Foxwell ET2530 User manual

1
ET2530 Multi-System Scanner Manual_English_V1.02
Trademarks
FOXWELL is the trademark of Shenzhen Foxwell Technology Co., Ltd.
All other marks are trademarks or registered trademarks of their respective holders.
Copyright Information
©2019 Shenzhen Foxwell Technology Co., Ltd.
All rights reserved.
Disclaimer
The information, specifications and illustrations in this manual are based on the latest information available
at the time of printing.
Foxwell reserves the right to make changes at any time without notice.
Visit our website at
www.endeavourtools.com.au
For Technical Assistance
[e-mail]

2
ET2530 Multi-System Scanner Manual_English_V1.02
One-Year Limited Warranty
Subject to the conditions of this limited warranty, Shenzhen Foxwell Technology Co., Ltd
(“FOXWELL”) warrants its customer that this product is free of defects in material and workmanship
at the time of its original purchase for a subsequent period of one (1) year.
In the event this product fails to operate under normal use, during the warranty period, due to
defects in materials and workmanship, FOXWELL will, at its sole option, either repair or replace the
product in accordance with the terms and conditions stipulated herein.
Terms and Conditions
1 If FOXWELL repairs or replaces the product, the repaired or replaced product shall be warranted
for the remaining time of the original warranty period. No charge will be made to the customer for
replacement parts or labor charges incurred by FOXWELL in repairing or replacing the defective
parts.
2 The customer shall have no coverage or benefits under this limited warranty if any of the following
conditions are applicable:
a) The product has been subjected to abnormal use, abnormal conditions, improper storage,
exposure to moisture or dampness, unauthorized modifications, unauthorized repair, misuse,
neglect, abuse, accident, alteration, improper installation, or other acts which are not the fault of
FOXWELL, including damage caused by shipping.
b) The Product has been damaged from external causes such as collision with an object, or from
fire, flooding, sand, dirt, windstorm, lightning, earthquake or damage from exposure to weather
conditions, an Act of God, or battery leakage, theft, blown fuse, improper use of any electrical
source, or the product was used in combination or connection with other product, attachments,
supplies or consumables not manufactured or distributed by FOXWELL.
3 The customer shall bear the cost of shipping the product to FOXWELL. And FOXWELL shall bear
the cost of shipping the product back to the customer after the completion of service under this
limited warranty.
4 FOXWELL does not warrant uninterrupted or error-free operation of the product. If a problem
develops during the limited warranty period, the consumer shall take the following step-by-step
procedure:
a) The customer shall return the product to the place of purchase for repair or replacement
processing, contact your local FOXWELL distributor or visit our website
www.endeavourtools.com.au to get further information.
b) The customer shall include a return address, daytime phone number and/or fax number, complete
description of the problem and original invoice specifying date of purchase and serial number.
c) The customer will be billed for any parts or labor charges not covered by this limited warranty.
d) FOXWELL will repair the Product under the limited warranty within 30 days after receipt of the
product. If FOXWELL cannot perform repairs covered under this limited warranty within 30 days, or
after a reasonable number of attempts to repair the same defect, FOXWELL at its option, will
provide a replacement product or refund the purchase price of the product less a reasonable amount
for usage.
e) If the product is returned during the limited warranty period, but the problem with the product is
not covered under the terms and conditions of this limited warranty, the customer will be notified and
given an estimate of the charges the customer must pay to have the product repaired, with all

3
ET2530 Multi-System Scanner Manual_English_V1.02
shipping charges billed to the customer. If the estimate is refused, the product will be returned freight
collect. If the product is returned after the expiration of the limited warranty period, FOXWELL’
normal service policies shall apply and the customer will be responsible for all shipping charges.
5 ANY IMPLIED WARRANTY OF MERCHANTABILITY, OR FITNESS FOR A PARTICULAR
PURPOSE OR USE, SHALL BE LIMITED TO THE DURATION OF THE FOREGOING LIMITED
WRITTEN WARRANTY. OTHERWISE, THE FOREGOING LIMITED WARRANTY IS THE
CONSUMER’S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED. FOXWELL SHALL NOT BE LIABLE FOR SPECIAL, INCIDENTAL,
PUNITIVE OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LOSS OF
ANTICIPATED BENEFITS OR PROFITS, LOSS OF SAVINGS OR REVENUE, LOSS OF DATA,
PUNITIVE DAMAGES, LOSS OF USE OF THE PRODUCT OR ANY ASSOCIATED EQUIPMENT,
COST OF CAPITAL, COST OF ANY SUBSTITUTE EQUIPMENT OR FACILITIES, DOWNTIME,
THE CLAIMS OF ANY THIRD PARTIES, INCLUDING CUSTOMERS, AND INJURY TO PROPERTY,
RESULTING FROM THE PURC HASE OR USE OF THE PRODUCT OR ARISING FROM BREACH
OF THE WARRANTY, BREACH OF CONTRACT, NEGLIGENCE, STRICT TORT, OR ANY OTHER
LEGAL OR EQUITABLE THEORY, EVEN IF FOXWELL KNEW OF THE LIKELIHOOD OF SUCH
DAMAGES. FOXWELL SHALL NOT BE LIABLE FOR DELAY IN RENDERING SERVICE UNDER
THE LIMITED WARRANTY, OR LOSS OF USE DURING THE PERIOD THAT THE PRODUCT IS
BEING REPAIRED.
6. Some states do not allow limitation of how long an implied warranty lasts, so the one-year
warranty limitation may not apply to you (the Consumer). Some states do not allow the exclusion or
limitation of incidental and consequential damages, so certain of the above limitations or exclusions
may not apply to you (the Consumer). This limited warranty gives the Consumer specific legal rights
and the Consumer may also have other rights which vary from state to state.

4
ET2530 Multi-System Scanner Manual_English_V1.02
Safety Information
For your own safety and the safety of others, and to prevent damage to the equipment and vehicles,
read this manual thoroughly before operating your scanner. The safety messages presented below
and throughout this user’s manual are reminders to the operator to exercise extreme care when using
this device. Always refer to and follow safety messages and test procedures provided by vehicle
manufacturer. Read, understand and follow all safety messages and instructions in this manual.
Safety Message Conventions Used
We provide safety messages to help prevent personal injury and equipment damage. Below are
signal words we used to indicate the hazard level in a condition.
Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury
to the operator or to bystanders.
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury
to the operator or to bystanders.
Indicates a potentially hazardous situation which, if not avoided, may result in moderate or minor
injury to the operator or to bystanders.
Important Safety Instructions
And always use your scanner as described in the user’s manual, and follow all safety messages.
● Do not route the test cable in a manner that would interfere with driving controls.
● Do not exceed voltage limits between inputs specified in this user’s manual.
● Always wear ANSI approved goggles to protect your eyes from propelled objects as well as hot or
caustic liquids.
● Fuel, oil vapors, hot steam, hot toxic exhaust gases, acid, refrigerant and other debris produced by
a malfunction engine can cause serious injury or death. Do not use the scanner in areas where
explosive vapor may collect, such as in below-ground pits, confined areas, or areas that are less
than 18 inches (45 cm) above the floor.
● Do not smoke, strike a match, or cause a spark near the vehicle while testing and keep all sparks,
heated items and open flames away from the battery and fuel / fuel vapors as they are highly
flammable.
● Keep a dry chemical fire extinguisher suitable for gasoline, chemical and electrical fires in work
area.
● Always be aware of rotating parts that move at high speed when an engine is running and keep a
safe distance from these parts as well as other potentially moving objects to avoid serious injury.
● Do not touch engine components that get very hot when an engine is running to avoid severe burns.

5
ET2530 Multi-System Scanner Manual_English_V1.02
● Block drive wheels before testing with engine running. Put the transmission in park (for automatic
transmission) or neutral (for manual transmission). And never leave a running engine unattended.
● Do not wear jewelry or loose fitting clothing when working on engine.
● Don't connect or disconnect the equipments while the ignition is on or the engine is running.

6
ET2530 Multi-System Scanner Manual_English_V1.02
Table of Contents
ONE-YEAR LIMITED WARRANTY .....................................................................................................2
SAFETY INFORMATION.....................................................................................................................4
SAFETY MESSAGE CONVENTIONS USED .............................................................................................4
IMPORTANT SAFETY INSTRUCTIONS ....................................................................................................4
1 USING THIS MANUAL.....................................................................................................................9
1.1 BOLD TEXT .................................................................................................................................9
1.2 SYMBOLS AND ICONS ...................................................................................................................9
1.2.1 Solid Spot ..........................................................................................................................9
1.2.2 Arrow Icon..........................................................................................................................9
1.2.3 Note and Important Message .............................................................................................9
2 INTRODUCTIONS..........................................................................................................................10
2.1 SCANNER DESCRIPTIONS ...........................................................................................................10
2.2 ACCESSORY DESCRIPTIONS ....................................................................................................... 11
2.3 TECHNICAL SPECIFICATIONS....................................................................................................... 11
3 GETTING STARTED ...................................................................................................................... 11
3.1 PROVIDING POWER TO SCANNER................................................................................................ 11
3.1.1 Connecting to Vehicle Power ........................................................................................... 11
3.1.2 Connecting to Computer with USB Cable.........................................................................12
3.2 APPLICATION OVERVIEW ............................................................................................................12
3.3 INPUT DIALOG BOX ....................................................................................................................13
4.VEHICLE IDENTIFICATION ...........................................................................................................14
4.1 SMART VIN...............................................................................................................................15
4.2 MANUAL SELECTION ..................................................................................................................16
5 DIAGNOSTIC OPERATIONS ......................................................................................................... 17
5.1 CONTROL MODULE SELECTION...................................................................................................17

7
ET2530 Multi-System Scanner Manual_English_V1.02
5.1.1 Quick Scan ......................................................................................................................18
5.1.2 Control Modules...............................................................................................................20
5.2 DIAGNOSTIC OPERATIONS ..........................................................................................................20
5.2.1 Read Codes.....................................................................................................................21
5.2.2 Clear Codes.....................................................................................................................22
5.2.3 Live Data .........................................................................................................................23
5.2.4 ECU Information ..............................................................................................................27
5.2.5 Active Tests......................................................................................................................28
5.2.6 Special Functions.............................................................................................................29
6 OBDII/EOBD OPERATIONS ..........................................................................................................30
7 SYSTEM SETUP............................................................................................................................ 31
7.1 SELECT LANGUAGE ...................................................................................................................31
7.2 CHANGE UNITS .........................................................................................................................32
7.3 CONFIGURE SHORTCUT KEYS.....................................................................................................33
7.4 DISPLAY TEST ...........................................................................................................................34
7. 5 KEYPAD TEST ...........................................................................................................................35
7.6 TOOL INFORMATION ...................................................................................................................35
8 UPDATE......................................................................................................................................... 36
8.1 CREATE A FOXWELL ID...............................................................................................................36
Register with FoxAssist.............................................................................................................36
8.2 REGISTER YOUR SCANNER ........................................................................................................38
Register With FoxAssist............................................................................................................38
8.3 UPDATE THE SCANNER ..............................................................................................................39

8
ET2530 Multi-System Scanner Manual_English_V1.02

9
ET2530 Multi-System Scanner Manual_English_V1.02
1 Using This Manual
We provide tool usage instructions in this manual. Below is the conventions we used in the manual.
1.1 Bold Text
Bold text is used to highlight selectable items such as buttons and menu options.
Example:
Press the ENTER button to select.
1.2 Symbols and Icons
1.2.1 Solid Spot
Operation tips and lists that apply to specific tool are introduced by a solid spot ●.
Example:
When Settings is selected, a menu that lists all available options displays. Menu options include:
● Language
● Unit
● Shortcuts
● Display Test
● Keypad Test
● About
1.2.2 Arrow Icon
An arrow icon indicates a procedure.
Example:
To change menu language:
1. Scroll with the arrow keys to highlight Language on the menu.
2. Press the ENTER button to select.
1.2.3 Note and Important Message
Note
A NOTE provides helpful information such as additional explanations, tips, and comments.
Example:
NOTE
Test results do not necessarily indicate a faulty component or system.
Important
IMPORTANT indicates a situation which, if not avoided, may result in damage to the test equipment
or vehicle.
Example:
IMPORTANT

10
ET2530 Multi-System Scanner Manual_English_V1.02
Do not soak keypad as water might find its way into the scanner.
2 Introductions
Foxwell ET2530 Multi-system scanner is a unique tool that delivers OE-level diagnosis for all the
electronic systems of different car brands. What’s more important is that it supports the most
commonly required service features such as Oil Light/Service reset, brake deactivation, transmission
adaptations, and so on.
Available applications are BMW, Mercedes Benz, Fiat, PSA, Chrysler, Ford, GM, Honda, Nissan,
Toyota and more. And the functions may vary by year and model.
2.1 Scanner Descriptions
This section illustrates external features, ports and connectors of the scanner.
Figure 2-1 Front View
1 Diagnostic Port - provides connection between vehicle and the scanner.
2 LCD Display - shows menus, test results and operation tips.
3 Function Keys / Shortcut keys - three keys that correspond with “buttons” on some screens for
executing special commands or provide quick access to most frequently used applications or
functions.
4 Direction Keys - select an option or scroll through a screen of data or text.
5 ENTER Key - executes a selected option and generally goes to the next screen.
6 BACK Key - exits a screen and generally returns to previous screen.
7 HELP Key - displays helpful information.

11
ET2530 Multi-System Scanner Manual_English_V1.02
8 USB Port - provides USB power connection between the scanner and PC/laptop.
9 TF Card Port - holds the TF memory card for data backup and software update.
IMPORTANT
Do not use solvents such as alcohol to clean keypad or display. Use a mild nonabrasive detergent
and a soft cotton cloth.
2.2 Accessory Descriptions
This section lists the accessories that go with the scanner. If you find any of the following items
missing from your package, contact your local dealer for assistance.
1 Quick Start Guide - provides brief operation instructions for the usage of the scanner.
2 Diagnostic Cable - provides connection between the scanner and a vehicle.
3 USB Cable - provides connection between the scanner and a computer to update and print data.
4 Warranty Card - A warranty card is required if you need any repair or replacement from us.
5 Nylon Carry Pouch - stores the scanner and its accessories.
2.3 Technical Specifications
Display: Backlit, 240*320 TFT color display
Working Temperature: 0 to 60 ℃ (32 to 140℉)
Storage Temperature: -20 to 70℃ (-4 to 158℉)
Power Supply: 8-18V vehicle power and 3.3V USB power
Dimensions: (L*W*H): 200*100*38mm
Weight: 0.6 Kg
3 Getting Started
This section describes how to provide power to the scanner, provides brief introductions of
applications loaded on the scanner and display screen layout and illustrates how to input text and
numbers with the scan tool.
3.1 Providing Power to Scanner
Before using the scanner, make sure to provide power to the scanner.
The unit operates on any of the following sources:
● 12-volt vehicle power
● USB connection to computer
3.1.1 Connecting to Vehicle Power
The scanner normally powers on whenever it is connected to the data link connector (DLC).
To connect to vehicle power:

12
ET2530 Multi-System Scanner Manual_English_V1.02
1. Locate the data link connector (DLC). The DLC is generally located under the dash on the driver
side of the vehicle.
2. Attached the Diagnostic cable to the scanner and tighten the captive screws to ensure good
connection.
3. Connect a correct adapter to the data cable according to the vehicle being serviced and plug it into
the vehicle DLC.
4. Switch the ignition key to the ON position.
5. The scanner automatically boots up.
IMPORTANT
Never try to provide power for the scan tool from USB connection when the scan tool is
communicating with a vehicle.
3.1.2 Connecting to Computer with USB Cable
The scan tool also receives power through the USB port when it is connected to a computer for
software updates and printing of data.
To connect to computer:
1. Connect the scanner to a computer with the USB cable provided.
3.2 Application Overview
When the scan tool boots up, the Home screen opens. This screen shows all applications loaded on
the unit. The available vehicle applications may vary depending on software configuration.
Take a Toyota customized scanner for example, following applications are preloaded into the scanner:
● Auto VIN - leads to screens for identifying a car by automatic VIN reading.
● OBDII/EOBD - leads to OBDII screens for all 9 generic OBD system tests.
● Toyota - leads to screens for diagnostic trouble code information, live data, ECU information,
active test, and special functions on vehicles sold worldwide.
● Settings - leads to screens for adjusting default settings to meet your own preference and view
information about the scanner.
● Data Manager - leads to screens for access to data records.
● Update - leads to screen for updating the scanner.

13
ET2530 Multi-System Scanner Manual_English_V1.02
Figure 3-1 Sample Home Screen
3.3 Input Dialog Box
This section illustrates how to use the scan tool to input letters and numbers, such as VIN number,
channel number, test values and DTC number. Typically, you may be required to input letters or
numbers when you are doing any of the following operations.
● VIN entry
● input channel number
● set adaptation value
● enter block number
● enter login code
● key matching
● look up DTCs
The scan tool provides 4 different types of keyboard to meet your specific needs. Depending on the
needs of text entry, it automatically shows the most suitable keypad.
● classic QWERTY keyboard for input of texts that contain both letters and numbers
● numeric keyboard for input of numbers
● alphabet keyboard for input of letters
● hexadecimal keyboard for special functions, such as key matching, UDS coding
To input text with the scan tool:
1. When you are requested to input text, press the function key Keyboard.

14
ET2530 Multi-System Scanner Manual_English_V1.02
Figure 3-2 Sample Input Text Screen
2. Scroll with the arrow keys to highlight your desired letter or number and press the ENTER key to
confirm.
Figure 3-3 Sample Numeric Keyboard Screen
3. To delete a letter or number, use the function key Cursor Forward to move the cursor to it and
then press the Backspace button.
4. When finished the entry, press Completed key to continue.
4.Vehicle Identification
This section illustrates how to use the scanner to identify the specifications of the vehicle under test.
The vehicle identification information presented is provided by the ECM of the vehicle being tested.
Therefore, certain attributes of the test vehicle must be entered into the scan tool to ensure the data
displays correctly. The vehicle identification sequence is menu driven, you simply follow the screen
prompts and make a series of choices. Each selection you make advances you to the next screen.
Exact procedures may vary somewhat by vehicle. It typically identifies a vehicle by any of the
following means:
● SmartVIN
● Manual selection

15
ET2530 Multi-System Scanner Manual_English_V1.02
4.1 Smart VIN
Smart VIN allows to identify a vehicle by automatically reading the vehicle identification number
(VIN).
To identify a vehicle by SmartVIN:
1. Scroll with arrow keys to highlight the vehicle application from main menu and press ENTER.
Figure 4-1 Sample Main Menu Screen
2. Select SmartVIN from the menu, and press the ENTER key.
Figure 4-2 Sample VIN Reading Screen
3. The scan tool starts to communicate with the vehicle and read the Vehicle Specification or VIN
Code automatically.

16
ET2530 Multi-System Scanner Manual_English_V1.02
Figure 4-3 Sample Automatic VIN Reading Screen
4. Answer YES if the Vehicle Specification or VIN code is correct and a menu of controller selection
displays. Answer NO if incorrect, and you are required to enter the correct VIN number manually.
Figure 4-4 Sample Manual VIN Entry Screen
4.2 Manual Selection
Manual Selection identifies a vehicle by making several selections according to certain VIN
characters, such as model year, and engine type.
To identify a vehicle by manual vehicle selection:
1. Scroll with arrow keys to highlight the vehicle application from main menu and press ENTER.

17
ET2530 Multi-System Scanner Manual_English_V1.02
Figure 4-5 Sample Main Menu Screen
2. Select Manual Selection from the menu, and press the ENTER key.
Figure 4-6 Sample Control Module Selection Screen
3. On each screen that appears, select the correct option and then press the ENTER key. Do this until
the complete vehicle information is entered and the menu of controller selection displays.
Figure 4-7 Sample Manual Vehicle Selection Screen
5 Diagnostic Operations
This section illustrates how to use the scanner to read and clear diagnostic trouble codes, and view
“live” data readings and ECU information on controllers installed on a variety of vehicles and also
save “recordings” of the data readings.
5.1 Control Module Selection
When you completed the identification of vehicle, you have to identify the control modules installed in
the vehicle. There are two ways to identify the controllers installed in a car:
● Quick Scan
● Control Modules

18
ET2530 Multi-System Scanner Manual_English_V1.02
5.1.1 Quick Scan
Quick Scan performs an automatic system test to determine which control modules are installed on
the vehicle and provides diagnostic trouble codes (DTCs) overview. Depending on the number of
control modules, it may take 10 minutes or longer to complete the test.
To perform an automatic system scan:
1. Scroll with the arrow keys to highlight Quick Scan from the menu and press ENTER to start.
Figure 5-1 Sample Main Group Screen
2. To pause the scan, press the function key corresponding with Pause on the screen.
Figure 5-2 Sample Quick Scan Screen
3. At the end of successful automatic controller scan, a menu with a list of installed controllers
together with their DTC overview displays.

19
ET2530 Multi-System Scanner Manual_English_V1.02
Figure 5-3 Sample Quick Scan Screen
4. If there is diagnostic trouble code(s) detected in a control unit, press the function key corresponding
with Report on the screen to view details of code information. Or press the function key Erase to
clear them.
Figure 5-4 Sample DTC Screen
5. Press function key F1 to save the trouble code information.
6. Select the system you would like to test, and press the ENTER key. When the scanner has
established connection with the vehicle, the Function Menu displays.
Figure 5-5 Function Menu screen

20
ET2530 Multi-System Scanner Manual_English_V1.02
5.1.2 Control Modules
Control Modules screen displays all controllers available on the vehicles. The controllers listed on
the menu do not mean that they are installed on the vehicle.
To select a system for testing:
1. Scroll with the arrow keys to highlight Control Modules from the menu and press the ENTER key.
A controller menu displays.
Figure 5-6 Sample Control Module Menu Screen
2. Select the system you would like to test. When the scanner has established connection with the
vehicle, the Function Menu displays.
Figure 5-7 Sample Control Module Menu Screen
5.2 Diagnostic Operations
After a system is selected and the scanner establishes communication with the vehicle, the Function
Menu displays. The menu options may include:
●Read Codes
●Clear Codes
●Live Data
● Active Test
