Unleashed Wireless Leash Guidance Trainer Series User manual

for Your Wireless Leash®
Guidance Trainer Series
Operator’s Manual

2
Congratulations!
The Unleashed Technology Wireless Leash®Guidance Trainer Series you have
purchased is a step forward in technology and training methodology. If you have
or have not used a remote trainer in the past, please read this manual and the Training
Guide provided. This will help ensure you receive all the wonderful training ben-
efits of this state of the art training device.
Regardless of the GT Series model you have purchased, it comes complete with
the very latest dog training methodology. Adjustable vibration is a unique
method of communicating with your dog and is capable of teaching all the
customary commands. Unleashed Technology products also include a special auto-
matic on-off quick reminder prior to continuous vibration or stimulation (patent
pending).
Please do not hesitate to use our professional staff if you have any training or
product questions. Our goal is for you to have a super relationship with your dog
based on mutual respect. Let us help by calling toll free 1.866.795.7387 or e-mail
[e-mail].

3
Table of Contents
Introduction – for you and your dog
Product Diagram - Transmitter & Receiver
Transmitter Operating Characteristics
1. Unleashed Technology Transmitter
2. Transmitter Operating Mode
Receiver Operating Characteristics
1. Unleashed Technology Receiver
2. LED Indicator
Charging System
Transmitter and Receiver Programming and Multi-dog Functions
FCC Compliance
Warranty
Customer Service Information

Introduction – for you and your dog
Unleashed Technology products are a totally new and unique training system
specifically designed for you and your dog. Even if you are an experienced
trainer and used other products in the past, we strongly recommend reviewing the
Unleashed Training Guide provided. Rather than explaining all the technical
details of the Unleashed Technology exclusive adjustable vibration and our
exclusive quick on-off reminder system, there is an easier way. You can simply
experience the same sensations used for training your dog. Please see “Feel the
Kind Vibration & Stimulation” in the GTSeries Training Guide. Your firsthand
knowledge is not only fair to your dog, but you will also learn how our unique
training method makes quick training solutions happen.
(Unleashed Technology equipment was designed for use during the training of healthy dogs. Please check
with your veterinarian to ensure that your dog is ready for traditional on-leash obedience training sessions
or any off-leash exercises.)
4

Product Diagram -
Transmitter Antenna
0-15 Level Select Switch
Level Select Indicator
Single Dog Red LED 2nd Dog
Green LED
Battery
Door Cover
Charging Jack &
Dust Cover (Charging
Jack under Dust Cover)
5
Front View Back View
Dog Select/Program Button
Top Activator Button (light blue)
Quick Vibration & Controlled Vibration
2nd Activator Button (medium blue)
Quick Vibration & Controlled
E-stimulation
3rd Activator Button (dark blue)
Quick E-stimulation & Controlled
E-stimulation
Lanyard Attachment

Product Diagram - Receiver
Charging Jack & Dust Cover
(Charging Jack under Dust Cover) Contact Electrodes
Operational Red LED
On/Off Switch
Collar Strap Retainers
6

7
Transmitter Operating Characteristics
Each Unleashed Technology Transmitter:
lCommunicates with the Receiver at distances from two feet to ½ mile.
lIs waterproof and operates in both high and low temperature extremes.
lProvides user rechargeable and replaceable NiMH battery pack.
lMonitors battery life - to check for low battery, press and release any activator
button, the LED will double flash for 30 seconds when the battery needs
recharging.
lLED Indicators - two different colors are used to indicate which Receiver is
currently selected. The red LED is factory set for single dog training. In the
event an Add-a-2nd Dog unit is purchased, the Green LED can be programmed
to activate the second Receiver.
lStops charging automatically after 12 hours.
lOffers 65,000 unique ID codes, therein reducing communication interference
between individual remote trainers.

8
Transmitter Operating Mode:
lProvides 15 individual user adjustable/selectable levels.
lHas from 1 to 3 activator buttons depending on the GTSeries Model
purchased. Buttons control different combinations of vibration stimulation, elec-
trical stimulation, or a combination of both.
lEach activator button provides a preset “quick” on/off stimulation with a brief
pause followed by controlled stimulation for up to 12 seconds by continuing to
press the button.
lProvides a safety “0” level setting where no stimulation can be transmitted. At
this setting, the user can press any button to confirm that the Transmitter and
Receiver are communicating with each other.
lProvides a multi-function Dog Select/Program Button allowing the
Transmitter to program itself as a single or 2nd dog unit. It is also used to pro-
gram the Receiver(s) to the appropriate Transmitter LED. Lastly, the Dog
Select/Program button is used to toggle between single and 2nd dog Receivers
(see page 11).

9
Receiver Operating Characteristics
Each Unleashed Technology Receiver:
lTurned on and off by pressure switch timed to protect the dog – hold down
for a minimum of one second to turn-on and a minimum of three seconds to
turn-off.
lIs waterproof and operates in both high and low temperature extremes.
lProvides user rechargeable and replaceable NiMH battery pack.
lOperates for a minimum of 24 hours on a full charge under normal use.
lConstantly monitors battery – LED light double flashes when recharging is
needed.
lStops charging automatically after 12 hours.
lWill only respond to the unique ID of its programmed
Transmitter.
lProtects dog – stimulation stops after 12 seconds of
continuous activation and then a safety cut off
engages for 30 seconds.
lEmploys two stainless steel electrodes to ensure consistency.
Receiver

10
Receiver LED Indicator:
lOn steady when receiving commands from the Transmitter, during the program
mode, and during the 12-hour charging cycle.
lFlashes once every second after the 12-hour charging cycle is complete.
lFlickers for 30 seconds when the safety override has been activated.
lFlashes once every three seconds when the battery is fully charged.
lDouble flashes every two seconds when the battery is low (for up to 3-hours).
Charging System
lAspecifically designed wall transformer with suitable connectors is used for
recharging and is rated to charge only an Unleashed Technology Transmitter and
two Receivers at the same time.
lSplitter cables are used when charging a Transmitter and Receiver(s).
lBoth the Transmitter and Receiver(s) will monitor the charging time and disable
charging after 12 hours.
lNo communication from either the Transmitter or the Receiver(s) is allowed
when the charger is present. Also, by default but as a safety precaution, no stim-
ulation is allowed by the Receiver.
lCircuit protector is provided in either the Transmitter or the Receiver(s) and
automatically shuts off power when its battery is below a specified voltage.

11
Transmitter and Receiver Programming and Multi-dog Functions
Transmitter Programming
lThe Transmitter has two LED’s used to indicate the selected dog. The single-dog
Red LED is on the left when holding the unit with the LED’s facing the opera-
tor, and the two-dog Green LED is on the right. (The functionality of each LED
is exactly the same.)
lThe Transmitter is factory set in the single dog mode. To verify, set the Level
Select Switch to the “0” position and press and release the Dog Select Button
multiple times (the Red LED will blink once for each press and release.)
lTo program the Transmitter to operate in the 2nd dog mode. First, set the Level
Select Switch to 2. Then, press and hold down the Dog Select Button continu-
ously for 5 seconds (the LED will blink once at the start of the 5 seconds and
once when it is complete.)
lIf desired to reprogram back to a single-dog mode, set the Level Select Switch
to 1. Then, press and hold the Dog Select Button continuously for 5 seconds (The
LED will blink once at the start of the 5 seconds and once when it is complete).

12
Receiver Programming
Set the Transmitter Level Select Switch to either position 1 or 2.
lWith the Receiver in the off position, press and hold the on/off button continu-
ously for 5 seconds, the LED stays on, even after the button is released and waits
to receive an ID for up to 12 seconds.
lDuring this 12 second programming mode, press and release the Transmitter’s
Dog Select Button once. (This sends the Transmitter’s unique ID to the Receiver.)
lWhen the LED light on the Receiver turns off, the new ID has been received.
(You can verify by pressing any of the Vibration Stimulation or Electrical
Stimulation Activator Buttons.)
lIf the Receiver does not receive the new ID, it will automatically exit the pro-
gramming mode and retain its previous ID.
Multi-Dog Functions
lTo select between single dog and 2nd dog, the Transmitter’s Level Select Switch
must be in the “0” position. Each press and release of the Dog Select Button
toggles back and forth between the single dog (Red LED) and the 2nd dog
(Green LED).
lThe Transmitter will remember the last dog selected.

13
FCC Compliance
Unleashed Technology Transmitters comply with Part 15 of the FCC rules.
Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
An FCC license is not needed to operate Unleashed Technology Transmitters.
However, any change or modification made to the Transmitter, including the sup-
plied antenna, without the expressed written approval of Unleashed Technology,
could void your authority to operate.
Warranty
To validate the warranty, register your new GT Series model at
www.unleashedtechnology.com. Click on warranty registration and follow the links.
Please give us your recommendations on how we can enhance our product to serve
you better or help in the training of your dog.

14
Unleashed Technology’s warranty is simple and based on our respect for you and
your personal integrity with us. These are the essentials of the agreement:
a. We provide a 30 day money back guarantee – just return the product with your
purchase receipt to the retail dealer for a full refund less any shipping costs.
b. Unleashed Technology warrants to the original owner our products are free from
defects in material and workmanship, under normal use, for a period of one year
from date of retail purchase. Unless there is neglect, alteration or misuse of the
product, there will be no charge for labor and parts during this one-year period.
c. We will continue to service your product with no labor charges for a second year
from date of retail purchase. There will be a charge for replacement parts.
d. Unleashed Technology shall not be liable or responsible for any incidental or
consequential damages resulting from the misuse of the product which would
cause any defect, failure or malfunction, whether a claim is based upon warran-
ty, contract, negligence or otherwise.

15
Customer Service
Should there be any questions regarding Unleashed Technology products, our
friendly and experienced staff would be happy to assist you. Please call the toll
free number at 1.866.795.7387, between 8 a.m. – 4:30 p.m. CST or visit our
website at www.unleashedtechnology.com.
Unleashed TechnologyTM GT Series products are covered by U.S. Design Patent
D541253 and patent pending.

Published by Unleashed Technology Minneapolis, Minnesota
© 2007 Unleashed Technology, Inc. All rights reserved. Printed in the USA
Unleashed Technology™, the Unleashed Technology™logo, and Wireless Leash® are trademarks of Unleashed Technology.
OM-1008
7301 32nd Avenue North •Minneapolis, MN 55427
Toll Free: 1.866.795.7387 •Fax: [phone]
www.unleashedtechnology.com •email: [e-mail]
