unios LINEAR Series User manual

Edition 10.9.20 | Product design and technical data may be subject to changeEdition 10.9.20 | Product design and technical data may be subject to change
Sagging/Hanging Cutting outside
designated area
Twisted Installed without
aluminium channel
+
-
Class III
24V DC
Glide XL GS35U Glide XL GR45
Refer to data sheet
for compatibility
Surface Mounted Recessed
Power
5 ~ 30 Watts
unios.com
Page 1/4
Eclipse G2 Glide XL
unios.com
Page 4/4
IP20 Strip
ECM0XXXX
IP67 Strip
ECM7XXXX
Glide XL GS35
-GS35XX.XX
Glide XL GS35U
-GS35UXX.XX
Glide XL GR45
-GR45XX.XX
Base
Codes
LINEAR SERIES
Material
Aluminium
IP Rating
20 | 67
For comprehensive protection of a luminaire against electrical surges, surge protection shall be installed
on the mains supply where required to protect luminaires and drivers from transient voltage damage.
CAUTION – This product must be installed by a qualified installer
Please read instruction manual carefully before installing luminaire
Surge Protection
For warranty information visit unios.com/warranty
Please read these installation instructions carefully before installing this product. This product must be installed and
maintained by a suitably qualified person/s in compliance with the latest applicable regulations and relevant legislation.
Unios does not warrant any claim based on defects or damage caused by misuse, improper installation, improper
operation and/or modifications carried out by the purchaser or third parties. This product shall not be used as a
'working light' during construction. This will result in the warranty of the product to be void. For warranty duration,
please refer to the data sheet.
IMPORTANT: Refer to ESD Protection Section
located on page 1 before mounting strip.
35
102.6
43.4
80
26.9
65
35
22
35
Install Person/s
1-2
Cutting Guide
Model: IP20, IP67
(ECM0XXXX.FPXX, ECM7XXXX.FPXX)
Model: RGB, RGBW, Tunable White
(ECM0XXXX.FPRG, ECM0XXXX.FPRW, ECM0XXXX.FPTW)
25mm 50mm
RGBW
+
W
B
R
G
RGB
+
B
RG
Standard
+
-
Tunable
White
+
WW
CW
Parts
2x Mounting Clips
(per metre)
2x End Caps
(per metre)
Mounting Plate w/ 2x
Screws (per metre)
Glide XL GS35
Avoid pressing LED
too hard and/or sliding
fingers across strip.
Additional Accessories
Invisimount
Suspension Kit
Midnight
Diffuser
Linear Canopy
Suspension Kit
Strip Mounting
Recommended cleaning products:
Wax and grease remover, methylated
spirits, isopropyl alcohol or
surface cleaners.
1 2 3
Aluminium Channel
Eclipse G2
Disposal
Ensure correct disposal of this
product (waste electrical and
electronic equipment).
Ambient Conditions
Recommended to install in an
ambient temperature <35°C.
Corrosion Protection
It is important to note that care must be taken
during installation or maintenance to ensure that
the surface of the luminaire is not damaged. Any
damage, which is exposed to moisture will result
in corrosion occurring.
Please also note that any chemical applications on
the luminaire or chemical contact via installation will
cause corrosion of the surface of the luminaire and will
void the warranty.
For humid and dusty environments, Eclipse IP20 Strip Light must be used with a
suitable extrusion or the use of Eclipse IP67 Strip Light is recommended.
ESD Protection
When Handling this product, care must be taken so that the LED strip is not
damaged. Damage due to inappropriate handling is not covered by warranty.
The following precautions must be taken:
• Ensure device is switched off and disconnected from power supply.
• During assembly/disassembly, care must be taken during handling of LED strip.
• Always ensure to discharge yourself of all charge by touching a grounded bare metal
surface or approved anti-static mat before working on device.
CAUTION
Contains parts and
assemblies susceptible to
damage by electrostatic
discharge (ESD)

Edition 10.9.20 | Product design and technical data may be subject to change
Page 2/4 unios.com Page 3/4
Glide XL GS35 Surface Mounted Profile
Glide XL GS35U Surface Mounted Profile
1
2
ø25
47
26 7
6
5
Linear Canopy is supplied
as an additional accessory
Linear Canopy Suspension Kit
4
3
+
-
342
1 2
2
3
4
4
5
5
3
Glide XL GR45 Recessed Profile
1
24
56
90°
Soldering Striplight
Product Code Max. single length run (X)
ECM0XX05/ECM7XX05 20m
10m
6.5m
5m
ECM0XX10/ECM7XX10
ECM0XX15/ECM7XX15
ECM0XX20/ECM7XX20
Wiring Options
B
C
A
A+B+C= X
Option 2
X
X
X
Option 1
Dimming
For dimming capabilities, luminaire must be paired with
dimmable driver. Please refer to driver's instructions for
pairing of suitable systems.
6.5mECM0XXFP.15XX.15XX
Recommended heat shrink:
IP20: 3M™ Heat Shrink Thin-Wall Tubing
IP67: 3M™ Heat Shrink Thin-Wall Flexible
Polyolefin Adhesive-Lined Tubing
1
+
-
2
4
3
Heat shrink2
IP67 model only
Invisimount is supplied
as an additional accessory
Invisimount Suspension Kit
4
3
5
+
-
2
1
15
ø13
1
3
