UNISENSE ADC-216USB User manual

1
UNISENSE A/DCONVERTER USER MANUAL

TABLE OF CONTENTS
UNISENSE A/DCONVERTER USER MANUAL ..................................3
WARRANTY AND LIABILITY...................................................6
Notice to Purchaser 6
Warning 6
Warranty and Liability 6
Repair or Adjustment 6
CONGRATULATIONS WITH YOUR NEW PRODUCT! ............................7
Support, ordering, and contact information 7
OVERVIEW ...................................................................9
SPECIFICATIONS ............................................................10
SOFTWARE .................................................................11
INSTRUCTIONS FOR USE ....................................................12
3
ADC-216 USB MAnUAl
Copyright © 2012 · Unisense A/S
Version November 2012

SUpport, orDering, AnD ContACt inforMAtion
If you wish to order additional products or if you encounter any
problems and need scientific/technical assistance, please do not
hesitate to contact our sales and support team. We will respond to
your inquiry within one working day.
E-mail: [email protected]
Unisense A/S
Tueager 1
DK-8200 Aarhus N, Denmark
Tel: [phone]
Fax: [phone]
Further documentation and support is available at our website
www.unisense.com.
CONGRATULATIONS WITH YOUR NEW PRODUCT!
notice to purchaSer
This product is for research use only. Not for use in human diagnostic or
therapeutic procedures.
Warning
Microsensors have very pointed tips and must be handled with care to
avoid personal injury and only by trained personnel.
Unisense A/S recommends users to attend instruction courses to ensure
proper use of the products.
Warranty and LiabiLity
The oxygen sensor is covered by a 180 days limited warranty.
Microsensors are a consumable. Unisense will only replace dysfunctional
sensors if they have been tested according with the instructions in the
manual within 14 days of receipt of the sensor(s).
The warranty does not include repair or replacement necessitated by
accident, neglect, misuse, unauthorized repair, or modification of the
product. In no event will Unisense A/S be liable for any direct, indirect,
consequential or incidental damages, including lost profits, or for any
claim by any third party, arising out of the use, the results of use, or the
inability to use this product.
Unisense mechanical and electronic laboratory instruments must
only be used under normal laboratory conditions and a dry and clean
environment. Unisense assumes no liability for damages on laboratory
instruments due to unintended field use or exposure to dust, humidity
or corrosive environments.
repair or adjuStment
Sensors and electrodes cannot be repaired. Equipment that is not co-
vered by the warranty will, if possible, be repaired by Unisense A/S with
appropriate charges paid by the customer. In case of return of equip-
ment please contact us for return authorization.
For further information please see the document General Terms of Sale
and Delivery of Unisense A/S as well as the manuals for the respective
products.
WARRANTY AND LIABILITY

67
OVERVIEW
A/D-converters provided by Unisense:
• ADC-216USB
• ADC-416USB
• ADC-816USB
As opposed to other amplifiers from Unisense, the picoammeter,
PA2000, and the Unisense thermocouple meter, T301, do not
have a built-in A/D-converter unit. These amplifiers produce an
analogue voltage output, which is proportional to the microsensor
signal. To make useful measurements, it is often necessary to con-
nect the analogue output to a data acquisition device. This can be
a paper strip chart recorder, but a more convenient way is to col-
lect data with a computer. To show and store data on a computer,
an A/D converter and computer software is necessary.
Unisense A/D-converter, ADC-216 USB

89
SOFTWARE
The following PC programs are available from Unisense (please see
separate manuals for instructions.
• SensorTrace BASIC for logging of timeseries
(2 ch, 2 Hz). Freeware
• SensorTrace PRO for automated microsensor
proling measurements
• Sloper for automated light-dark shift photo-
synthesis measurements.
• MicOx for respiration rate measurements
SPECIFICATIONS
• Interface: USB 2.0
• Power supply: from USB connection
• Channel mode: single-ended
• Number of channels: 2
• Resolution: 16-bit

10 11
INSTRUCTIONS FOR USE
1. Connect the signal output of the amplier
to the BNC inputs of the A/D converter
(ADC) using the signal cables.
2. Connect the USB port of the ADC to a USB
port on the PC using the USB cable.
3. Turn on the PC and install your data acquisi-
tion software (e.g. SensorTrace)
CAUTION
Do not apply
voltages in excess
of +/- 15V as the
A/D-converter may
be damaged by
this.
NOTE
If one of the chan-
nels is not used, it
can be provided
with an electrical
shortcut, as the
otherwise drifting
signal may confuse
the user.
ADC-216 USB (back) including USB cable and amplifier connection
cables
