled and the baery cover securely in place.
SAVE THESE INSTRUCTIONS

2
GETTING STARTED
Use only with the supplied power adapter and rechargeable battery.
CAUTION: Risk of explosion if battery is replaced by an incorrect
type. Dispose of used batteries according to the instructions.
Rechargeable Batteries Must Be Recycled or Disposed of Properly.
xDo not place the unit in direct sunlight or subject it to high temperatures.
xDo not open or tamper with the handset or base (other than to change the
baeries).
Installing your phone
Charge the battery
1. Remove a battery cover. Press
in on the notch and slide the
cover down.
2. Place the batteries in the
correct polarity.
3. Replace the battery cover and
slide it up into place.
4. Use the base AC adapter to connect the power jack on the base to a
standard AC power outlet. If you have two or more handsets, connect
each charger in the same way.
5. Place a handset in the base with the display facing forward.
For two or more handsets, place each handset in a charger.
#Charge all handsets completely (about 15 hours) before using them.
Connect the telephone cord
Use the telephone cord to connect the jack on the base to a standard
telephone wall jack.
Installing a line filter or DSL filter
xA telephone line filter or DSL filter prevents services that use the
phone line from causing interference on your phone. To get a line
filter, contact your service provider or look in an electronics store.
xPlug the filter into the telephone wall jack and plug the base into the
filter. Make a test call to make sure the noise is gone.

3
Getting to know your phone
Parts of the base
Parts of the handset
FIND
In standby: page
all handsets to
find a lost one.
Charging cradle
UP
During a call: increase the volume.
In any menu or list: move to
the previous item.
In standby: open the call log.
When entering text: move the
cursor to the left.
MENU/OK
In standby: open the menu.
In any menu or list: select and
confirm the selection.
TALK /RECALL
In standby: start a telephone
call (get a dial tone).
While the phone is ringing:
answer an incoming call.
During a call: switch to a
waiting call.
*
In standby: press and hold for
about 3 sec. to lock/unlock
the keypad.
REDIAL
In standby: open the redial list.
MUTE
During a call:mute the microphone on or off
CLEAR
In a menu: go back to the
previous screen.
When entering text: delete
one character.
(Press and hold to delete
all the characters.)
END
Press and hold to turn the
handset on or off.
During a call: hang up.
DOWN
During a call: decrease the volume.
In any menu or list: move to the
next item.
In standby: open the phonebook.
When entering text: move the
cursor to the right.
#
In standby: press and hold
to turn the ringer on or off.
While entering a phone number:
press and hold to insert
a 3-second pause.
INTERCOM
In standby: page another handset
for a internal call.
During a call: page another handset
to transfer the call.

4
Display icons and what they mean
On: you have a strong signal from the base.
Blinking: the signal from the base is weak or not received.
The handset is on a call.
The alarm on this handset is activated.
The ringer is turned off.
On: you have records in the call log.
Blinking: you have missed calls.
The handset opens the phonebook.
You have a voice message waiting.
The battery is fully charged.
On: the battery is getting low.
Blinking: the battery is empty.
OK To select and confirm the selection, press
MENU/OK .
To rotate through the items, Press UP or DOWN .
To go back to the previous screen, press CLEAR .
To check more information, press MENU/OK repeatedly.

5
To enter text on your phone
Use the 12-key dial pad when you want to enter text into your phone.
xThe phone enters the letters in the order they appear on the key. For
example, if you press the number key
2 once, the phone enters the
letter
A . Press 2 twice for B , and three times for C .
xIf two letters in a row use the same number key, enter the first letter
and wait a few seconds; then enter the next letter.
To... Press...
move the cursor left
UP .
move the cursor right
DOWN .
erase the character at the cursor
CLEAR .
erase the entire entry and hold
CLEAR .
enter a blank space
1 .
rotate through the punctuation and symbols
0 or 1 .
Basic setup
To use the menus
To... Press...
open the menu; with the phone in standby, MENU/OK .
rotate through the menu options
UP or DOWN .
select and confirm the option MENU/OK .
go back to the previous screen
CLEAR .
exit the menu END .
If you don't press any keys for 30 seconds, the handset exits the menu.
In the operating instructions on this document...
x“Select” means “scroll to the menu option and press
MENU/OK .”
x“ Ö“ means “and then select the next menu option.”

6
To set the clock
#Only one handset at a time can change the clock.
1. Open the menu. Select
CLOCK & ALARM Ö DATE/TIME .
2. Enter the date and press
MENU/OK .
3. Enter the time. Change AM/PM using *or
# (if the time format is “12
hours”). To confirm, press
MENU/OK .
xTo set the date and time format: Open the menu. Select
CLOCK &
ALARM
Ö
SET FORMAT
Ö
TIME FORMAT or DATE FORMAT .
xIf you subscribe to CLI, the phone automatically sets the date and time
from the received CLI information.
Open the menu. Select
CLOCK & ALARM
Ö
AUTO CLOCK Ö ON .
To set the ringer
xTo change the base ringer volume: Press UP or DOWN .
xTo change the handset ringer volume: See the table below.
To set the handset tones
Open the menu. Select HS SETTINGS Ö HANDSET TONE Ö...
To set this handset’s... Select...
ringer volume
RING VOLUME
ringer tone for external calls EXT/RING
ringer tone for internal calls INT/RING
tone when you press a key KEY BEEP
tone when the handset is traveling out of range RANGE TONE
tone when the battery gets too low BATTERY TONE
tone when you place the handset on a cradle CHARGE TONE
To set other handset settings
Open the menu. Select HS SETTINGS Ö...
To... Select...
set this handset’s name used on the display
HANDSET NAME
set this handset’s display language LANGUAGE
answer a call when you pick up this handset from the
cradle (without pressing any keys)
AUTO ANSWER
program your voice mail access number (see page 9) VOICEMAIL

7
USING YOUR PHONE
To make and answer calls
To... Follow these steps:
make a call (pre-dialing) Dial the number, and then press
TALK /
RECALL
.
make a call (direct dialing)
Press TALK /RECALL and then dial the
number.
answer a call Press
TALK /RECALL .
hang up Press
END .
change the earpiece volume Press
UP or DOWN .
mute the microphone on or off Press MUTE .
To switch the handset power on/off
xTo switch the handset off, press and hold END for at least 5 seconds.
xTo switch it on, press and hold
END until the display turn on.
To use the call log and redial list
#You have to subscribe to Caller Line Identification (CLI) and Call
Waiting services to use these features.
Each handset can save the last 10 received calls in the call log and
the last 5 numbers you dialed on it in its redial list.
To… Press...
open the list
UP( ) for call log or REDIAL for redial list.
scroll through the list
UP or DOWN .
view the caller’s
information (in call log)
MENU/OK , then select VIEW . To check more
information, press
MENU/OK repeatedly.
dial the current number
TALK /RECALL .
save it to the phonebook MENU/OK , then select COPY TO PB .
delete the current
entry
MENU/OK , then select DELETE ( DELETE ALL to
delete all entries).
T o confirm, press MENU/OK .
close the lists
CLEAR .

8
To use Call Waiting
If you get a Call Waiting call, the phone sounds a tone.
To switch between the current and waiting call, press
TALK /RECALL .
To use the phonebook
Each handset can store up to 20 entries in its phonebook.
To create a new phonebook entry
1. In standby, enter a phone number (up to 24 digits).
2. Press
MENU/OK . The phone prompts you to enter a name and edit the
number, and select a special ringer tone for that entry.
To make a call from the phonebook
1. In standby, press DOWN( ) . Use UP and DOWN to find a entry.
(To check the entry’s information, press
MENU/OK repeatedly.)
2. Press
TALK /RECALL to dial.
To edit or delete phonebook entries
Open the menu. Select PHONEBOOK Ö...
To… Select...
edit an entry EDIT ENTRY
. Use UP / DOWN to find an entry, and press
MENU/OK .
delete an entry DELETE . Use UP / DOWN to find an entry, and press MENU/OK .
delete all entries DELETE ALL . To confirm, press MENU/OK .
To use multi-handset features
To use these features, you must have at least two handsets.
To make an internal call
To page another handset To answer the page
In standby, press
INTERCOM . If you have two or
more handsets, Press the number key of the
handset. (To cancel, press
INTERCOM again.)
Press
TALK /RECALL .
To leave an internal call, press
END .
#If an outside call comes in during an internal call, the phone sounds
a tone. Press
END to leave the internal call, and then press TALK /
RECALL
to answer the external call.

9
To transfer a call
To page another handset To answer the page
1. During a call, press
INTERCOM .
Press the number key of the handset.
(To cancel, press
INTERCOM again.)
2. To complete the transfer Press
END .
To start a conference call, wait the paged
handset answers, and press and hold
INTERCOM .
1. Press
TALK /RECALL .
2. When the
transferring
handset hangs up,
you can talk to the
outside caller.
To use the alarm feature
You can set an alarm on each handset. You need to set the date and time
before using the alarm feature.
xWhen the time on the handset reaches the time on the setting, the
handset sounds for 1 minute. (Other handsets and the base don’t ring.)
xTo stop the alarm tone, press any key on the handset.
xWhen an alarm is set, the alarm icon ( ) appears on the display.
To set the alarm
Open the menu. Select CLOCK & ALARM
Ö
ALARM Ö ONCE , DAILY , or OFF .
To setting the alarm tone
Open the menu. Select CLOCK & ALARM Ö ALARM TONE .
Voice message notification
#You have to subscribe to a voice mail service to use these features.
If you have new messages in your voice mail box, blinks on the display.
You can program your access number so you can get your messages at
the touch of a button.
To set up your voice mail access number
If you don't have the access number information, contact your service
provider.
1. Open the menu. Select
HS SETTINGS Ö VOICEMAIL . (You have to
program the number separately for each handset.)
2. Enter your access number (up to 24 digits) exactly as you would dial it.
3. To confirm, press
MENU/OK .
To get your messages
Press and hold the number key 1to dial the access number.

10
IMPORTANT INFORMATION
Troubleshooting
If you have any trouble with your phone
Try these simple steps first.
General problems Possible solutions
No handsets can
make or receive calls.
xCheck the telephone cord connection.
xDisconnect the base AC adapter. Wait a few
minutes, then reconnect it.
xMake sure the base is plugged in.
A handset can’t make
or receive calls. xMove the handset closer to the base.
A handset won’t ring. xMake sure the ringer is turned on.
A handset is not
working.
xCheck the battery is fully charged.
xCheck the battery connection.
xRe-register the handset to the base.
A handset says
SEARCHING .
xMove the handset closer to the base. The handset
may be at the edge of the base’s range.
There’s a lot of noise
or static on the line.
xMove the handset or base away from the
interference sources; appliances (TVs,
computers, microwave ovens, etc.) or wireless
devices (headphones, room monitors,
controllers, WiFi equipment, etc.).
Callers sound weak
or soft.
xMove the handset closer to the base.
xKeep the handset’s battery fully charged.
xIncrease the earpiece volume.
If you want to change the base PIN (default 0000)
Open the menu. Select ADVANCED SET Ö CHANGE PIN . Enter the current
PIN and press
MENU/OK . Then enter the new PIN and press MENU/OK .
If you want to add a new handset
Register the handset. If you see ” UNREGISTERED “ on the display, the
handset is ready to register.
Your base supports a total of 5 handsets, including any that were
supplied with your phone.

11
1. On the base, press and hold FIND for about 5 seconds with the phone
in standby.
2. On the handset you want to register, open the menu. Select
ADVANCED SET Ö REGISTER .
3. Enter the PIN (default 0000) and press
MENU/OK .
If you want to de-register the handset
1. Open the menu. Select ADVANCED SET Ö UNREGISTER .
2. Enter the PIN (default 0000) and press
MENU/OK .
3. Find the handset you want to de-register and press
MENU/OK .
If you want to connect the phone to a PBX
You may need to change the Recall Time setting.
Open the menu. Select
ADVANCED SET Ö RECALL TIME . Ö SHORT ,
MEDIUM , or LONG .
If you want to select tone or pulse dialing
Open the menu. Select ADVANCED SET Ö DIAL MODE
Ö
TONE or PULSE.
If you use pulse dialing and you need to send DTMF tones during a call,
press and hold *to temporarily switch to tone dialing for that call.
If your phone starts to ring before the phone displays caller’s info
Set the First Ring setting to off.
Open the menu. Select
ADVANCED SET Ö FIRST RING
Ö
ON or OFF.
If you want to reset your phone to the factory default settings
Open the menu. Select ADVANCED SET Ö RESET . To confirm, press MENU/OK .
AC adapter and battery information
xBe sure to use the proper adapter for the base and any chargers.
xDo not place the power cord where it creates a trip hazard or where it
could become chafed and create a fire or electrical hazard.
xThis equipment contains a rechargeable battery.
xWith normal use, the battery should last about one year. Replace the
battery when the talk time becomes short even when the battery is
charged.
xFor best results, return the handset to the cradle after each call to
keep it fully charged.
xDo not short-circuit the battery.
xDo not open or mutilate the battery.
xDisconnect the battery before shipping this product.

12
xThe rechargeable batteries contained in this equipment may explode
if disposed of in a fire.
xDo not charge the battery used in this equipment in any charger
other than the one designed to charge this battery as specified in the
owner’s manual. Using another charger may damage the battery pack
or cause it to explode.
安裝電池
1. 手制後面有個凹位，用力推使可
以將蓋打開。
2. 依照正負極將電池放入。
3. 把手制的蓋重新合好
4. 將交流電連接到手制座的插位
5. 將手制放到插座
注意第一次充電，需要15小時
測試連接
1. 拿起手制並按 TALK/RECALL 的
鍵，你應該聽到撥號聲，而且螢
幕也會顯示 TALK 的字眼
如果你聽不到撥號聲，或者螢幕
顯示 Check Tel Line。
那請重新檢查插座與電話的連接
2. 打一個電話測驗(按END鍵掛線)
如果你聽到有很多雜音，可能你
受到干擾。
3. 用同一的方法測試其他手制。如
果你聽不到撥號聲，請把手制移
近插座。
AS1101 說明書
手制鍵的意思
UP
增加鈴聲或者音量，或者做向上選項的用途
MEUN/OK
主選單目錄，或做確定的用途
TALK/RECALL
接聽或撥出電話
*
按3秒鎖定或解封鍵盤
REDIAL
打開重撥清單
CLEAR
回到螢光幕主頁或作清除數字用途
END
掛線，按數秒可開機或關機
DOWN
減少鈴聲或者音量，或者做向下選項的用途
#
按數秒開關響鈴
INT
內部電話轉移
MUTE
開關靜音

13
使用主選單
接收信號程度
(如閃動: 接收差)
通話中
開啟了鬧鐘
關閉鈴聲
通話紀錄
(如閃動: 有未接來電)
電話簿
口信
電量充足
電量低
(如閃動: 需要充電)
OK
選擇及確定, 按
控制音量大小, 按 ( )
或
( )
回上一頁, 按
更多資訊, 按
日期及時間目錄
用主選單設定時間。(如果有人來
電，電話會自動根據對方的時間做為
設定時間。)當然你亦可以用數字鍵
自行輸入小時、分鐘，(例如：0345
代表3:45)。之後請選擇AM或PM。
全球設定目錄
這個目錄設定只會影響手制。
撥號模式：選擇鈴聲或脈衝撥號
視覺信息提示：設定你的視覺信息
提示
在電話輸入文字
用12個數字鍵在電話輸入你想要的文
字(電話簿的名，手制的使用者名稱
等等。)
1. 電話預設了第一個英文字母及隔
格後的英文字母為大楷，否則其
他英文字母為小楷。
2. 你可以用
*
鍵轉換大小楷
3. 如果兩個英文字是在同一行，請
在輸入第一個字母後等候數秒(或
按
CALLER ID/RIGHT 的鍵)，你
便可以再隨後的空白位輸入另一
字母。
4. 按#輸入空白位
5. 加若要改變輸入的字母，請按
CLEAR 的鍵去刪除，然後重新
輸入。
6. 刪除整個輸入請按住
CLEAR 的
鍵數秒。
7. 按數字鍵0，可以選擇電話內置
的符號
使用你的電話
打出電話：輸入電話號碼，然後按
TALK/RECALL 鍵
接聽來電：按
TALK/RECALL 鍵
掛線：按
END 鍵或把手制放回插座
忽略來電：當電話響時，按
END 鍵
調教聽筒聲量：按
UP 鍵或 DOWN 鍵
開關靜音：按
MUTE 鍵
開關電話：按
END 鍵5秒
改變音量
當你接聽電話時可以透過按 ( ) 或
( ) 來增加或減少音量。
你也可以透過按
( ) 或 ( ) 來增
加或減少鈴聲的音量。

14
使用來電顯示及重撥清單
來電顯示是由你的電信供應商提供的
服務，它會顯示來電的號碼(有時是
來電者的名稱)請聯絡你的供應商索
取更多資訊。
來電顯示清單
1. 電話可以儲存10組來電顯示清單
2. 所以手制會共用來電顯示清單
3. 打開來電顯示清單，請按
UP( )
4. 由最新至最舊，請按 ( )
5. 由最舊至最新，請按 ( )
重撥清單
1. 重撥清單可以記錄最近的 5 個重
撥清單
2. 只有一個手制可以登入重撥清單
3. 打開來電顯示清單，請按
REDIAL
4. 由最新至最舊，請按 ( )
5. 由最舊至最新，請按 ( )
6. 關閉重撥清單，請按 CLEAR 鍵
個人輸入選項，請在電顯示及重撥清
單找一個號碼，然後按
MEUN/OK
# Delete Entry (由電顯示及重撥清
單刪除該號碼)
# Store Into Pb (把電顯示及重撥清
單的號碼加入電話簿)
# Delete All (把電顯示清單全部號碼
刪除)
使用來電等候
使用來電等候服務是由你的供應商提
供，目標是讓你可以接聽其他來電，
當你在對話時。當你想接聽其他來電
時，請按
TALK/RECALL 鍵。
使用電話簿
電話簿上可以儲存 20 組的電話號碼
1. 按
PHONEBOOK( ) 鍵打開
電話簿
2. 按
DOWN 鍵從 A-Z 中選擇單字
3. 按
UP 鍵從 Z-A 中選擇單字
4. 輸入打出號碼請按
MENU/OK 鍵
5. 編輯輸入號碼請按
MENU/OK
鍵，然後選擇
EDIT
6. 刪除輸入號碼請按 MENU/OK 鍵，
然後選擇
DELETE
加電話號碼到電話簿
輸入電話號碼後按 MENU/OK 鍵，選
擇 CREATE NEW
注意：最多只能輸入
24 位的電話號碼
刪除整個電話簿
打開電話簿，按 MENU/OK 鍵，然後
選擇 DELETE ALL
找回手制：
按插座上的 FIND 鍵，手制會發出1
分鐘的嘟嘟響。要取消請按
FIND 鍵
或者手制的任意一個鍵。
來電會議
兩個手機可以同時與街外來電進行
會議
1. 參加會議，按
TALK/RECALL 鍵
2. 若要離開會議，照平時掛線便可

15
內部通話
兩個手制可以進行內部通話，並不需
用電話線。
進行內部通話時，你仍然可以接聽街
外來電。
1. 進行內部對話按
INTERCOM ，再
選擇你想對話的手制。
2. 取消內部對話按
END
3. 接聽按 INTERCOM 或 TALK/
RECALL
4. 結束內部對話按 END
來電轉移
1. 按 INTERCOM
2. 選擇你想轉移的手制
3. 當其手制接聽時，你便會掛線(按
TALK/RECALL 重新參加對話)
設定語音信箱
當 STATUS 的燈亮著時，代表你有
新的留言，螢幕也會出現一個信息
的圖示。
當你收聽留言後，螢幕上的信息圖示
會消失。
開啟清單，選擇 HS SETTINGS，再
選擇 VOICE MAIL
輸入語音信箱電話號碼(最多24位
數字)
按
MENU/OK 確定
按 ＂1＂鍵數秒便可撥出電話至語
音信箱
鬧鐘設定
設定鬧鐘前必須設定日期和時間
鬧鐘會響鬧1分鐘，按任何鍵可停止
響鬧
若設定了鬧鐘，螢幕會顯示
開啟清單，選擇 CLOCK&ALARM，
再選擇ALARM，可自定循環響鬧
循環響鬧可選 ONCE，DAILY，
或 OFF
選擇 CLOCK&ALARM，再選擇
ALARM TONE，可選擇鬧鐘鈴聲
AC變壓器及電池資訊
# 使用供應商提供的AC變壓器，絕
對適合插座及任何的充電器
# 不要將電線放在容易絆倒或摩擦的
地方，這會產生火生火花和電力干
擾
# 不要將電話原部件放在陽光下直接
照射或高溫的地方
# 為了有最佳的功能，請每次用完電
話後，把手機放回插座充電
# 當你發覺談話的時間越來越短，即
使電池是滿，這代表你要更換新的
電池
可充電電池
# 此裝置包含了可充電電池。
# 可充電電池暴露於火時，會發生爆
炸。
# 不要將充電池放在其他充電器上充
電，因為設計不 一定相同，這可
能會引致充電池損壞。
