Unitronics UCR-ST-B8 User manual

1
UCR-ST-B8 Router
The Unitronics UCR-B8 enable Unitronics PLC products to communicate via mobile networks (4G).
Highlights:
1. 3 Ethernet LAN ports and 1 WAN (configurable can act as LAN)
2. Embedded GPS receiver.
3. Wireless LAN access point or client to existing network.
4. Embedded send / receive SMS messages directly from UniStream PLCs.
5. RS232, RS485 and USB interfaces with embedded Serial-To-Ethernet functionality.
6. I/O: a. 3 Digital Inputs
b. 1 Analog Input
c. 2 Digital Outputs
d. 1 Relay Output
Note: UniLogic SMS embedded support from Ver. 1.29 and above.
Package Content
#
Description
Quantity
Unitronics P/N
1
UCR-B8 Router
1
2
Power cable, 2m, 4 pins terminal block
1
UCR-ACC-01
3
LTE antenna (magnetic mount, SMA male, 3 m cable)
2
UCR-ACC-02
4
WiFi antenna (magnetic mount, RP-SMA male, 1.5 m cable)
2
UCR-ACC-03
5
GNSS antenna (adhesive , SMA male, 3 m cable)
1
UCR-ACC-04
6
RS485 and I/O terminal blocks
1
UCR-ACC-05
7
Ethernet cable (1.5 m)
1
8
Quick Start Guide
1
SIM Card
SIM Card Insertion
1
Pull the SIM needle out of the router
2
Push the SIM holder button with the SIM needle
3
Pull out the SIM holder
4
Insert your SIM card into the SIM holder
5
Slide the SIM holder back into the router
Spectra GmbH & Co. KG
[email protected]
Spectra (Schweiz) AG
[email protected]

UCR-ST-B8
2
Front View
#
Description
1
LAN Ethernet ports
2
WAN Ethernet port
3
LAN LEDs
4
WAN LED
5
RS485 connector
6
Power connector
7
RS232 connector
8
Input / Output connector
9
Power LED
10
Mobile connection status LED
11
Mobile signal strength indication LEDs
Back View
#
Description
1
Mobile antenna connectors
2
GPS antenna connector
3
USB connector
4
WiFi antenna connectors
5
Reset button
6
SIM card slots
LED: Status Indication
Power LED
ACTION
DESCRIPTION
LED turned ON
Router is powered up
LED turned OFF
Router is not powered up
Spectra GmbH & Co. KG
[email protected]
Spectra (Schweiz) AG
[email protected]

UCR-ST-B8
Router: Teltonika RUT955
UCR-ST-B8_INSTAL_GUIDE
3
Ethernet Port LEDs
ACTION
DESCRIPTION
LED turned ON
Operating as a 10/100 Mbps connection
LED turned OFF
No link established
LED blinking
Connection established and there is activity on this port (data
being transferred)
LEDs light up and turn OFF in
sequence from WAN port to LAN1
port
The router is in the bootloader menu state*
* The bootloader menu is a special router state from which certain upgrades can be performed
Connection Status LED
The LED displays the router's current connection state and network type
ACTION
DESCRIPTION
Green and red blinking alternatively
ever 500 ms
No SIM or bad PIN
Green, red and orange blinking
alternatively every 500 ms
Connecting to GSM
Red blinking every 1 sec
Connected 2G, no data session established
Orange blinking every 1 sec
Connected 3G, no data session established
Green blinking every 1 sec
Connected 4G, no data session established
Red lit and blinking rapidly while
data is being transferred
Connected 2G with data session
Orange lit and blinking rapidly while
data is being transferred
Connected 3G with data session
Green lit and blinking rapidly while
data is being transferred
Connected 4G with data session
Signal Strength LEDs
Each lit up LED represents a different value of the router's current signal strength in RSSI:
NO. OF LIT UP LEDs
SIGNAL STRENGTH VALUE
0
≤ -111 dBm
1
-110 dBm to -97 dBm
2
-96 dBm to -82 dBm
3
-81 dBm to -67 dBm
4
-66 dBm to -52 dBm
5
≥ -51 dBm
All 5 LEDs are lit up after pressing and holding the reset button to initiate a factory reset.
Spectra GmbH & Co. KG
[email protected]
Spectra (Schweiz) AG
[email protected]

UCR-ST-B8
4
RS485 Connector Pinout
Pin
Description
D_P
Positive signal
D_N
Negative signal
R_P
Shortcut to D_R
R_N
Shortcut to D_N
Ground
Signal ground
Network termination- Place 120Ωtermination resistor at each end of the network
Powering Options
Power Connector
4 pin power connector:
Pin
Description
Direction
1
Power
Red
2
Ground
Black
3
Digital Input
Green
4
Digital Output
White
Passive Power Over Ethernet
The device may also be powered by an Ethernet
cable via the LAN1 port:
(Do not use in other ports!)
Spectra GmbH & Co. KG
[email protected]
Spectra (Schweiz) AG
[email protected]

UCR-ST-B8
Router: Teltonika RUT955
UCR-ST-B8_INSTAL_GUIDE
5
RS232 Connector Pinout
D-type 9 pin female connector:
Pin
Description
Direction
1
DCD (Data Carrier Detect)
Output
2
RxD (Receive Data)
Output
3
TxD (Transmit Data)
Input
4
DTR (Data Terminal Ready)
Input
5
GND (Signal Ground)
-
6
DSR (Data Set Ready)
Output
7
RTS ( Request to Send)
Input
8
CTS (Clear To Send)
Output
9
RING (Ring Indicator)
Output
Input / Output Specification and Pinout
Associated
Pins
Description
1, 6
Digital Input 1, 0-3VDC (Low 0-1.2V, High 1.8-3V)
2, 7
Digital Input 2, 0-30VDC (Isolated, Low 0-4V, High
9-30V)
9, 6
Analog Input 1, 0-24VDC / 0-20mA
3, 8, 4
Digital Output 1, 0-30VDC, 250mA (sink, Isolated)
5, 10
Relay Output 1, 0-24VDC / 0-40VAC, 4A
I/O Terminal
Block Pinout
Description
1
Digital Input 1 (Input Signal)
2
Digital Input 2 (Input Signal)
3
Digital Output 1 (Output Signal)
4
Digital Output 1 (V+)
5
Relay Output 1 (COM)
6
Digital Input 1 and Analog Input 1 (GND)
7
Digital Input 2 (GND)
8
Digital Output 1 (GND)
9
Analog Input 1 (Input Signal)
10
Relay Output 1 (Output Signal)
Spectra GmbH & Co. KG
[email protected]
Spectra (Schweiz) AG
[email protected]

UCR-ST-B8
6
Power Connector
Associated
Pins
Description
3
Digital Input 1, 0-40VDC (Low 0-5V, High 8-40V)
4
Digital Output 1, 0-30VDC, 300mA (sink)
Mounting
Use the Din Rail bracket or M3 screws to mount the device.
Spectra GmbH & Co. KG
[email protected]
Spectra (Schweiz) AG
[email protected]

UCR-ST-B8
Router: Teltonika RUT955
UCR-ST-B8_INSTAL_GUIDE
7
Technical Specifications
Power voltage range
9 –30 VDC, 4 pin DC connector
Power consumption
< 7W
Power over Ethernet
(passive)
Passive PoE over spare pairs. Possibility to power up through LAN1
port, not compatible with IEEE802.3af and 802.3at standards
Status LEDs
1 x bi-color connection status
5 x connection strength
4 x LAN status
1x Power
SIM card
2 x external SIM holders
Ethernet
4 x 10/100 Ethernet ports:
- 1 x WAN (configurable as LAN)
- 3 x LAN ports
Inputs
3 x Digital Inputs
1 Analog Input
Outputs
1 Relay, 24V, 4A, SPST
2 x Digital Open Collector Output
Connectors
1 x 4 pin DC, 4 x Ethernet
2 x Mobile SMA
2 x WiFi RP-SMA
1 x GPS SMA
1 x RS232
1 x 6 pin RS485
1 x 10 pin I/O
USB 2.0
Mobile
4G (LTE) –Cat 4 DL up to 150 Mbps, UL up to 50 Mbps; DC-
HSPA+; UMTS; TD-SCDMA; EDGE; GPRS
Housing
Aluminum housing, plastic panels
Dimensions
100 mm x 110 mm x 50 mm (3.94”x4.33”x1.97”)
Weight
287 g (10.12 oz)
Storage and Operational
temperature
-40 °C to 75 °C (-40°F to 167°F)
