Uniden FP 107 User manual

FP
107
MANUAL
OWNER’S
Digital
Answer Machine
Caller ID
Speaker Phone

1
CONTROLS & FUNCTIONS
1 LCD Screen
2 Delete
3 Hold / Answer LED
New Call LED
New Message LED
4 Answer on/off
Out Going Message (OGM)
Stop
5Handset
6 Alpha Numeric Keypad
7 Dial
8 Call Diversion
Block CID
Call Waiting
9 12 one touch Speed Dial
10 Flash
11 Store
12 Cancel
13 Redial/Pause
14 Hold
15 Speaker
16 Mute
1
2
3
4
6
7
8
9
10
11
12
14 15 16
13
Answer Phone Base Unit
5
hold / answer new call new message
answer on / off ogm stop
call diversion call waitingblock cid
play
123 4
5 6 7 8
910 11 12
abc def
ghi jkl mno
pqrs tuv wxyz
hold speaker mute
0
789
6
5
43
2
1
rdl/p
cancel
store
flash
delete dial
Caller ID
Telephone Answering Machine
AM
PM call#
NEW
RPT OGM 1 ANS ON

2
18 LCD Screen
19 Repeat
20 Battery low icon
21 Time
22 OGM 1
23 Speaker phone
24 Date
25 Message
26 New call icon
27 Call counter
28 Telephone number
29 Name
30 Review
LCD Screen
delete dial
Caller ID
Telephone Answering Machine
21 24 26 27
20
18
2829
Base Unit - right side
Base Unit - left side
Base Unit - rear
32
31
3534 37
36 38
33
power
telephone
line ringer
volume
off / lo / hi
ringer
select
2 4 7 TS reset
handset volume
hi
normal
speaker volume
min max
mid
31 Handset volume control
32 Speaker volume control
33 Handset cord jack
34 AC Adaptor plug
35 Telephone line connection
36 Ringer volume control
37 Answer machine ring select
38 Reset
22
23
25
30
19
1 2:22AM
PM 01/01 call#
NEW 00
RPT OGM 1 ANS ON
02-9599-3355
UNIDEN

CONTENTS
CONTENTS
OF YOUR OWNERS MANUAL
3
Controls and Functions
Contents
Quick Start Guide
Introduction
Features
Installation / Safety
Supplied with Your FP107
Wall Installation
Adjusting the Ringer Volume and Tone
Setting the Clock
Telephone Operation
Making a Call
Answering an Incoming Call
Using Flash
Using Hold
Using Mute
Memory Dialling
Storing a Number in Memory
Storing a Number from Caller ID Records
Entering a Pause in a Memory Number
Reviewing Memory Numbers
Dialling a Memory Number
Chain Dialling
Call Diversion
Telephone Answer Device
Recording Outgoing Messages
Checking te Outgoing Message
Using Toll Saver
Setting the FP107 to Answer Calls
Caller ID Operation
Name Tagging
Reviewing Caller ID Records
Deleting Call Records
FP107 Operation
Playing Messages
Deleting Messages
Screening Calls
Advanced Features
Setting the Display Contrast
Using Call Breakthrough
Remote Operation
Changing the Remote Operation Security Code
Remote Command List
Troubleshooting
Warranty
1
3
4
6
6
6
7
8
9
9
10
10
10
11
11
11
12
12
12
13
13
13
14
14
15
15
16
16
16
17
17
18
18
19
19
19
20
19
20
20
20
20
21
22
23

4
Plug the Telephone Cord into the Base Unit,
then into the Phone Socket on the wall.
Plug the AC Adaptor into the Base Unit, then
into the Power Point.
Start
Here!
Quick Start Guide
Make sure the AC
Adaptor remains
switched ON at all
times.
Installing
the Base Unit
Phone socket
!
AC Adaptor Power point
Telephone cord
power
telephone
line ringer
volume
off / lo / hi
ringer
select
2 4 7 TS reset
This page is a very condensed version of the Owners Manual. It is designed to allow you
to get your phone installed and operating as quickly as possible - however it does not
attempt to explain any of the advanced features of the FP107 .
Plug one end of the Handset curly cord into the handset and the
other into the jack on the side of the telephone base.

Installing the
Backup Battery
This symbol on the display screen indicates the battery level
is low. Disconnect the telephone line cord and replace it with a 9V alkaline
battery.
Making a Call
Pick up the handset from the base and speak.
OR
Press and speak
Answering a Call
Pick up the handset
OR
Press
Dial the number
To hang up, replace the handset on
the base - or press
NOTE
Use a small Phillips screwdriver to remove the two screws on
the battery compartment cover located under the base.
Remove the cover.
Plug the battery contacts in place and lay the battery in the battery
compartment.
Replace the cover and secure with the screws.
speaker speaker
To Redial (last number dialled)
Pick up the handset
OR
Press
Press
The telephone will automatically
redial the last number dialled.
speaker
rdl/p
speaker
5

6
FEATURES
TO YOUR NEW PHONE
INTRODUCTION
l
l
l
l
l
INSTALLATION & SAFETY
AVOID -
moisture
3
AVOID -
Connecting
more than
phones as Ringing
may be impaired.
DON’T -
overload the
power oulet
OR
plug into a multi
power board.
l
l
l
l
l
12 Number Memory Dialling
Speakerphone
Flash
Mute
Hold
ANSWER MACHINE
FEATURES
Recordable Outgoing Message
Voice/Date/Time Stamp
Adjustable Ring Number
Toll-Saver
Phone Pick-Up Detection
CALLER ID FEATURES
3-Line Display
Caller ID Memory
Call Summary
Name Tagging
l
l
l
Pause
Redial
Volume Controls
Adjustable Ringer Volume
Hearing-Aid Compatible
Tone Dialing
Call Breakthrough (CBT) with Programmable Code
Call Screen
Remote Operation with Programmable Code
Room Monitor
Memory Backup
New Call Indicator
Review Scrolling
Dialling Option
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l

SUPPLIED WITH YOUR FP107
If any of these items are
missing or damaged,
contact the place of
purchase.
To get the most from your
purchase, please read the
Owners Manual
thoroughly. Also be sure
to complete the Customer
Support Card.
1 - AC Adaptor
1 - 9V battery
1 - Wall mount bracket
and 2 screws
1 - Telephone line cord
NOTE
NOTE
1 - Owners Manual
1 - Customer Support card
7
MANUAL
OWNER’S
Digital Answerphone
FP
107

Wall Mounting
•
•
•
If required, you can mount your phone directly on a wall.
Before mounting your phone, please consider the following:
Select a location away from electrical cables, pipes or other items behind the
mounting location that could cause a hazard when inserting screws into the wall.
Make sure the wall material is capable of supporting the weight of the telephone.
Use the screws (supplied) with anchoring devices suitable for the wall material
where the Telephone will be placed.
Insert two mounting screws 100mm apart.
Allow about 5mm between the wall and
screw heads for mounting the phone.
WALL INSTALLATION
5mm
100mm
Gentlypullout thehandset retainer
tab, turn it 180 and refit it.
Attach the wall mounting
bracket to the telephone base.
Place the base unit on the
screws and push down until it
is firmly seated.
hold / answer new call new message
answer on / off ogm stop
delete dial
Caller ID
Telephone Answering Machine
AM
PM call#
NEW
PM VIP OGM OGM2 ANS ONLY
8

ADJUSTING THE RINGER VOLUME AND TONE
Ringer volume control
Locate the volume control switch at the rear of the
base.
Slide the ringer volume switch to the desired
off/lo/hi setting.
9
To avoid losing the day and time settings if AC power fails, we recommend you install
a backup battery before you set the day and time (see “Installing a Backup Battery” on
Page 5). Follow these steps so the FP107 can record the correct day and time each
message and memo is recorded.
1. Hold down until the FP107 beeps once.
2. Press 3 times until SUNDAY appears.
3. Repeatedly press or #to select AM or PM.
4. Press . The hour digit flashes.
5. Repeatedly press to set the correct hour.
6. Repeat Steps 4 and 5 to set the minute, month, date, and the day of the week.
7. Press .
If you do not complete
each step with-in 8
seconds, the FP107 exits
setup. Start again at
Step 1.
NOTE
store
store
VOLUME CONTROL
Handset volume control
While using the phone you can adjust the handset volume with
the control, located at the side of the base.
Speaker volume control
During a speaker phone conversation, you can adjust the speaker volume by sliding the
control (located on thr side of the base) until you hear the desired volume.
ringer volume
off / lo / hi
handset volume
hi
normal
speaker volume
min max
mid
speaker volume
min max
handset volume
hi
normal mid
SETING THE CLOCK
store

TELEPHONE OPERATION
If any background noise
interferes with the
speakerphone's operation,
press to turn off
the base's microphone
while the other party is
speaking.
NOTE
mute
Making a Call
To make a call with the handset, pick up the handset. When you hear the dial tone, dial
the phone number, DIALLING is displayed. You will see the number as you dial, then
(after 8 seconds) the elapsed time of your call.
Press to make a call using the speakerphone. SPEAKERPHONE is displayed.
Dial the phone number, DIALING is briefly displayed, followed by the number as you
dial, then (after 8 seconds) the elapsed time is displayed.
Answering an Incoming Call
To answer an incoming call:
1. Pick up the handset
OR
Press .
To end a call:
1. Place the handset back on the base
OR
Press .
Using Redial
To redial the last number you dialled:
1. Lift the handset and press
OR
Press . Press . The telephone will
automatically redial the last number dialled
speaker
speaker
delete dial
Caller ID
Telephone Answering Machine
1 2:22AM
PM 01/01 call#
NEW 00
RPT OGM 1 ANS ONLY
02-9599-3355
SPEAKERPHONE
hold speaker mute
Mic
0
rdl/p
speaker
speaker rdl/p
10
rdl/p
hold speaker mute
Mic
0
rdl/p

Using Mute
To talk to someone else in the room without the person on the other end of the phone
line hearing you, press . The FP107 beeps, and <MIC MUTE> is displayed.
Press again to resume your conversation.
If you do not have special
phone services, from your
telephone company or
PBX, pressing
may disconnect the
current call.
The FP107 will not show
Caller ID information for
an incoming call while
another call is on hold.
NOTE
mute
mute
Using Flash
Use to perform the hook switch operation for special services, such as Call
Transfer on a business PBX.
Using Hold
To put a caller on hold, press . The FP107 beeps, <HOLD> is displayed, and the
hold/answer indicator flashes. You can now hang up the handset without disconnecting
the call.
To resume the call:
Press again
OR
Lift the handset if the handset is placed on the base
OR
Pickup any extension phone on the same line.
hold
delete dial
Caller ID
Telephone Answering Machine
1 2:22AM
PM 01/01 call#
NEW 00
rpt OGM 1 ANS ONLY
02-9599-3355
<MIC MUTE>
hold speaker mute
Mic
0
rdl/p
NOTE
delete dial
Caller ID
Telephone Answering Machine
1 2:22AM
PM 01/01 call#
NEW 00
rpt OGM 1 ANS ONLY
02-9599-3355
<HOLD>
hold speaker mute
Mic
0
rdl/p
flash
flash
11
hold

You can store up to 12 numbers in memory and dial any stored number by pressing one
key.
Storing a Number in Memory
There are 12 memory location buttons.
1. Press . NUMBER? is displayed.
2. Enter the number you want to store.
3. Press , NAME? is displayed.
4. Enter the name using the alpha keys.
5. Press again. STORE TO? is displayed.
Press a memory location (1-12).
You must complete each
step within 8 seconds.
NOTE
If you make a mistake
while entering the number,
or name press
once then re-enter.
NOTE
store
store
store
To change a number or
name in memory, store a
new one in its place.
Storing Numbers from Caller ID Records
You can store a number from a Caller ID record.
1. Repeatedly press or to select the desired phone number.
2. Press three times.
3. Then press a memory location key to store the number
MEMORY DIALLING
store
delete dial
Caller ID
Telephone Answering Machine
1 2:22AM
PM 01/01 call#
NEW 00
RPT OGM 1 ANS ONLY
02 - 9599 - 3355
NUMBER?
store
123 4
5 6 7 8
910 11 12
abc def
3
2
1
flash
11
def
mno
wxyz
9
6
3
cancel
store
flash
12
NOTE
To erase a memory press
3 times, followed
by the memory location
you wish to delete.
NOTE
1234
5678
910 11 12
abc def
3
2
1
flash
Store your area code with
your number eg: 02, for
name tagging to operate.
NOTE

Entering a Pause in a Memory Number
The pause feature is useful for long distance calling or for access codes that require a
pause between digits.
When storing a number in memory, press . This enters a 2-second pause. P
(pause) is displayed. For a long pause, press again.
Reviewing Memory Numbers
To review stored numbers, press the memory location key (1 - 12). Only the first 12
digits of the phone number is displayed. To view the remainder press that location
number button again.
Dialing a Memory Number
There are two ways of dialling memory numbers.
1. Lift the handset or press
2. Press the desired memory location key.
OR
Press the desired memory location key then press .
Each pause entry uses one
digit of memory.
NOTE
speaker
dial
rdl/p
rdl/p
hold speaker mute
Mic
0
rdl/p
delete dial
Caller ID
Telephone Answering Machine
1 2:22AM
PM 01/01 call#
NEW 00
RPT OGM 1 ANS ONLY
02-9599-3355
hold speaker mute
Mic
0
rdl/p
123 4
5 6 7 8
910 11 12
abc def
3
2
1
flash
13

Chain-Dialling
For quick recall of numbers for special services, you can store each group of numbers
in its own memory location. Then, when calling special services, dial the service's
main number first. At the appropriate place in the call, press the memory location
button for the additional numbers you want to send.
Call Waiting:
When the call waiting tone sounds, press followed by . This will
switch between the original and incoming call.
Block CID:
Each time you make a call, your telephone number is automatically forwarded to the
party you are calling. You can use Block CID to prevent your number being sent.
1. Pick up the handset or press .
2. Wait for the dial tone. Press then press .
3. Dial the telephone number of the person you wish to call. Your telephone number
will not be forwarded for this call only.
call waiting
dial
Call Diversion:
If your phone is not answered within 20 seconds (approximately 7 or 8 rings), it can be
diverted to another number.
Pick up the handset
OR
Press the button.
Wait for the dial tone, press - CALL DIVERT ON is displayed - then
press and hang up.
The telephone will automatically dial the access code 61# and will enable the “Call
Forward No Answer” feature, diverting unanswered calls to the fixed number you have
previously assigned the divert to.
speaker
block cid
dial
speaker call diversion
dial
hold / answer new call new message
answer on / off ogm stop
call diversion call waiting
block cid
play
delete dial
Caller ID
For Call Waiting to
operate, you must first
subscribe to this service
through your telephone
company.
NOTE
For Call Diversion to
operate, you must first
subscribe to this service
through your telephone
company.
NOTE
14

NOTE
The maximum length for
outgoing message is 60
seconds. As you record,
the message counter
shows the recording time.
OGM1 flashes on the
display if an out-going
message has not yet been
recorded.
NOTE
15
Recording Outgoing Messages
Before the FP107 can answer calls and record messages, you must record an outgoing
message (OGM).
1. To record the OGM 1 message, hold down until the timer starts counting.
OGM1 RECORDING is displayed.
2. Speak clearly at about 20cm from the front of the FP107 the message that you want
incoming callers to hear.
3. When you finish speaking, press . The FP107 beeps and plays back the outgoing
message. stop
To Cancel ‘Call Diversion’
1. Pick up the handset
OR
Press .
2. Press - CALL DIVERT OFF is displayed - then press again
and hang up.
The telephone will automatically dial the access code 61# and will cancel the
diversion.
speaker
call diversion dial
hold / answer new call new message
answer on / off ogm stop
call diversion call waiting
block cid
play
delete dial
Caller ID
TELEPHONE ANSWER DEVICE
ogm
hold / answer new call new message
answer on / off ogm stop
call diversion call waiting
block cid
play
delete dial
Caller ID
#

The maximum recording
capacity is 16 minutes (or
68 recorded messages), or
86 Caller ID records.
NOTE
16
Checking the Outgoing Message
To check an outgoing message, press . OGM1 PLAYING appears and the message
plays.
If no outgoing message is recorded when you press OGM1, the FP107 announces
“You have no announcement one” and sounds four beeps.
Number of Rings
The FP107 can be set to 2, 4 or 7 rings before it answers the call and plays
your message. The selector is located at the rear of the base unit.
Setting the FP107 to Answer Calls
To turn on the FP107 and set it to answer calls and record messages, press the
once. The FP107 says “Answer on”. ANS ON is displayed, the FP107
plays the outgoing message. The hold answer indicator lights to show that the FP107
is ready to answer calls.
answer on/off
ogm
Using the Toll Saver
If the ring select switch is set to TS (toll-saver), the FP107 answers after two rings if you
have new messages. If there are no new messages, the FP107 answers after four rings.
This gives you time to hang up before the FP107 answers so you can avoid unnecessary
long-distance charges.
ringer
select
2 4 7 TS
ANS ON
Telephone Answering Machine
1 2:22AM
PM 01/01 call#
NEW 00
RPT OGM 1 ANS ON
123 4
hold / answer new call new message
answer on / off ogm stop
call diversion call waitingblock cid
play
delete dial
Caller ID
Telephone Answering Machine
1 2:22AM
PM 01/01 call#
NEW 00
RPT OGM 1 ANS ONLY
OGM1 PLAYING
123 4
hold / answer new call new message
answer on / off ogm stop
call diversion call waitingblock cid
play
delete dial
Caller ID
-00- -00-
CALLS MESSAGES
If the FP107 Answer
Machine is off, after 15
rings it will automatically
switch on and answer the
call.
NOTE

17
If you subscribe to Caller ID service from your phone company, the phone automatically
displays the information the phone company sends between the first and second rings
of every call you receive. It stores up to 86 numbers only or name and number call
records in its Caller ID memory.
It also shows the date and time the call was received. The display also shows if caller
information is not available or if the sender chose not to send the information.
The new call LED flashes during an incoming call, and the Caller ID record
is displayed. The total Caller ID record is displayed for about 8 seconds, after the last
ring stops.
If you receive more than one call (without an accompanying message) from the same
phone number, RPT (repeat) is displayed, and the FP107 stores a single Caller ID record
for that number with the date and time of the last call. Any call with a voice message
will have a call ID record.
If only Caller ID records (both incoming messages and Caller ID records) are full, the
FP107 announces “Memory is full”, and CALLS MSG FULL appears. The FP107
answers calls after answer rings and plays “Message is full. Thank you for your call”.
Caller ID Messages
CALLER ID OPERATION
Display Description
CALLS MESSAGES Appears as new calls are received. xx is the number of new calls.
PRIVATE Appears when the caller has blocked the Caller ID information from
being sent.
OUT OF AREA Appears when the caller is not within a Caller ID service area. No caller
information appears.
ERROR Appears if there was an error during the transmission of Caller ID
information.
END OF CALLS Appears when you have reached the end of your call records.
TOP OF CALLS Appears when you have reached the top of your call records.
RPT Appears when you review a Caller ID record from someone who has
called more than one time from the same number.
-XX- -XX-
Name Tagging
If the caller ID telephone number exactly matches a number you have stored in memory,
the name stored in memory will be displayed with caller ID numbers.

Each time you receive a call, the FP107 stores a Caller ID record that you can review
later, even during a call.
A Caller ID record includes:
• Call number
• Time and date of the call
• Callers' telephone number (if available)
• Caller's name (if available)
• Voice message (if the calling party leaves a message)
Repeatedly press to see more recent call records or to see older call records.
To review the new call only, hold down or until the new call appears.
If you receive a call with a message, flashes on the display. To play a specific
message, repeatedly press or until the selected Caller ID information
appears, then press . To play all messages, press only.
Deleting Call Records
Deleting a Single Call
To delete a specific call record, repeatedly press or until the call you want
to delete appears. Then press .
To delete a call that has a message, repeatedly press or until the desired
call appears. Press to play the message, then press during the playback.
After the message is deleted, press to delete the Caller ID record.
Deleting All Calls
To delete all calls, press and hold on the current date/time display until dEL
ALL appears, then press . To return to the current time display, wait for seconds,
or press .
Using Dial
1. Repeatedly press or to select the desired phone number.
2. To callback a phone number from Caller records with the speakerphone, press
OR
To call back a phone number from Caller ID records with the handset, pick up the
handset then press .
18
REVIEWINGCALLERID RECORDS
The FP107 returns to the
time/date display after 8
seconds if you do not
press a key.
NOTE
You can review the Caller
ID information, but
cannot play the messages
when the handset is off the
cradle or the speakerphone
is in use.
NOTE
The FP107 will not delete
Caller ID records or
messages that have not
been reviewed or played.
You cannot delete Caller
ID records during a call.
NOTE
delete
play
delete
stop
dial
play
play delete
delete
dial

FP107 OPERATION
Playing Messages
The FP107's message window shows the total number of messages, both old and new.
If there are new messages, the new message LED flashes.
To play all messages, press .
To adjust the FP107’s volume, slide the speaker volume min/max on the right side
of the phone.
To play only new messages, hold down for 2 seconds.
To replay a message while you are listening to it, press . The current message
replays from the beginning.
To select another message, press or until the desired message number
appears in the display.
To pause while listening to messages, press . PAUSE is displayed. To resume
playback, press again within 60 seconds.
To stop playback, press . The FP107 beeps, says “End of messages” and END
OF MESSAGES is displayed. The FP107 then resets to answer calls.
Deleting Messages
To delete a specific message, press while the message is playing.
To delete all messages, stop playback and hold down until dEL ALL appears,
then press .
The TAD does not delete new messages.
Screening Calls
To screen calls, let the FP107 answer them. TAD IN USE is displayed.
Listen to the caller's message through the FP107's speaker. To adjust the volume, slide
speaker volume - min / max on the right side of the FP107.
If you decide to answer the call, pick up any phone on the same phone line as the
FP107. The FP107 stops recording and resets to answer the next call.
If you do not want to take the call, let the FP107 finish recording the caller's message.
delete delete
If you answer the phone
just as the TAD answers,
the TAD may not stop
playing the outgoing
message. If this occurs,
simply press .
NOTE
stop
stop
play
play
play
play
19
