unii UN-WPAMOUT Manual

UN-WPAMOUT
Two Way Wireless Outdoor Double PIR
Detectors with Anti-masking
INSTALLATION INSTRUCTIONS
&
USER MANUAL

UN-WPAMOUT
UNii Wireless outdoor PIR AM
INSTALLATION INSTUCTIONS
1
1 Introduction................................................................................................................................................. 2
2 Features ...................................................................................................................................................... 3
3 Operation..................................................................................................................................................... 3
4 Assembly Description ................................................................................................................................. 4
5 Detection Pattern ........................................................................................................................................ 6
5.1
Range Adjustment........................................................................................................................ 6
5.2
Pet Immunity ................................................................................................................................ 7
6 Learning & Installation................................................................................................................................ 8
6.1
Select Mounting Location............................................................................................................ 8
6.2
Learning Procedure...................................................................................................................... 9
6.3
Detector Installation................................................................................................................... 10
7 Settings & Adjustments ............................................................................................................................ 11
7.1 Detection beam direction ................................................................................................................. 11
7.2 Detection range setting .................................................................................................................... 11
7.3 Dip Switches Functions.................................................................................................................... 12
8 Test procedure .......................................................................................................................................... 14
9
Specifications ..................................................................................................................................... 15
UNii Limited Warranty ...................................................................................................................................... 16

UN-WPAMOUT
UNii Wireless outdoor PIR AM
INSTALLATION INSTUCTIONS
2
1
The UN-WPAMOUT is a unique two-way wireless outdoor double quad motion detector with active
Anti-Mask feature. The advanced Double PIR Elements provide two detection areas for superior
stability.
The UN-WPAMOUT is designed for outdoor usage in most severe and extreme climate conditions
that may also accommodate pets.
High reliability is achieved by combining both Dual Quad Sensors with highly sophisticated
software as well as an adaptive coverage area, reducing false alarms alerts to zero while
maintaining high security standards for the detection of human intruders into protected area.
The detection sensitivity and range are controlled by optical rotary switch allowing 25 calibration
levels, so that the effective pattern will be set for every installation environment and protection
site.
The UN-WPAMOUT is designed to protect large areas and can easily be installed on walls to provide
a solid protection of the area while rejects interferences from birds and small animals due to “PET
MASK” optics.
The UN-WPAMOUT has a unique ID code - compatible with the UNii Wireless Interface Elite.
Double PIR
Elements
Pet Immunity Anti-Masking 2 Way Wireless Remotely
Configurable

UN-WPAMOUT
UNii Wireless outdoor PIR AM
INSTALLATION INSTUCTIONS
3
2
•UN 2-way wireless security
•Detection Range 3 - 12m
•PIR sensitivity adjustment
•Temperature compensation
•Pet Immunity up to 35kg
•Anti-Masking feature enabled by Dip Switches
•Protection from: direct sunlight, wind up to 30m/sec, snow and rain, small animals…
•Unique waterproof and seal plastic design
•Powered by 4 Lithium batteries Type AA (Battery life: up to 3 years)
•Operating Frequencies: 868.35MHz / 916MHz
•Height installation calibrations free: from 0.8m to 1.5m
•Tamper Open/Close transmission
•Supervision transmission
•Battery status transmission
•LED indications
•Range up to 500m in open space
•Front and Back tamper protection
•Sound indication for walk test and intruder detection
•Unique ID number.
3
This UN-WPAMOUT wireless outdoor detector transmits the following events:
•SUPERVISION– A periodical transmission every 7 min. indicates detector’s presence.
•ALARM – Alarm transmission triggered by the device indicating Motion detection. The Red
LED will blink once.
•LOW BATTERY – Whenever the battery reaches the low level (2.5V), a Battery Low signal will
be sent. When Battery level drops below Cut Off level (2.3V) the device will stop functioning
and the Red LED will blink for 10 seconds and then turned Off.
•TAMPER – Whenever the cover is removed from Bracket or the device is tear off from the wall,
a Tamper signal will be transmitted to the UNii control panel. When cover will be returned,
cancel the tamper signal on the UNii keypad.
•ANTI-MASKING – If an attempt is made to mask the lens with a sticker or to put a masking
object close to the lens, a trouble alert will result up to 180 seconds after masking (future
development).

UN-WPAMOUT
UNii Wireless outdoor PIR AM
INSTALLATION INSTUCTIONS
4
4
The UN-WPAMOUT wireless outdoor detector is a robust detector which includes indication LED
prism that can be easily observed from long distance.
Having a back-metal bracket, the UN-WPAMOUT can be easily mounted to walls and poles using
mounting screws or metal bands (both supplied)
1 Front Cover 3 Detector Main Unit
2 LED Indicator 4 Back Metal Bracket

UN-WPAMOUT
UNii Wireless outdoor PIR AM
INSTALLATION INSTUCTIONS
5
Front view Back view with battery
2 LED Detector 9 Batteries Cover
4
Upper PIR Element
10
Back Tamper Switch (Removal)
5
Anti-Mask Sensor
6 Lower PIR Element
7 Dip Switches
8 Front Tamper Switch (Opening)

UN-WPAMOUT
UNii Wireless outdoor PIR AM
INSTALLATION INSTUCTIONS
6
5
5.1 Range Adjustment
The UN-WPAMOUT wireless outdoor detector has a 90° top view Double PIR detection pattern with
over 12m detection distance (when installed at 1.5m above the ground surface).
The UN-WPAMOUT has an internal rotating housing (which includes the 2 PIR elements) that can be
adjusted vertically, so its 90° coverage may vary between 0° and 180°.
The Upper PIR element can be horizontally adjusted to 5 different levels.
Adjustable
Detection
Range
Upper PIR element detection pattern
Adjustable between 3m to 12m

UN-WPAMOUT
UNii Wireless outdoor PIR AM
INSTALLATION INSTUCTIONS
7
5.2 Pet Immunity
The UN-WPAMOUT wireless outdoor detector can differentiate between pets and human bodies and
alert accordingly by having PIR detection beams movement detection:
A. Lower PIR element which is fixed to 12m range and 60 cm above ground level which helps
avoiding pets’ detection over the entire area.
B. Upper PIR element which has adaptive range between 3m and 12m.
By having both PIR detection beams detection the crossing object will be defined as intrusion,
causing an alarm.

UN-WPAMOUT
UNii Wireless outdoor PIR AM
INSTALLATION INSTUCTIONS
8
6
6.1 Select Mounting Location
The installation of the UN-WPAMOUT wireless outdoor detector requires straight and solid base for
the detector and setting of front panels against the center of protected area.
The protected area must be free from obstacles like walls, fences, trees, ditches, and other
microwave detectors, as well as systems of anti-intrusion surveillance.
The back-metal bracket provides UN-WPAMOUT installation on a wall or pole. The wall or pole
should be leveled.
Choose a location most likely to intercept an intruder according to detection pattern on page 6.
Avoid the following Installation Locations:
•Facing direct sunlight.
•Facing areas subject to rapid temperature changes.
•Wall angle of more than 10º from perpendicular line.
•Mounting at more than 10º Deviation from horizontal line.
•Facing metal doors.
•Do not install near direct source of heat or air gust.
•Clear all physical obstacles from the detection area (e.g.,
Plants, laundries, etc.)
•Clear all light reflecting surfaces from the detection area, as
well as water puddles.
•Avoid installation on the following types of ground:
Thick vegetation
Grass (un-mown)
Water
Sand
Metal.
NOTE:
Recommended installation height is 1.2m.
If there is a risk of tall pets (over 60cm) the detector is to be installed at 1.5m.
The Double Quad high quality sensor detects motion crossing the beam; it is less sensitive
detecting motion towards the detector.
The UN-WPAMOUT performs best when provided with a constant and stable environment.
To ensure suitable operation of the UN-WPAMOUT, type of ground should be one of the following:
Asphalt concrete, Cement, Soil, Clay, Gravel, or Grass (mown).

UN-WPAMOUT
UNii Wireless outdoor PIR AM
INSTALLATION INSTUCTIONS
9
6.2 Learning Procedure
LED of the detector will start blinking alternately Red/Green
during the warmup and learning process (30 secs)
30 Sec during Warm Up and Learning
Open the detector unscrewing the bottom screw.
Unscrew the detector unit from the back-metal bracket
and remove it by tilting it.
Remove the batteries cover
The learning process should be completed within 30 seconds.
UNii Control panel will indicate completion at the end of the process.
Close the battery cover
Refer to the Installer manual UNii Wireless Interface module for
learning wireless components.
Make sure that the UNii control panel is on learning mode
according to installation instruction.
Insert batteries in the detector respecting the polarity (+/-)

UN-WPAMOUT
UNii Wireless outdoor PIR AM
INSTALLATION INSTUCTIONS
10
6.3 Detector Installation
Important! Prior to installation, read “Select mounting location” section carefully.
1. Detector must be installed in such manner that the
intruder is most likely to cross the detection area
from side to side.
2. The detector must be installed at height of 0.8m to
1.5m
3. Draw metal bracket holes on the wall, leaving 15cm
from all sides, for easy installation and maintenance.
4. Install the metal bracket on the wall or a pole using
mounting screws or metal bands.
5. Install the detector unit on the metal bracket
6. Screw the detector unit to the back-metal bracket
7. Screw the detector unit to the back-metal bracket.
8. Close the detector cover screwing the bottom
Screw.
IMPORTANT NOTICE
After detector closure, the detector starts calibration process. Do
not stand in detector's range during this period of 3 minutes.
After this period, the detector is ready for operation

UN-WPAMOUT
UNii Wireless outdoor PIR AM
INSTALLATION INSTUCTIONS
11
7
7.1 Detection beam direction
The UN-WPAMOUT detection beam direction may vary between 0º and 180º.
To change the detection beam direction, rotate the internal detection element housing to the desired
direction.
7.2 Detection range setting
The UN-WPAMOUT detection range may vary between 3m and 12m, while installed on 1.2m
height above the ground surface.
Changing the detection range is achieved by sliding the upper detection element up or down:
Slide the detection element down for long range or up for short range detection.

UN-WPAMOUT
UNii Wireless outdoor PIR AM
INSTALLATION INSTUCTIONS
12
7.3 Dip Switches Functions
There are 5 DIP switches on the UN-WPAMOUT board that enable settings of following functions:
Switches 1 & 2 – PIR ELEMENTS SENSITIVITY SETTING
Use the following combinations for setting PIR upper and lower element sensitivity control according to the
environment.
Switch Position
DESCRIPTION
SW1
SW2
OFF
OFF
LOW SENSITIVITY
OFF
ON
MEDIUM SENSITIVITY
**ON
**OFF
** NORMAL SENSITIVITY
ON
ON
HIGH SENSITIVITY
Switch 3 – LED VISUAL INDICATION
Use for setting LED Enable / Disable
** UP Position (ON) – LED enabled
DOWN Position (OFF) – LED
disabled
Setting the Led ON gives the installer the ability to check each detection during the walk test. After
this process it is recommended to switch the Led OFF.
Note: the state of the switch “LED” does not affect the operation of the ALARM and TROUBLE
relays.
ON = ENABLE
SW1
PIR Sensitivity
SW2
SW3
LED Indication
SW4
Anti-Mask Activation
SW5
Buzzer Audio
OFF = DISABLE
** Factory Defaults
Positions

UN-WPAMOUT
UNii Wireless outdoor PIR AM
INSTALLATION INSTUCTIONS
13
Switch 4 – ANTI-MASK ACTIVATION
Future development:
Use for Anti Mask function setting
** UP Position (ON) – AM feature enabled
Down Position (OFF) – AM feature disabled
MASKING CONDITION
Future development:
If an attempt is made to mask the lens with a sticker or to put a masking object close to the lens, a
trouble alert will result up to 180 seconds after masking:
The Red LED will blink, and the TROUBLE (Tamper) will be transmitted.
RESET AFTER TROUBLE OR MASKING
Future development:
In case of masking alarm, proceed as follows:
Search for masking material or objects on the lens or in front of the detector and remove them.
Reset the detector by walking in front of it. Cross its field detection causing it to alarm several
times.
If everything is back to normal, the LED should stop blinking, and the TROUBLE should reset.
Note: If walk testing does not cause the trouble alert to stop, recheck for masking.
Switch 5 – BUZZER AUDIO INDICATION
Use for setting Audio Buzzer Enable / Disable
** Up Position (ON) – Buzzer enabled
Down Position (OFF) – Buzzer disabled
Setting the buzzer ON gives the installer the ability to hear a beep on each detection for 1.8 seconds during
the adjustments and walk test. After this process it is recommended to switch the buzzer OFF.

UN-WPAMOUT
UNii Wireless outdoor PIR AM
INSTALLATION INSTUCTIONS
14
8
Alarm Test
Allow 3 minutes of warm up time.
Make sure that the protected area is cleared of all people.
ARM the UNii control panel.
Start walking across the detection zone.
Listen to ALARM sound whenever motion is detected (the red LED and the Buzzer can also turn ON
whenever motion is detected, see 7.3).
Allow 5 sec. between each test for the detector to stabilize.
During the alarm test, verify the UNii keypad indicating the alarm. Verify receiving the indication in
the UNii manager software (diagnosis).
Walk test mode can be activated on the UNii keypad or using UNii Manager software.
Tamper Transmission Test
Changing the tamper switch state (by attaching / removing the detector to / from the bracket
and/or the detector from the wall) will cause tamper transmissions.
Check on the UNii keypad if it indicates a tamper alarm. Or check with UNii Manager software (at
diagnostics) whether the detector indicates a tamper alarm.
Communication signal test.
Check the RF Communication quality. Special indication at the UNii keypad that displays
continuously the received RF signal quality.
The UNii keypad has a “RF Signal Strength Indication” to help the installer to define the best
location for the detector from RF perspective.
The indication values are “excellent”, “strong”, “poor” or “unknown”. If this indication value is
“poor” or “unknown”, it is a sign for a weak or no RF link and it is recommended to find a better
installation for the UN-WPAMOUT wireless outdoor detector.
Upon installation, the unit should be thoroughly tested to verify proper operation.
Walk across the entire area where coverage is desired. Should the coverage be incomplete,
readjust coverage range or relocate the detector.
Note: Test procedure should be conducted, at least once a year, to verify proper operation and
range coverage of the detector.
DETECTOR TESTING

UN-WPAMOUT
UNii Wireless outdoor PIR AM
INSTALLATION INSTUCTIONS
15
9
Detection Method
Double PIR Elements with optional Anti-masking feature
Detection Pattern 90⁰with 30 zones detection
Communication UN-RF Two Way with unique serial ID
Modulation Type
GFSK
Frequency 868MHz
Events Transmission Alarm, Anti-Mask, Tamper, Supervision, Low Battery
Supervision Time
7 min by default
Detection Range Configurable from 3m to 12m
Installation Height From 0.8m to 1.5m (Optimal 1.2m)
Range in open space
500m
Battery 4 Lithium Batteries 1,5V Type AA LR06
Battery life Up to 3 years
Current Consumptions
Standby ~22 mA
Receive mode ~24 mA
Transmit mode ~45 mA
Transmit Power: ~14dBm
Tamper Switch Front Cover and Wall Removal (Back Tamper)
Weatherproofing
All openings with gasket and sealed
Protection against water and dust
RFI Protection 10V/m plus 80% AM from 80MHz to 2GHz
EMI Protection 6kV contact, 8kV air
Tamper Switch Front Cover and Wall Removal (Back Tamper)
Temp Compensation
Yes, Dual slop temperature compensation
Alarm Period 2 sec (±0.5sec)
Warm up Period 30 sec (± 5sec)
LED Indicator
LED is ON during ALARM and TROUBLE
Operation Temp -25ºC ~ +55ºC
Protection Degree IP 65
Dimensions
200mm x 86mm x 80mm
Weight 500gr.
*Specifications are subject to change without prior notice.
