READ ALL INSTRUCTIONS
Thesmokealarmhasarecommendedservice lifeofatleast10yearsundernormalconditions.
The smoke alarm uses an extremely small amount of a radioactive element in the ionization
chamber. Do not tamper with radioactive sealed source or try to repair the smoke alarm
yourself. Refer to instructions for repairs.
SMOKE ALARM LIMITATIONS AND FUNCTIONS
• THERE ARETWO BASIC SMOKE ALARM TYPES - IONIZATION AND PHOTOELECTRIC.
Ionizationsmokealarms (suchas this SmokeAlarm)are yourbestoverallchoiceforreliability
and fast response time, since they quickly sense small "invisible" smoke particles and will
also sense larger "visible" smoke particles. Photoelectric smoke alarms may respond more
quickly in certain types of fires, for example - slow smoldering fires with large "visible" smoke
particles. ALL TYPES OF SMOKE ALARMS HAVE LIMITATIONS. NO TYPE OF SMOKE
ALARM CAN SENSE EVERY KIND OF FIRE OR SMOKE EVERY TIME.
• WARNING-SMOKEALARMSWILLNOTWORKDURINGALOSSOFPOWER.SINCEASMOKE
ALARMWILLNOTWORKWITHOUTPOWER,havingan alarm(s)thatworks fromtwocompletely
differentpowersources,suchasanACdirectwirewithbatterybackupsmokealarm,cangiveyouan
extra measure of protection in case of an AC power failure or a dead battery.
• USINGA SMOKE ALARM IN ASMOKY AREA LIKE A KITCHEN,OR IN A HIGH HUMIDITY
AREA NEAR A SHOWER, CAN CAUSE FALSE ALARMS. DO NOT TURN OFF THE AC
POWERTO QUIETTHE ALARM. A SMOKE ALARMWILL NOT HELP PROTECTYOU IF IT
IS NOT POWERED.Properly locate your alarm to avoid nuisance alarms.
• A SMOKE ALARM MAY NOT ALWAYS WARN YOU ABOUT FIRES CAUSED BY
CARELESSNESS AND SAFETY HAZARDS LIKE SMOKING IN BED, VIOLENT
EXPLOSIONS, ESCAPING GAS, IMPROPER STORAGE OF FLAMMABLE MATERIALS,
OVERLOADEDELECTRICAL CIRCUITS,CHILDRENPLAYINGWITHMATCHES,NATURAL
CAUSES SUCH AS LIGHTNING, OR ARSON. FIRE PREVENTION IS YOUR BEST
SAFEGUARD.
• INSTALLING SMOKE ALARMS MAY MAKE YOU ELIGIBLE FOR LOWER INSURANCE
RATES, but SMOKE ALARMS ARE NOT A SUBSTITUTE FOR INSURANCE. Homeowners
and renters alike should continue to insure their lives and properties.
• SMOKEALARMS CANNOTWORKWITHOUTPOWER.Battery operatedunits cannot work ifthe
batteriesaremissing, disconnectedordead,if thewrongtypeof batteriesareusedorifthebatteries
are not installed correctly. AC (only) powered units cannot work if the AC power is cut off for any
reason.If you areconcernedabout the limitations of battery or ACpower,install bothtypes of units.
• SMOKE ALARMS CANNOT DETECT FIRES IF THE SMOKE DOES NOT REACH THEM.
Smoke from fires may not reach the sensing chamber and set off the alarm.One unit should
be installed inside each bedroom or sleeping area.
• SMOKE ALARMS MAY NOT DETECT FIRE ON ANOTHER FLOOR OR AREA OF THE
HOME. Recommended minimum protection is at least one unit in every sleeping area and
everybedroomon everylevel of yourhome.Interconnected units mayprovideearlierwarning
than stand-alone units since all units alarm when one detects smoke.
• SMOKEALARMSMAY NOTBE HEARD.Thealarmhorn in thisunitmeets or exceedscurrent
standards,butit maynot be heard if:(1) the unitis located outsidea closed or partiallyclosed
door;(2) residents recently consumed alcohol or drugs;(3)the alarmis drowned out bynoise
fromstereos,TV's,air conditionersor other appliancesor(4) if residentsare hearing impaired
or sound sleepers.
• SMOKE ALARMS ARE NOT FOOLPROOF. You must test the unit weekly to ensure your
continued protection.Smoke alarms cannot prevent or extinguish fires.
• SMOKEALARMS HAVE A LIMITED LIFE.Theunit should be replaced immediately if it is not
operating properly.You should always replace a smoke alarm after 10 years.
PART #USI-1209
SMOKE & FIRE ALARM
MODEL
USI-1208

RECOMMENDED LOCATION OF ALARMS
• Locatethe first smoke alarmin the immediatearea of the bedrooms.Trytoprotect the exitpath as
the bedrooms are usually farthest from an exit. If more than one sleeping area exists, locate
additional smoke alarms in each sleeping area.
• Locate additional smoke alarms to protect any stairway as stairways act like chimneys for
smoke and heat.
• Locate at least one smoke alarm on every floor level.
• Locate a smoke alarm in any area where a smoker sleeps or where electrical appliances are
operated in sleeping areas.
• Smoke, heat and other combustion products rise to the ceiling and spread horizontally. Mounting
the smoke alarm on the ceiling in the center of the room places it closest to all points in the room.
Ceiling mounting is preferred in ordinary residential construction. However, in mobile homes, wall
mountingonan inside partition is preferredtoavoidthe thermalbarrier thatmay form at theceiling.
• When mounting smoke alarm on the ceiling, locate it a minimum of 4" (10cm) from a side wall or
corner (see Diagram A).
• When mounting smoke alarm on a wall, if local codes allow, use an inside wall with the top edge
of the smoke alarm a minimum of 4" (10cm) and a maximum of 12" (30.5cm) below the ceiling/
wall intersections (See Diagram A).
Mobile Home Installation:
For minimum protection,smoke alarms should be installed in compliance with H.U.D.Manufactured Home
Construction Safety Standards,Title 24 CFR, Section 3280.208 and Section 3282.For additional protection,
see Single Story Residence smoke alarm requirements/recommendations for Existing Homes and New
Construction Homes.
Note: For mobile homes built before 1978, install smoke alarms on inside walls between 4” and 12”from
the ceiling (older mobile homes have little or no insulation in the ceiling).This is especially important if the
ceiling is unusually hot or cold.
Install a smoke alarm inside each bedroom and in the hallway outside each separate sleeping area.
Page 2

THIS SMOKE ALARM WILL NOT WORK WITHOUT 120 VAC POWER AND A
GOOD BATTERY PROPERLY INSTALLED.THE SMOKE ALARM SHOULD BE
TESTED WHEN INSTALLED AND THEN TESTED WEEKLY AFTER THAT.
INSTALLATION
Installation of this unit must conform to the electrical codes in your area;Article 760 of the
National Electrical Code, NFPA 72, 101; SBC (SBCCI); UBC (ICBO); NBC (BOCA): OTFDC
(CABO),and any other local or building codes that may apply.Wiring and installation must be
performed by a licensed electrician. Failure to follow these guidelines may result in injury or
property damage.
This unit must be powered by a 24-hour, 120V AC 60Hz circuit.Be sure the circuit cannot be
turned off by a switch, dimmer or ground fault circuit interrupter. Failure to connect this unit
to a 24-hour circuit may prevent it from providing constant protection.
IMPORTANT: Do not subject this smoke alarm to megger, high voltage or high-pot tests.
Remove the smoke alarm(s) before high-potting tests occur on the circuit or system.
(Ref.Section 550-17, National Electric Code,2002 Edition).
ELECTRICAL SHOCK HAZARD
Turn off power to the area where you will install this unit at the circuit breaker or fuse box
before beginning installation. Failure to turn off the power before installation may result in
serious electrical shock,injury or death.
TAMPER LOCKING PIN: To makeyour smoke alarm somewhattamper resistant, alockingpin has
beenprovided.Usingthispinwilldeterchildrenandothersfromremovingthe alarmfromthemounting
ring.To use the pin, insert it into the hole in the side of the alarm after it has been installed on the
mountingring.Note that thetamperpin will haveto be removed in order tochange the battery,which
can be done easily with a pair of long nose pliers.Using the long nose pliers, pull the pin out of the
hole.It is now possible to remove the smoke alarm from the mounting ring.
1. Turnthe smoke alarm counterclockwise to removeit from the mountingring.NOTE:The smoke
alarmis sealed and thecoveris notremovable.Yoursmokealarmis also equipped witha safety
device which prevents mounting unless a battery is installed.If your smoke alarm will not lock
onto the mounting ring, check to make sure a battery is installed.
2. Wiring Instructions:
a. Theappropriatepowersupplyis120Volt single phase powersuppliedfromanon-switchable
circuit NOT protected by a ground fault circuit interrupter.
b. Turn off main power to the circuit before wiring the smoke alarm.
c. There are three pigtail leads (black, white and yellow) coming from the AC QUICK
CONNECTOR.The proper wire connection is as follows:
WIRES FROM QUICK CONNECTOR CONNECTTO
BLACK "HOT" side of AC line
WHITE "NEUTRAL" side of AC line
YELLOW Interconnect wires of other units
AVOID THESE LOCATIONS
• the garage – products of combustion are present when you start your automobile.
• near appliances or areas where normal combustion regularly occurs (kitchens, near furnaces,
gas hot water heaters).Use smoke alarms with Silence Control for these areas.
• in areas with high humidity, like bathrooms or areas near dishwashers or washing machines.
Install at least 3 feet (0.9 meters) away from these areas.
• in areas of turbulent air such as air returns or heating and cooling supply vents.Install at least 3
feet (0.9 meters) away from these areas.The air could blow smoke away from the smoke alarm,
interrupting its alarm.
• in extremely dusty, dirty or insect-infested areas. Loose particles interfere with smoke alarm
operation.
• in areas where temperature may fall below 400F (4.40C) or rise above 1000F (37.80C).
• closer than 5 feet (1.5m) from fluorescent lights, electrical "noise" and flickering may affect the
alarm'soperation.
Page 3

3. Attach the mounting ring to the electrical junction box.
4. To activate 9 volt battery and smoke alarm, pull and remove the thin colored plastic tab at
battery door hinge.Discard plastic tab.
5. Plug the AC QUICK CONNECTORS together. Push and turn the smoke alarm clockwise onto
the mounting ring.
6. See "TAMPER LOCKING PIN."
7. Turn on ACpower and check the LED's for proper operation.The green LED lights to indicate
AC power.The red LED will flash every 40-60 seconds to indicate proper operation.
Early warning fire detection is best achieved by the installation of fire detection equipment in
all rooms and areas of the household as follows: A smoke alarm installed in each separate
sleeping area (in the vicinity of, but outside of, the bedrooms) and heat or smoke alarms in
living rooms,dining rooms,kitchens, hallways,attics, furnace rooms,closets,utility storage
rooms, basements and attached garages. Test the smoke alarm weekly to assure proper
operation.
For units that are used as single smoke alarms, do not connect the yellow wire to anything.
Insulate this wire (tape it) in place to make certain the yellow wire cannot contact any metal
parts.
Interconnected units can provide earlier warning of fire than stand-alone units,especially if a
fire starts in a remote area of the dwelling. If any unit in the series senses smoke,all units will
alarm.This smoke alarm may be interconnected with as many as 11 other USI ELECTRIC
model smoke alarms and 6 other units which may be a combination of USI-2430 Heat Alarms
or USI-960 Relay Modules for a total of not more than 18 interconnected devices.
The yellow wire is used only for multiple station operation with USI ELECTRIC Models USI-
1103, USI-1203, USI-1204, USI-1208 AND USI-1213 only. Connecting this yellow wire to any
other circuits may result in damage.When smoke alarms are interconnected,all units must
be powered from a single AC branch circuit.If local codes do not permit be sure the neutral
wire is common to both phases.The maximum wire run distance between the first and last
smoke alarm in an interconnected system is 1,000 feet.NOTE:Use standard household wire
(18 gauge or larger,rated at least 300V,as required by local codes) available at all electrical
supply/hardware stores.
Page 4

OPERATION,TESTING & MAINTENANCE
OPERATION:The smokealarm isoperatingoncethepoweris connected andturned on(thebattery
must also be installed). When products of combustion are sensed, the unit sounds a loud alarm
which continues until the air is cleared.
This alarm incorporates the internationally recognized horn signal for evacuation. During alarm
mode, the horn produces three short beeps followed by a two second pause and then repeats.
STANDBY CONDITION: The red LED flashes once every 40-60 seconds to indicate the unit is
properly functioning.
LOCAL ALARM CONDITION: The red LED flashes rapidly and the unit emits a loud, pulsating
alarm sound.
REMOTE ALARM CONDITION:The red LED is off and the unit emits a loud, pulsating alarm.
GREEN LED: The green LED is on whenever AC power is turned on.
TESTING: Test by pushing the test button on the smoke alarm cover until the alarm sounds, then
release.The alarm sounds if all electronic circuitry, horn and battery are working.The alarm may
continueto sound forupto 10 secondsafter the buttonis released.Ifno alarm sounds, the unitmay
haveadefectivebatteryor otherfailure.Test the smoke alarm weekly to assure proper operation.
NEVER use an open flame of any kind to test this unit.You might accidentally damage or set
fire to the unit or to your home.The built-in test switch accurately tests the unit's operation as
required by Underwriters Laboratories Inc.(UL).
If you choose to use an aerosol smoke product to test the smoke alarm,be certain to use one
that has been Listed to Underwriters Laboratories, Inc. Safety Standards and use it only as
directed. Use of non-UL Listed products or improper use of UL Listed products may affect
the smoke alarm's sensitivity.
MAINTENANCE:Thesmokealarm isvirtuallymaintenance free.However, under dusty conditions,
a vacuum hose may be used to clear the sensing chamber of dust.
Clean the smoke alarm at least once a month toremovedust, dirt or debris.Always turn off power
tosmokealarmbefore cleaning.Usinga soft brushorwandattachment to a vacuumcleaner, vacuum
all sides and cover of smoke alarm. Be sure all the vents are free of debris.
Page 5
BACKUP BATTERY REPLACEMENT
Disconnect AC power before changing battery.Shock hazard exists if AC power is miswired.
The smoke alarm uses a 9 Volt battery.The battery should last for at least one year under normal
operatingconditions.Thesmokealarm has a low batteryindicator,an audible "beep."It will operate
at 30-40 second intervals for a minimum of 7 days.When this indication occurs, replace the battery
withan Alkaline type(Radio ShackCat.No.23-553, Eveready Energizer#522, Duracell #MN1604),
Carbon-Zinctype (Gold Peak#1604P[UL], Eveready#216),or Lithium type (ULTRALIFE U9VL-J).
Push and lift the battery door latch and remove the battery from the battery door.While observing
polarity, push thereplacement batteryinto the battery door untilit is held securelyin place.Carefully
close and latch the battery door. REPAIRS AND SERVICES
Thesmokealarm contains less than1 microcurie (37 kilobecquerel)of Americium 241,aradioactive
material. This substance requires that the smoke alarm be returned to the manufacturer or the
Departmentof Health fordisposal.Donotdispose of in anyotherway.If the smokealarmis defective
inanyway,donot tamper withthe unit.Returntheunit forservicing.(See warranty forinstructions or
in-warranty returns.)There will be a service charge for repairing out of warranty units.

DEVELOP AND PRACTICE A PLAN OF ESCAPE
BASICS OF ESCAPE PLAN
o Make a floor plan indicating all doors and windows and at least two escape routes from each
room.Second story windows may need a rope or chain ladder.
o Have a family meeting and discuss your escape plan, showing everyone what to do in case of
fire.
o Determine a place outside your home where all of you can meet if a fire occurs.
o Familiarize everyone with the sound of the smoke alarm and train them to leave your home when they
hearthesound.
o Identifychildren's bedrooms with redstickersplaced inthe upper left cornerof thewindows.They
are available from your local fire department.
o Practice a fire drill at least every six months. Practice allows you to test your plan before an
emergency.You may not be able to reach your children. It is important they know what to do!
WHATTO DOWHENTHE ALARM SOUNDS
o Leave immediately by your plan of escape. Every second counts, so don't waste time getting
dressed or picking up valuables.
o In leaving, don't open any inside door without first feeling its surface.If hot, or if you see smoke
seepingthrough cracks,
don't open that door! Instead, useyouralternateexit.If inside dooris
cool,place your shoulder against it,open it slightlyand be ready toslam it shutif heat and smoke
rush in.
o Stay close to the floor if air is smoky. Breathe shallowly through a cloth, wet if possible.
o Once outside, go to your selected meeting place and make sure everyone is there.
o Call the fire department from your neighbor's home –
not from yours!
o Don't return to your home until fire officials say that it is all right to do so.
NATIONAL FIRE PROTECTION ASSOCIATION REQUIRED PROTECTION
For your information, the National Fire Protection Association's Standard 72, reads as follows:
"2-2.1.1.1 Smokedetectors shall be installed outsideof each separatesleepingarea in
the immediate vicinity of the bedrooms and on each additional story of the family living
unit including basements and excluding crawl spaces and unfinished attics. In new
construction, a smoke detector shall be installed in each sleeping room."
"A-2.5.2.1 Smoke Detection - Are More Smoke Detectors Desirable? The required
numberof smokedetectors might notprovidereliableearlywarning protection forthose
areas separated by a door from the areas protected by the required smoke detectors.
For this reason, it is recommended that the householder consider the use of additional
smoke detectors for those areas for increased protection.The additional areas include
the basement, bedrooms, dining room, furnace room, utility room, and hallways not
protectedbytherequiredsmokedetectors.Theinstallationofsmokedetectors in kitchens,
attics(finished or unfinished), or garagesisnotnormally recommended,astheselocations
occasionally experience conditions that can result in improper operation."
The equipment should be installed in accordance with the National Fire Protection Association's
Standard 72.(National Fire Protection Association, Batterymarch Park, Quincy, MA 02269).
THIS PRODUCT IS LISTED TO UL STANDARD FOR SAFETY,
UL217 5TH EDITION, BY UNDERWRITERS LABORATORIES.
Page 6

288-3257-00A ©2002, USI ELECTRIC, INC. Printed in China
Visit Us on the Web! www.usielectric.com
USI FIVE YEAR LIMITED WARRANTY
USI ELECTRIC, INC. ("USI") warrants your USI product to be free from defects
in material and workmanship for a period of five (5) years from the date of
purchase. This warranty applies only to the original consumer purchaser and only to
products used in normal residential use and service. If this product is found to be
defective,USI'sonly obligation, and your exclusive remedy, is therepairorreplacement
of the product, at USI's discretion, provided that the product has not been damaged
through misuse, abuse, accident, modifications, alteration, neglect or mishandling.
This Warranty shall not apply to any product which is found to have been improperly
installed, set-up, or used in any way not in accordance with the instructions supplied
with the product. This warranty shall not apply to any batteries used in the product or
to any damage which may be caused by such batteries. For repair or replacement,
send the defective product to USI ELECTRIC, INC. at 7-A Gwynns Mill Court, Owings
Mills, Maryland 21117, postage prepaid with a payment of $4.00 to cover the costs of
return postage and handling. You must include a proof of purchase (receipt) along
with the returned product.
USI DOES NOT WARRANT AND SPECIFICALLY DISCLAIMS ANY WARRANTY,
WHETHER EXPRESS OR IMPLIED, OF FITNESS FOR A PARTICULAR PURPOSE,
OTHER THAN THE WARRANTY CONTAINED HEREIN. NO IMPLIED WARRANTY
ON THIS PRODUCT, CREATED BY STATE LAW, SHALL EXTEND BEYOND THE
TERM OF THIS WARRANTY UNLESS SUCH LAW OTHERWISE PROVIDES. USI
SPECIFICALLY DISCLAIMS ANY LIABILITY AND SHALL NOT BE LIABLE FOR
ANY CONSEQUENTIAL OR INCIDENTAL LOSS OR DAMAGE, INCLUDING, BUT
NOT LIMITED TO, DAMAGES TO ANY EQUIPMENT WITH WHICH THIS PRODUCT
IS USED.
Some states do not allow the exclusion or limitation of incidental or consequential
damages so the above limitations or exclusions may not apply to you.
No agent, representative, dealer, or employee of the company has the authority to
increase or alter the obligations or terms of this Warranty.
This Warranty gives you specific legal rights and you may also have other rights
which vary from state to state.
This Warranty is only valid for merchandise purchased from outlets in the United
States and Canada.
