UNIMO Technology PZ-S400 User manual

Manual
PZ-S series Portable Radio
PZ-S400, PZ-S100

Maintenance Manual
2
TABLE OF CONTENTS
SPECIFICATIONS .................................................................................................................................................5
MODEL: PZ-S100...........................................................................................................................................5
MODEL: PZ-S400...........................................................................................................................................6
MODEL NUMBER................................................................................................................................................. 7
PZ-S SERIES RADIO PACKAGE NUMBERS.....................................................................................................7
FEATURES............................................................................................................................................................. 7
CONTROLS & INDICATORS...............................................................................................................................9
Controls ......................................................................................................................................................... 10
On/Off Volume Switch........................................................................................................... 10
Channel Select Switch .......................................................................................................... 10
PTT Button............................................................................................................................ 10
Monitor Button ...................................................................................................................... 10
Red Button............................................................................................................................. 10
Side Button (Scan Button)..................................................................................................... 11
Speaker Microphone Jack ..................................................................................................... 11
Indicators....................................................................................................................................................... 11
Status Indication LED............................................................................................................ 11
BATTERY PACKS................................................................................................................................................ 12
Installing the Battery Pack.............................................................................................................................13
Removing the Battery Pack...........................................................................................................................14
Charging the Battery Pack.............................................................................................................................15
How to Charging ................................................................................................................... 15
CHARGER............................................................................................................................................................ 16
RADIO OPERATIONS......................................................................................................................................... 17

Maintenance Manual
3
Installation and Removal of Antenna.............................................................................................................17
Power On/Off................................................................................................................................................. 17
Transmission.................................................................................................................................................. 17
Receiving....................................................................................................................................................... 17
Changing Channels........................................................................................................................................ 18
Adjusting Transmitting Power.......................................................................................................................18
SCAN Operating mode..................................................................................................................................18
Normal Scan .......................................................................................................................... 18
Priority Scan.......................................................................................................................... 19
Transmitting .......................................................................................................................... 19
Emergency Call ............................................................................................................................................. 19
Monitor.......................................................................................................................................................... 19
Subtone.......................................................................................................................................................... 20
CTCSS tone frequency ......................................................................................................... 20
DCS code............................................................................................................................... 21
2 Tone Function............................................................................................................................................. 22
VOX .............................................................................................................................................................. 22
Compander..................................................................................................................................................... 22
Scramble........................................................................................................................................................ 22
Stun / Revive Function ..................................................................................................................................22
BCL/BCLO.................................................................................................................................................... 23
TOT ............................................................................................................................................................... 23
Key Lock ....................................................................................................................................................... 23
Battery Indication ..........................................................................................................................................23
PSC................................................................................................................................................................ 23

Maintenance Manual
4
Squelch Level................................................................................................................................................ 24
Cloning .......................................................................................................................................................... 24
Wire Cloning.......................................................................................................................... 24

Maintenance Manual
5
SPECIFICATIONS
MODEL: PZ-S100
GENERAL
Dimensions(Less Antenna) H x W x D
Weight
Radio (less battery)
with battery (2600mAH)
Programmable Channels
Channel Spacing
Power Source
Current Drain (maximum)
Receive Standby mode
Receive Full Audio
Transmit at 5 Watts
112.2 ×56mm ×31.9 mm
16 Channels
12.5 / 25 kHz
7.5V DC Rechargeable Li-ion 2600 mAH battery pack
69 mA
350 mA
1.6 A
TRANSMITTER
Frequency Range
Frequency Stability
RF Power Output
Spurious and Harmonic
FM Hum and Noise
Audio Distortion
Audio Frequency Response
136 ~ 174 MHz
±2.5 ppm (-30 to +60℃)
5 Watts / 2 Watts
-65dB
40dB (12.5 kHz), 45dB (25 kHz)
5% maximum
+1, -3dB from 6dB per octave pre-emphasis
Characteristic from 300 ~ 3000Hz
RECEIVER
Frequency Range
Sensitivity
Squelch Sensitivity
Selectivity
Spurious and Harmonic Rejection
Inter-modulation
FM Hum and Noise
Audio Output Power
Audio Distortion
Audio Response
136 ~ 174 MHz
.282uV 12 dB SINAD
.25uV 10dB SINAD
60dB (12.5KHz), 65dB(25KHz)
70dB
60dB
40dB
1 Watt across an 16-ohm load
Less than 5% at rated output
+1, -3 dB from 6dB per octave de-emphasis
Characteristic from 300 ~ 3000Hz

Maintenance Manual
6
MODEL: PZ-S400
GENERAL
Dimensions(Less Antenna) H x W x D
Weight
Radio (less battery)
with battery (2600mAH)
Programmable Channels
Channel Spacing
Power Source
Current Drain (maximum)
Receive Standby mode
Receive Full Audio
Transmit at 5 Watts
112.2 ×56mm ×31.9 mm
16 Channels
12.5 / 25 kHz
7.5V DC Rechargeable Li-ion 2600 mAH battery pack
69 mA
350 mA
1.6 A
TRANSMITTER
Frequency Range
Frequency Stability
RF Power Output
Spurious and Harmonic
FM Hum and Noise
Audio Distortion
Audio Frequency Response
400 ~ 470 MHz
±2.5 ppm (-30 to +60℃)
4 Watts / 2 Watts
-65dB
40dB (12.5 kHz), 45dB (25 kHz)
5% maximum
+1, -3dB from 6dB per octave pre-emphasis
Characteristic from 300 ~ 3000Hz
RECEIVER
Frequency Range
Sensitivity
Squelch Sensitivity
Selectivity
Spurious and Harmonic Rejection
Inter-modulation
FM Hum and Noise
Audio Output Power
Audio Distortion
Audio Response
400 ~ 470 MHz
.282uV 12 dB SINAD
.25uV 10dB SINAD
60dB (12.5KHz), 65dB(25KHz)
70dB
60dB
40dB
1 Watt across an 16-ohm load
Less than 5% at rated output
+1, -3 dB from 6dB per octave de-emphasis
Characteristic from 300 ~ 3000Hz

Maintenance Manual
7
MODEL NUMBER
To identify the model number of PZ-S series Radio is as followings
P Z –S1 0 0
Model Number Description
PZ – S100
Frequency band: 136 – 174 Mhz,
PZ – S400
Frequency band: 400 – 470 Mhz,
PZ-S SERIES RADIO PACKAGE NUMBERS
Package Number Description
PZS10XE
PZS10WE
PZS40XE
PZS40WE
136 – 174Mhz PZ series radio
136 – 174Mhz PZ series radio (Waterproof model)
400 – 470Mhz PZ series radio
400 – 470Mhz PZ series radio (Waterproof model)
FEATURES
PZ-S series radio is designed for a rugged, lightweight and it can be provided for powerful sound and for
better performance of conversation distance & sound quality. The new PZ-S series radio provides reliable
service in the industrial fields and public places for the safety & convenience of users.
The PZ-S series radio is offered with several packages available with respect to the options (Waterproof
function). The radio is programmed using a Personal computer and program cable connected to the phone
jack on the side of the radio.
16 channels are selectable.
Call Guard Squelch of standardized 53 CTCSS / 104 DCS Tones.
Identification number of radio
manufactured by UNIMO
Frequency Band

Maintenance Manual
8
Scramble function of frequency Inverter Type
Compander function
Dual Tone Modulation Frequency (DTMF)
Selectable Channel Spacing (12.5kHz / 25KHz)
Normal Scanning and Priority Scanning
Time-Out Timer (TOT)
2-Tone Paging
BCL (Busy Channel Lock) / BCLO (Busy Channel Lock Out)
High/Low Power Switching
9 Step Squelch Control Using RSSI (0~9)
Remote Radio Stun/Revive (Use 5 Tone)
Monitor
VOX
Easy Cloning
USB PC Programming
PC Tuning

Maintenance Manual
9
CONTROLS & INDICATORS
The following section provides a description of the controls and Indicators for the PZ-S series radio.
Detailed operating instructions can be found the later chapter.
Antenna
Channel Select switch
Emergency Button
ON/OFF Volume switch
Speaker-Microphone Jack
Speaker
Microphone
PTT Button
Monitor Button
Status LED
Emergency
Button
Antenna connector
Status LED
16 Channel Select switch
ON/OFF Volume
switch
Belt-clip

Maintenance Manual
10
Controls
On/Off Volume Switch
Turn the knob of Volume Switch clockwise to turn the Radio on and if turning the Switch to the opposite
direction, the Radio is turned off. The audio volume level can be adjusted by turning the Volume Switch
and when adjusting the volume, please refer to the index mark indicated nearby the Volume knob. The
knob of volume doesn’t exist for the GPS model of PZ-S series radio. In this case, press and hold the
“F4” button then the radio is turn ON. And during the operation press and hold “F4” button then the radio
is turn OFF.
Channel Select Switch
Turn the knob of Channel Select Switch clockwise to increase the channel number and if turning the
switch to the opposite direction then decrease the channel number. The channel numbers are pre-
programmed using by PC program.
PTT Button
The radio is converted to transmission mode and transmitting the RF power by pressing and holding the
PTT button on the side of the radio. The status indication LED lights in red color. And the radio is
converted to receive standby mode by release the PTT button. It is recommended to talk about 5~7cm
away from the microphone for using in better sound quality and for better voice communication.
Monitor Button
When this button is assigned to “Monitor” then this function is activated.
The receiving status of the selected channel can be checked using by “Monitor” button.
Normal Mode: During the press and holding the “Monitor” button for about 2 seconds, it is possible to
check the receiving status of the channel.
Continuous Mode: Press and holding the “Monitor” button for more than 2 seconds, a beep tone is heard
along with a noise and the monitor function is continuously maintained. If pressing the Monitor button
again, the monitor function will be released.
Red Button
This button can be pre-assigned for several kinds of function.

Maintenance Manual
11
When this button is assigned to “Emergency” then the red button is activated for emergency function.
Press the “Emergency” button in an emergency situation, an emergency siren sound will be heard through
the speaker in the Radio. And the Radio will transmit an emergency signal to the party through the
emergency channel.
Side Button (Scan Button)
This button can be pre-assigned for several kinds of function.
Speaker Microphone Jack
The speaker microphone Jack on the side of the radio will be used for interface with external speaker
microphone accessories and making PC programming/Cloning/Tuning,
Indicators
Status Indication LED
The users can be recognized the current status of PZ-S series radio by the color of LED. The status
indication will be as followings.
When the transmitting status is normal, the red LED will be ON.
When the receiving status is normal, the green LED will be ON.
When the CTCSS tone or DCS code is not being received due to mismatch, the green LED will be
blinked.
When the low battery condition, the red LED will be blinked and an alert tone will be generated.
When the Cloning mode, the orange LED will be blinked.

Maintenance Manual
12
BATTERY PACKS
The following battery pack is available for use with the PZ-S series radio.
PBX-2260LA: Rechargeable Battery Packs (2600mAH Li-ion).
PBX-2220LA: Rechargeable Battery Packs (2200mAH Li-ion).
The PZ-S series Radio receives power from high-performance Li-ion battery.
The battery is safe, of high-performance and highly reliable. Using the
enclosed standard charger makes it possible to get sufficient efficiency and
lifetime of the battery.
☞
CAUTION
Battery Packs used with the PZ-S series radio must be supplied by UNIMO Technology Co., Ltd.

Maintenance Manual
13
Installing the Battery Pack
Ensure the ON/OFF volume switch is set to OFF position of the radio.
Hold the radio and battery pack with the back of them facing you. See Figure
Align the hook back of the radio with the hook front side of the battery pack
Press and slide the battery pack fully upper side of the radio until the battery release latch click into
place.

Maintenance Manual
14
Removing the Battery Pack
Ensure the ON/OFF volume switch is set to OFF position of the radio.
Press down the release latch and slide the battery pack down side of the radio. See Figure

Maintenance Manual
15
Charging the Battery Pack
New batteries or batteries that have been stored for a long time period should be fully charged before
placing into service. Low battery voltage will shorten the talk range and will make the performance of
radio worse.
When the battery pack requires charging then the radio will sound a high pitch tone every second
How to Charging
Plug the charger (CHZ-260FB) into the electricity power outlet for AC220V.
The charger (CHZ-260FB) has two slots.
When charging the radio with the battery installed, insert the radio into front slot of the charger
after power off.

Maintenance Manual
16
When charging the battery only, insert battery into rear slot of the charger.
Although the green LED is on after full charge, please continue the charging for 30 more minutes
for the complete full charge.
During the charging
After complete charging
Error condition
During maintaining charge
red LED is turn ON
green LED is turn ON
red LED is blinks
green LED is turn ON
☞
CAUTION
Charger used with battery packs must be supplied by UNIMO Technology Co., Ltd. Charging the
battery on the other manufacturer’s can cause unexpected damage of the battery and the radio
CHARGER
The CHZ-260FB is designed for charging the high
capacity batteries (PBZ-2260LA) of PZ-S series radio.
Input Voltage
Battery
Rapid Charging Time
Operating Temperature
Charging Current
AC 85V ∼250V
PBZ-2260LA, PBZ-2260LB
In 3 and half hour
0 ~50℃
900 mA (Fast Charging)

Maintenance Manual
17
RADIO OPERATIONS
Installation and Removal of Antenna
Put the antenna into the antenna connector of the radio and turn the antenna clockwise for installation of
antenna and in order to remove the antenna from Radio, turn the antenna counterclockwise.
☞
CAUTION`
When installation of the antenna, giving a strong pressure to the Radio or pulling the antenna from
Radio with a strong power can make damage on the antenna connector, which may cause the Radio
to have critical problem.
Power On/Off
Turn Power switch clockwise and as soon as power is supplied, a “beep” sound is heard and the model
name of the radio is displayed and the Radio enters into the previous latest state.
☞
CAUTION`
If turning power on by pressing a button on Radio, the Radio may enter into a special mode, in this
case, the transmitting and receiving of radio may not be possible. Don’t use the Radio for the other
purpose apart from the above.
Transmission
Press the PTT button on the left side of Radio for transmission. The DTMF or 5 Tone is transmitted
according to the setting of the radio. During this time voice communication will not be made and after
that the red LED is turned on and voice is transmitted. For voice communication in the best sound quality,
it is recommended to talk 5~10cm away from the radio.
☞
CAUTION`
If transmitting consecutively for more than a certain time when setting of BCLO function and TOT
function, the transmission can be forcibly interrupted for other users.
Receiving
The radio operates as a receiving standby mode except for the transmitting period. User can adjust the
volume by using the volume switch. The green LED is turn ON when the radio receives the RF signal and
can heard the transmitting voice. According to the setting of transmitting radio, can be heard the DTMF

Maintenance Manual
18
tone or 5 Tone.
If frequency is same as current channel but sub-tone is not same as current setting than the green LED
blinks. In order to check if the current channel is in use, press the Monitor button (M) on the left side of
Radio. If pressing the Monitor button (M) for about 2 seconds, the monitor function is activated with a
“beep” sound. To release from the monitor function, press the monitor button shortly.
Changing Channels
Channel Switch is used for changing channels. Turn the Channel switch clockwise to increase the channel
number with beep sound or channel number announced voice. And Turn the Channel switch counter-
clockwise to decrease the channel number with beep sound or channel number announced voice. The
channel frequencies include sub-tone information are pre-programmed by PC program.
Adjusting Transmitting Power
The transmitting power can be selected to High-Power mode or Low-Power mode. The user can change
the transmitting power by pressing the button which is pre-assigned by PC program. By changing the
power to Low-power mode under a good communication condition, the user can extend the battery life.
SCAN Operating mode
SCAN function is executed with a “beep” sound when pressing the button which is pre-assigned by PC
program during the standby state. The radio will change the scan channel and check the RF signal at
regular interval. Repress this button shortly then SCAN function can be deactivated.
A scan channel list must be created before SCAN can be used. The radio will not go into SCAN mode
where no scan channels are programmed.
Normal Scan
Once SCAN is activated, the radio will perform a normal scan mode. When the scan channel list is NS1,
NS2 and NS3 on the normal scan mode, the radio proceeds to scan in the sequence of NS1, NS2, NS3,
NS1, NS2, NS3.... During the receiving mode user can move to the next channel by pressing the red
button. And delete current receiving channel temporarily from the scan channel list.
If getting out of SCAN Mode or turning on power again, the list deleted temporarily is returned back to
the original.

Maintenance Manual
19
Priority Scan
As soon as priority scan channel is detected, the radio will change priority scan mode. When the scan
channel list is NS1, NS2, NS3 and priority scan channel is PS, the radio proceeds to scan in the sequence
of PS, NS1, PS, NS2, PS, NS3, PS, NS1....
During receiving signal through common channel, the radio scans the priority channel periodically. And if
the radio detects the signal on the priority channel, it starts to receive the signal from the priority channel.
During the receiving mode user can move to the next channel by pressing the red button. The user can
delete current receiving channel temporarily from the scan list and at that time, user can move to the next
channel. But the radio receives the signal from priority channel then it will not be deleted.
Transmitting
Pressing the PTT button cause the radio to transmit on selected channel frequency and to stop the SCAN
mode. And the selected channel frequency can be established in PC programmer.
Home channel.
Last receiving channel
Current scan channel.
Emergency Call
If pressing the button which is pre-assigned by PC program, radio transmitting the emergency alert tone
or 5-Tone message in Sell-call mode. Also user can hear the emergency alert tone. If the radio is set up
in repeated mode, the radio is transmitting the emergency alert tone periodically. This function can be
performed when SCAN is activated.
Monitor
In order to open the squelch compulsorily, press the button which is pre-assigned by PC program. If
pressing the MON key for more than 2 seconds, the squelch is opened continuously with a “beep” sound.
If you want to get out of this mode, press the MON key shortly once again, or turn off and on the power.

Maintenance Manual
20
Subtone
The radio can be programmed for CTCSS encode/decode tone frequencies and DCS code.
CTCSS tone frequency
A list of standard tone frequencies for CTCSS tone are describing as shown below.
No. Frequency No. Frequency No. Frequency No. Frequency
1
67.0
15
110.9
29
179.9
43
196.6
2
71.9
16
114.8
30
186.2
44
199.5
3
74.4
17
118.8
31
192.8
45
206.5
4
77.0
18
123.0
32
203.5
46
229.1
5
79.7
19
127.3
33
210.7
47
254.1
6
82.5
20
131.8
34
218.1
48
165.5
7
85.4
21
136.5
35
225.7
49
171.3
8
88.5
22
141.3
36
233.6
50
177.3
9 91.5 23 146.2 37 241.8 51 60.7
10
94.8
24
151.4
38
250.3
52
62.5
11
97.4
25
156.7
39
69.3
53
64.7
12
100.0
26
162.2
40
159.8
13
103.5
27
167.9
41
183.5
14
107.2
28
173.8
42
189.9
