Unitech PA768 User manual

PA768
Rugged Touch Computer
Quick Start Guide
609606G V1.0
Package
Product View
Product View
Please make sure the following contents are in the
PA768 gift box.
If something is missing or damaged, please contact
your Unitech representative.
PA768 Terminal
Battery
Hand Strap
USB 3.0 Type-C Cable
Quick Start Guide
Quick charge adaptor
9H glass screen protector
Standard/UHF gun grip
Stylus with coil strap
1-Slot USB cradle
1-Slot Charging cradle
1-Slot Ethernet cradle
The Package Contents
Optional Accessories
1. Barcode Scanner Window
2. Front Camera
3. Volume Key
4. Scanner Trigger Key
5. Power Key
6. Programmable Key
7. Scanner Trigger Key
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
8. Rear Camera
9. Speaker
10. Hand Strap Holes
11. NFC
12. Pogo Pin for gun grip
13. Pogo Pin for cradle
14. Hand Strap Hole
15. USB Type-C port

Checking LED Status
Charging the battery
Install the Battery
Before using the terminal for the first time, you need to
charge it for about 24 hours. For the regular use, you can
charge the terminal for 4 hours to recharge the battery to
full capacity.
To charge the terminal, please use the USB charging cable
or the cradle. Connect the Type-C USB cable to the USB
port on PA768 and the other end of the USB cable
connect to AC power Adapter into the electrical outlet on
the USB plug. The charging LED indicator on PA768 is
turning red in the charging state.
Align the battery with the battery compartment
following the picture below.
Press and hold both of the plastic buckles at the bottom,
then push against the front.
1.
2.
LED Description
Red Light ．Battery Charging
Green Light ．Battery Fully charged
．Barcode scan good read
Blue Light ．Message
If scanner app is running, LED is controlled by scanner
app. No LED (Red and Green) display when battery is
out. (even AC IN)
1. Press and hold both of the plastic buckles at the bottom.
Press down the battery to secure in place.
3.
Remove the battery
Inserting Micro SD/Nano SIM Card
Inserting the Micro SD/Nano SIM Card
1. Pick out the Micro SD/Nano SIM card holder.
2. You may put in 2 SIM cards or put in one SIM
card and one SD card at a time.
or
3. Align the card holder with the slot, and push it
in till it reaches the end. (Make sure the cards
stay flat while pushing in the card holder)
2. Push the battery against the front and lift to remove.
To ensure the unit working properly, please keep all connectors away
from the contaminants staying inside of them such as dust, grease, mud,
and water. The negligence may cause the unit with no communication,
short circuited, overheated and so on. If the connector is damaged,
please ensure the connector is being fully repaired before using the unit
to avoid causing short circuited.
WARNING!
There is a risk of fire and burns if the battery is handled improperly.
DO NOT disassemble, crush, puncture, short external contacts,
or dispose the battery pack in fire or water.
DO NOT attempt to open or service the battery. Dispose of used
batteries according to local recycling guidelines in your area.
CAUTION!
http://www.ute.com/
Copyright 2022 Unitech Electronics Co., Ltd. All rights reserved.
Unitech is a registered trademark of Unitech Electronics Co., Ltd.
