UNITED UNI-12063C User manual

AUTO indicator
COOLING indicator
DRYING indicator
HEATING indicator
FANNING indicator
SWING indicator
AIR FLOW indicator
Temperature indicator
indicates the set temperature
SLEEP indicator
indicates during sleep operation
TURBO indicator
indicates during turbo operation
Key lock indicator
FAN SPEED indicator
indicates the set air rate
SET TEMPERATURE button
This button sets the room temperature.
FAN SPEED button
This button set air rate: natural wind, high,
medium, low.
When the AC is powered on, this button changes
to TURBO operation(it doesn’t work in AUTO,
DRY and FAN mode.);
When the AC is powered off, this button changes
to CLEAN operation: the AC will be powered on
and gets into the cool,25 , high fan speed mode.℃
TURBO/CLEAN button
SLEEP button
This button changes to SLEEP operation.
HOLD button
Press this button to lock or unlock the
keyboard.
TIMER button
This button is used to the switch-on or
switch-off and the timer time.
AIR FLOW button
This button used for selection of the left/right
air ow direction, whenever pressed the Infl
flfiap will swing or x. (It) just work on three-
dimensional air ow model.fl
SWING button
This button changes the ap mode: naturalfl
ow, swing or xed wind.flfi
MODE button
This button changes the operation mode:
AUTO, COOL, DRY, HEAT, FAN.
ON/OFF button
This button, when pressed starts operation
and stops when pressed.
IONIZER button
This button changes to IONIZER operation ..
LIGHT button
This button controls the lamp panel separately.
Press this button, the lamp will be turned on
or off whenever the AC is on or off. When the
AC is powered off, the lamp will be turned off.
NOTE:
Above gure shows all indications for the purpose of explanation, but practically only the pertinent parts are indicated. Whenfi
air-conditioner is cooling-only mode, the HEAT is for FAN.
When TURBO operation is selected, room temperature is not controlled with operation being continually. If you feel the room
temperature is too cool or too heat, please cancel the TURBO operation.
IONIZER indicator

Herewith, Amiridis-Savvidis S.A. states that this product, complies with the requirements of
below directives:
EMC-Directive: 14 / 30 / EU
Low Voltage Directive: 14/ 35 / EU
ErP Directive 09 / 125 / EC
CE Marking: 93 / 68 / EEC
RoHS Directive: 11 / 65 / EU
The detailed declaration of conformity can be found at www.united-electronics.gr
