Universal Pumps UP-GPP600 User manual

INSTRUCTION MANUAL
UPGPP600 & UPGPP600A
Protect yourself and others by observing all safety information, warnings, and cautions. Failure to
comply with instructions could result in personal injury and/or damage to product or property.
Please retain instructions for future reference.
UP-GPP600 UP-GPP600A

UP-GPP650
PERFORMANCE GRAPH

DESCRIPTION
General purpose garden water pumps for use in domestic situations for water transfer applications. e
UP-GPP600A has the additional feature of automatic ON / OFF control based on pressure and ow.
Not for use with chemical or ammable liquids.
PRODUCT SPECIFICATION
KNOW YOUR PRODUCT
1. Water Inlet
2. Inlet strainer
3. Water Outlet
4. ON / OFF Switch
5. Pump housing drain plug.
A. Automatic controller
B. Status lamps
C. Reset switch
E. Pressure gauge (Not visible)
D. Service switch. (Must be ON at all times)
Models: UP-GPP600 & UP-GPP600A
Input: 230V ~ 50Hz
Power Rating: 600W
Protection: IPX4
Max. Flow: 2,800L/Hr
Max. Head: 35m
Max. Suction Depth: 7m
Power cord length 1.2m
1
2
3
4
5
UP-GPP600
AB
C
D
D
5
3
2
1
UP-GPP600A

SAFETY
IMPORTANT
Please read all of the safety and operating instructions carefully before using this product. Please pay
particular attention to all sections of this manual that carry warning symbols
SAFETY WARNING FOR PUMPS
WARNING! Do not use in swimming pools or spas.
WARNING! is product is intended for pumping water in a home domestic
application. Do not use it for corrosive, abrasive, explosive or dangerous liquids. Fluids other than
water will damage the water pump and/or create a re hazard.
CAUTION! Do not run the pump without water or allow the pump to run dry. is
will damage the pump’s seal and void the warranty
CAUTION! is pump is not suitable for drinking water. Some lubricants and other
materials used in the pump may leach into the water.
CAUTION! Do not place the suction line in mud or sludge. ey can block the inlet and
cause the pump to overheat.
CAUTION! Do not use this pump as a mains pressure booster pump. is may cause
the pump body to crack and will void warranty.
CAUTION! e pump MUST be protected from the elements. e pump must be
protected by a cover or similar.
WARNING! Always use an electrical outlet that is protected by Residual Current
Device RCD (Safety switch) with a trip current of 30mA or less.
is appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
WARNING! DO NOT ABUSE THE MAINS LEAD
• Never pull the mains lead to disconnect the pump from the mains socket.
• Keep the mains lead away from heat, oil and sharp edges.
• If you have to use an extension lead with this product, it must be designed for outdoor use.

PREPARATION TYPICAL SETUP
Tank
Gate Valve
Outlet Pipe to
garden tap
Solid Base
UP-GPP600 and UP-GPP600A Typical set up with base
level of tank below the pump.
Foot Valve
is is a one way valve to stop
water back owing into the tank
Fig 2.
Inlet
Tank
Gate Valve
Outlet Pipe to
garden tap
Solid Base
UP-GPP600 and UP-GPP600A Typical setup with base level
of tank at same level as the pump.
Fig 1.
Inlet
NOTE: IT IS NOT RECOMMENDED TO USE AN EXTENSION CORD WITH
THESE PUMPS. If you have to use an extension lead with this product, it must be
designed for outdoor use.

PREPARATION
Before the pump can be used the pump body must be primed before use and will depend on the type of
installation.
1. Setup with base level of tank at same level (Fig 1.)
• Open the gate valve and the garden tap.
• Run the pump until there is no air visible in the clear cover of the inlet strainer.
• Close the garden tap and turn the pump OFF
2. Setup with base level of tank below the pump. (Fig 2.)
• Check that the pump is turned OFF at the mains outlet. (Power point)
• With the gate valve open, unscrew the clear cover of the strainer, ll with water until the suction line and
pump body are lled with water.
• Replace the cover.
WARNING! Always use an electrical outlet that is protected by Residual Current
Device RCD (Safety switch) with a trip current of 30mA or less.
OPERATION
NOTE: A FOOT VALVE MUST BE FITTED OR THE WATER WILL DRAIN
BACK INTO THE TANK. is may lead to having to prime the pump continually.
NOTE: FOR THE UPGPP600A. is model is tted with a automatic controller
that will try to prime the pump two times only. If the controller detects that the pump is
still not primed aer the two attempts it will turn o and the failure lamp will FLASH.
To RESET the controller re-prime the pump and press the reset button to try again.
• Check that the ON / OFF switch (service switch) is in the ON position.
• Turn the power ON at the mains outlet (Power point)
• e pump should start.
• Slowly open the outlet taps and allow the lines to clear and purge any air in the pipes.
• is priming procedure may need to be repeated several times.
• Aer successfully priming the pump turn the garden tap OFF and check for leaks and rectify.
UP-GPP600 (Manual ON / OFF model)
• With the pump primed, Turn the pump ON at the power switch and power point.
• Turn the garden tap on and use the water as required.
• When nished turn the garden tap OFF
• Turn the power to the pump OFF
CAUTION! e pump must be protected from the elements. ese pumps are not
designed to be exposed to the elements. ey must be protected by a cover or similar with ventilation.
Under the eave of a house is NOT considered being protected. Failure to protect the pump from the
elements will void the warranty.
ENVIRONMENT

CLEANING AND MAINTENANCE
WARNING! Check that the pump is unplugged from the mains supply and gate
valve is turned OFF before preforming any cleaning or maintenance on the pump.
• ese pumps should require no maintenance other than regular cleaning.
• Do not attempt to repair the pump yourself, repairs must be carried out by an authorized service centre.
• Check the pump regularly to ensure the inlet strainer is clear of leaves or other debris.
UP-GPP600A (With automatic controller)
• With the pump primed,
• Check that the service switch is in the ON position and that the mains power is connected to the pump.
• Open the garden tap.
• e pump should automatically start.
• Use the water as required.
• Turn the garden tap OFF and the pump should stop aer a short delay
FAULT POSSIBLE CAUSE SOLUTIONS
e pump starts and stops
irregularly or continuously.
(UP-GPP600A only)
Leak on the discharge line or outlets. Fix any leaks.
Not enough water being
pumped.
A) Dirty inlet strainer.
B) Air in pump housing.
C) Water level low.
A) Clean strainer.
B) Release air via priming plug
and x any air leaks on suction
line.
C) Check that the suction line is
completely under water level.
Pump does not run A) No mains voltage.
B) Sha locked.
C) Pump not primed (UP-GPP600A only)
A) check power supply is on and
connected.
B) Disconnect pump from power
supply and clear blockage.
C) Check the power/service
switch on the pump is ON.
D) Check Failure lamp and prime
the pump (UP-GPP600A only)
e pump runs but does
not deliver water
A) Air in pump housing.
B) Air in suction pipe.
C) Intake valve not in water.
D) Intake valve closed or clogged.
E) Max suction depth exceeded.
A) Prime the pump.
B) Check that suction pipe and
ttings are tight.
C) Put intake into the water.
D) Open intake valve or remove
blockage.
E) Check suction depth.
TROUBLE SHOOTING

WARRANTY
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and for compensation for any other reasonably foresee-
able loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
is product is covered by a 24 month warranty.
is warranty will not apply:
(i) where this product has been subjected to misuse, abuse, accident or want of care;
(ii) where this product has been used for a purpose for which it was not designed or is not suited;
(iii) where the service of this product has been undertaken by a non-authorised person or company or if
non approved parts have been used;
(iv) where this product has been used for industrial purposes.
Should service become necessary during the warranty period, the purchaser should contact an Authorised
Service centre of White International. In order to obtain warranty service, the purchaser must present the
store receipt showing the name of the retailer and the date of purchase.
e period of the warranty begins from the original date of purchase, notwithstanding any subsequent repair
or parts replacement.
Purchaser shall be responsible for all transport charges to and from the Authorised Service Centre.
Damage in transit is not covered by this warranty.
e purchaser should remove from the product any liquids (if applicable) before sending the tool for service
or repair. e tool should be packed securely to prevent damage.
WARRANTY EXCLUSIONS
Wear parts or service related parts required when performing normal and regular maintenance of this
product are not covered by warranty unless it is found to be defective by an Authorised Service Centre.
ese include, but are not limited to: Power cords and seals.
Distributed in Australia by White International.
PO Box 304 Milperra LPO, NSW Australia, 2214
Ph:1800 251 338
e White International is one of continuous improvement and the company reserves the right to alter
designs, colours and specications without notice.
