UROVO i6200s User manual

i6200s Quick Guide
Important notice on lithium ion battery
1)Charge the battery only with original Urovo power adaptor supplied
in the box
2)Do not store the device with battery installed for long period of time
3)If long period storage is required, remove battery from device.
4) During long storage period, maintenance work is required at every
3 months period. During maintenance, discharge the battery
completely, and then charge to 60% - 70% (or 3.8V - 3.9V).
5) Store battery in dry, cool environment. Temperature should be -
20 to 40 degree Celsius and relative humidity should be 45% to 85%
6) Charge battery at 5 to 45 degree Celsius
7) Do not operate the device outside the recommended temperature,
which is from -20 to 60.
8) Do not install a third party battery into Urovo device
1）Do not transport the battery at temperature higher than 65 degree
Celsius
2）Do expose battery to fire or heat source
3）Do not forcefully install the battery in opposite direction into the
device
4）Avoid impact and high vibration force on the battery
5）Keep battery dry at all time
6）Do not use battery that is damaged or appear to have been
modified
7）Do not use unauthorized power adaptor to charge the battery
8）Do not discharge the battery beyond the specification of the
battery
9）Do not place battery into microwave oven or pressured container
10）Do not damage battery with sharp objects
11）Do not operate in environment with extreme electrostatic fields
or magnetic fields.
12）If leakage found in battery, avoid contact with body parts.
Should leakage be in contact with body parts, flush with water and
immediately seek medical attention
13）If battery exhibits unusual behavior like color change,
temperature became hot, shape is swollen, remove battery from
device and stop using that battery
14）If the contact point on the battery is dirty, clean with a dry cloth
15）Dispose the battery according local regulation. Recycle if
possible.
16）Improper usage or storage may cause battery performance to
drop, leak, damage, or even escalate to personal safety issue.
Safety precaution
Rear view
Appearance and Buttons
Side view
Front view
To turn on: Hold power button until device switches on
To turn off: Hold power button until the device screen shows the
power off menu. Select shutdown on the menu.
Sleep: Under operation mode, press the power button once
Wake up: Press power button once
Scan button
User define button
LED indicator
Touch screen
Main key pad
Scan engine
window
POGO pin connector
for cradle charging
Power button
Volume control
Reset button
Audio jack
USB connector
Scan button
Camera and LED flash
Speaker
SIM Slot
Battery lock
Micro SD card slot
Contactless reader
PSAM Slot
1 2 34

i6200s Quick Guide
Important notice on lithium ion battery
1)Charge the battery only with original Urovo power adaptor supplied
in the box
2)Do not store the device with battery installed for long period of time
3)If long period storage is required, remove battery from device.
4) During long storage period, maintenance work is required at every
3 months period. During maintenance, discharge the battery
completely, and then charge to 60% - 70% (or 3.8V - 3.9V).
5) Store battery in dry, cool environment. Temperature should be -
20 to 40 degree Celsius and relative humidity should be 45% to 85%
6) Charge battery at 5 to 45 degree Celsius
7) Do not operate the device outside the recommended temperature,
which is from -20 to 60.
8) Do not install a third party battery into Urovo device
1）Do not transport the battery at temperature higher than 65 degree
Celsius
2）Do expose battery to fire or heat source
3）Do not forcefully install the battery in opposite direction into the
device
4）Avoid impact and high vibration force on the battery
5）Keep battery dry at all time
6）Do not use battery that is damaged or appear to have been
modified
7）Do not use unauthorized power adaptor to charge the battery
8）Do not discharge the battery beyond the specification of the
battery
9）Do not place battery into microwave oven or pressured container
10）Do not damage battery with sharp objects
11）Do not operate in environment with extreme electrostatic fields
or magnetic fields.
12）If leakage found in battery, avoid contact with body parts.
Should leakage be in contact with body parts, flush with water and
immediately seek medical attention
13）If battery exhibits unusual behavior like color change,
temperature became hot, shape is swollen, remove battery from
device and stop using that battery
14）If the contact point on the battery is dirty, clean with a dry cloth
15）Dispose the battery according local regulation. Recycle if
possible.
16）Improper usage or storage may cause battery performance to
drop, leak, damage, or even escalate to personal safety issue.
Safety precaution
Rear view
Appearance and Buttons
Side view
Front view
To turn on: Hold power button until device switches on
To turn off: Hold power button until the device screen shows the
power off menu. Select shutdown on the menu.
Sleep: Under operation mode, press the power button once
Wake up: Press power button once
Scan button
User define button
LED indicator
Touch screen
Main key pad
Scan engine
window
POGO pin connector
for cradle charging
Power button
Volume control
Reset button
Audio jack
USB connector
Scan button
Camera and LED flash
Speaker
SIM Slot
Battery lock
Micro SD card slot
Contactless reader
PSAM Slot
1 2 34

i6200s Quick Guide
Important notice on lithium ion battery
1)Charge the battery only with original Urovo power adaptor supplied
in the box
2)Do not store the device with battery installed for long period of time
3)If long period storage is required, remove battery from device.
4) During long storage period, maintenance work is required at every
3 months period. During maintenance, discharge the battery
completely, and then charge to 60% - 70% (or 3.8V - 3.9V).
5) Store battery in dry, cool environment. Temperature should be -
20 to 40 degree Celsius and relative humidity should be 45% to 85%
6) Charge battery at 5 to 45 degree Celsius
7) Do not operate the device outside the recommended temperature,
which is from -20 to 60.
8) Do not install a third party battery into Urovo device
1）Do not transport the battery at temperature higher than 65 degree
Celsius
2）Do expose battery to fire or heat source
3）Do not forcefully install the battery in opposite direction into the
device
4）Avoid impact and high vibration force on the battery
5）Keep battery dry at all time
6）Do not use battery that is damaged or appear to have been
modified
7）Do not use unauthorized power adaptor to charge the battery
8）Do not discharge the battery beyond the specification of the
battery
9）Do not place battery into microwave oven or pressured container
10）Do not damage battery with sharp objects
11）Do not operate in environment with extreme electrostatic fields
or magnetic fields.
12）If leakage found in battery, avoid contact with body parts.
Should leakage be in contact with body parts, flush with water and
immediately seek medical attention
13）If battery exhibits unusual behavior like color change,
temperature became hot, shape is swollen, remove battery from
device and stop using that battery
14）If the contact point on the battery is dirty, clean with a dry cloth
15）Dispose the battery according local regulation. Recycle if
possible.
16）Improper usage or storage may cause battery performance to
drop, leak, damage, or even escalate to personal safety issue.
Safety precaution
Rear view
Appearance and Buttons
Side view
Front view
To turn on: Hold power button until device switches on
To turn off: Hold power button until the device screen shows the
power off menu. Select shutdown on the menu.
Sleep: Under operation mode, press the power button once
Wake up: Press power button once
Scan button
User define button
LED indicator
Touch screen
Main key pad
Scan engine
window
POGO pin connector
for cradle charging
Power button
Volume control
Reset button
Audio jack
USB connector
Scan button
Camera and LED flash
Speaker
SIM Slot
Battery lock
Micro SD card slot
Contactless reader
PSAM Slot
1 2 34

i6200s Quick Guide
Important notice on lithium ion battery
1)Charge the battery only with original Urovo power adaptor supplied
in the box
2)Do not store the device with battery installed for long period of time
3)If long period storage is required, remove battery from device.
4) During long storage period, maintenance work is required at every
3 months period. During maintenance, discharge the battery
completely, and then charge to 60% - 70% (or 3.8V - 3.9V).
5) Store battery in dry, cool environment. Temperature should be -
20 to 40 degree Celsius and relative humidity should be 45% to 85%
6) Charge battery at 5 to 45 degree Celsius
7) Do not operate the device outside the recommended temperature,
which is from -20 to 60.
8) Do not install a third party battery into Urovo device
1）Do not transport the battery at temperature higher than 65 degree
Celsius
2）Do expose battery to fire or heat source
3）Do not forcefully install the battery in opposite direction into the
device
4）Avoid impact and high vibration force on the battery
5）Keep battery dry at all time
6）Do not use battery that is damaged or appear to have been
modified
7）Do not use unauthorized power adaptor to charge the battery
8）Do not discharge the battery beyond the specification of the
battery
9）Do not place battery into microwave oven or pressured container
10）Do not damage battery with sharp objects
11）Do not operate in environment with extreme electrostatic fields
or magnetic fields.
12）If leakage found in battery, avoid contact with body parts.
Should leakage be in contact with body parts, flush with water and
immediately seek medical attention
13）If battery exhibits unusual behavior like color change,
temperature became hot, shape is swollen, remove battery from
device and stop using that battery
14）If the contact point on the battery is dirty, clean with a dry cloth
15）Dispose the battery according local regulation. Recycle if
possible.
16）Improper usage or storage may cause battery performance to
drop, leak, damage, or even escalate to personal safety issue.
Safety precaution
Rear view
Appearance and Buttons
Side view
Front view
To turn on: Hold power button until device switches on
To turn off: Hold power button until the device screen shows the
power off menu. Select shutdown on the menu.
Sleep: Under operation mode, press the power button once
Wake up: Press power button once
Scan button
User define button
LED indicator
Touch screen
Main key pad
Scan engine
window
POGO pin connector
for cradle charging
Power button
Volume control
Reset button
Audio jack
USB connector
Scan button
Camera and LED flash
Speaker
SIM Slot
Battery lock
Micro SD card slot
Contactless reader
PSAM Slot
1 2 34

Battery Installation
The device battery is polymer type battery, which should only be
charged by using original Urovo power supply.
Metal contact is unavailable or artificial short circuit electrode.
Do not store battery in hot, humid, or corrosive environment.
Do no break or crack battery.
Do not store battery when it is fully charged completely drained.
If device is not used for long period of time, remove the battery from
the device, pelase.
If the battery is misshapen or is found leaking, replace the battery
immediately.
Note: The battery should be charged for at least 8 hours before the
first use.
Battery Operation
5 6 8
After the device connected to your PC, you could drag the
top part of the screen downto show the USB options.
Note: When you enable device as USB Storage to PC, the flash
memory of the device are map as a PC drive. At this point of time,
you cannot install APK to the device.
To install APK to the device, it should not be in USB Storage mode.
Check this to enable USB debugging.
Charging using power adaptor
Device Slot
Battery Slot
C Indication light
P Indication light
1.Swing open the main battery
cover clip by 90 degrees, you can
then remove the battery cover.
2.Insert the SIM card or Micro
SD/TF card into their
corresponding slots in the battery
compartment.
Note: You should gently push the
SIM/TF card to the correct position
without using excessive force.
Connect the USB cable into the device and the power adaptor. Red
LED indicates charging and Green LED indicates fully charge.
Power Adaptor
USB Data Cable
Charging using cradle
Connect the power cable into the cradle.
P: LED indicates the cradle is operational.
Slot the device into the cradle and take note of the LED change on
the device which indicate the charging process
Slot the battery into the cradle as shown in the picture.
C: LED should lit up to indicate charging.
Installing SIM/ TF Card
Insert the battery into the battery compartment as shown in the
picture. Battery should sit tightly in the compartment when correctly
installed. Do not apply excessive force when inserting the battery.
Power Adaptor
After you install the Android driver or an Android smart phone
assistant, you can connect the devices to your PC with USB cable
provided. (You can download the software mentioned above from
www.urovo.com/en. After device connected to your PC, the screen
would display like this:
7
Connecting to PC
Check this to enable device as USB storage to PC.
Select this option to enable / disable device as USB
storage to the PC.
Select this option to enable / disable USB debugging

Battery Installation
The device battery is polymer type battery, which should only be
charged by using original Urovo power supply.
Metal contact is unavailable or artificial short circuit electrode.
Do not store battery in hot, humid, or corrosive environment.
Do no break or crack battery.
Do not store battery when it is fully charged completely drained.
If device is not used for long period of time, remove the battery from
the device, pelase.
If the battery is misshapen or is found leaking, replace the battery
immediately.
Note: The battery should be charged for at least 8 hours before the
first use.
Battery Operation
5 6 8
After the device connected to your PC, you could drag the
top part of the screen downto show the USB options.
Note: When you enable device as USB Storage to PC, the flash
memory of the device are map as a PC drive. At this point of time,
you cannot install APK to the device.
To install APK to the device, it should not be in USB Storage mode.
Check this to enable USB debugging.
Charging using power adaptor
Device Slot
Battery Slot
C Indication light
P Indication light
1.Swing open the main battery
cover clip by 90 degrees, you can
then remove the battery cover.
2.Insert the SIM card or Micro
SD/TF card into their
corresponding slots in the battery
compartment.
Note: You should gently push the
SIM/TF card to the correct position
without using excessive force.
Connect the USB cable into the device and the power adaptor. Red
LED indicates charging and Green LED indicates fully charge.
Power Adaptor
USB Data Cable
Charging using cradle
Connect the power cable into the cradle.
P: LED indicates the cradle is operational.
Slot the device into the cradle and take note of the LED change on
the device which indicate the charging process
Slot the battery into the cradle as shown in the picture.
C: LED should lit up to indicate charging.
Installing SIM/ TF Card
Insert the battery into the battery compartment as shown in the
picture. Battery should sit tightly in the compartment when correctly
installed. Do not apply excessive force when inserting the battery.
Power Adaptor
After you install the Android driver or an Android smart phone
assistant, you can connect the devices to your PC with USB cable
provided. (You can download the software mentioned above from
www.urovo.com/en. After device connected to your PC, the screen
would display like this:
7
Connecting to PC
Check this to enable device as USB storage to PC.
Select this option to enable / disable device as USB
storage to the PC.
Select this option to enable / disable USB debugging

Battery Installation
The device battery is polymer type battery, which should only be
charged by using original Urovo power supply.
Metal contact is unavailable or artificial short circuit electrode.
Do not store battery in hot, humid, or corrosive environment.
Do no break or crack battery.
Do not store battery when it is fully charged completely drained.
If device is not used for long period of time, remove the battery from
the device, pelase.
If the battery is misshapen or is found leaking, replace the battery
immediately.
Note: The battery should be charged for at least 8 hours before the
first use.
Battery Operation
5 6 8
After the device connected to your PC, you could drag the
top part of the screen downto show the USB options.
Note: When you enable device as USB Storage to PC, the flash
memory of the device are map as a PC drive. At this point of time,
you cannot install APK to the device.
To install APK to the device, it should not be in USB Storage mode.
Check this to enable USB debugging.
Charging using power adaptor
Device Slot
Battery Slot
C Indication light
P Indication light
1.Swing open the main battery
cover clip by 90 degrees, you can
then remove the battery cover.
2.Insert the SIM card or Micro
SD/TF card into their
corresponding slots in the battery
compartment.
Note: You should gently push the
SIM/TF card to the correct position
without using excessive force.
Connect the USB cable into the device and the power adaptor. Red
LED indicates charging and Green LED indicates fully charge.
Power Adaptor
USB Data Cable
Charging using cradle
Connect the power cable into the cradle.
P: LED indicates the cradle is operational.
Slot the device into the cradle and take note of the LED change on
the device which indicate the charging process
Slot the battery into the cradle as shown in the picture.
C: LED should lit up to indicate charging.
Installing SIM/ TF Card
Insert the battery into the battery compartment as shown in the
picture. Battery should sit tightly in the compartment when correctly
installed. Do not apply excessive force when inserting the battery.
Power Adaptor
After you install the Android driver or an Android smart phone
assistant, you can connect the devices to your PC with USB cable
provided. (You can download the software mentioned above from
www.urovo.com/en. After device connected to your PC, the screen
would display like this:
7
Connecting to PC
Check this to enable device as USB storage to PC.
Select this option to enable / disable device as USB
storage to the PC.
Select this option to enable / disable USB debugging

Battery Installation
The device battery is polymer type battery, which should only be
charged by using original Urovo power supply.
Metal contact is unavailable or artificial short circuit electrode.
Do not store battery in hot, humid, or corrosive environment.
Do no break or crack battery.
Do not store battery when it is fully charged completely drained.
If device is not used for long period of time, remove the battery from
the device, pelase.
If the battery is misshapen or is found leaking, replace the battery
immediately.
Note: The battery should be charged for at least 8 hours before the
first use.
Battery Operation
5 6 8
After the device connected to your PC, you could drag the
top part of the screen downto show the USB options.
Note: When you enable device as USB Storage to PC, the flash
memory of the device are map as a PC drive. At this point of time,
you cannot install APK to the device.
To install APK to the device, it should not be in USB Storage mode.
Check this to enable USB debugging.
Charging using power adaptor
Device Slot
Battery Slot
C Indication light
P Indication light
1.Swing open the main battery
cover clip by 90 degrees, you can
then remove the battery cover.
2.Insert the SIM card or Micro
SD/TF card into their
corresponding slots in the battery
compartment.
Note: You should gently push the
SIM/TF card to the correct position
without using excessive force.
Connect the USB cable into the device and the power adaptor. Red
LED indicates charging and Green LED indicates fully charge.
Power Adaptor
USB Data Cable
Charging using cradle
Connect the power cable into the cradle.
P: LED indicates the cradle is operational.
Slot the device into the cradle and take note of the LED change on
the device which indicate the charging process
Slot the battery into the cradle as shown in the picture.
C: LED should lit up to indicate charging.
Installing SIM/ TF Card
Insert the battery into the battery compartment as shown in the
picture. Battery should sit tightly in the compartment when correctly
installed. Do not apply excessive force when inserting the battery.
Power Adaptor
After you install the Android driver or an Android smart phone
assistant, you can connect the devices to your PC with USB cable
provided. (You can download the software mentioned above from
www.urovo.com/en. After device connected to your PC, the screen
would display like this:
7
Connecting to PC
Check this to enable device as USB storage to PC.
Select this option to enable / disable device as USB
storage to the PC.
Select this option to enable / disable USB debugging
