Univox PLS-100 User manual

How to connect a 1-turn / 2-turn loop
Balanced
Unbalanced
How to connect unbalanced / balanced input
Shield
Signal to pin 2 or 3
Disconnect the mains power before removing the cover!
IN1
Phantom power on (Default): S1 & S2 closed. Phantom power off: S1 & S2 open.
Microphone sensitivity (Default): S3 open. Line sensitivity: S3 closed.
IN2
Phantom power on: S5 & S6 closed. Phantom power off (Default): S5 & S6 open.
Microphone sensitivity: S4 open. Line sensitivity (Default): S4 closed.
Borrmall / Drill mask
Strap settings for Inputs 1 & 2
2-turn loop
1-turn loop
UniVox
®
UniVox® UniVox
PLS-100
® PLS-100 ®
Loop amplifi er 170m
2
Installation Guide
Page 4
2008-06-27 Z:\Products Public\Loop Amplifi ers - Systems\PLS-100\English\Service\PLS-100_IgGbV3.indd
Coverage area 170m² (free fi eld)
according to IEC 60118-4:2006
2008-06-27
Telephone
[phone]
Telefax
[phone]
E-mail
[email protected]
Website
www.edin.se
Bo EDIN AB
Stockby Hantverksby 3
SE-181 75 LIDINGÖ
Sweden
WARNING!
Live terminals enclosed!

UniVox
®
PLS-100 Installation Guide
® PLS-100 Installation Guide ®
General planning and installation procedures
1. Preparations
a) If the loop cable is already planned, install according to the drawings. Then read clause 2.
b) If the loop cable is already planned and installed, read clause 2.
c) If the loop cable is to be planned and installed ”on site”, please read the following guidelines.
● Use a 2x2.5mm² twin loop wire, for high fl exibility to the installer. If other loop wires are used, the amplifi er’s effi ciency
may be affected. Recommended minimum loop wire area is described in the table at page 3.
● If the space for the loop cable is limited, a fl at copper foil (Part No 861023) can be used as an alternative.
● The fi eld strength can be reduced due to reinforced concrete and other metal structures. If so, the fi eld strength can be
doubled (appr. 6dB) if 2 amplifi ers are used, one for each separate wire of the twin wire, or use a more powerful amplifi er
as an alternative.
● Do not place input cables close/parallel to the loop wire.
● Do not place the loop wire close to and parallel with reinforcement iron or other metal structures. This will reduce the
magnetic fi eld strength.
● If the smallest distance in a loop exceeds 10 meters, please consider another loop confi guration, for example a fi gure-
eight loop or plan for a SLS System (see next paragraph).
● Please be aware of the overspill effect. If the overspill is not acceptable, plan for a UniVox
®
Super Loop System with
® Super Loop System with ®
minimized overspill. Log on to www.edin.se for more information.
● Beware of the background noise created by other electrical equipment when planning the loop system.
● Proceed to clause 2.
2. Installation
Mount the amplifi er
Mount the amplifi er vertically or horizontally. Use the drill mask to mark the positions for the holes. If the amplifi er is to be
mounted in a 19"-rack, use a separate mounting panel (Part No 289011). The rubber feet should not bee removed. The
amplifi er must have free access to normal room temperature.
Connect the loop cable
Connect the loop cable to terminal F. on the rear panel. Please see page 4 for how to do 1- or 2-turn loop connections.
Connect signal source/s
Connect signal sources to the inputs IN1-3,
K., L. and M. on the rear panel. See page 4 for
balanced/unbalanced connections. The inputs
IN1 and IN2 can be set to different sensitivities
according to table (right). If you need to set
IN1 or IN2 otherwise than default, remove the
cover and set the switches S1-6 according to
the instruction at page 4.
Connect line outputs
UniVox
®
PLS-100 has 2 line outputs; I. = LINE OUT 0dBm without the input AGC activated (linear), and J. SLS 0dBm with
® PLS-100 has 2 line outputs; I. = LINE OUT 0dBm without the input AGC activated (linear), and J. SLS 0dBm with ®
the AGC-function activated.
Connect mains power
Connect mains power to the inlet E. The LED D. on the front panel starts lighting. UniVox
®
PLS-100 has an automatic
resetable built-in mains fuse. If it’s triggered by any reason, please remove the mains power and let the amplifi er cool off.
Investigate the possible fault reason before reconnecting the mains power.
3. Function check (basic start up check)
Adjust the input levels one by one letting the LED A. on the front panel light up distinctivly at the peaks of the program signal
source (AGC knee).
Increase the Loop Current trimmer G. until the LED B. on the front panel lights up. Use the loop monitor output C. for direct
listening to the output current (magnetic fi eld). If necessary, adjust TREBLE with the potentiometer H.
4. Certifi cation
Very important!
Adjust the amplifi er following ”The UniVox Way” for certifi cation according to IEC-60118-4:2006 using a fi eld strength meter,
like the UniVox
®
FSM. If you don’t have access to the instrument, hire the service! Certifi cate and measuring guide are
included with each amplifi er.
5. Information
Inform people responsible for the loop system how to use the system. Recommend a listening device for a daily basic check
of the loop system. The UniVox
®
Listener is a high quality listening device with built-in level check.
® Listener is a high quality listening device with built-in level check. ®
Page 3
Page 2
E. Mains
connector
F. Loop wire
connector
H. Treble
G. Loop
current
J. SLS
L. IN 2
K. IN 3
M. IN 1
UniVox
®
FSM
® FSM ®
Field Strength Meter
UniVox
®
Listener
® Listener ®
Loop receiver/testing device
I. Line out
Loop area m² Wire area, 1-turn-loop Wire area, 2-turn-loop
75-170 3.0mm² Not recommended
50-75 1.5mm² 2x1.5mm²
35-50 1.0mm² 2x1.0mm²
<35 0.75mm² 2x0.75mm²
Loop area m² Wire area, 1-turn-loop Wire area, 2-turn-loop
75-170 3.0mm² Not recommended
50-75 1.5mm² 2x1.5mm²
35-50 1.0mm² 2x1.0mm²
<35 0.75mm² 2x0.75mm²
Loop area m² Wire area, 1-turn-loop Wire area, 2-turn-loop
75-170 3.0mm² Not recommended
50-75 1.5mm² 2x1.5mm²
35-50 1.0mm² 2x1.0mm²
<35 0.75mm² 2x0.75mm²
Recommended minimum loop wire area for UniVox
®
PLS-100,
® PLS-100, ®
when installed to an existing loop system
Distributor
:
A. Input
check
B. Loop
check
D. Mains power check
C. Loop monitor,
6.35mm jack and
volume adjust.
Sensitivity Impedance
IN1 / Mic 0.5mV-180mV 10kOhm Default setting
IN1 / Line 50mV-10V 10kOhm
IN2 / Mic 0.5mV-180mV 10kOhm
IN2 / Line 50mV-10V 10kOhm Default setting
IN3 50mV-10V 10kOhm
IN1 / Mic 0.5mV-180mV 10kOhm Default setting
IN1 / Line 50mV-10V 10kOhm
IN2 / Mic 0.5mV-180mV 10kOhm
IN2 / Line 50mV-10V 10kOhm Default setting
IN3 50mV-10V 10kOhm
Sensitivity Impedance
IN1 / Mic 0.5mV-180mV 10kOhm Default setting
IN1 / Line 50mV-10V 10kOhm
IN2 / Mic 0.5mV-180mV 10kOhm
IN2 / Line 50mV-10V 10kOhm Default setting
IN3 50mV-10V 10kOhm
Sensitivity Impedance
IN1 / Mic 0.5mV-180mV 10kOhm Default setting
IN2 / Line 50mV-10V 10kOhm Default setting
