Usr USR-WIFI232-S User manual

USR-WIFI232-S/T/G2 /H Low Power WiFi Module User Manual http://en.usr.cn
Jinan USR IOT Technology Limited [e-mail] 1 of 87
USR-WIFI232-S/T/G2
USR-WIFI232-S/T/G2
USR-WIFI232-S/T/G2
USR-WIFI232-S/T/G2 /H
/H
/H
/H
Low
Low
Low
Low Power
Power
Power
Power WiFi
WiFi
WiFi
WiFi Module
Module
Module
Module User
User
User
User Manual
Manual
Manual
Manual V2.
V2.
V2.
V2. 3
3
3
3
Overview
Overview
Overview
Overview of
of
of
of Characteristic
Characteristic
Characteristic
Characteristic
Support IEEE802.11b/g/n Wireless Standards
Based on Self-developed High Performance MCU
Ultra-Low-Power Applications with Excellent Power Save
Support UART/PWM/GPIO Data Communication Interface
Support Work As STA/AP Mode
Support Smart Link Function (APP program provide)
Support N etwork C onfiguration by Audio. (USR-WIFI232-H)
Support USRLINK Function (Fast set SSID)
Support Wireless Upgrade Function
Support WPS Function
Support Multi-TCP Link (5 Channel) Ap p lication
Support Internal/External(I-PEX/SMA) Antenna Option
Single +3.3V Power Supply
Smallest Size:
USR-WIFI232-S 22mm x 13.5mm x 2.3mm , SMT Footprint
USR-WIFI232-T 22mm x 13.5mm x 6mm , 1x10 2mm Connector
USR-WIFI232-G2 23.1mm x 32.8mm x 2.7mm , SMT Footprint
USR-WIFI232- H 23.1mm x 32.8mm x 2.7mm , SMT Footprint
FCC/CE Certificated
