unios Emerald User manual

Edition 14.11.19 | Product design and technical data may be subject to changeEdition 14.11.19 | Product design and technical data may be subject to change
A
Ø 105
B
130
C
Ø 119
D
35
Parts
2x Wall Screws2x Wall Plugs3x Allen Key
2x Seal Washers
unios.com
Page 4/4 unios.com Page 1/4
Emerald
Install Person/s
1x
Sizing Variations
D
C
A
EMSP0025
Product Code
All measurements are in millimetres.
For comprehensive protection of a luminaire against electrical surges, surge protection shall be installed
on the mains supply where required to protect luminaires and drivers from transient voltage damage.
CAUTION – This product must be installed by a qualified installer
Please read instruction manual carefully before installing luminaire
Surge Protection
For warranty information visit unios.com/warranty
Please read these installation instructions carefully before installing this product. This product must be installed and
maintained by a suitably qualified person/s in compliance with the latest applicable regulations and relevant legislation.
Unios does not warrant any claim based on defects or damage caused by misuse, improper installation, improper
operation and/or modifications carried out by the purchaser or third parties. This product shall not be used as a
'working light' during construction. This will result in the warranty of the product to be void. For warranty duration,
please refer to the data sheet.
Power
25 Watts
Material
Aluminium
IP Rating
65
Emerald Spotlight
EMSP0025
Base
Codes
Class I
220–240V ~ 50/60Hz
SPOTLIGHT
B
Disposal
Ensure correct disposal of this
product (waste electrical and
electronic equipment).
Ambient Conditions
Recommended to install in an
ambient temperature <35°C.
Corrosion Protection
It is important to note that care must be taken
during installation or maintenance to ensure that
the surface of the luminaire is not damaged. Any
damage, which is exposed to moisture will result
in corrosion occurring.
Please also note that any chemical applications on
the luminaire or chemical contact via installation will
cause corrosion of the surface of the luminaire and will
void the warranty.
Cleaning
Warning: Before cleaning, disconnect from
mains supply and allow luminaire to cool.
1 1

Edition 14.11.19 | Product design and technical data may be subject to change
Page 2/4 unios.com Page 3/4
5
ON
OFF
1
2
4
3
N
L
Wiring Mounting Plate
AC
Power Source
L
E
DRIVER
LED
N
35
80
Ø15
Ø110
6
All measurements are in millimetres.
Driver Compatibility
EMSP0025
Output
Power
Driving
Current
Forward
Voltage
Product Code
25W 500mA 36-38V
Dimming
This luminaire can be dimmed. Unios
® recommends a
phase-cut dimmer optimised for LED technology. For
non-standard configurations refer to driver data sheet.
For full list of compatible drivers, see unios.com
