Universal Remote Control Easy Clicker UR3-SR3 User manual

Universal Remote Control, Inc.
www.universalremote.com
UR3-SR3
Operating Manual
For Easy Clicker

1
This remote control is designed to operate most Digital
and Analog Cable Boxes, as well as TVs, and a VCR or
DVD player.
Introduction
Install two
AAA alkaline batteries
as shown here
1
Before you program or operate the remote control, you
must install two new AAA alkaline batteries.
STEP1 Remove the battery compartment cover from the
back of your remote control.
STEP2 Check battery polarity carefully, and install the
batteries as shown in the illustration below.
STEP3 Replace the battery compartment cover.
Replacing Batteries
2

2
Button Functions
3
Programming the Remote Control.
4
A. Quick Set-Up Method
A. Quick Set-Up Method
STEP1 Turn on the equipment you want to program. To
program your TV, turn on the TV.
STEP2 Point the remote at the component and press and
hold the [DEVICE] key for 4 seconds until the Device
*Note : In this section, when you are instructed to press a
[DEVICE] button, that means you should press either
the CBL, TV, or DVD button, depending on which
device you are programming the remote to operate.

3
LED blinks off and turns back on. Continue holding
the [DEVICE] key and press the number keys, one
at a time, starting with 1, then2, 3...0. Stop pressing
the number keys when the device turns off.
STEP3 Release the [DEVICE] key to save the code. The
Device LED will blink twice to confirm the code is
stored.
Repeat the steps above for all components(CBL, TV, DVD).
B. Manual Pr
B. Manual Programming ogramming
The remote control can be programmed by entering a three-
digit code number that corresponds to particular brands and
models of equipment. The three-digit code numbers are
listed in the code tables sections of this instruction manual.
STEP1 Turn on the equipment that you want the remote
control to operate Cable Box, TV and DVD(VCR).
STEP2 Press the [DEVICE] button and the [OK/SEL]
button simultaneously for 10 seconds. The
corresponding device LED will turn on indicating
that it is ready to be programmed. The LED will
remain on for 20 seconds. The next step must be
entered while the LED is on.
STEP3 Point the remote control toward the equipment
and enter the three-digit code number assigned
to your brand from the code tables. If there are
more than one three-digit number listed for your
brand, try one code number at a time until your
equipment turns off.
*Note : You can verify that you have selected the correct
code by pressing the [MUTE] button. The
equipment should turn on or off.
STEP4 Store the three-digit code by pressing the same
[DEVICE] button once again. The device LED will
blink twice to confirm that the code has been
stored.
*Note : Try all the functions on the remote control. If any
of the functions do not operate as they should,
repeat the instructions from Step 2 using the next

4
three-digit code number from the same brand list.
C. Auto Sear
C. Auto Search Method ch Method
If none of the three digit code numbers assigned to your
brand of equipment works, or the code table does not list your
brand, you can use the Auto Search Method to find the
correct three-digit code number for your equipment by
following steps:
STEP1 Turn on the equipment that you want the remote
control to operate (Cable Box, TV, VCR, or DVD).
STEP2 Press the [DEVICE] button and the [OK/SEL]
button simultaneously for 10 seconds. The device
LED will turn on indicating that it is ready to be
programmed. The LED will remain on for 20
seconds. The next step must be entered while
the LED is on.
STEP3 Press the [CH+] or [CH-] button one at a time or
keep it pressed. The remote will emit a series of
Power ON/OFF code signals. Release the [CH+] or
[CH-] button as soon as the equipment turns off.
*Note : You can verify that you selected the correct code
by pressing the [MUTE] button. The equipment
should turn On or Off.
STEP4 Press the same [DEVICE] button to store the
code. The Device LED will blink twice to confirm
that the code has been stored.
D.
D. T To find the Thr o find the Three-Digit Code that W ee-Digit Code that Was as
Pr
Programmed using the Auto Sear ogrammed using the Auto Search ch
Method
Method
STEP1 Press the appropriate [DEVICE] button and the
[OK/SEL] button simultaneously for 10 seconds.
The device LED will turn on for 20 seconds.
The next step must be performed while the
LED is on.
STEP2 Press the [INFO] button. The device LED will blink
a number of times indicating the number of each

5
digit for the code. Each digit is separated by a
one second interval of the LED being off.
Example : One blink, then three blinks, then eight blinks
indicates the code number 138.
*Note : Ten blinks indicates the number 0.
E.
E.
Pr
Programming a Second TV to the DVD Button ogramming a Second TV to the DVD Button
STEP1 Press the [DVD] button and the [OK/SEL] button
simultaneously for 10 seconds. The DVD LED will
turn on for 20 seconds. The next step must be
performed while the LED is on.
STEP2 Press the [TV] button.
STEP3 Point the remote control toward the TV and enter the
three-digit code for your TV from the TV codes table.
STEP4 Store the three-digit code by pressing the [DVD]
button. The device LED will blink twice to confirm
that the code has been stored.
F
F. Pr . Programming for Advanced Functions. ogramming for Advanced Functions.
In the CABLE device mode, the A,B,C,D and blank macro
buttons can be programmed to act as a 'Macro' or
Favorite Channel button. This allows you to program up to
five 2-digit channels, four 3-digit channels or three 4-digit
channels that can be accessed with on button press.
*Note : The A,B,C and D buttons are not programmable
if you have a Digital Cable Box made by Pace,
Pioneer or Scientific-Atlanta.
STEP1 Press the [CBL] button to select the CBL mode.
STEP2 Press the [MACRO] button and [OK/SEL] button
simultaneously for 10 seconds. The [CBL] button
will turn on for 20 seconds.
STEP3 Enter the the 2, 3 or 4-digit code for the channel you
want programmed first (for example, 007) using the
Number Pad, then press the [STOP] button. Then
enter the code for the next channel (for example,
050), then press the [STOP] button. Repeat this

6
process for the third channel. The [CBL] button will
blink once for each channel entered.
STEP4 Press the [CH] button to store the channels
that were selected. The [CBL] button will blink
twice to confirm the storage of commands.
To access the programmed channels, press the [MACRO]
button once. This will bring up the first channel. Press
once again and it will bring up the second channel.
Press again and it will bring up the third channel.
To erase the Macro programming and return to the
original function:
STEP1 Press the [CBL] button to select the CABLE mode.
STEP2 Press a [MACRO] button and the [OK/SEL] button
simultaneously for 10 seconds. The CBL device
LED will turn on for 20 seconds. The next step
must be performed while the LED is on.
STEP3 Press the [CH+] button to erase the functions stored
in the button. The CBL device LED will blink twice to
confirm that the memory button has been erased.
G.
G. Assigning the V Assigning the Volume and Mute keys to olume and Mute keys to
a Dif
a Differ ferent Device ent Device
By default, the VOL+, VOL- and MUTE keys operate
through your TV. If you would like those keys to operate
those functions on a different device, follow these steps.
STEP1 Press the [OK/SEL] button and [CBL] button
simultaneously for 10 seconds. The device LED
will turn on for 20 seconds. The next step must
be performed while the LED is on.
STEP2 Press the [VOL +] button. The device LED will
blink.
STEP3 Press the [DEVICE] button corresponding to the
device that you would like the volume and mute
buttons to control. The device LED will blink
twice to confirm the programming.
Example : If you wish to have the volume and mute keys

7
operate your Cable Box, press the [CBL]
button in Step3.
H.
H. Assigning the Channel keys to a Assigning the Channel keys to a
Dif
Differ ferent Device ent Device
By default, the CH+, CH-, NUMERIC and LAST keys
operate through your Cable Box. If you would like those
keys to operate those functions on a different device,
follow these steps.
STEP1 Press the [OK/SEL] button and [CBL] button
simultaneously for 10 seconds. The device LED
will turn on for 20 seconds. The next step must
be performed while the LED is on.
STEP2 Press the [VOL -] button. The device LED will
blink.
STEP3 Press the [TV] button. The device LED will blink
twice to confirm the programming.
*Note : If you wish to have the channel keys operate your
Cable Box, press the [CBL] button instead of the
[TV] button in Step 3.
I.
I.
Assigning the VCR/DV
Assigning the VCR/DVD D
–
–
VOD keys to
VOD keys to
contr
control your VCR or DVD ol your VCR or DVD
By default, the REW, Play, FF, Record, Stop and Pause keys
operate VOD (Video On Demand) through your Cable Box.
If you would like those keys to operate those functions on
your DVD or VCR, press the PLAY button for 10 seconds
until the DVD/VCR button lights. To return to your Cable
Box control, press the PLAY key again for 10 seconds until
the CBL button lights.
J.
J. Low Batter Low Battery W y War arning ning
When the battery is low (2.3V-2.0V) and needs to be
replaced with fresh batteries, device LED will blink 2 times
in sequence whenever a [DEVICE] button is pressed to
turn on equipment.
K.
K. Memor Memory Lock System. y Lock System.
This remote control is designed to retain programmed
memory for 10 years — even after batteries are removed
from the remote control.

8
Quick Set-up Code Tables
5
Quick Number Manufacturer/Brand
CBL
DVD
0 PACE
1 SCIENTIFIC ATLANTA/CISCO, PACE,
SAMSUNG
2 MOTOROLA
3 AMINO
4 AT&T
5 CISCO
6 DIRECTV
7 MOXI
8 TIVO
9 HUMAX
0 SANYO
1 SONY
2 SAMSUNG
3LG
4 TOSHIBA
5 PANASONIC
6 PHILIPS
7 HITACHI
8 SHARP
9 VIZIO
0 HITACHI
1 SONY
2 PHILIPS
3 SAMSUNG
4 PHILIPS MAGNAVOX
5 PANASONIC
6LG
7 JVC
8 DENON
9 PIONEER
Quick Number Manufacturer/Brand
Quick Number Manufacturer/Brand
TV
