Uniteck UNIFIX 300 User manual

16/04/2018
www.uniteck.fr CO00117
NICHARGE
Le support universel
(sol, mur, mât, …)
UNIFIX 300
FR
EN
ES

EN
www.uniteck.fr 13/34
UNIFIX 300
Dear customer, we thank you for purchasing one of our Uniteck products. Please read carefully all
instructions before using your product.
Unifix brackets have been specially designed to fix your Unisun photovoltaic panels or equivalent (see part
compatible panels):
•Unifix 300 for your Unisun panels Unisun 80.12M (x3) / 100.12M (x3) / 100.24M (x3) / 110.12BC
(x3) / 150.12M (x2) / 150.12BC (x2) / 200.24M
UNIFIX 300
Simple to install, they attach either:
•on a rigid horizontal or vertical surface (eg wall, concrete floor, wood frame).
•on round mast with a diameter of 40 to 60 mm (supplied flange)
•on signaling posts using flanges with M8 screws (flange not included)
With our galvanized steel structure and corrosion-resistant stainless-steel screws, they are perfectly suited
for outdoor use.
Equipped with the multi-position tilt system, Unifix supports allow you to optimize your performance
according to the chosen orientation.
To make the panel / regulator / battery connection, we recommend that you use the Uniconnect ready-to-
use kits that optimize your electrical performance and simplify installation:
•Uniconnect 1.6 = connection 1 panel
•Uniconnect 2.6 = connection 2 panels
•Uniconnect 3.6 = connection 3 panels
Electrical performance depending on tilt and panel
orientation
0°
30°
60°
90°
East
93%
90%
78%
55%
South east
93%
96%
88%
66%
South
93%
100%
91%
68%
South west
93%
96%
88%
66%
West
93%
90%
78%
55%
90°
0°
Adjustable
By 10 °

EN
14/34 www.uniteck.fr
UNIFIX 300
PANEL COMPATABILITY
With the design based on the use of Oblong drilling, Unifix allows the fixing of different panels of the market.
Unifix accepts 1, 2 or 3 panels according to the references, with the spacings and dimensions of panels
indicated below.
SAFETY INSTRUCTIONS
•Take appropriate measures to prevent accidents during assembly work.
•If the bracket and mounting hardware are exposed to direct sunlight for a long time, there is a
risk of burns. Protect yourself.
•At the end of the work, check that your supports and panels are securely fastened.
Dim
Support
Number of
panels
Spacers for fastening
of each panel
(in mm)
Panel Dimension
Max
Total weight
Of panels
(In Kg)
L
H
x1
x 2
x 3
L (e)
H (e)
L (p)hh
H (p)
Unifix
300
1650
1100
●
150 > 1600
400 > 1030
No max
1200
35
●
150 > 750
880
●
150 > 500
550
Oblong fastening system
H (e)
H (p)
L (e)
L (p)
Centre distance and panel dimensions
UNIFIX 300
Configuration 2 panels

EN
www.uniteck.fr 15/34
UNIFIX 300
RECOMMENDATIONS
Mount Unifix brackets only on surfaces with sufficient lift. Consider the additional load with panel:
Support
Panel
Unifix 300
= 15 kg
Unisun 80.12M (x3) / 100.12M (x3) / 100.24M (x3) /
110.12BC (x3) / 150.12M (x2) / 150.12BC (x2) / 200.24M
=19kg / 23kg / 23kg/
21kg/ 20kg/ 19kg /14kg
Fastening: to prevent large quantities of snow from accumulating behind the sensor, install appropriate
shut-off gates upstream.
The arrangement of the solar panel influences your electrical performance. Choose the most optimal
inclination and orientation to suit your environment. Avoid shaded areas or objects that are a source of
shadow (eg tree)
Before attaching and connecting, please observe:
•the maximum distances shown below between each element.
•connection order
Unifix + wiring with Uniconnect connection kit
(1) Possibility of extending the distance between the panels by one additional meter, by adding a
Unicable 612B and 612 R (cables not supplied with the Uniconnect kits).
(2) Unicable 612B and 612 R (cables not supplied with the Uniconnect kits).
Ordre de connexion
For disconnection please proceed in reverse order. For more information, refer to the operating manual of
your photovoltaic charge regulato
Panel 3
Panel 2
panel 1
Cable-
Regulator
Batteries
1 m
max(1)
1 m
max(1)
8 m max
2 m max
4 m
max (2)
1
2
1
connection regulator ➔batterie
connecting solar panel ➔régulateur
connecting regulator ➔electrical usage

EN
16/34 www.uniteck.fr
UNIFIX 300 - PREPARATION
LIST OF PIECES
M8x100
X8
M8X20
X50
D8
X58
M8
X58
n°15
x2
n°16
x2
n°18
x4
n°34
x2
n°17
x2
n°13
x4
N°9
x2
N°10
x2
FOR USAGE WITH ONE PANEL:
M8x45
X4
8X18x10
X4
Recommended tightening torque
Vis
Couple
M5
5,10 Nm
M 6
8,80 Nm
M 8
21,50 Nm
M 10
44,00 Nm
Nb. Average friction coefficient μ= 0.20 / Tightening at 50% of the elastic limit

EN
www.uniteck.fr 17/34
UNIFIX 300 - PREPARATION BEFORE MOUNTING
•Fix the pieces n°8 by 2.
M8x20
X4
D8
X4
M8
X
n°18
x4
•Fix the parts n°17 on the parts previously assembled
M8x20
X8
D8
X8
M8
X8
n°17
x2

EN
18/34 www.uniteck.fr
UNIFIX 300 - - WALL MOUNTING / FLOOR / ROOF
•Attach parts n°15 and n°16 to part n°34. Pre-tighten the nuts. The final tightening will be done at
the end of the assembly.
M8x20
x8
D8
x8
M8
x8
n°15
x2
n°16
x2
n°34
x1
•Pre-attach parts n°9 to part n°34. Do not tighten completely
M8x20
X2
D8
X2
M8
X2
n°34
x1
N°9
x2

EN
www.uniteck.fr 19/34
UNIFIX 300 - - WALL MOUNTING / FLOOR / ROOF
•Secure the top bracket with 8 screws to fit your surface (screws and dowels not included).

EN
20/34 www.uniteck.fr
UNIFIX 300 - - WALL MOUNTING / FLOOR / ROOF
•Unifix has a multi-position tilt system. (10 positions). Set the desired tilt to the desired orientation.
•Attach your panel to the desired tilt.
•Now tighten the 4 nuts that were previously pre-screwed and check that all other screws have been
tightened
Electrical performance depending on tilt and panel
orientation
0°
30°
60°
90°
Est
93%
90%
78%
55%
Sud-Est
93%
96%
88%
66%
Sud
93%
100%
91%
68%
Sud Ouest
93%
96%
88%
66%
Ouest
93%
90%
78%
55%
M8x20
X8
D8
X8
M8
X8
90°
0°
Adjustable
by 10°

EN
www.uniteck.fr 21/34
UNIFIX 200 - WALL MOUNTING / FLOOR / ROOF
•Add reinforcements n°10 and bar n°34 previously assembled.
The position of your fixing screws on the rail of the bar N°9 determines the position of the lower
bar on your wall.
•Fix the bar n°34 on the wall or flat surface.
M8x20
X8
D8
X8
M8
X8
•Attach your Unisun solar panels
•Tighten all screws and check that all other screws have been tightened.
1
panneau
2
panneaux
3
panneaux
-
M8x20
X8
M8x20
X12
M8x45
X4
-
-
D8
X4
D8
X8
D8
X12
M8
X4
M8
X8
M8
X12
8,2 x 18 x
10
X4

EN
22/34 www.uniteck.fr
UNIFIX 300 - FIXING ON ROUND MAT (40 TO 60 MM DIAMETER)
•Attach the bracket to the mast with 2 flanges and associated M8 screws (for fixing to the signal
mast, use the flanges corresponding to the mast used, flanges not included
•Unifix has a multi-position tilt system (10 positions). Set the desired incline according to the
chosen orientation.
•Fasten your panel according to the chosen inclination.
Fixing on round mat (40
to 60 mm diameter)
M8x100
x4
D8
x4
M8
x4
n°13
x2
Electrical performance depending on tilt and panel
orientation
0°
30°
60°
90°
East
93%
90%
78%
55%
South east
93%
96%
88%
66%
South
93%
100%
91%
68%
South west
93%
96%
88%
66%
West
93%
90%
78%
55%
90°
0°
M8x20
X8
D8
X8
M8
X8
Adjustable
by 10°

EN
www.uniteck.fr 23/34
UNIFIX 300 - FIXING ON ROUND MAT (40 TO 60 MM DIAMETER)
•Add reinforcements n°10 and bar n°34 previously assembled.
The position of your fixing screws on the rail of the bar n°9 determines the position of the lower
bar on your mast. Tighten all screws and check that all other screws have been tightened.
•Tighten all screws and check that all other screws have been tightened.
M8x20
X8
D8
X8
M8
X8
•Fix the bar N°34 on the mast using the flanges N°13 and the associated screws.
M8x80
X4
D8
X4
M8
X4
n°13
x2
•Tighten all screws and check that all other screws have been tightened.
•Attach your Unisun solar panels
1
panneau
2
panneaux
3
panneaux
M8 x 45
X4
M8 x 20
X8
M8 x 20
X12
D8
X4
D8
X8
D8
X12
M8
X4
M8
X8
M8
X12
8,2 x 18
x 10
X4
/
/
