URYU G Series User manual

S0140153-E
表紙
SPINDLE UNIT
INSTRUCTION MANUAL
VERSION 1.0 JULY 2020
URYUSEISAKU, LTD.

About this book
This book will explain installation, wiring, handling, and troubleshooting of G-type nutrunner
system. G-System will be used as the collective term covering all materials and software-
related configuration. Hereafter this book will use the underlined names G-Unit, G-Tool
(motor), Cables, and G-Console as individual terms. Utilize G-System’s rich functions to the
full reading through everything in this book before use. Save this book at the place where
you can read any time.
◆ Arrange for this book to be kept and read by end-users.
◆ Contents of this book, specifications and appearance of G-System are subject to change
without prior notice.
◆ No part of this book may be reproduced or transmitted in any form or by any means
without our permission in writing.
◆ We have taken all possible means to ensure contents of this book, however, should you
find any questions, errors or omissions in this book, please contact us immediately.
◆ Understand all the contents reading through [Safety Instructions] and use G-System
correctly following all safety instructions.
◆ After reading, save this book at hand always.
◆ Only expert engineers carry out wiring and parameter setting.
◆ Always make an indication highlighting “Danger High Voltage” in instruction manuals for
machines having G-System within.
◆ Never carry out withstand voltage test and insulation test for G-System and the products.
◆ Does the product agree to types ordered?
◆ Examine the products against invoice and packing list to see any short shipment.
◆ Check the products for any damages caused during transportation.
◆ Anybus is registered trademark or brand of HMS Industrial Networks AB.
◆ CC-Link is registered trademark or brand of CC-Link (CC-Link Partner Association: CLPA).
◆ CompactFlash and CF are trademark or brand of SanDisk in the U.S.
◆ DeviceNet and Ethernet/IP are registered trademark or brand of ODVA (Open DeviceNet
Vendor association).
◆ Ethernet and “イーサーネット” are registered trademark of FUJI XEROX.
◆ MELSEC-Q and GX-Developer are registered trademark or brand of MITSUBISHI
ELECTRIC.
◆ Microsoft Excel and Windows are registered trademark or brand of Microsoft Corporation
in the U.S. and other countries.
◆PROFIBUS-DP and PROFINET IO are registered trademark or brand of Profibus
Association. We fully respect registered trademark and brand of the respective
companies even if there is no annotation. Other product names and company names
are their registered trademark or brand.
Request for compliance
Check point when unpacking
Precautions
Trademarks

Safety instructions
(Never fail to read)
Safety instructions show rules which we request users to observe for safety use of G-System
and prevention of damages for properties and harms for users and non-user. Use G-System
only after mastering the knowledge, safety information and safety instructions.
◆ This book has divided safety instructions into DANGER and CAUTION depending upon
harm and damage due to bad use ignoring displayed contents.
A dangerous situation can happen and a fatality or
severe injury is possible in the event of mishandling.
A dangerous situation can happen when mishandling, and
personal injury or only physical damage is supposed.
sign also warns the risk of serious consequences depending upon the
situation. Follow all the instructions as they state important contents.
◆ We will explain the instructions by pictorial signs.
FIRE
DANGER
険
SHOCK
CAUTION
EARTH
GROUNDING
DON’TS
HEAT
CAUTION
NO
DISASSEMBLE
OBLIGATORY
SHOCK
DANGER
FIRE
CAUTION
PINCH
DANGER
CAUTION
DANGER
CAUTION

Safety instructions
(Never fail to read)
S
Don’t touch tools in operation.
Make sure that even a part of the body and G-Tool’s movable part do not cross.
There is a risk of injury.
Do not detach motor and gear case from G-Tool.
G-Tool’s output shaft rotates and is dangerous to touch. There is a risk of injury.
Never repair, disassemble and modify G-Unit, G-Tools, and Cables.
There is a risk of injury, shock, fire and breakdown.
Avoid place where tools can be damaged by water. Don’t use G-tools nearby corrosive gas
or combustible gas atmosphere. There is a risk of fire.
Do not touch connectors while applying current and also for a while after power-off.
There is a risk of shock and injury.
Only expert engineers conduct wiring, maintenance and inspection with power supply turned
off. There is a risk of shock and injury.
Don’t give scratch, apply unreasonable force and pinch the Cables. Don’t use damaged
Cables. There is a risk of shock and fire.
It takes 15 minutes for G-Unit to make condenser discharge. Don’t touch G-Unit and the
terminals for the mean time after power-off.
Provide an independent grounding for FG terminal avoiding terminal share with strong
electric circuit (not exceeding 100Ω, tension strength 0.39kN or more by metal wire, or
1.6mm or thicker annealed copper wire). There is a risk of shock.
Immediately stop the operation and shut the power off if G-tool outputs unusual smell, sound,
or behavior. There is a risk of injury and fire.
Install stop device in the machine side to secure safety.
There is a risk of injury.
For immediate operation stop, install emergency stop circuit outside of whole device of the
machine. There is a risk of injury.
Don’t approach whole device of the machine after power recovery from an instantaneous
power failure because it can restart all of a sudden. Carry out management securing safety
even if the restart takes the place. There is a risk of injury.
DANGER

Safety instructions
(Never fail to read)
Transport and storage
CAUTION
Transport G-System by right method and procedure appropriate to its weight.
There is a risk of injury and breakdown due to fall and overturn.
Follow below instructions for G-System shipment by boatlift.
◆Ambient temperature: -5~+55 deg C (No freeze)
◆Ambient humidity: Below 50%RH (No dew)
◆Packaging: Fully sealed
◆Rust-proofing: Apply grease or oil to G-Tool.
There is a risk of leak and breakdown.
Don’t hold Cables or spindle for G-Tool transportation.
There is a risk of injury and breakdown.
Don’t hold Display Unit attached to front panel of G-Unit for transportation because doing so
will separate them causing injury and breakdown.
Display Unit is detached and causes injury and breakdown.
Store G-System under the following environment.
◆Ambient temperature: -5~+55 deg C (No freeze)
◆Ambient humidity: Below 90%RH (No dew)
◆Within a building and no direct rays of the sun
◆Place free from vibration and shock
◆Place free from corrosive gases and combustible gases
◆Place free from oil-mist, refuse, water, saline matter, iron powder, and organic solvent
There is a risk of fire, leak, and breakdown.
Dispose of G-System as an industrial waste.

Safety instructions
(Never fail to read)
CAUTION
Firmly install G-Tool in the place sustaining G-Tool’s weight and reaction of maximum
fastening force using designated screws. There is a risk of injury and breakdown.
Firmly install G-Unit in a dust-free housing (in control box) using designated screws. There
is a risk of breakdown.
Use G-Tool, G-Unit and Cables in the designated assemblage.
There is a risk of fire and breakdown.
Keep designated distance between G-Unit and other equipment within control box.
There is a risk of fire and breakdown.
Don’t cover vent hole of G-Unit. Avoid foreign matter inclusion in G-Unit.
There is a risk of fire and breakdown.
Give power input part a breaker or a circuit protector for safety measures.
Select delay action type circuit breaker. There is a risk of fire and breakdown.
Never use G-Tool and G-Unit with worn-out, damaged or less components assembled.
There is a risk of fire, injury and malfunction.
Don’t put heavy materials on G-Tool, G-Unit and Cables. Don’t get on G-Tool, G-Unit and
Cables. There is a risk of shock, injury and breakdown.
Don’t give G-System strong vibration and shock.
There is a risk of breakdown.
Use accessory cable or connector to supply power to G-Unit. Set all connector part of
Cables firmly in place. Make Cable arrangement so it will not share space with power
cable in the same duct. There is a risk of injury, malfunction and breakdown.
Use G-System by power supply conforming to the standard voltage.
Carry out wiring DC24V control power to G-Unit without mistaking the polarity.
There is a risk of injury, shock, fire and breakdown.
Use noise filters like surge damper if you install relay or solenoid switch in dust-free housing
within control box. Also use noise filter to G-Unit for noise reduction.
There is a risk of malfunction and breakdown.
Installation and wiring
CAUTION

Safety instructions
(Never fail to read)
Do not operate G-System with wet hand. There is a risk of shock.
Do not touch radiator fin of G-Unit and motor of G-Tool while applying current and also for a
while after power off as they get hot in the meantime. There is a risk of burn.
Use G-System under the following environment.
◆Ambient temperature: 0~+45 deg C (dry convection necessary)
◆Ambient humidity: Below 90%RH (No dew)
◆Noise free place
◆Place not causing strong electric field and strong magnetic field
◆Place keeping distance from power wire
◆Within a building protected against water and direct rays of the sun
◆Place free from vibration and shock
◆Place free from corrosive gases and combustible gases
◆Place free from oil-mist, refuse, water, saline matter, iron powder, and organic solvent
◆Easy to make inspection and cleaning place
There is a risk of fire, leak, malfunction, and breakdown.
Make confirmation and adjustment of every setting value before operation.
Never make significant adjustment and setting change because doing so causes unstable
behavior. There is a risk of injury, malfunction and breakdown.
Execute RESET only after START signal has been confirmed “OFF” status.
There is a risk of injury and malfunction
.
Don’t make frequent power-on and shut-down. There is a risk of breakdown.
Also, make Cable insert and remove of G-System with control power “OFF” status because
doing the same with the control power “ON” status can cause breakdown.
Prevent G-Tool from generating torque momentary overrunning its maximum output.
Also, use G-Tool within the prescribed DUTY even if the torque is less than its nominal
torque. There is a risk of lifetime decrease and breakdown.
If an error code appears on front panel G-Unit, remove cause of the error first.
Restart G-Unit only after securing safety. There is a risk of injury.
Discharge your static electricity touching grounded metallic object before operating G-Unit
with the front panel. There is a risk of malfunction and breakdown.
Wipe G-Unit and G-Tool with a cloth damped with tepid water or alcohol. Don’t use a kind
of thinner of organic solvent. There is a risk of breakdown.
CAUTION
Operation and adjustment
CAUTION

Modification history
Date
Reference
Contents
2018/8/30
GUN0001
1st Edition (for version 1.001)
COPYRIGHT
The information described in this instruction manual is solely the property of URYU SEISAKU, LTD.
No part of this instruction manual may be reproduced or transmitted in any form or by any means,
electronic or mechanical, including photocopying and recording and sold for monetary figure without
the express written permission of URYU SEISAKU, LTD.
DISCLAIMER
・Contents of this instruction manual is subject to change without prior notice.
・We warrant that G-System will conform to the specifications, but disclaim all implied warranties,
including, without limitation, all implied warranties of merchantability and fitness for a particular
purpose.

Contents
Cover page
About this book
Safety instructions
Contents
Chapter 1 Introduction
1-1. How to use this book ..................................................................................................................... 1-2
1-2. G-System ............................................................................................................................................. 1-3
1-4. Item configuration............................................................................................................................ 1-7
1-4-1. System configuration diagram ................................................................ 1-8
1-5. Model numbers ...............................................................................................................................1-10
1-5-1. Cable models........................................................................................ 1-10
1-5-2. G-Unit models....................................................................................... 1-10
1-5-3. G-Tool models ...................................................................................... 1-12
1-6. Specifications...................................................................................................................................1-13
1-6-1. G-system environment ......................................................................... 1-13
1-6-2. G-Tool performance.............................................................................. 1-14
1-6-3. G-Unit specificatios............................................................................... 1-14
1-6-4. DUTY calculation .................................................................................. 1-16
1-6-5. Fieldbus specifications ......................................................................... 1-16
1-7. Parts names......................................................................................................................................1-17
1-7-1. G-Unit front panel switch and connectors............................................. 1-17
1-7-2. G-Unit front panel LED ......................................................................... 1-19
1-7-3. G-Unit sole panel, top panel, switch and connectors............................ 1-21
1-7-4. G-Unit side-on connectors.................................................................... 1-22
1-7-5. G-Unit Display Unit with switch and LED.............................................. 1-23
1-7-6. Extension unit ....................................................................................... 1-24
1-7-7. Cable specifications.............................................................................. 1-25
Chapter 2 Installation
2-1. Peripheral devices ........................................................................................................................2－3
2-2. External control signal connection.......................................................................................2－4
2-2-1. Usable plug (I/O) ..................................................................................2－4
2-2-2. PLC I/O signal (MASTER) ....................................................................2－4
2-2-3. PLC I/O signal (Multi-system: Out data from MASTER) .......................2－6
2-2-4. PLC I/O signal (Multi-system: from SLAVE)..........................................2－7
2-2-5. IN & OUT hardware specifications and recommended connection.......2－8
2-2-6. IN & OUT signals..................................................................................2－9
2-2-7. Fastening timing chart ........................................................................2－13
2-3. G-Unit switch setting................................................................................................................. 2－15
2-3-1. Spindle number switch setting ............................................................2－15
2-3-2. Special function SW1 switch setting ...................................................2－16
2-3-3. Sole panel SW2 switch setting ...........................................................2－17
2-4. G-Unit External shape and installation dimensions................................................ 2－18
2-4-1. UEC-G024, UEC-G060, UEC-G120 ...................................................2－18
2-4-2. Layout in control box ..........................................................................2－23
2-5. G-Tool dimensions..................................................................................................................... 2－24
2-5-1. Straight models...................................................................................2－24

Chapter 3 Wiring and test operation
3-1. G-Unit wiring.....................................................................................................................................3－2
3-2. Power source connection .........................................................................................................3－3
3-3. G-Tool wiring and fixing..............................................................................................................3－5
3-3-1. G-Tool fixing method.............................................................................3－5
3-3-2. G-Tool cable wiring ...............................................................................3－6
3-4. External monitor interface.........................................................................................................3－7
3-4-1. Usable plug (external monitor)..............................................................3－7
3-4-2. External monitor signal specifications...................................................3－7
3-4-3. External monitor equipment calibration ................................................3－8
3-4-4. Output circuit ........................................................................................3－8
3-5. RS232C interface..........................................................................................................................3－9
3-5-1. Usable plug (RS232C)..........................................................................3－9
3-5-2. RS232C communication specifications ................................................3－9
3-5-3. RS232C fastening result output (Multi-system) ..................................3－10
3-6. Ethernet interface....................................................................................................................... 3－15
3-6-1. TCP/IP setting procedure (Windows)..................................................3－16
3-6-2. TCP/IP setting procedure (User console) ...........................................3－19
3-6-3. TCP/IP setting procedure (Touch panel).............................................3－21
3-7. AUX. Interface .............................................................................................................................. 3－23
3-7-1. Usable plug (STOP signal) .................................................................3－23
3-7-2. STOP signal specifications .................................................................3－23
3-8. AXIS LINK IN/OUT interface ................................................................................................ 3－24
3-9. Power ON and test operation.............................................................................................. 3－25
3-9-1. Check point before power ON ............................................................3－25
3-9-2. Check point at power ON ...................................................................3－26
3-9-3. Initial setting value input .....................................................................3－26
3-9-4. Check point after power ON ...............................................................3－27
Chapter 4 Extension unit
4-1. External control interface ..........................................................................................................4－2
4-1-1. External control interface table .............................................................4－2
4-1-2. Timing chart (Multi-system)...................................................................4－2
4-1-3. Input signals .........................................................................................4－4
4-1-4. PLC output layout .................................................................................4－6
4-1-5. Output signals.......................................................................................4－8
4-1-6. Fieldbus message setting...................................................................4－14
4-1-7. ID output setting .................................................................................4－19
4-2. Extension I/O................................................................................................................................. 4－22
4-2-1. Hardware............................................................................................4－22
4-2-2. I/O signal specifications......................................................................4－23
4-2-3. IN & OUT hardware specifications and recommended connection.....4－27
4-3. CompactFlash .............................................................................................................................. 4－28
4-3-1. Data saving in memory card...............................................................4－29
4-3-2. Data saving flow .................................................................................4－30
4-3-3. Format memory card ..........................................................................4－34
4-3-4. Setting value auto backup ..................................................................4－35
4-3-5. Read setting value from memory card................................................4－36
4-4. Extension RS232C interface................................................................................................ 4－38

Chapter 5 Setting operation
5-1. Display unit........................................................................................................................................5－2
5-2. RUN/BYPASS switch ..................................................................................................................5－5
5-3. RUN status........................................................................................................................................5－6
5-3-1. MODE change ......................................................................................5－7
5-3-2. Display (real time mode).......................................................................5－8
5-3-3. Display (fastening result mode) ..........................................................5－10
5-3-4. Display (parameter setting mode).......................................................5－12
5-3-5. Display (system setting mode)............................................................5－13
5-3-6. Display (screen during operation).......................................................5－14
5-4. BYPASS status ............................................................................................................................ 5－15
5-4-1. MODE change under BYPASS MODE ...............................................5－16
5-4-2. Display (setting value select mode) ....................................................5－17
5-4-3. Display (setting value edit mode)........................................................5－19
5-5. Parameter copy/clear fastening result history............................................................ 5－21
Chapter 6 System parameter
6-1. Parameter structure .....................................................................................................................6－2
6-2. System parameter.........................................................................................................................6－3
6-2-1. G-Unit information 1 .............................................................................6－5
6-2-2. G-Tool setting .......................................................................................6－9
6-2-3. G-Unit information 2 ...........................................................................6－11
6-2-4. Extension unit information 1 ...............................................................6－13
6-2-5. Extension unit information 2 ...............................................................6－17
6-2-6. Touch panel display unit .....................................................................6－19
Chapter 7 Fastening parameter
7-1. Fastening setting. ..........................................................................................................................7－4
7-2. Torque ............................................................................................................................................... 7－10
7-3. Angle.................................................................................................................................................. 7－14
7-4. Rate/time ......................................................................................................................................... 7－16
7-5. Speed................................................................................................................................................ 7－19
7-6. Thread numbers/current......................................................................................................... 7－21
7-7. Fastening parameter setting sheet................................................................................... 7－23
Chapter 8 Maintenance and inspection
8-1. Check items......................................................................................................................................8－2
8-1-1. G-Tool (motor part) ...............................................................................8－2
8-1-2. Cables ..................................................................................................8－2
8-1-3. G-Unit ...................................................................................................8－3
8-2. Inspection items .............................................................................................................................8－3
8-2-1. Torque transducer.................................................................................8－3
8-2-2. Resolver ...............................................................................................8－4
8-2-3. Motor ....................................................................................................8－4
8-3. Replacing method .........................................................................................................................8－5
8-3-1. G-Unit ...................................................................................................8－5
8-3-2. G-Tool...................................................................................................8－5
Chapter 9 Trouble shooting
9-1. Alarm signal display .....................................................................................................................9－2

9-2. Alarm contents/cause and solution .....................................................................................9－3
9-2-1. A.01: Torque transducer error ...............................................................9－3
9-2-2. A.03: Pre-amplifier error .......................................................................9－4
9-2-3. A.04: System memory error ..................................................................9－4
9-2-4. A.05: Servo response error...................................................................9－5
9-2-5. A.06: Servo type error...........................................................................9－5
9-2-6. A.08: Servo amplifier error....................................................................9－5
9-2-7. A.09: Setting data error.........................................................................9－7
9-2-8. A.10: Multi-system signal error .............................................................9－8
9-3. NOK Judgment contents information.................................................................................9－9
9-4. Ethernet communication......................................................................................................... 9－10
9-5. RTC (Real time clock).............................................................................................................. 9－12
Chapter 10 Warranty and service
10-1. Warranty........................................................................................................................................ 10－2
10-1-1. Warranty period ................................................................................10－2
10-1-2. Scope of warranty.............................................................................10－2
10-2. Inquiries......................................................................................................................................... 10－3

Chapter 1 Introduction
1

Chapter 1 Introduction
PAGE 1-2
1-1. How to use this book
This book will tell you system configuration, specifications and handling method of
G-type nutrunner unit (hereafter simply referred to as G-Unit) as follows. G-System
is collective term covering G-Unit, G-Tool, Cables and the dedicated parts.
Chapter
Items
Contents
1
Introduction
Basic specifications and parts names of G-Unit, G-Tool, and
Cables
2
Installation
Installation method
3
Wiring and test operation
Wiring, confirmation point before power ON, and test
operation procedure
4
Extension unit
G-Unit and extension unit
5
Setting operation
Contents of display on Display Unit and fastening parameter
setting method
6
System parameter
Function and contents of system setting value
7
Fastening parameter
Function and contents of fastening setting value
8
Maintenance and inspection
Check items, inspection items, and the method of G-System
9
Trouble shooting
Alarm display during operation and trouble shooting
10
Warranty and service
Warranty period and service system
G-Console (USER CONSOLE INSTRUCTION MANUAL) is not
included in this book. Refer to the separate volume. Read
relevant manuals.
G Series Nutrunner USER CONSOLE INSTRUCTION MANUAL
Relevant manuals
CAUTION

Chapter 1 Introduction
PAGE 1-3
1-2. G-System
G type nutrunner is electric motor-driven nutrunner. G type nutrunner fastens bolt
and nut by automatic operation. Integrating main unit functions in conventional spindle
unit, we have made single spindle unit (hereafter referred to as G-Unit) without
distinction of main unit and spindle unit. Reinforcing multi-system control and exterior
communication, we have developed a new fastening system satisfying future-oriented
productive facilities with flexibility. G-System serves dynamic torque control fastening
by combination of servo-motor and torque transducer.
○ Reduced start-up time
G-System does not require complicated ladder of PLC. Easy to understand
parameter setting realizes fastening step entry in this system without special
knowledge. G-System contributes to job improvement in the field.
○ Easy setting change
G-Console, the dedicated software, realizes easy setting of fastening parameter,
fastening objectives and other items.
○ Support diversified external control interfaces
Attach extension unit to G-Unit, and it will support various Fieldbuses controlling
all signal exchange of G-System and external devices.
○ Fastening data saving in CF card
An extension unit saves fastening result and fastening torque waveform in
CF card. Saving data numbers depend upon numbers of G-Unit and
fastening method. As a guideline with 8GB, however, extension unit will
save following data to CF card: 1.8 million cases/spindle, 0.9 million cases/2
spindles, 0.6 million cases/4 spindles, 0.4 million cases/8 spindles, 0.2
million cases/16 spindles and 0.1 million cases/32 spindles.
○ High speed communication with host system
Employment of Ethernet has realized shorter communication hours for data
transmission. G-Type’s dedicated communication method serves 250 times
faster communication speed than our ordinary type.
○ Power source and I/O serving multi-safety
An independent emergency stop signal takes care of interruption during fastening.
Using DC24V as control power, G-Unit communicates its status to host system
despite blackout due to an emergency.
○ Multi-functionalized G-Unit
One G-Unit serves main unit and spindle unit both required by ordinary system.
G-Unit supports Fieldbus specifications and serves space-saving having legacy
spindle function within.

Chapter 1 Introduction
PAGE 1-4
1-3. Functions
(1) Fastening function
G-System offers following fastening methods.
1．Torque method 2．Angle method 3．Plastic area angle
4．Pre-load 5．Pin-hole control 6．Idle check 7．Position adjust
(2) BYPASS (switch off intended spindle) function
PLC I/O BYPASS "ON" or RUN/BYPASS switch set to BYPASS side
G-Unit is BYPASS status with BYPASS LED lighting red. G-Unit will not restart even if
START signal changed OFF to ON under BYPASS status. Fastening is shut-down
during operation once G-Unit came to BYPASS status.
(3) ALARM signal output function
G-Unit outputs ALARM signal if an error was found with the system by SYSTEM
CHECK, CONNECTION CHECK and LOAD CHECK with STATUS LED lighting red
and Display Unit displaying Alarm number and sub code.
(4) Tool type check function
G-Unit verifies if the connected G-Tool agrees with the setting at the time of power ON
and G-Tool replacement. If the verification finds disagreement, ALARM signal 03-02
[Tool type error] takes the place.
(5) Self-check function
Upon switching control power-ON, G-Unit acquires ZERO voltage and CAL voltage of
transducer serving criterion of fastening. Also acquiring these voltages again every
before fastening start, G-Unit conducts self-check comparing these values of switching
on to before fastening start. This self-check is not available for reverse operation.
Change PLC I/O [Auto Z/C Check OFF] to ON, and G-Unit will pass up self-check.
(6) Fastening torque waveform display function
G-Console-developed PC screen displays fastening torque waveform 1980 deg (5.5
turns) retroactive from fastening end or for 40 sec from fastening start.
(7) Error history function
When an error happens with the system together with alarm signal, G-Unit will store
the error contents and history of 500 cases within and 20 cases in G-Tool ID.

Chapter 1 Introduction
PAGE 1-5
(8) Waveform history function
G-Unit retains 100 each OK and NOK fastening result waveform data always. Use
G-Console to read the waveform history.
・Data type :Torque-Angle (540 deg)
・Data contents (OK waveform history) :100 cases from the latest data
※Shut off control power to G-Unit, and the retained data (waveform history) will
disappear.
・Data contents (NOK waveform history) :100 cases of spindle judgment NOK,
ALARM and STOP from the latest data
(9) Fastening result history function
G-Unit retains 12,000 cases fastening result from the latest data. Use G-Console to
read the fastening result history.
G-Unit brought to MASTER (hereafter referred to as Master-Unit) retains not only its
own but also whole multi-system’s other G-Units’ fastening result. Number of
fastening result retained by Master-Unit depends on how many G-Units are under
Master-Unit.
・Number of fastening result retained by Master-Unit
Total G-Unit
1
2
3
4
5
6
7
8
9
10
Max data
numbers
5880
3936
2952
2376
1968
1704
1488
1320
1176
1080
Total G-Unit
11
12
13
14
15
16
17
18
19
20
Max data
numbers
984
912
840
792
744
696
648
624
576
552
Total G-Unit
21
22
23
24
25
26
27
28
29
30
Max data
numbers
527
503
479
455
455
431
407
407
383
383
Total G-Unit
31
32
Max data
numbers
359
359
※Above numbers are just guideline as there will be an error due to fastening method and
the environment.

Chapter 1 Introduction
PAGE 1-6
●G-System fastening result retaining function table
Function name
Result data retention ※1
Fastening result history
G-Console
screen
Fastening
result monitor
Waveform
monitor
Fastening result monitor
Setting tab
Fastening
result display
Auto read
setting
Fastening history
Store objective
Master/each
Each
Master
Each
Store contents
Fastening
history
Fastening
waveform
Fastening
history
Fastening
history
Error
history
Store place
PC
Master
Each
Each
Numbers
-
See last
page
12,000
cases
500
cases
Setting item
Yes
No
Judge
OK
O
O
O
O
NOK
O
O
O
O
ALARM
O
O
O
O
O
BYPASS
O
O
O
O
STOP
O
O
O
O
Par No.SYS
D-No.021
[history clear]
No
Multi
Single
ALARM
※1：G-Unit carries out data storing when G-Console is data collection status under [FASTENING
RESULT MONITOR].
Function name
Waveform history
Saving in CF card※2
G-Console
Waveform history
-
Store contents
Waveform
history※3
NOK
waveform
history
Fastening
history
Fastening
waveform
Store objective
Each
Each
Master/Each
Store place
Each
CF card
Numbers
100 each
-
-
Store form
Torque-Angle (540 deg)
-
Torque-Angle
(180 deg)
Judge
OK
O
O
O
NOK
O
O
O
O
ALARM
O
O
O
O
BYPASS
O
O
O
STOP
O
O
O
O
Par No.SYS
D-No.021
[History clear]
Curve1
Curve2
CF
※2：Buy Extension unit 2 (UEC-GCF) and CF card.
※3：Shut off control power to G-Unit, and the retained data will disappear.

Chapter 1 Introduction
PAGE 1-7
1-4. Item configuration
Put one (1) G-Unit on an administrative unit, which is Master-Unit (see page 1-5)
controlling all G-Unit grouped by I/O (PLC) in a syetem. G-Unit having direct
communication with PC or Fieldbus is Master-Unit, and other G-Unit relying on
communication under Master-Unit is SLAVE or simply referred to as G-Unit.
※Refer to 2-3-2 Special function SW1 switch setting at PAGE 2-17 for MASTER and
SLAVE.
●Support table by system
System structure
Multi-system
I/O (PLC) control
Master-Unit controls other G-Units grouped by
I/O (PLC) in a system.
AUX. connector
External STOP signal
Parameter (sequence) select
method
PLC I/O input by factory configuration.
ID data input by G-console.
Self-check function OFF
PLC I/O input
START signal is OFF during
fastening operation.
No. 2 of SW1 on G-Unit front panel
Output from RS232C
Free allocation
Fieldbus function
Effective
Extension RS232C function
Effective
Touch panel display unit
Effective
Touch panel display unit: Par
No.SYS D-No.003 [system
display]
Multi

Chapter 1 Introduction
PAGE 1-8
1-4-1. System configuration diagram
G-Unit setting
MASTER No.1
SLAVE No.2
G-Unit front panel SW1：No. 8 setting
ON
OFF
Touch panel display D-No.SYS-003
Multi
Multi
・Refer to our recommendation for your own selection and purchase of LAN
cable, circuit protector and noise filter as they do not come with G-System.
(See 2-1 Peripheral device at PAGE 2－3)
・For G-Unit to G-Unit communication, hook up AXIS LINK IN of head unit to
AXIS LINK OUT of tail unit with F-SPINDLE CABLE, or attach 2 pieces
G-END connectors to them. (Refer to 3-8. AXIS LINK IN/OUT at PAGE 3-
24.
UNR-G613-**NT
UNR-G640-**NT
UNR-G613-**NT
UNR-G640-**NT
UEC-G024
UEC-G060
UEC-G024
UEC-G060
NOISE
FILTER
NOISE
FILTER
DC24V
EMERGENCY STOP
*Make sure to ground
*CP: Circuit Protector
*CP: Circuit protector
*
