UpDown Desk ECS+ User manual

Handset Control Unit
NOTICE You must read the user manual carefully before installing or operating the control unit. If
chosen handset doesn't match this user manual, please see separate user manual for actual handset.
Over load protection!
If the total load on the equipment is too high, you will only be able to adjust for 2 seconds. The system
will then stop and you need to release the table from load before new adjustment is attempted. After
load release, press button again.
Over heat protection!
If heavy loaded is driven continuously for a long period of time the motor might get overheated. The
software observes this and, if overheated, the system will shut down and you will have to wait about 9
minutes before being able to run again.
Anti Collision "AC" (optional)!
The ECS+ can be equipped with intelligent software for pinch protection. If a collision is detected system
will stop and back off about 1 inch.
IMPORTANT! Make sure to remove the blocking item causing the pinch before trying to operate the
table again.
Failure to do so may cause injury to user or equipment.
During low ration the currents to each connected motor is continuously measured and any variation of
current is evaluated about 50 times each second.
Upward desktop movement
This function enables you to adjust the desktop upwards.
To change its position, proceed as follows: Press the handset "up" button. Keep
pressing the button until the required desktop height is reached.
NOTICE - The desktop will continue moving upwards until you release the button or
the maximum height is reached.
Downward desktop movement
This function enables you to adjust the desktop downwards. To change its position,
proceed as follows: Press the handset "down" button. Keep pressing the button
until the required desktop height is reached.
NOTICE - The desktop will continue moving downwards until you release the
button or the minimum height is reached.

Programmable Positioning Control
ECS+ has programmable personal standing height positioning control and a low limit control used to
avoid collision with obstacles placed under the work surface such as cabinets and pedestals (allow 3.75”
below the underside of the desk top for the frame assembly)
Setting the memory: Adjust your table to the first position of your choice. Press both buttons 3 times
(0.5-1 seconds between each press) Do the same procedure for your second choice. The table will do a
gentle rise to confirm the setting. To erase the setting, follow manual reset in section 3.2.
To bypass this position and go 'outside' the setting you just hold the button for 5 seconds and the desk
moves again.
AutoDrive (optional)
A quick double press will drive the table automatically to the end position or to the programmed
position.
Advanced functions. Manuel Reset
In case of exchanged parts (i.e. motor, electronics) there could be a need of a manual reset so columns
and handsets correspond to each other. Even poor connection of the cables could create a need of
resetting.
