INSTALLATION INSTRUCTIONS
LENOX CABINET LARGE — INSTALLING CABINET FRAME 1 OF 2
WWW.URBANARCHAEOLOGY.COM
Lenox Cabinet Large — Installing Cabinet Frame
REV 4.21.11
Lenox Medicine Cabinet
Installing Cabinet Frame
(This step requires 2 people)
1. Insert Lenox frame into Marble Box.
2. Check alignment of cabinet frame. Ensure door opens & closes and ball-catch actuates. Ball-catch
tension will be adjusted later. If necessary, shim the frame inside using metal washer between the frame
& Marble Box.
3. Mark location of mounting holes on shelf brackets onto inside of Marble Box.
Washer leveling frame.
Inside rear view of frame.
Rear cutaway view.

INSTALLATION INSTRUCTIONS
LENOX CABINET LARGE — INSTALLING CABINET FRAME 2 OF 2
WWW.URBANARCHAEOLOGY.COM
4. Remove Lenox frame with attached shelf bracket. Drill 4 holes through sides of Marble Box into studs. Be
sure Step 2 has been completed before drilling holes.
5. Insert Lenox frame and fasten shelf brackets to Marble Box. Check operation of door and ball-catch.
6. Adjust ball-catch pressure if necessary.
Hole drilled through side of
Marble Box through stud.
4 holes total.
