Universal Security Instruments Sensing Plus AMIC3511S User manual

Conforms to
UL Std. 217
8th Edition
Helps Reduce Cooking Nuisance Alarms
®
MODEL AMIC3511S
Multi-Criteria Single/Multiple Station Smoke Alarm
& Carbon Monoxide Alarm
Universal Sensing Plus®
3-in-1 Smoke & Fire & Carbon
Monoxide Alarm with 10 Year Tamper
Proof, Permanent Power, Lithium-Free,
Sealed Battery Power
THANK YOU for purchasing this 3-in-1 Smoke + Fire + Carbon Monoxide Smart
Alarm. This alarm does not require battery changes. This alarm contains a 10 year
permanent power lithium free sealed battery to provide continuous protection –
even in the event of a power outage. The sealed battery will last for approximately
10 years. This manual includes important information regarding where to install
the alarm, how to operate, maintenance, testing and product features. It also
includes tips and information which can help protect you and your family. This
alarm detects products of combustion using a multi-criteria smoke & fire sensor.
TABLE OF CONTENTS ....................................................................................PAGE
Alarm Technology & Key Product Features....................................................2
Alarm Limitations and Functions.....................................................................2
Installation Instructions.....................................................................................3
Where This Alarm Should Be Installed ..........................................................3
Where This Alarm Should Not Be Installed...................................................5
Mounting Instructions....................................................................................6
Tamper Resistant Alarm Locking Feature......................................................6
Industry & Agency Recommendations ...........................................................7
Alarm Operation ..................................................................................................7
Normal Operation ..........................................................................................7
Trouble Signal .................................................................................................7
Alarm Reset.....................................................................................................8
Quick Find®Alarm Origination......................................................................8
Silence Feature................................................................................................9
Testing Instructions.........................................................................................9
Alarm & Battery Deactivation ..........................................................................9
What To Do If Alarm Sounds—Carbon Monoxide Detected ....................10
What You Should Know about Carbon Monoxide.....................................10
Symptoms of CO ...........................................................................................10
Required CO Alarm Levels............................................................................10
Response to CO Alarm Sounding.................................................................10
Potential Sources of CO................................................................................11
What To Do If Alarm Sounds—Smoke Detected .........................................12
How Can I Protect My Family from Fire ......................................................12
Develop An Escape Plan ...............................................................................12
Quick Reference Guide .....................................................................................13
Troubleshooting Information ......................................................................13
Warranty
Alarm Returns ...............................................................................................15
Repairs and Service.......................................................................................15
Regular Maintenance ...................................................................................15
READ ALL INSTRUCTIONS
This smoke alarm uses an extremely small amount of a radioactive
element in the ionization chamber. Do not tamper with radioactive
sealed source or try to repair the smoke alarm yourself.
288-3645-00 ©2020 UNIVERSAL SECURITY INSTRUMENTS, INC., Rev. 05/2020 CD
Printed in China

Page 2
ALARM TECHNOLOGY & FEATURES
This is a 3-in-1 combination smoke + re + carbon monoxide (CO) alarm. The 10 year lithium-free
sealed battery provides continuous protection even in the event of a power outage.
• There are three basic smoke alarm types: UNIVERSAL® Sensing Plus®, Ionization and
Photoelectric
• UNIVERSAL® Sensing Plus® uses the Advanced Intelligence of Multi-Criteria Technology and a
Patented Microprocessor to respond quickly to both fast aming res and slow smoldering res.
• Ionization smoke alarms are typically more effective at detecting fast aming res—res which
consume combustible materials rapidly and spread quickly. Sources of these res may include
paper burning in a wastebasket, or kitchen grease res.
• Photoelectric smoke alarms, on the other hand, are typically more effective at detecting slow
smoldering res—res which burn for hours before bursting into ame. Sources of these res
may include cigarettes burning in couches or bedding.
• Installing alarms containing UNIVERSAL® Sensing Plus® technology ensures maximum
detection of all types of res.
The enclosed alarm is a 3-in-1 Carbon Monoxide +
UNIVERSAL®Sensing Plus®Smoke + Fire Smart Alarm.
KEY PRODUCT FEATURES
Smart Alarm Technology virtually eliminates nuisance alarms caused by non-hazardous sources
such as every day cooking smoke and steam
Permanent Power battery provides continuous protection and eliminates low battery chirps.
Never replace batteries.
Lithium Free 10 Year Sealed Power Supply features Duracell® Duralock Power Preserve™
Technology alkaline batteries providing a safer, greener alternative
This alarm meets the new UL217 8th Edition requirements for the detection of polyure-
thane foam in both slow smoldering & fast aming res; resistance to false alarms from
cooking; and it passes the tests for immunity to high-voltage current surges.
ALARM LIMITATIONS AND FUNCTIONS
• IMPORTANT: ALARMS WILL NOT WORK WITHOUT POWER. Therefore, installing an alarm
with a sealed battery or an alarm powered from two different power sources can give an extra
measure of protection. A hardwired alarm with backup battery power will provide protection in
the event of an AC power failure. Battery operated alarms cannot work if the batteries are
missing, disconnected or dead. If you are concerned about the limitations of the battery or
AC power, install both types of alarms.
• PROPERLY LOCATE THE ALARM TO AVOID NUISANCE ALARMS. Using an ionization
smoke alarm without UNIVERSAL®Sensing Plus® in a smokey area, such as a kitchen, or in a
high humidity area near a shower, can cause nuisance/false alarms.
• DO NOT DEACTIVATE THE BATTERY TO QUIET A NUISANCE/FALSE ALARM. The alarm
will not provide protection if it is not receiving power. Properly locate the alarm to avoid
nuisance/false alarms.
• SMOKE, CO OR GAS ALARMS MAY NOT ALWAYS WARN ABOUT DANGERS CAUSED BY
CARELESSNESS. Safety hazards such as smoking in bed, violent explosions, escaping gas,
improper storage of ammable materials, overloaded electrical circuits, children playing with
matches, natural causes such as lightning and arson. Prevention and appliance maintenance is
the best safeguard.
• INSTALLING ALARMS MAY MAKE YOU ELIGIBLE FOR LOWER INSURANCE RATES,
BUT ALARMS ARE NOT A SUBSTITUTE FOR INSURANCE. Home-owners and renters alike
should continue to insure their lives and properties.
• SMOKE ALARMS CANNOT DETECT FIRES IF THE SMOKE DOES NOT REACH THEM.
Smoke from res may not reach the sensing chamber and set off the alarm. Do not obstruct
airow around the smoke alarm or place in areas of obstructed airow.
• SMOKE ALARMS MAY NOT BE EFFECTIVE IN VARIOUS AREAS. For example: (1) Fires
where the victim is intimate with re due to a person’s clothes catching re while cooking; (2)
Fires where the smoke is prevented from reaching the alarm due to a closed door or other
obstruction; (3) Incendiary res where the re grows so rapidly that an occupant’s egress is
blocked even with properly located alarms.

Page 3
• SMOKE ALARMS MAY NOT DETECT FIRE ON ANOTHER FLOOR OR AREA OF THE
HOME. Recommended minimum protection is at least one smoke alarm inside every
bedroom, outside every sleeping area and on every level of the residence. Interconnected
alarms may provide earlier warning than stand-alone alarms since all alarms will sound when
the initiating alarm sounds.
• SMOKE ALARMS CANNOT PREVENT OR EXTINGUISH FIRES.
• ALARMS CAN ONLY SENSE CO WHICH REACHES THE ALARM SENSOR. Carbon
monoxide may be present in other areas of the dwelling without reaching the alarm. CO
may be present on one level of the dwelling and not reach the alarm installed on a different
level. For example, CO in the basement may not reach an alarm on the second level, near
the bedrooms. For this reason, we recommend you provide complete coverage by placing a
combination alarm on every level of the dwelling.
• ALARMS MAY NOT BE HEARD. The horn in this alarm meets or exceeds current standards,
but it may not be heard if: (1) The alarm is located outside a closed or partially closed door;
(2) Residents recently consumed alcohol or drugs; (3) The sound of the alarm is drowned out
by noise from stereos, TV’s, air conditioners or other appliances; (4) Residents are hearing
impaired or (5) Residents are sleeping. Current studies have shown alarms may not awaken
all sleeping individuals and that it is the responsibility of individuals in the household who are
capable of assisting others to provide assistance to those who may not be awakened by the
alarm sound or to those who may be incapable of safely evacuating the area unassisted.
• ALARMS ARE NOT FOOLPROOF. Test alarms weekly to ensure continued protection.
• ALARMS HAVE A LIMITED PRODUCT SERVICE LIFE. This alarm should be replaced
immediately if it is not operating properly. If the self-diagnostic test reveals a malfunction, the
service signal will warn it is time to replace the alarm. Alarms should always be replaced after
10 years.
• DO NOT PAINT THE ALARM. Paint may clog the openings to the sensing chambers and
prevent the alarm from operating properly.
• DO NOT STAND TOO CLOSE TO THE ALARM WHEN IT IS SOUNDING. It is loud to wake
occupants in an emergency. Exposure to the horn at close range may harm your hearing.
• DO NOT TAMPER WITH THE SEALED RADIOACTIVE SOURCE. This alarm contains an
extremely small amount of a radioactive element in the ionization chamber—less than
1 microcurie (37 kilobecquerel), of a radioactive element, Americium 241. This element is used
to detect combustion products. The source is manufactured and distributed under license from
the U.S. Nuclear Regulatory Commission; and meets or exceeds government standards.
The consumer is exempt from any licensing requirements.
INSTALLATION INSTRUCTIONS
IMPORTANT CONSIDERATIONS THIS ALARM HAS BEEN
DESIGNED WITH A PRODUCT END-OF-SERVICE LIFE SIGNAL WHICH WILL SOUND
AFTER APPROXIMATELY 10 YEARS OF OPERATION FROM INITIAL POWER UP. NOTE:
Manufacturer recommends replacement of this alarm 10 years after date of installation.
WHERE THIS ALARM SHOULD BE INSTALLED
This product is intended for use in ordinary indoor locations of family living units. It is not
designed to measure compliance with Occupational Safety and Health Administration (OSHA)
commercial or industrial standards. Individuals with medical problems may consider using
warning devices which provide audible and visual warnings for carbon monoxide concentrations
under 30 ppm.
IMPORTANT: This alarm must be mounted on a ceiling or a wall.
It is not designed for use as a tabletop device.
For maximum protection, install an alarm inside every bedroom, outside every sleep area,
and on every level of the home including basements and nished attic spaces.
• Temperature limits for proper operation are 40ºF to 100ºF (4.4ºC to 37.8ºC)
• Humidity operating range is up to 95% RH non-condensing
• Install an alarm in each room where the occupant closes the door while sleeping.
• For all locations, make sure doors or other obstructions don't prevent the smoke or carbon
monoxide from reaching the alarm.

• Install an alarm in every family living unit containing a fuel-burning appliance, replace, or
an attached garage.
• Alarms should be centrally located outside of each separate sleeping area in the immediate
vicinity of the bedrooms. Where bedrooms are separated and audibility of the alarm to occu-
pants within the bedroom area could be seriously impaired, more than one alarm may
be needed.
• Protect the escape route, as the bedrooms are usually farthest from an exit. If more than
one sleeping area exists, locate additional alarms in each sleeping area. If a hall is more
than 41 feet (12.5 meters) long, install an alarm at each end of the hallway.
• Add additional alarms to protect any stairway, as stairways may act like chimneys for
smoke and heat.
• Locate at least one alarm on every oor level.
• Locate an alarm in any area where a smoker sleeps or where electrical appliances are
operated in sleeping areas.
• Smoke, heat and other combustion products rise to the ceiling and spread horizontally.
Mounting the alarm on the ceiling in the center of the room places it closest to all points in
the room. Ceiling mounting is preferred in ordinary residential construction. However, in
mobile homes, wall mounting on an inside partition is preferred to avoid the thermal barrier
that may form at the ceiling.
• When mounting the alarm on a wall, if local codes allow, use an inside wall with the top
edge of the smoke alarm up to a maximum of 12” (30.5cm) below the ceiling/wall intersec-
tions (See Diagram A).
Existing Homes:
The NFPA requires smoke alarms or combination alarms on every level and outside each
sleeping area in existing construction. An existing household with one level and one sleeping
area is required to have one smoke alarm.
New Construction Homes and Manufactured Homes:
The NFPA requires AC-powered, interconnected smoke alarms to be installed inside each
bedroom, outside each bedroom area, and on every level of the home. They also require
a minimum of two AC-powered, interconnected smoke alarms or combination alarms in any
new construction home.
Sloped Ceilings (Peaked Ceilings):
Smoke alarms or combination alarms mounted on a peaked ceiling shall be located within
36 in. (914 mm) horizontally of the peak, but not closer than 4 in. (102 mm) vertically to the peak.
Sloped Ceilings (Shed Ceilings):
Smoke alarms or combination alarms mounted on a sloped ceiling having a rise greater than
1 ft. in 8 ft. (1 m in 8 m) horizontally shall be located within 36 in. (914 mm) of the high side of
the ceiling, but not closer than 4 in. (102 mm) from the adjoining wall surface.
Tray-Shaped Ceilings:
Smoke Alarms or combination alarms shall be installed on the highest portion of the ceiling
or on the sloped portion of the ceiling within 12 in. (305 mm) vertically down from the highest
point.
Page 4
Ceiling
Acceptable
Top of detector
acceptable here
Sidewall
12 in.
(300 mm)
maximum
Note: Measurements shown are to
the closest edge of the detector.
DIAGRAM A

Page 5
Mobile Home Installation:
For minimum protection, smoke alarms should be installed in compliance with H.U.D.
Manufactured Home Construction Safety Standards, Title 24 CFR, Section 3280.208 and
Section 3282. For additional protection, see Single Story Residence smoke alarm
requirements/recommendations for Existing Homes and New Construction Homes.
Note: For mobile homes built before 1978, install smoke alarms or combination alarms on
inside walls between 4” and 12” from the ceiling (older mobile homes have little or no insula-
tion in the ceiling). This is especially important if the ceiling is unusually hot or cold.
Install smoke alarms or combination alarms inside each bedroom and in the hallway outside
each separate sleeping area.
WHERE THIS ALARM SHOULD NOT BE INSTALLED
Installation in an improper location can affect the sensitive electronic components in this alarm.
This alarm is not suitable for installation in hazardous locations as dened in the National
Electrical Code.
To avoid causing damage to this alarm, to provide maximum protection, and to prevent
unnecessary alarms, DO NOT LOCATE THIS ALARM:
• In extremely humid areas. This alarm should be at least 3 feet (0.9m) from a bath or
shower, sauna, humidier, vaporizer, dishwasher, laundry room, utility room or other source
of high humidity.
• In very cold or very hot environments or in unheated buildings or outdoor rooms where the
temperature can go below or above the operating range of the alarm.
• In garages, kitchens crawl spaces and unnished attics.
• In turbulent air, such as near ceiling fans, heat vents, air conditioners, fresh air returns or
open windows. Blowing air may prevent smoke or CO gas from reaching the sensors.
• In extremely dusty, dirty or greasy areas. Installation in these areas could lead to nuisance
alarms, may expose the sensor to substances which could damage or contaminate the
alarm.
• In the garage, vehicle exhaust can contain some carbon monoxide. These levels are higher
when the engine is rst started. Within hours of starting a vehicle and backing it out of the
garage, the levels present over time can activate the alarm and become a nuisance.

Page 6
• Less than 12 inches (306mm) away from uorescent lights. Electrical noise can interfere
with the operation of the alarm.
• In the kitchen, some gas appliances can emit a short burst of CO or gas upon startup. This
is normal. If this alarm is installed too close to these appliances, it may sound often and
become a nuisance.
• Less than 20 feet (6m) from the sources or combustion particles such as a stove, furnace,
water heater, non-electric space heater. In areas where a 20 foot (6m) distance is not
possible i.e. modular, mobile or smaller homes, it is recommended the alarm be placed as
far from these fuel-burning sources as possible.
• Where heavy furniture drapes or other objects will not block the sensor.
• Peaks of vaulted ceilings, “A” frame ceilings or gabled roofs.
• Alarms are not to be used with detector guards unless the combination has been evaluated
and found suitable for that purpose.
NOTES: Good ventilation is recommended when household cleaning supplies or similar
contaminants are used.
Excessive spillage or reverse venting of fuel-burning appliances caused by outdoor ambient
conditions, such as: (1) Wind direction and/or velocity, including high gusts of wind; (2) Heavy
air in the vent pipes with cold/humid air with extended periods between cycles; (3) Negative
pressure differential resulting from the use of exhaust fans; (4) Simultaneous operation of several
fuel-burning appliances competing for limited internal air; (5) Vent pipe connections vibrating
loose from clothes dryers, furnaces or water heaters; (6) Obstructions in or unconventional vent
pipe designs which can amplify the above situations.
These placement recommendations are intended to keep alarms at a reasonable distance
from a fuel-burning source and reduce unwanted/nuisance alarms. Nuisance alarms may
occur if an alarm is placed directly next to a fuel-burning source. Ventilate these areas as
much as possible.
MOUNTING INSTRUCTIONS
To use the optional Alarm Tamper Resistant Mounting Feature, refer to the next section for
further instructions.
1. Be sure to select the proper location for this alarm as described in the placement
instructions. This alarm should be mounted either on the ceiling or a wall.
2. To identify the replacement date for this alarm, a label has been placed on the side of the
alarm cover. With permanent marker, write the date of installation in the space provided.
3. Remove the mounting bracket from the back of the alarm by holding the mounting bracket
and twisting the alarm in the direction indicated by the “TWIST TO REMOVE” arrow on the
top of the alarm base.
4. Attach the mounting bracket using the two screws and wall anchors provided.
5. Activate the Permanent Power sealed battery by removing the battery pull tab. The alarm
will sound one long beep to let you know it is powered. NOTE: Once activated, the alarm
cannot be turned off without permanent deactivation.
6. The alarm will remain on for approximately ten years.
7. Test the alarm again to ensure proper operation.
OPTIONAL ALARM TAMPER RESISTANT LOCKING FEATURE
This feature will help to deter children and others from removing the alarm from the
mounting bracket. It is not necessary to activate this feature in places where unauthorized
alarm removal is not a concern.
TO INSTALL: The locking pin is molded into the mounting bracket and clearly identied.
Refer to Figure 1. To use the locking feature, followed these steps:
1. Remove/break off the locking pin located in the mounting bracket.
2. Attach the mounting bracket to the wall or ceiling using the two screws and wall anchors
provided.
3. Install the alarm on the mounting bracket.
INSERT ALARM
LOCKING PIN
HERE
ALARM & BATTERY
DEACTIVATION KEY
FIGURE 2

Page 7
4. Insert the pin into the opening located in the base of the alarm (Figure 2)
TO REMOVE: To remove the alarm after the tamper resistant locking feature has been
engaged; remove the locking pin using long nose pliers. The locking pin is reusable.
IMPORTANT: Two self-adhesive labels are included with this alarm. On each label write in
the phone number of your emergency responder, for example 911, and a qualied appliance
technician. One label should be placed near where this alarm is installed, and the other label
should be placed in the “fresh air” location you plan to go if the alarm sounds.
INDUSTRY & AGENCY INSTALLATION RECOMMENDATIONS
CALIFORNIA STATE FIRE MARSHAL
“Early warning re detection is best achieved by the installation of re detection equipment
in all rooms and areas of the household as follows. A smoke alarm installed in each separate
sleeping area (in the vicinity of, but outside of the bedrooms), and heat or smoke detectors in
the living rooms, dining rooms, bedrooms, kitchens, hallways, attics, furnace rooms, closets,
utility and storage rooms, basements and attached garages.”
NATIONAL FIRE PROTECTION ASSOCIATION
For your information, the National Fire Alarm Code, NFPA 72, reads as follows:
29.8.1 *Required Detection - Where required by applicable laws, codes, or standards for a
specic type of occupancy, Listed single and multiple-station smoke alarms shall be installed
as follows:
1. *In all sleeping rooms and guest rooms.
2. *Outside of each separate dwelling unit sleeping area, within 6.4 m (21 ft) of any door to a
sleeping room, the distance measured along a path of travel.
3. On every level of a dwelling unit, including basements.
4. On every level of a residential board and care occupancy (small facility), including
basements and excluding crawl spaces and unnished attics.
5. *In the living area(s) of a guest suite.
6. In the living area(s) of a residential board and care occupancy (small facility).
The equipment should be installed using wiring methods in accordance with the National Fire
Protection Association’s Standard 72, National Fire Code. For additional information, contact:
National Fire Protection Association, One Batterymarch Park, Quincy, MA 02169-7471 or go
to www.nfpa.org
ALARM OPERATION
NORMAL OPERATION: The alarm is operating once the battery power is connected,
the battery pull tab has been removed, and the alarm has sounded one long beep. The red
smoke LED blinks on once approximately every two minutes. The red CO LED is off. The
horn is silent.
CAUTION! This combination smoke & re & carbon monoxide alarm has separate alarm
sounds. This alarm is not designed to detect any other gas. Carbon monoxide and smoke
may be present in other areas. The alarm will only indicate the presence of CO or smoke
which reaches the sensor. This carbon monoxide alarm is designed to detect carbon
monoxide gas from any source of combustion.
TEST SEQUENCE: The horn beeps 3 times with a 6 second pause and then beeps
4 times. The red smoke LED blinks on in sync with the 3 beeps. The red CO LED blinks on in
sync with the 4 beeps.
This alarm incorporates the NFPA recognized horn signal for evacuation.
SMOKE ALARM CONDITION: The horn beeps 3 times with a 2 second pause and
continues until the air is cleared. The red smoke LED blinks on in sync with the 3 beeps.
The red CO LED is off.
CO ALARM CONDITION: The horn beeps 4 times with a 5 second pause and continues
until the air is cleared. The red smoke LED blinks on every two minutes. The red CO LED
blinks on in sync with the 4 beeps.
SENSOR TROUBLE: This alarm contains multiple self-diagnostics. If a sensor fault is de-
tected, the horn chirps 3 times approximately every 60 seconds. The red smoke LED blinks on

once approximately every two minutes. The red CO LED is off. The trouble signal cannot be
silenced. Reset the alarm. If this does not clear this trouble signal, deactivate the alarm. Refer
to the “alarm deactivation section.” Replace alarm immediately.
RESET ALARM: Press the test/silence button for 10-15 seconds, then release. This will
clear the alarm origination. Be sure to reset alarms after every alarm event.
QUICK FIND®ALARM ORIGINATION FEATURE: To quickly identify the originating alarm
after all the alarms have stopped sounding
1. Press and release the test/silence button on any alarm. After releasing the button, the test
sequence will sound and last for approximately 5-20 seconds, and then stop.
2. Once the test sequence ends, the originating alarm will continue to sound for approximately
60 seconds which provides ample time to locate the originating alarm.
3. Remember to reset the originating alarm in order to clear the Quick Find® and return the
system to normal operation
4. NOTE: It is necessary to test each alarm by pressing and releasing the test/silence button
to determine the originating alarm.
PRODUCT END-OF-SERVICE LIFE ALARM/LOW BATTERY WARNING: When it
is time to replace this alarm, which is approximately 10 years of operation from initial power up,
the alarm will provide audible and visual warnings. The product end-of-service life warning
cannot be silenced. The horn chirps 2 times approximately every 60 seconds. The red smoke
LED blinks on approximately every 2 minutes. The red CO LED is off. Deactivate the alarm.
Refer to the “alarm deactivation section.” Replace alarm immediately.
USING THE SILENCE FEATURE
NEVER ignore any alarm. If the alarm sounds and it is not being
tested, it is warning of a potentially dangerous situation which requires immediate attention.
NEVER disconnect the power to your alarm to silence the horn—use the Silence feature.
Disconnecting the alarm removes your protection!
IMPORTANT! The Silence feature is intended to temporarily silence the alarm warning.
It will not correct a smoke or CO problem.
In the event of a smoke alarm, do not use the Silence feature until the source of the
alarm has been identied and safe conditions exist.
The Silence feature is intended to temporarily silence the horn while identifying and correcting
the problem. To use the Silence feature, press and release the test/silence button until the
horn is silent if it was the initiating alarm. If the test/silence button is pressed while the alarm
is in the silence mode, the alarm will start sounding again.
The CO alarm Silence feature can be activated by a press and release of the test/silence
button on the initiating alarm while in alarm condition. The alarm will remain silent for approxi-
mately 5 minutes, depending on the level of CO detected. The red CO LED will blink on ap-
proximately every 10 seconds. If CO levels drop below the alarm levels, the alarm will remain
silent and return to normal operation. If CO levels remain constant or increase, the alarm will
sound again. This indicates a potentially dangerous situation. Ventilate the area.
The smoke alarm Silence feature can be activated by a press and release of the test/
silence button on the initiating alarm while in alarm condition. The alarm will remain silent for
approximately 8-12 minutes, depending on the level of smoke detected. The red smoke LED
will blink on approximately every 10 seconds. If smoke levels have not cleared during the
silence period, the alarm will sound again. This indicates a potentially dangerous situation.
Ventilate the area. If the alarm remains silent, the smoke levels have dropped and the alarm
will return to normal operation. If smoke levels remain constant or increase, the alarm will
sound again.
TESTING INSTRUCTIONS
NEVER use an open ame of any kind to test this alarm. You may
accidentally damage or set re to the alarm or to your home.
NEVER use vehicle exhaust to test the alarm! Exhaust may cause permanent damage
and voids the warranty.
NEVER use a gas range or an open ame of any kind to test this alarm. You might ac-
cidentally damage or set re to the alarm or to your home.
CAUTION: Continuous exposure to the high sound level of this alarm over an extended
period of time may cause hearing loss. Due to the loudness, we suggest that you place your
ngers over the sounder opening, or step back from the alarm while testing.
Page 8

Page 9
NOTE: The alarm horn loudness meets or exceeds current UL standards of 85 decibles at 10
feet (3 meters).
WEEKLY TESTING: This alarm is designed to act as a monitor, not for use as a short-term
testing device, or to perform a quick check for the presence of CO or smoke. The built-in test
switch accurately tests the alarm operation as required by ANSI/UL 2034/UL 217 Standards
for Safety. If at any time the alarm does not perform as described when tested, replace it
immediately. Weekly testing is required to ensure proper operation. Irregular or low volume
sound may indicate a defective alarm and it should be returned for service. Follow deactiva-
tion instructions to prepare alarm for shipment or disposal.
NOTE: Actuation of the test button must be by use of a person’s nger or thumb. Use of any
other instrument is strictly prohibited.
USING THE TEST FEATURE:Press and release the Test button on the alarm cover. During
testing, the alarm will sound a loud horn pattern consisting of 3 beeps, followed by a 6 second
pause, then 4 beeps. The red smoke LED will blink in sync with the 3 beeps and the red CO
LED will blink in sync with the 4 beeps. The alarm will sound if all the electronic circuitry, horn
and battery are working properly.
If the alarm does not sound properly:
1. Hold the test button down longer. Try holding the test button down for up to 10 seconds.
2. Make sure the battery activation pull tab has been completely removed.
3. If there is still a problem, call customer service. Do not attempt to x the alarm.
ALARM AND BATTERY DEACTIVATION
This alarm uses a sealed battery for power.
The battery should last for approximately 10 years under normal operating conditions.
Deactivation of the alarm is permanent.
Place this alarm into shut-down mode at the end of its useful service life. Once the alarm has
entered end-of-service-life mode, it is necessary to turn off the alarm to deactivate the alarm
operation. This will stop the product end-of-service-life warning signal and also discharge the
remaining capacity of the battery and ready the alarm for disposal.
1. Remove the alarm from the mounting bracket by rotating it in the direction shown the
arrows on the rim of the base.
2. The plastic alarm deactivation key is molded in the mounting bracket of the alarm. Refer to
Figure 3). Use a small at blade tool to remove (breakaway) the deactivation key from the
mounting bracket.
3. Insert the key into the deactivation keyhole slot outlined on alarm label, and insert fully.
4. Slowly turn key clockwise to the “off” position, approximately 3/4 turn. Do not remove key.
5. This will discharge the alarm battery and stop the alarm chirping after approximately on
minute. The alarm is now ready for disposal.
6. The deactivation key should not be removed and the alarm cannot be re-attached to the
mounting bracket.
7. Be sure to install a new alarm immediately.
Once this alarm has been deactivated/turned off:
• The alarm cannot be re-activated
• The alarm cannot be re-attached to the bracket
• The alarm will no longer detect smoke or carbon monoxide
• The alarm contains no serviceable parts
DEACTIVATION KEY
FIGURE 3

Page 10
WHAT YOU SHOULD KNOW ABOUT CO
Carbon monoxide (CO) is an insidious poison. It is a colorless, odorless, tasteless gas. It is
a cumulative poison. Even low levels of CO have been shown to cause brain and other vital
organ damage in unborn infants with no effect on the mother.
The following symptoms are related to CARBON MONOXIDE POISONING and should be
discussed with ALL members of the household:
MILD EXPOSURE: Slight headache, nausea, vomiting, fatigue (often described as “u-like” symptoms).
MEDIUM EXPOSURE: Severe throbbing headache, drowsiness, confusion, fast heart rate.
EXTREME EXPOSURE: Unconsciousness, convulsions, cardiorespiratory failure, death.
Many cases of reported CARBON MONOXIDE POISONING indicate that victims are aware
they are not well, but they become so disoriented that they are unable to save themselves by
either exiting the building or calling for assistance. Young children and household pets may
be the rst affected.
Your combination alarm is designed to detect the toxic CO fumes that result from incomplete
combustion, such as those emitted from appliances, furnaces, replaces and auto exhaust.
What Levels of CO Cause an Alarm?
Underwriters Laboratories Inc. UL2034 denes three specic alarm points by which all
residential CO alarms must alarm. They are measured in parts per million (ppm) of CO over
time (in minutes).
UL2034 Required Alarm Points:
• If the alarm is exposed to 400 ppm of CO, it must alarm between 4 and 15 minutes.
• If the alarm is exposed to 150 ppm of CO, it must alarm between 10 and 50 minutes
• If the alarm is exposed to 70 ppm of CO, it must alarm between 60 and 240 minutes.
• This alarm is designed to act as a continuous monitor. It is not designed for use as a short-term
testing device to perform a quick check for the presence of CO.
WHAT TO DO IF CARBON MONOXIDE IS DETECTED
Never ignore the alarm sound. If you hear the alarm horn
sounding a continuous horn pattern of 4 beeps, 5 second pause, carbon monoxide has been
detected. Evacuate everyone from the dwelling.
Never disconnect the power from the alarm to stop a
nuisance alarm. Doing so will disable the alarm and remove the protection. In the case of
a true unwanted alarm, use the silence feature. The silence feature is intended to temporarily
silence the alarm while the problem is identied and corrected. Open a window or fan the CO
away from the alarm. The alarm will reset automatically when it returns to normal operation.
The alarm will stop sounding automatically
Actuation of your CO Alarm indicates the presence of carbon monoxide
(CO), which can kill you. In other words, when your CO Alarm sounds, you must not
ignore it! Some individuals are more sensitive to CO than others, including people with
cardiac or respiratory problems, infants, unborn babies, pregnant mothers and elderly people
can be more quickly and severely affected by CO. Members of sensitive populations should
consult their doctors for advice on taking additional precautions.
IF THE CO ALARM SOUNDS:
1. Operate the Silence button.
2. Call your emergency services, re department or 911. Write down the number of your local
emergency service here: ___________________________________.
3. Immediately move to fresh air—outdoors or by an open door or window. Do a head count
to check that all persons are accounted for. Do not reenter the premises or move away
from the open door or window until the emergency services responder has arrived, the
premises have been aired out, and your alarm remains in its normal condition.
4. After following steps 1-3, if the alarm reactivates within a 24 hour period, repeat steps 1-3
and call a qualied appliance technician to investigate for sources of CO from fuel-burning
equipment and appliances and inspect for proper operation of this equipment. If problems are
identied during this inspection, have the appliances and equipment serviced immediately.
Note any combustion equipment not inspected by the technician and consult the manufacturers’
instructions or contact the manufacturer(s) directly for more information about CO safety and
this equipment. Make sure that motor vehicles are not, and have not been, operating in an
attached garage or adjacent to the residence. Write down the number of a qualied appliance
technician here: _______________________________________________________.

Page 11
NOTE: A qualied appliance technician is dened as “a company engaged in and
responsible for the installation, testing, servicing, or replacement of heating, ventilation, air
conditioning (HVAC) equipment, combustion appliances and equipment, gas replaces
or other combustion equipment.”
Because carbon monoxide may dissipate by the time a rst responder or investigator arrives, it may be difcult to
locate the source of CO. USI Electric/Universal Security Instruments shall not be obligated to pay for or reimburse the
user of this alarm for any carbon monoxide investigation or service calls. Fire departments, HVAC contractors and most
utility companies will perform CO inspections. Some may charge for this service. It is advisable to inquire about any
applicable fees prior to having the service performed
POTENTIAL SOURCES OF CARBON MONOXIDE
Carbon monoxide (CO) is a colorless, invisible, odorless, tasteless, poisonous gas produced
when fossil fuels do not burn completely, or are exposed to heat, usually re. This alarm is not
designed to detect any other gas. This alarm will only indicate the presence of CO or smoke
which reaches the sensor. Carbon monoxide and natural gas may be present in other areas.
Fossil fuels such as wood, charcoal, coal, natural gas, oil, gasoline, propane and kerosene produce CO.
Household appliances may be sources of CO and include the gas kitchen range, cook top,
gas clothes dryer, heater, furnace, water heater, wood-burning stove, certain pool heaters,
replaces and portable space heathers. When they are not properly maintained, are
improperly ventilated, or malfunction, CO levels can rise quickly.
Electrical appliances typically do not produce CO.
Energy efcient homes. CO is a real danger now that homes are more “air-tight”, with
added insulation, sealed windows, and other weatherproong can trap CO inside.
Damaged or insufcient venting such as; corroded or disconnected water heaters, vent
pipes, leaking chimneys, pipes or ues or cracked heat exchangers, blocked or clogged
chimney openings.
Vent pipe connections improperly designed or becoming loose.
Improper use of appliances by operating a barbeque grill, using charcoal, gas or wood
pellets, hibachi in an enclosed area such as a garage or screened porch.
Vehicles and portable generators operating in a garage or any area too close to the living space.
Transient CO problems also known as on-again/off-again CO problems, can be caused by
outdoor conditions and other special circumstances.
Excessive spillage or reverse venting of fuel-burning appliances.
Outdoor ambient conditions and temperature inversions which can trap exhaust and
pollutants close to the ground.
Wind direction or wind velocity pushing heavy air in the vent pipes back in to the dwelling.
Negative air pressure caused by simultaneous operation of multiple fuel burning appliances
competing for limited internal air.
HOW CAN I PROTECT MY FAMILY FROM CO POISONING?
This alarm is an excellent means of protection. It monitors the air and sounds a loud alarm before (CO) levels
become threatening to the average, healthy adult.
An alarm is not a substitute for proper maintenance of home appliances. To help prevent CO problems and
reduce the risk of CO poisoning:
Clean chimneys and ues yearly. Keep them free of debris, leaves and nests for proper air ow. Have a
professional check for rust and corrosion, cracks or separations. These conditions can prevent proper air
movement and cause backdrafting.
Never “cap” or cover a chimney in any way that would block air ow.
Test and maintain all fuel-burning equipment annually. Many local gas or oil companies and HVAC
companies offer appliance inspections for a nominal fee.
This alarm will not operate until it is activated and properly installed. This alarm
should be tested immediately after installation and then tested weekly after that. If
the alarm ever fails to test correctly, have it replaced immediately. If the alarm is not
working properly, it cannot alert you to a problem. This alarm must have an activated
sealed battery power to operate properly. If the battery is dead or deactivated, the
alarm will not operate. The sealed battery cannot be replaced. The cover of this
10 year permanent power tamper proof alarm is sealed, and cannot be removed.

Page 12
Make regular visual inspections of all fuel-burning appliances. Check appliances for excessive rust and
scaling. Check the color of the ame on the burner and pilot lights to ensure they are burning properly. They
should be blue. If the ame is orange or yellow, it is a sign the fuel is not burning completely and a repair
technician should be contacted.
Teach every member of your home about the sounds and operation of this alarm. Proper response is
key to survival.
DEVELOP AND PRACTICE A PLAN OF ESCAPE
BASICS OF ESCAPE PLAN
• Make a oor plan indicating all doors and windows and at least two escape routes from each
room. Second story windows may need a rope or chain ladder.
• Have a family meeting and discuss your escape plan, showing everyone what to do in case of re.
• Determine a place outside your home where all of you can meet if a re occurs.
• Familiarize everyone with the sound of the smoke alarm and train them to leave your home
when they hear the sound.
• Identify children’s bedrooms with red stickers placed in the upper left corner of the windows.
They are available from your local re department.
• Practice a re drill at least every six months. Practice allows you to test your plan before an
emergency. You may not be able to reach your children. It is important they know what to do!
WHAT TO DO WHEN THE ALARM SOUNDS
• Leave immediately by your plan of escape. Every second counts, so don’t waste time getting
dressed or picking up valuables.
• In leaving, don’t open any inside door without rst feeling its surface. If hot, or if you see smoke
seeping through cracks, don’t open that door! Instead, use your alternate exit. If inside door
is cool, place your shoulder against it, open it slightly and be ready to slam it shut if heat and
smoke rush in.
• Stay close to the oor if air is smoky. Breathe shallowly through a cloth, wet if possible.
• Once outside, go to your selected meeting place and make sure everyone is there.
• Call the re department from your neighbor’s home – not from yours!
• Don’t return to your home until re ofcials say that it is all right to do so.

Page 13
C O N D I T I O N
New-Out of package.
The Test button has been
pressed. The test sequence
lasts for approx 10 seconds.
ALARM AUDIBLE & VISUAL SIGNALS
HORN
Silent
3 Beeps, 6
second pause,
4 beeps.
SMK RED
LED
Off
Blinks On in
sync with 3
beeps.
CO RED
LED
Off
Blinks On
i n s y n c w i t h
4 beeps.
RECOMMENDATION
To a c t i v a t e t h e a l a r m r e m o v e t h e p u l l t a b .
The alarm will sound one long beep to conrm
it is powered up.
DC power is present. Silent Blinks On
approx. every
2 minutes.
Off Alarm is operating properly.
Originating Smoke Alarm.
Originating CO alarm
3 Beeps,
2 second
pause, repeat
4 Beeps, 5
second pause,
repeat
Blinks On in
sync with the
3 beeps
Blinks on
approx. every
2 minutes
Off
Blinks On in
sync with the
4 beeps
If hazard is identied, please take all precau-
tions if an alarm sounds by calling Emergency
Service and getting out of the home.
If hazard is identied, please take all precau-
tions if an alarm sounds by calling Emergency
Service and getting out of the home.
None
CO alarm when cause of alarm
is known and poses no threat
4 Beeps, 5
second pause,
repeat
Blinks on
approx. every
2 minutes
Blinks On in
sync with the
4 beeps
Nuisance alarm
Smoke alarm when cause
of alarm is known and poses
no threat
Horn sounds
when no hazard
present
3 Beeps,
2 second
pause, repeat
Blinks On in
sync with the
3 beeps
Blinks On in
sync with the
3 beeps
Blinks On in
sync with the
4 beeps
Off
If there is no hazard present, verify the alarm
is mounted in the correct location (see user’s
manual). Reset alarm as instructed below.
The smoke alarm Silence Feature can be
activated by pressing and releasing the Silence
button while in alarm condition. Silence mode
will last for approximately 8 - 12 minutes [With
the red smoke LED blinking on approx every
10 seconds].
Alarm needing reset due
to abnormal operation/
previous alarms
Silent (alarmed
previously)
Blinks on
approx. every
2 minutes
Off To reset the alarm, hold the Test/Silence button
for 10-15 seconds. This will clear alarm origina-
tion. Reset after each alarm event.
Previous alarm condition at
unidentied source
Silent (alarmed
previously)
Blinks on
approx. every
2 minutes
Off Quick Find® Alarm Origination - It may be dif-
cult to determine which alarm has previously
sounded. The Quick Find® feature will allow
you to immediately locate the originating alarm
(once the alarm has stopped sounding). To
initiate Quick Find® press the Test/Silence
button on the alarm. After releasing the button
and following the test sequence, the originating
alarm will continue to sound for approximately
60 seconds.
The CO alarm Silence Feature can be
activated by pressing and releasing the Silence
button while in alarm condition. The alarm will
remain silent for approx 5 minutes [with the red
CO LED blinking on approx every 10 seconds],
depending on the level of CO detected. If CO
levels drop below alarm levels, the alarm will
remain silent and return to normal operation.
If CO levels remain constant or increase, this
indicates a potentially dangerous situation and
the horn will sound again. Ventilate area.
Quick Reference Guide Model AMIC3511S
Low Battery 1 Chirp approx.
every 60
seconds
1 Blink ap-
prox. every 2
minutes
Off Deactivate Alarm. See User’s Manual “ALARM
DEACTIVATION” section. Replace alarm
immediately.
Product-End-of-Service-Life
Notication
2 Chirps ap-
prox. every 60
seconds
1 Blink ap-
prox. every 2
minutes
Off Deactivate Alarm. See User’s Manual “ALARM
DEACTIVATION” section. Replace alarm
immediately.
Sensor Trouble 3 Chirps ap-
prox. every 60
seconds
Blinks on
approx. every
2 minutes
Off Reset the alarm. See Reset Instructions below.
If this does not clear the problem, replace
alarm. Deactivate Alarm. See User’s Manual
“ALARM DEACTIVATION” section. Replace
alarm immediately.
(Alarm Calibration) Warning Silent 3 Blinks
approx. every
2 minutes
Off Clean Alarm. See MAINTENANCE instructions
on the following page. Reset the alarm. See
Reset Instructions below. If this does not clear
the problem, replace alarm. Deactivate Alarm.
See User’s Manual “ALARM DEACTIVATION”
section. Replace alarm immediately.

Page 14
RESET INSTRUCTIONS: Press the Test/Silence button for 10-15 seconds and then release. This will clear the alarm origination. Be sure to RESET
alarms after each alarm event. QUICK FIND® Alarm Origination/Location Feature: The QUICK FIND® feature will allow you to immediately locate the
originating alarm (the alarm that triggered the other alarms), once the alarms have stopped sounding.
1. Press and release the Test/Silence button on alarm. After releasing the button, the test sequence on this alarm will begin, and
last approximately 5-20 seconds. If it is not the originating alarm, continue to each alarm until the originating alarm is located.
2. Once this test sequence ends, the originating alarm continues to sound for approximately 60 seconds, which provides ample time to
locate the originating alarm.
3. Remember to reset the originating alarm in order to clear the QUICK FIND® and return the system to normal operation.
NOTE: If you have any additional questions about the operation of this product, please contact our Customer Service Department
at 800-390-4321, and we will gladly assist you.
THIS PRODUCT IS LISTED TO UL STANDARD FOR SAFETY, UL 217 8TH EDITION and UL 2034 4th Edition.
Quick Reference Guide Model AMIC3511S (continued from previous page)

Page 15
TEN-YEAR LIMITED WARRANTY
USI Electric, Inc. /Universal Security Instruments, Inc. (“USI”) warrants this product
to be free from defects in material and workmanship for a period of 10 (ten) years
from the date of purchase. This warranty shall not apply to any damage which may be
caused by the sealed batteries used in this product. This warranty applies only to the
original consumer purchaser and only to products used in normal residential use and
service. If this product is found to be defective, USI’s only obligation, and your exclusive
remedy, is the repair or replacement of the product, at USI’s discretion, provided that
the product has not been damaged through misuse, abuse, accident, modication,
alteration, neglect or mishandling. This Warranty shall not apply to any product which is
found to have been improperly installed, set-up, or used in any way not in accordance with
the instructions supplied with this product.
ALARM RETURNS
For replacement of this alarm under the terms of this Warranty, contact the Customer
Service Department at 800-390-4321 extension 238 to obtain the current postage and
handling fees. USI does not warrant, and specically disclaims any warranty, whether
express or implied, of tness for a particular purpose, other than the warranty contained
herein. No implied warranty on this product, created by state law, shall extend beyond the
term of this warranty unless such law otherwise provides. USI specically disclaims any
liability and shall not be liable for any consequential or incidental loss or damage,
including, but not limited to, damages to any equipment with which this product is used.
Some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you. No agent,
representative, dealer, or employee of the company has the authority to increase or alter
the obligations or terms of this Warranty. This Warranty gives you specic legal rights and
you may also have other rights which vary from state to state. This Warranty is only valid
for merchandise purchased from outlets in the United States and Canada. This warranty
expires upon product end-of-service life signal.
REPAIRS AND SERVICES
If this alarm is defective in any way, do not attempt to open or tamper with it. Return the
alarm for servicing. Refer to Warranty for instructions. There will be a service charge for
repairing out of warranty alarms.
BASIC SAFETY INFORMATION
IMPORTANT! This alarm will not operate until it is activated and properly installed. This
alarm should be tested immediately upon installation and then tested weekly thereafter. If
the alarm ever fails to test correctly, have it replaced immediately. If the alarm is not working
properly, it cannot alert to a problem. This alarm must have an activated sealed battery
power to operate properly. If the battery is dead or deactivated, the alarm will not operate.
The sealed battery cannot be replaced. This alarm has no serviceable parts.
REGULAR MAINTENANCE
IMPORTANT: DO NOT use spray cleaning chemicals or insect sprays, ammonia-based
cleaners, paints, varnishes, most aerosol sprays including compressed gas dusters on or
near your alarm. DO NOT paint over the alarm. Doing so may permanently damage the
alarm.
Clean this alarm at least once per year. The outside can be wiped with a damp cloth.
IMPORTANT: After cleaning, reinstall alarm and test it by pressing the test button.
Visit Us on the Web
www.UniversalSecurity.com
11407 Cronhill Drive, Suite A
Owings Mills, Maryland 21117-6218
USA
