UniPOS FS5200R User manual

REPEATER
FS5200R
OPERATION MANUAL
1. Function
Repeater FS5200R receives and transmits data for Fire condition and Fault
condition from remote fire control panels (repeaters) and provides information about their
status:
►when the security guards stay at a different place from the location of the
fire control panel
►when several fire control panels are monitored from one location
►when the fire control panel or panels are monitored from several locations
It is compatible with FS4000, FS 5100, FS 5200 FS5200R and FS 5200E.
2. Indication and Control Panel
12345678910 11 12 13 14 15
1
2
3
4
5
6
7
8
9
1
0
11 21
13
14
15
16
17
18
19
20
12
Front panel of repeater FS5200R
1 Common indicator for Fault condition
2 Indicator for System error
3 Indicator for Fault in power supply
4 Common indicator for Fault condition in a remote fire control panel
5 Common indicator for Fault in power supply in a remote fire control panel
1

6 Common indicator for Fault condition in fire detecting line of a remote fire
control panel
7 Common indicator for Fault condition in monitored output of remote fire control
panel
8 Buttons Menu
9 Button Down
10 Button Up
11 Button Cancel
12 Indicator Power supply
13 Indicator Delay of the outputs for Fire condition of the repeater
14 Button Reset
15 Button Alarm with indicator Suppressed alarm
16 Indicator Suppressed alarm
17 Button Outputs with indicator Suppressed outputs
18 Indicator Suppressed outputs
19 Indicator Fire condition stage
20 LCD display (4х20)
21 Individual indicators for Fire condition and Fault condition in the remote fire
control panels
3. Duty Mode
3.1. Description
The repeater is in Duty Mode when it is not in Fault condition and there is no remote
fire control panel or remote repeater in Fire Condition or Fault condition.
3.2. Indication
3.2.1. LED and sound indication
In Duty Mode the green LED indicator (Power Supply) and indicator for
prolonged inspection time of the outputs are activated.
3.2.2. Text message
The display shows the message “Fire protect” for the
mode of operation of the fire control panel and information
on the current local time:
Duty 17:05:34
Thursday 16-07-2008
3.3. Using the keypad
The only accessible button in Duty Mode is (Menu). Press it and the fire
control panel enters Information and Control Mode.
4. Fire condition
4.1. Description
The fire control panel enters Fire condition if a remote fire control panel is in Fire
condition.
To exit this condition press button , only the line in Fire condition shown in
the top field of the display is reset.
4.2. Indication
2

4.2.1. LED and sound indication
In this condition the indicator (Fire) illuminates in red. The individual indicator
for Fire condition of a remote fire control panel is illuminated in red.
If the outputs for Fire condition phase are suppressed by button (Outputs), the
LED indicator of the button illuminates in continuous red light.
The local sounder produces discontinuous signal. If the sound indication is
suppressed by button (Alarm), the LED indicator of the button illuminates in
continuous red light.
4.2.2. Text messages
For this condition the display is divided into two text panels, one in the first two lines
and the other in the last two lines. The panels provide information on the number of the
fire control panel and the respective line in fire condition. The second panel is displayed
if more than one line is in fire condition.
If more than 2 lines are in fire condition use the buttons (Down) (Up)
to review all lines in fire condition at the respective fire control panels.
4.3. Using the keypad
4.3.1. Button (Alarm)
Press it to:
−switch the local sounder off if it was activated for Fire condition or Fault condition;
−activate the local sounder if the fire control panel is in Fire condition or Fault
condition and the local sounder has been switched off by preceding pressing of
the same button.
The LED indicator of the button illuminates if the local sounder is switched off for
Fire Condition or Fault Condition.
Button’s operation does not effect and is not cancelled by the following events:
- a new fault condition will trigger the local sounder for Fault condition only.
4.3.2. Button (Outputs)
Button’s operation depends on the current access level and the operating mode of
the fire control panel.
Press it:
−To suppress the outputs activated in Fire condition.
−To activate the suppressed outputs, if any.
The LED indicator of the button illuminates if there are suppressed outputs for fire
condition.
4.3.3. Button (Reset line)
Press it to reset the line of the respective remote control panel shown in the top
panel of the display. After receiving a confirmation from the remote fire control panels
that their lines are reset and are not in fire condition, the Repeater enters Duty Mode.
4.3.4. Button (Menu)
Press the button to enter Information and Control Mode.
3

4.3.5. Button (Exit)
Press it and on the display appears the main screen.
5. Fault condition
5.1. Description
The repeater enters Fault Condition when any of the events below have been registered:
−low power supply – low backup battery during fault in the mains supply;
−fault in a processor programme;
−fault in a monitored output – short circuit or break;
−fault in mains supply;
−fault in the backup batteries supply;
−short circuited ground wire;
−fault in external devices supply.
The repeater enters Fault Condition when any of the events below have been registered
in the remote fire control panels:
−low power supply – low backup battery during fault in the mains supply;
−fault in a processor programme;
−fault in a monitored output – short circuit or break;
−fault in mains supply;
−fault in the backup batteries supply;
−fault in a line – removed fire detector, short circuit or break;
−short circuited ground wire;
−fault in external devices supply
−in any fault condition in the remote fire control panel with its respective specific
functions.
Fault condition is indicated by the respective messages on the display. The LED
indication provides additional information.
5.2. Indication
5.2.1. LED and sound indication
Where low power supply occurs no LED indicator is activated. The local sounder
produces discontinuous signal (1s sound, 3s break). The illumination of LCD display is
off.
All other fault conditions in the repeater are designated by indicator pos. 1
(Fault condition) illuminating in flashing yellow light. Depending on the specific fault, the
following indicators are illuminated too:
−Upon System error – indicator pos.2 (System error) in continuous yellow
light;
−pos.3 (Fault in mains supply) in continuous yellow light;
For any Fault condition in the remote fire control panels indicator pos.4 (Fault
condition) illuminates in flashing yellow light. Depending on the specific fault, the
following indicators are illuminated too:
pos. 5 (Fault in mains supply) in continuous yellow light;
4

−pos. 6 (Fault condition in fire detecting line of a remote fire control panel)
in continuous yellow light;
−pos.7 (Fault condition in monitored output of a remote fire control panel) in
continuous yellow light;
−The individual indicator for Fault condition of the remote fire control panel
illuminates in yellow light.
If the sounder is suppressed by button (Alarm), the LED indicator of the button
illuminates in continuous red light.
5.2.2. Text messages
Upon fault conditions when the repeater is not in Fire condition screens with the
specific fault condition are displayed.
When the fire control panel is in Fire condition the messages for Fault conditions are
suppressed.
The suppressed messages are displayed in Information and Control Mode.
5.3. Using the keypad
For fault condition 2 active buttons are supported. Активни бутона. Where the fire
control panel operates in combination of other conditions, their buttons are active too.
5.3.1. Button (Alarm)
Press it to:
−switch the local sounder off if it was activated for Fire condition or Fault condition;
−activate the local sounder if the fire control panel is in Fire condition or Fault
condition and the local sounder has been switched off by preceding pressing of
the same button.
The LED indicator of the button illuminates if the local sounder is switched off for
Fire Condition or Fault Condition.
Button’s operation does not effect and is not cancelled by the following events:
- a new fault condition will trigger the local sounder for Fault condition only.
5.3.2. Button (Menu)
Press the button to enter Information and Control Mode.
6. Disabled component mode
From the menu press button and button to enter menu Disables. It is
possible to disable the outputs for Fire condition in the Repeater:
> Out1 ;
> Out2 ;
> RelFire ;
If an output is disabled it is not activated for Fire condition or for Fault condition in
the line of the monitored outputs.
UniPOS wishes you a successful work!
