UNILED Sumner User manual
Mirror Installation Instructions
UNILED
LED Mirror
Installation
Instructions
Sumner “Arch” Mirror
• 240VAC power feed in the centre of the wall
• Make sure you have a round hole of 30-40mm in diameter where the power feed will sit in
the wall.
• Please ensure you have secure nogging in this area where the screws are to be mounted
for hanging the mirror.
The Sumner LED Mirror is mounted to the wall with 2 x 6mm screws which is to be mounted
in the location as per Diagram 1.
Once the screws are entered into the secure wooden nogs (with no more than 10mm protruding
from the wall) at the height and spacing specified in Diagram 1, the mirror is then hardwired to the
240VAC power feed which is in the wall in the centre of the mirror. The excess cable is then tucked
back into the wall and the mirror is mounted onto the 2 screws via the mounting slots located
on the back of the mirror as per Diagram 2.
Sumner “ Arch” Mirrors
DIAGRAM 2
DIAGRAM 1
PREPERATION OF THE AREA WHERE THE MIRROR IS TO BE MOUNTED
Mirror Installation Instructions
Power
Cable
Y
x
Y
x
Screws
240VAC
VELCRO STRIP
Once the mirror is hooked onto the screws, move the mirror to your right approximately
15mm and then down by 15mm. The mirror is now securely and safely mounted to the wall.
For increased safety, wipe the wall behind the mirror at the bottom and remove the
protective film from the Velcro strip and press firmly to the wall.
The PILL mirrors have an adhesive Velcro at the bottom back side to secure the mirror to
the wall. Wipe the wall or tiles behind the mirror thoroughly, remove the tape from the
Velcro and press the bottom of the mirror firmly towards the wall.
The mirror installation is now complete.
- 800X400mm Portrait- Left and Right screws to be mounted 138mm(x) apart from
the centre of the mirror and 245mm(y) below the desired height of the mirror.
- 900X500mm Portrait- Left and Right screws to be mounted 138mm(x) apart from
the centre of the mirror and 295mm(y) below the desired height of the mirror.
Should you require any further assistance, please email
Sumner “ Arch” Mirrors
Please note that a registered electrician must connect the mirror
to the 240Vac power feed!
Mirror Installation Instructions
Sumner“ Arch” Mirrors
Mirror Installation Instructions
